This work was supported by the National Natural Science Foundation of China (No. 31870746), Shenzhen Basic Research Grants (JCYJ20200109140414636), and Natural Science Foundation of Guangdong Province, China (No. 2021A1515010796) to W. L. We thank LetPub (www.letpub.com) for its linguistic assistance during the preparation of this manuscript.

1. Purification of GST-tagged TRP and His-tagged NORPA fragments
<ol>
	<li>Purify GST-tagged TRP 1261-1275 fragment
	<ol>
		<li>Transform the pGEX 4T-1 TRP 1261-1275 plasmid10 into Escherichia coli (E. coli) BL21 (DE3) cells using the CaCl2 heat-shock transformation method21. Inoculate a single colony in 10 mL of Luria Bertani (LB) medium and grow overnight at 37 &#176;C. Then, amplify the 10 mL of seeding culture in 1 L of LB medium at 37 &#176;C.</li>
		<li>After the optical density (OD600) of the cells reaches 0.5, cool down the cells to 16 &#176;C and add 0.1 mM isopropyl &#946;-D-1-thiogalactopyranoside (IPTG; final concentration) to induce the overexpression of the target protein and incubate at 16 &#176;C for 18 h.</li>
		<li>After overexpression, pellet 1 L of cultured cells by centrifugation at 3,993&#160;&#215; g&#160;for 20 min and resuspend in 40 mL of phosphate-buffered saline (PBS) buffer.</li>
		<li>Load the resuspended cells in a high-pressure homogenizer pre-cooled at 4 &#176;C. Slowly increase the homogenizer pressure to 800 bar. Open the inlet tap and let the resuspended cells circularly pass through a valve with very narrow slits.
		NOTE: The cells are homogenized by the high shearing forces caused by a large pressure drop and cavitation.</li>
		<li>Load 5 mL of glutathione beads to a gravity flow column and wash the beads with 50 mL of PBS buffer for a total of three times.</li>
		<li>Centrifuge the cell lysate from the high-pressure homogenizer at 48,384 x g. Add the supernatant of the centrifuged cell lysate (40 mL) to the equilibrated glutathione beads in the gravity flow column and incubate for 30 min at 4 &#176;C. Resuspend the glutathione beads every 10 min.</li>
		<li>After 30 min of incubation, open the column outlet tap to separate the beads and flow-through fraction. Discard the flow-through fraction. Rinse the remaining glutathione beads twice with 50 mL of PBS buffer.</li>
		<li>Add 15 mL of elution buffer to the glutathione beads and incubate for 30 min. Resuspend the beads every 10 min.</li>
		<li>After 30 min of incubation, elute the GST-tagged TRP 1261-1275 fragment in a 50 mL conical tube and load in a size-exclusion column (preparation grade), which is equilibrated using 50 mM Tris (pH 7.5, 100 mM NaCl, 1 mM EDTA, 1 mM DTT) buffer.</li>
		<li>Keep the elution flow rate of the size-exclusion column to 3 mL/min. Collect the eluted proteins at the rate of 5 mL/tube.</li>
		<li>Identify the peak of the target protein in the size-exclusion column by analyzing the UV absorption signals at 280 nm and verify by SDS-PAGE gel analysis (electrophoresis parameters: 150 V for the stacking gel; 200 V for the resolving gel). Stain the gel with Coomassie blue R250.</li>
		<li>Concentrate the purified GST-tagged TRP 1261-1275 fragment from the size-exclusion column to 1 mL using a 15 mL ultrafiltration spin column centrifuged at 3,000 x g at 4 &#176;C in a desk-top refrigerated centrifuge.</li>
		<li>Determine the concentration of concentrated protein using the Beer-Lambert Law. Measure the UV absorption of GST-tagged TRP 1261-1275 fragment at 280 nm using a spectrophotometer.</li>
		<li>Obtain the extinction coefficient at 280 nm by importing the protein sequences into the Protparam program (https://web.expasy.org/protparam/). Typically, 1 L culture of GST-tagged TRP 1261-1275 yields 1 mL of 600 &#956;M of protein (6 x 10-7 mol). See Table 1 for materials needed.</li>
	</ol>
	</li>
	<li>Purification of His-tagged NORPA 863-1095 fragment
	<ol>
		<li>Transform the pETM.3C NORPA 863-1095 plasmid20 into E. coli BL21 (DE3) cells using the CaCl2 heat-shock transformation method21. Inoculate a single colony in 10 mL of LB medium and grow overnight at 37 &#176;C. Then, amplify the 10 mL seeding culture in 1 L of LB medium at 37 &#176;C.</li>
		<li>After the OD600 of the cells reaches 0.5, cool down the cells to 16 &#176;C and add 0.1 mM IPTG (final concentration) to induce the overexpression of target protein and incubate at 16 &#176;C for 18 h.</li>
		<li>After overexpression, pellet 1 L of cultured cells by centrifugation at 3,993&#160;x g&#160;for 20 min and resuspend in 40 mL of binding buffer. Next, lyse the resuspended cells in a high-pressure homogenizer at 4 &#176;C as described in step 1.1.4.</li>
		<li>Load 5 mL of Ni-beads into a gravity flow column and wash three times with 50 mL of binding buffer.</li>
		<li>Centrifuge the cell lysate from the high-pressure homogenizer at 48,384 x g. Add the supernatant of the centrifuged cell lysate to the equilibrated Ni-beads in the gravity flow column and incubate for 30 min at 4 &#176;C. Resuspend the Ni-beads every 10 min.</li>
		<li>After 30 min of incubation, open the column outlet tap to separate the beads and flow-through fraction. Discard the flow-through fraction and wash the remaining Ni-beads twice with 50 mL of wash buffer.</li>
		<li>Add 15 mL of elution buffer to the Ni-beads and incubate for 30 min. Resuspend the Ni-beads every 10 min.</li>
		<li>After 30 min of incubation, collect the eluted His-tagged NORPA 863-1095 fragment in a 50 mL conical tube and load into a size-exclusion column (preparation grade), which is equilibrated using 50 mM Tris (pH 7.5, 100 mM NaCl, 1 mM EDTA, 1 mM DTT).</li>
		<li>Keep the elution flow rate of the size-exclusion column to 3 mL/min. Collect the eluted protein at the rate of 5 mL/tube.</li>
		<li>Identify the peak of the target protein in the size-exclusion column by analyzing the UV absorption signals at 280 nm and verify by SDS-PAGE gel analysis (electrophoresis parameters: 150 V for the stacking gel; 200 V for the resolving gel). Stain the gel using Coomassie blue R250.</li>
		<li>Concentrate the purified His-tagged NORPA 863-1095 fragment from the size-exclusion column to 1 mL using a 15 mL ultrafiltration spin column centrifuged at 3,000 x g at 4 &#176;C in a desk-top refrigerated centrifuge.</li>
		<li>Determine the concentration of concentrated protein using the Beer-Lambert Law. Measure the UV absorption of His-tagged NORPA 863-1095 fragment at 280 nm using a spectrophotometer.</li>
		<li>Obtain the extinction coefficient at 280 nm by importing the protein sequences into the Protparam program (https://web.expasy.org/protparam/). Typically, 1 L culture of His-tagged NORPA 863-1095 fragment yields 1 mL of 600 &#956;M of protein (6 x 10-7 mol). See Table 2 for materials needed.</li>
	</ol>
	</li>
</ol>
2. Preparation of Drosophila heads
<ol>
	<li>Collect adult flies in 50 mL conical centrifugation tubes using the CO2 anaesthetization method22,23; immediately freeze in liquid nitrogen for 10 min and store in a -80&#176;C freezer.</li>
	<li>After collecting a sufficient number of flies, vigorously shake the frozen 50 mL conical tubes by hand to separate the flies&#39; legs, heads, wings, and bodies. Transfer the mixture to three sequentially stacked pre-cooled stainless-steel sieves (20/30/40 mesh size, respectively) and shake the sieves.</li>
	<li>Next, since the heads cannot pass through the 40-mesh sieve, use a brush to sweep the fly heads off the 40-mesh sieve, transfer them into 50 mL conical tubes, and store them at &#8722;80 &#176;C.</li>
	<li>Continuously collect the flies and their heads and store them in a -80 &#176;C freezer until they reach the required amount needed for experimentation (0.5 g). Typically, to collect 0.5 g of heads, 35 mL of flies in a 50 mL conical tube are needed. See Table 3 for materials needed.</li>
</ol>
3. Drosophila TRP channel purification
<ol>
	<li>Weigh a total of 0.5 g of heads and completely homogenize in liquid nitrogen using a pre-cooled mortar-pestle. Dissolve the homogenized heads in 10x v/w lysis buffer (5 mL), incubate in a shaker at 4 &#176;C for 20 min, and then centrifuge at 20,817 x g for 20 min at 4 &#176;C.</li>
	<li>Collect the spin-down supernatant (&#34;20817 g S&#34;, Figure 4) and further centrifuge it at 100,000 x g for 60 min at 4 &#176;C. Use the spin-down supernatant (&#34;100,000 g S&#34;, Figure 4) for the following pull-down assay.</li>
	<li>Add 1 mL of Ni-beads into the gravity flow column and wash the beads with 10 mL of double-distilled H2O (ddH2O) at 4 &#176;C for a total of three times. Equilibrate the beads with 10 column volumes of lysis buffer three times at 4 &#176;C.</li>
	<li>Add 500 &#181;L of 600 &#181;M purified His-tagged NORPA 863-1095 protein (3 x 10-7 mol) into the Ni-column and incubate for 30 min at 4 &#176;C. Resuspend the beads every 10 min.</li>
	<li>Open the column outlet tap to separate the beads and flow-through fraction. Take the flow-through fraction for SDS-PAGE analysis (NORPA F, Figure 4). In this section, the bait proteins are immobilized on the Ni-beads.</li>
	<li>Wash the Ni-beads with 10 column volumes of lysis buffer (10 mL) at 4 &#176;C and keep the washing fraction for SDS-PAGE analysis (Wash 1, Figure 4A). Repeat the above steps and keep the sample for SDS-PAGE analysis (Wash 2, Figure 4A). In this section, the excessive bait proteins on the Ni-beads are removed.</li>
	<li>Add the supernatant of Drosophila head homogenate after 100,000 x g centrifugation into the Ni-column at 4 &#176;C, where the His-tagged NORPA 863-1095 fragment has been immobilized.</li>
	<li>Incubate the supernatant with the Ni-beads at 4 &#176;C for 30 min. Resuspend the beads every 10 min. Then, open the column outlet tap to separate the beads and flow-through fraction.</li>
	<li>Collect the supernatant for SDS-PAGE analysis (Dro head lysis F, Figure 4A). In this section, the INAD protein complexes (INAD/TRP/ePKC) in the head homogenates are captured by the immobilized NORPA 863-1095 fragments on the Ni-beads.</li>
	<li>Wash the Ni-beads with 10 column volumes of lysis buffer (10 mL) at 4 &#176;C and keep the supernatant from gravity precipitation for SDS-PAGE analysis (Wash 3, Figure 4A). Repeat the above steps and collect the supernatant for SDS-PAGE analysis (Wash 4, Figure 4A). In this section, the unbound proteins on the Ni-beads are removed.</li>
	<li>Add 500 &#181;L of 600 &#181;M of GST-tagged TRP 1261-1275 protein (3 x 10-7 mol) into the Ni-beads and incubate for 20 min at 4 &#176;C. Resuspend the beads every 10 min.</li>
	<li>Collect the eluted fraction from the gravity column (TRP E1, Figure 4B), which contains the endogenous Drosophila TRP channel. Repeat the above stepsand collect the elution fraction (TRP E2, Figure 4B). In this step, by using the GST-tagged TRP 1261-1275 fragments as the competitor, the TRP channels are eluted from the captured INAD protein complexes (INAD/TRP/ePKC) on the Ni-beads.</li>
	<li>Wash the Ni-beads with 10 column volumes of binding buffer (10 mL; Table 1) at 4 &#176;C and collect the washing fraction for SDS-PAGE analysis (Wash 5, Figure 4B).</li>
	<li>Add 500 &#181;L of elution buffer (Table 1) into the Ni-beads and incubate for 20 min at 4 &#176;C. Collect the elution fraction from the gravity flow column (NORPA E1, Figure 4B). Repeat the above steps, and collect the elution fraction (NORPA E2, Figure 4B).</li>
	<li>Using the elution buffer, elute the His-tagged NORPA 863-1095 fragment accompanied with the INAD/ePKC protein complexes. Next, resuspend the Ni-beads in 500 &#181;L of binding buffer.</li>
	<li>Take the resuspended Ni-beads to run the SDS-PAGE (stained by Coomassie blue R250) to analyze the efficiency of the elution and evaluate whether the elute buffer works (beads, Figure 4B). See Table 4 for materials needed.</li>
</ol>
4. Size-exclusion column purification of Drosophila TRP channel
<ol>
	<li>Install a size-exclusion column (analytical grade) on the protein purification system. Equilibrate the column with the column buffer (50 mM Tris-HCl pH 7.5, 150 mM NaCl, 2 mM DTT, 0.75 mM DDM), which is filtered by a 0.45 &#181;m filter.</li>
	<li>Concentrate the TRP E1 and E2 fraction from step 3.14 using a 4 mL ultrafiltration spin column, centrifuged at 3,000 x g at 4 &#176;C in a refrigerated centrifuge.</li>
	<li>Rinse the sample loop with the column buffer and load the sample into the sample loop. Inject the sample into the size-exclusion column and elute the proteins with a proper flow rate (0.5 mL/min).</li>
	<li>Identify the peak of the target protein by absorption at 280 nm and run an SDS-PAGE gel to detect the purified endogenous Drosophila TRP channel (Figure 5). See Table 5 for materials needed.</li>
</ol>

<ol>
	<li>Tsunoda, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+multivalent+PDZ-domain+protein+assembles+signalling+complexes+in+a+G-protein-coupled+cascade.">A multivalent PDZ-domain protein assembles signalling complexes in a G-protein-coupled cascade.</a> Nature. 388 (6639), 243-249 (1997).</li><li>Huang, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Activation+of+TRP+channels+by+protons+and+phosphoinositide+depletion+in+Drosophila+photoreceptors.">Activation of TRP channels by protons and phosphoinositide depletion in Drosophila photoreceptors.</a> Current Biology: CB. 20 (3), 189-197 (2010).</li><li>Chyb, S., Raghu, P., Hardie, R. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Polyunsaturated+fatty+acids+activate+the+Drosophila+light-sensitive+channels+TRP+and+TRPL.">Polyunsaturated fatty acids activate the Drosophila light-sensitive channels TRP and TRPL.</a> Nature. 397 (6716), 255-259 (1999).</li><li>Hardie, R. C., Franze, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Photomechanical+responses+in+Drosophila+photoreceptors.">Photomechanical responses in Drosophila photoreceptors.</a> Science. 338 (6104), 260-263 (2012).</li><li>Chen, W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Calmodulin+binds+to+Drosophila+TRP+with+an+unexpected+mode.">Calmodulin binds to Drosophila TRP with an unexpected mode.</a> Structure. 29 (4), 330-344 (2021).</li><li>Hardie, R. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effects+of+intracellular+Ca2++chelation+on+the+light+response+in+Drosophila+photoreceptors.">Effects of intracellular Ca2+ chelation on the light response in Drosophila photoreceptors.</a> Journal of Comparative Physiology. A, Sensory, Neural, and Behavioral Physiology. 177 (6), 707-721 (1995).</li><li>Scott, K., Sun, Y., Beckingham, K., Zuker, C. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Calmodulin+regulation+of+Drosophila+light-activated+channels+and+receptor+function+mediates+termination+of+the+light+response+in+vivo.">Calmodulin regulation of Drosophila light-activated channels and receptor function mediates termination of the light response in vivo.</a> Cell. 91 (3), 375-383 (1997).</li><li>Hardie, R. C., Minke, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Phosphoinositide-mediated+phototransduction+in+Drosophila+photoreceptors:+the+role+of+Ca2++and+trp.">Phosphoinositide-mediated phototransduction in Drosophila photoreceptors: the role of Ca2+ and trp.</a> Cell Calcium. 18 (4), 256-274 (1995).</li><li>Delgado, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Light-induced+opening+of+the+TRP+channel+in+isolated+membrane+patches+excised+from+photosensitive+microvilli+from+Drosophila+photoreceptors.">Light-induced opening of the TRP channel in isolated membrane patches excised from photosensitive microvilli from Drosophila photoreceptors.</a> Neuroscience. 396, 66-72 (2019).</li><li>Lev, S., Katz, B., Minke, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+activity+of+the+TRP-like+channel+depends+on+its+expression+system.">The activity of the TRP-like channel depends on its expression system.</a> Channels (Austin). 6 (2), 86-93 (2012).</li><li>Hardie, R. C., Raghu, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Activation+of+heterologously+expressed+Drosophila+TRPL+channels:+Ca2++is+not+required+and+InsP3+is+not+sufficient.">Activation of heterologously expressed Drosophila TRPL channels: Ca2+ is not required and InsP3 is not sufficient.</a> Cell Calcium. 24 (3), 153-163 (1998).</li><li>Gutorov, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Modulation+of+transient+receptor+potential+C+channel+activity+by+cholesterol.">Modulation of transient receptor potential C channel activity by cholesterol.</a> Frontiers in Pharmacology. 10, 1487 (2019).</li><li>Yagodin, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Thapsigargin+and+receptor-mediated+activation+of+Drosophila+TRPL+channels+stably+expressed+in+a+Drosophila+S2+cell+line.">Thapsigargin and receptor-mediated activation of Drosophila TRPL channels stably expressed in a Drosophila S2 cell line.</a> Cell Calcium. 23 (4), 219-228 (1998).</li><li>Guo, W., Chen, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Recent+progress+in+structural+studies+on+canonical+TRP+ion+channels.">Recent progress in structural studies on canonical TRP ion channels.</a> Cell Calcium. 83, 102075 (2019).</li><li>Li, X., Fine, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=TRP+channel:+The+structural+era.">TRP channel: The structural era.</a> Cell Calcium. 87, 102191 (2020).</li><li>Liao, M., Cao, E., Julius, D., Cheng, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structure+of+the+TRPV1+ion+channel+determined+by+electron+cryo-microscopy.">Structure of the TRPV1 ion channel determined by electron cryo-microscopy.</a> Nature. 504 (7478), 107-112 (2013).</li><li>Cao, E., Liao, M., Cheng, Y., Julius, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=TRPV1+structures+in+distinct+conformations+reveal+activation+mechanisms.">TRPV1 structures in distinct conformations reveal activation mechanisms.</a> Nature. 504 (7478), 113-118 (2013).</li><li>Liu, W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+INAD+scaffold+is+a+dynamic,+redox-regulated+modulator+of+signaling+in+the+Drosophila+eye.">The INAD scaffold is a dynamic, redox-regulated modulator of signaling in the Drosophila eye.</a> Cell. 145 (7), 1088-1101 (2011).</li><li>Ye, F., Liu, W., Shang, Y., Zhang, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+exquisitely+specific+PDZ/target+recognition+revealed+by+the+structure+of+INAD+PDZ3+in+complex+with+TRP+channel.">An exquisitely specific PDZ/target recognition revealed by the structure of INAD PDZ3 in complex with TRP channel.</a> Structure. 24 (3), 383-391 (2016).</li><li>Ye, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+unexpected+INAD+PDZ+tandem-mediated+plc&#946;+binding+in+Drosophila+photo+receptors.">An unexpected INAD PDZ tandem-mediated plc&#946; binding in Drosophila photo receptors.</a> eLife. 7, (2018).</li><li>Rahimzadeh, M., Sadeghizadeh, M., Najafi, F., Arab, S., Mobasheri, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Impact+of+heat+shock+step+on+bacterial+transformation+efficiency.">Impact of heat shock step on bacterial transformation efficiency.</a> Molecular Biology Research Communications. 5 (4), 257-261 (2016).</li><li>Ashburner, M., Golic, K. G., Hawley, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Drosophila: A laboratory handbook. Second Edition. 80 (2), (2005).</li><li>Nicolas, G., Sillans, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Immediate+and+latent+effects+of+carbon+dioxide+on+insects.">Immediate and latent effects of carbon dioxide on insects.</a> Annual Review of Entomology. 34 (1), 97-116 (1989).</li><li>Arachea, B. T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Detergent+selection+for+enhanced+extraction+of+membrane+proteins.">Detergent selection for enhanced extraction of membrane proteins.</a> Protein Expression and Purification. 86 (1), 12-20 (2012).</li><li>Hellmich, U. A., Gaudet, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structural+biology+of+TRP+channels.">Structural biology of TRP channels.</a> Handbook of Experimental Pharmacology. 223, 963-990 (2014).</li></ol>

The authors have nothing to disclose.

INAD, which contains five PDZ domains, is the core organizer of Drosophila phototransduction machinery. Previous studies showed that INAD PDZ3 binds to the TRP channel C-terminal tail with exquisite specificity (KD = 0.3 &#181;M)18. INAD PDZ45 tandem interacts with NORPA 863-1095 fragment with an extremely high binding affinity (KD = 30 nM). These findings provide a solid biochemical basis to design the affinity purification plus competition strategy, which enables t...

Phototransduction is a process where absorbed photons are converted into electrical codes of neurons. It exclusively relays opsins and the following G protein-coupled signaling cascade in both vertebrates and invertebrates. In Drosophila, by using its five PDZ domains, scaffold protein inactivation-no-after-potential D (INAD) organizes a supramolecular signaling complex, which consists of a transient receptor potential (TRP) channel, phospholipase C&#946;/No receptor potential A (PLC&#946;/NORPA), and eye-specific protein kinase C (ePKC)1. The formation of this supramolecular signaling complex guarantees the correct subcellular localization, high efficiency, and specificity of Drosophila phototransduction machinery. In this complex, light-sensitive TRP channels act as downstream effectors of NORPA and mediate calcium influx and the depolarization of photoreceptors. Previous studies showed that the opening of the Drosophila TRP channel is mediated by protons, disruption of the local lipid environment, or mechanical force2,3,4. The Drosophila TRP channel also interacts with calmodulin5 and is modulated by calcium by both positive and negative feedback6,7,8.
So far, electrophysiology studies on the gating mechanism of Drosophila TRP and TRP-like (TRPL) channels were based on excised membrane patches, whole-cell recordings from dissociated wild-type Drosophila photoreceptors, and hetero-expressed channels in S2, SF9, or HEK cells2,9,10,11,12,13, but not on purified channels. The structural information of the full-length Drosophila TRP channel also remains unclear. In order to study the electrophysiological properties of purified protein in a reconstituted membrane environment and to gain structural information of the full-length Drosophila TRP channel, obtaining purified full-length TRP channels is the necessary first step, similar to the methodologies used in mammalian TRP channel studies14,15,16,17.
Recently, based on the assembling mechanism of INAD protein complex18,19,20, an affinity purification plus competition strategy was first developed to purify the TRP channel from Drosophila head homogenates by streptavidin beads5. Considering the low capacity and expensive cost of streptavidin beads, an improved purification protocol is introduced here that uses His-tagged bait protein and corresponding low-cost Ni-beads with much higher capacity. The proposed method will help to study the gating mechanism of the TRP channel from structural angles and to measure the electrophysiological properties of the TRP channel with purified proteins.

<table><tbody><tr><td>&lt;strong&gt;Bacterial strains&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>&lt;em&gt;BL21(DE3) Competent Cells&lt;/em&gt;</td><td>Novagen</td><td>69450</td><td>Protein overexpression</td></tr><tr><td>&lt;strong&gt;Experiment models&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>D.melanogaster: W&lt;sup&gt;1118&lt;/sup&gt; strain</td><td>Bloomington Drosophila Stock Center</td><td>BDSC:3605</td><td>&lt;em&gt;Drosophila &lt;/em&gt;head preparation</td></tr><tr><td>&lt;strong&gt;Material&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>20/30/40 mesh stainless steel sieves</td><td>Jiufeng metal mesh company</td><td>GB/T6003.1</td><td>&lt;em&gt;Drosophila &lt;/em&gt;head preparation</td></tr><tr><td>30% Acrylamide-N,N&amp;prime;-Methylenebisacrylamide(29:1)</td><td>Lablead</td><td>A3291</td><td>SDS-PAGE gel preparation</td></tr><tr><td>Ammonium Persulfate</td><td>Invitrogen</td><td>HC2005</td><td>SDS-PAGE gel preparation</td></tr><tr><td>Cocktail protease inhibitor</td><td>Roche</td><td>05892953001</td><td>Protease inhibitor</td></tr><tr><td>Coomassie brilliant blue R-250</td><td>Sangon Biotech</td><td>A100472-0025</td><td>SDS-PAGE gel staining</td></tr><tr><td>DL-Dithiothreitol (DTT)</td><td>Sangon Biotech</td><td>A620058-0100</td><td>Size-exclusion column buffer preparation</td></tr><tr><td>Ethylenediaminetetraacetic acid disodium salt (EDTA)</td><td>Sangon Biotech</td><td>A500838-0500</td><td>Size-exclusion column buffer preparation</td></tr><tr><td>Glycine</td><td>Sangon Biotech</td><td>A610235-0005</td><td>SDS-PAGE buffer preparation</td></tr><tr><td>Glutathione Sepharose 4 Fast Flow beads</td><td>Cytiva</td><td>17513202</td><td>Affinity chromatography</td></tr><tr><td>Imidazole</td><td>Sangon Biotech</td><td>A500529-0001</td><td>Elution buffer preparation for Ni-column</td></tr><tr><td>Isopropyl-beta-D-thiogalactopyranoside (IPTG)</td><td>Sangon Biotech</td><td>A600168-0025</td><td>Induction of protein overexpression</td></tr><tr><td>LB Broth Powder</td><td>Sangon Biotech</td><td>A507002-0250</td><td>&lt;em&gt;E.coli.&lt;/em&gt; cell culture</td></tr><tr><td>L-Glutathione reduced (GSH)</td><td>Sigma-aldrich</td><td>G4251-100G</td><td>Elution buffer preparation for Glutathione beads</td></tr><tr><td>Ni-Sepharose excel beads</td><td>Cytiva</td><td>17371202</td><td>Affinity chromatography</td></tr><tr><td>N-Dodecyl beta-D-maltoside (DDM)</td><td>Sangon Biotech</td><td>A610424-001</td><td>Detergent for protein purification</td></tr><tr><td>N,N,N&#039;,N&#039;-Tetramethylethylenediamine (TEMED)</td><td>Sigma-aldrich</td><td>T9281-100ML</td><td>SDS-PAGE gel preparation</td></tr><tr><td>PBS</td><td>Sangon Biotech</td><td>E607008-0500</td><td>Homogenization buffer for &lt;em&gt;E.coli.&lt;/em&gt; cell</td></tr><tr><td>PMSF</td><td>Lablead</td><td>P0754-25G</td><td>Protease inhibitor</td></tr><tr><td>Prestained protein marker</td><td>Thermo Scientific</td><td>26619/26616</td><td>Prestained protein ladder</td></tr><tr><td>Size exclusion column (preparation grade)</td><td>Cytiva</td><td>28989336</td><td>HiLoad 26/60 Superdex 200 PG column</td></tr><tr><td>Size exclusion column (analytical grade)</td><td>Cytiva</td><td>29091596</td><td>Superose 6 Increase 10/300 GL column</td></tr><tr><td>Sodium chloride</td><td>Sangon Biotech</td><td>A501218-0001</td><td>Protein purification buffer preparation</td></tr><tr><td>Sodium dodecyl sulfate (SDS)</td><td>Sangon Biotech</td><td>A500228-0001</td><td>SDS-PAGE gel/buffer preparation</td></tr><tr><td>Tris base</td><td>Sigma-aldrich</td><td>T1503-10KG</td><td>Protein purification buffer preparation</td></tr><tr><td>Ultrafiltration spin column</td><td>Millipore</td><td>UFC901096/801096</td><td>Protein concentration</td></tr><tr><td>&lt;strong&gt;Equipment&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>Analytical Balance</td><td>DENVER</td><td>APX-60</td><td>Metage of &lt;em&gt;Drosophila &lt;/em&gt;head</td></tr><tr><td>Desk-top high-speed refrigerated centrifuge for 15mL and 50mL conical centrifugation tubes</td><td>Eppendorf</td><td>5810R</td><td>Protein concentration</td></tr><tr><td>Desk-top high-speed refrigerated centrifuge 1.5mL centrifugation tubes</td><td>Eppendorf</td><td>5417R</td><td>Centrifugation of &lt;em&gt;Drosophila&lt;/em&gt; head lysate after homogenization</td></tr><tr><td>Empty gravity flow column (Inner Diameter=1.0cm)</td><td>Bio-Rad</td><td>738-0015</td><td>TRP protein purification</td></tr><tr><td>Empty gravity flow column (Inner Diameter=2.5cm)</td><td>Bio-Rad</td><td>738-0017</td><td>Bait and competitor protein purification from &lt;em&gt;E.coli.&lt;/em&gt;</td></tr><tr><td>Gel Documentation System</td><td>Bio-Rad</td><td>Universal Hood II Gel Doc XR System</td><td>SDS-PAGE imaging</td></tr><tr><td>High-speed refrigerated centrifuge</td><td>Beckman coulter</td><td>Avanti J-26 XP</td><td>Centrifugation of &lt;em&gt;E.coli.&lt;/em&gt; cells/cell lysate</td></tr><tr><td>High pressure homogenizer</td><td>UNION-BIOTECH</td><td>UH-05</td><td>Homogenization of &lt;em&gt;E.coli.&lt;/em&gt; cells</td></tr><tr><td>Liquid nitrogen tank</td><td>Taylor-Wharton</td><td>CX-100</td><td>&lt;em&gt;Drosophila &lt;/em&gt;head preparation</td></tr><tr><td>Protein purification system</td><td>Cytiva</td><td>AKTA purifier</td><td>Protein purification</td></tr><tr><td>Refrigerator (-80&amp;deg;C)</td><td>Thermo</td><td>900GP</td><td>&lt;em&gt;Drosophila &lt;/em&gt;head preparation</td></tr><tr><td>Spectrophotometer</td><td>MAPADA</td><td>UV-1200</td><td>OD600 measurement of &lt;em&gt;E.coli.&lt;/em&gt; cells</td></tr><tr><td>Spectrophotometer</td><td>Thermo Scientific</td><td>NanoDrop 2000c</td><td>Determination of protein concentration</td></tr><tr><td>Ultracentrifuge</td><td>Beckman coulter</td><td>Optima XPN-100 Ultracentrifuge</td><td>Ultracentrifugation</td></tr></tbody></table>

purification of endogenous drosophila transient receptor potential channels

Drosophila phototransduction is one of the fastest known G protein-coupled signaling pathways. To ensure the specificity and efficiency of this cascade, the calcium (Ca2+)-permeable cation channel, transient receptor potential (TRP), binds tightly to the scaffold protein, inactivation-no-after-potential D (INAD), and forms a large signaling protein complex with eye-specific protein kinase C (ePKC) and phospholipase C&#946;/No receptor potential A (PLC&#946;/NORPA). However, the biochemical properties of the Drosophila TRP channel remain unclear. Based on the assembling mechanism of INAD protein complex, a modified affinity purification plus competition strategy was developed to purify the endogenous TRP channel. First, the purified histidine (His)-tagged NORPA 863-1095 fragment was bound to Ni-beads and used as bait to pull down the endogenous INAD protein complex from Drosophila head homogenates. Then, excessive purified glutathione S-transferase (GST)-tagged TRP 1261-1275 fragment was added to the Ni-beads to compete with the TRP channel. Finally, the TRP channel in the supernatant was separated from the excessive TRP 1261-1275 peptide by size-exclusion chromatography. This method makes it possible to study the gating mechanism of the Drosophila TRP channel from both biochemical and structural angles. The electrophysiology properties of purified Drosophila TRP channels can also be measured in the future.

In this article, a protein purification method is demonstrated to purify endogenous Drosophila TRP channel (Figure 1).
First, recombinant protein expression and purification are applied to obtain the bait and competitor proteins. Then, a GST-tagged TRP 1261-1275 fragment is expressed in E. coli BL21 (DE3) cells in LB medium and purified using glutathione beads and a size-exclusion column (Figure 2). The samples were ...

Watch this Scientific Journal Video about Purification of Endogenous Drosophila Transient Receptor Potential Channels at JoVE.com

Purification of Endogenous Drosophila Transient Receptor Potential Channels

Based on the assembling mechanism of the INAD protein complex, in this protocol, a modified affinity purification plus competition strategy was developed to purify the endogenous Drosophila TRP channel.

Purification of Endogenous Drosophila Transient Receptor Potential Channels

Drosophila phototransduction is one of the fastest known G protein-coupled signaling pathways. To ensure the specificity and efficiency of this cascade, ...
