We thank Tatsuji Ihana, Sachiyo Kurimoto, Kazuko Takahasih, Yuki Yoshizawa, Maho Arashi, Kentaro Fujita, Erina Kudo, Yuka Kurimoto and Mayuko Wakatsuki for supporting the drug-free IVA procedure and Prof. Aaron J.W. Hsueh (Stanford University School of Medicine, Stanford, CA) for critical reading and editing of the manuscript. We also thank Rebecca Truman and Gregory Truman for inserting English narration. This study was supported by The Japan Society for the Promotion of Science (JSPS), Scientific Research B (19H03801), and Challenging Exploratory Research (18K19624).

Written informed consent was obtained from each POR patient with diminishing ovarian reserve who enrolled in the drug-free IVA treatment. This study was approved by ethical committee of International University of Health and Welfare (No. 17-S-21). Clinical trial was registered under number UMIN000034464 and carried out in accordance with the Code of Ethics of the World Medical Association (Declaration of Helsinki).
1. Ovarian cortex extraction
<ol>
	<li>Remove part of ovarian cortex (10 x 10 mm, 2-3 mm thickness) from one or both ovaries under general anesthesia through laparoscopic surgery as previous described19,20.</li>
	<li>Place the collected ovarian cortexes in a sterile container containing 10 mL of modified HTF (mHTF) at 37 &#176;C.</li>
</ol>
2. Ovarian cortex fragmentation
NOTE: Prior to dissection of the ovarian cortex, warm up mHTF to 37 &#176;C. Maintain sterile conditions throughout the procedure. All tools for this procedure are listed in Table of Materials.
<ol>
	<li>Place the collected ovarian cortexes in a plastic dish containing 5-10 mL of mHTF at 37 &#176;C and place them on the heat plate to maintain the tissue at 37 &#176;C (Figure 2A).</li>
	<li>Take a picture of each cortex using a digital camera with patient&#39;s name before starting next procedure to link patient background data.</li>
	<li>Place an individual cortex on a sterile gauze moistened with mHTF (Figure 2B).
	NOTE: Apply additional mHTF with a disposable pipette on the gauze to prevent the surface of cortex being dried out during this procedure.</li>
	<li>Remove residual medulla tissue where looks pink using a micro-scissors so that thickness of tissue reaches 1-2 mm (Figure 2C and D).
	NOTE: To avoid the loss of follicles at early stage, do not prepare the cortical strips less than 1 mm in thickness, because the early-stage follicles are located within 1-2 mm from the surface of ovarian cortex21.</li>
	<li>Dissect a 1 mm x 1 mm x 5 mm of tissue piece from each ovarian cortical strip using a fine scalpel and subject it to histological analysis to determine the presence of residual follicles as previous described18 (Figure 2E).
	NOTE: The dissected tissues for histology are immersed in mHTF and keep at 4 &#176;C until fixing (Figure 2F, see Step 4).</li>
	<li>Cut the cortex into 1mm x 1 mm x 10 mm strips using a fine scalpel (Figure 2G).
	NOTE: It is easier to cut by pressing down on the scalpel than by pulling on it.</li>
	<li>Cut these tissue strips into 1 mm x 1 mm x 1 mm small cubes (Figure 2H).
	NOTE: To avoid changes of osmotic pressure in the medium, add mHTF in moderation before tissue autografting.</li>
</ol>
3.&#160;Auto-grafting of ovarian cortical fragments
<ol>
	<li>Open the package of the IVA cannula and put it on a sterile drape.</li>
	<li>Rinse inside of the IVA cannula with mHTF by aspirating and discharging mHTF several times.</li>
	<li>Aspirate 100-200 &#181;L of mHTF to fill the tip of IVA cannula to avoid the cortical cubes from drying out during loading (Figure 3A).</li>
	<li>Load the cortical cubes into the tip of IVA cannula using a fine tweezer (Figure 3B-E).
	NOTE: The number of cortical cubes for loading depends on the grafting site. Generally, 20-30 cubes can be transplanted into an orthotropic remaining ovary, whereas 10-15 cubes can be transplanted into a pouch beneath the serosa of the Fallopian tube.</li>
	<li>After loading the cortical cubes, hold the tip of the cannula containing the cortical cubes by the fingers until transferring the IVA cannula to a surgeon. This will avoid the cube temperature to decreases.
	&#8203;NOTE: The details of autografting procedure under laparoscopic surgery have been reported previously19. For grafting ovarian cortical cubes, a cannula-shaped device (IVA cannula) was developed by our collaborator, the Kitazato Corporation.</li>
</ol>
4.&#160;Histological analysis of ovarian cortex
NOTE: To count the number of residual follicles, perform histological analysis as previous described15.
<ol>
	<li>Mark the cortical strip surface with a tissue marking dye before sample fixation. This will indicate the side of cortex in strip for histology.</li>
	<li>Fix the tissue strips overnight at 4 &#176;C using Bouin&#39;s solution.
	NOTE: To detect atretic follicles, we do not recommend using paraformaldehyde for fixing to avoid shrinkage of oocyte cytoplasm.</li>
	<li>Dehydrate and embed the tissue strips in paraffin.</li>
	<li>Serially section the paraffin block containing the tissue sample.</li>
	<li>Stain each section using hematoxylin and eosin to visualize the follicles.</li>
	<li>Count the follicles as previously described17.</li>
</ol>

<ol>
	<li>Liang, T., Motan, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mature+Oocyte+Cryopreservation+for+Fertility+Preservation.">Mature Oocyte Cryopreservation for Fertility Preservation.</a> Advances in Experimental Medicine and Biology. 951, 155-161 (2016).</li><li>Yoon, T. K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Live+births+after+vitrification+of+oocytes+in+a+stimulated+in+vitro+fertilization-embryo+transfer+program.">Live births after vitrification of oocytes in a stimulated in vitro fertilization-embryo transfer program.</a> Fertility and Sterility. 79 (6), 1323-1326 (2003).</li><li>Donnez, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Livebirth+after+orthotopic+transplantation+of+cryopreserved+ovarian+tissue.">Livebirth after orthotopic transplantation of cryopreserved ovarian tissue.</a> Lancet. 364 (9443), 1405-1410 (2004).</li><li>Meirow, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Pregnancy+after+transplantation+of+cryopreserved+ovarian+tissue+in+a+patient+with+ovarian+failure+after+chemotherapy.">Pregnancy after transplantation of cryopreserved ovarian tissue in a patient with ovarian failure after chemotherapy.</a> New England Journal of Medicine. 353 (3), 318-321 (2005).</li><li>De Vos, M., Devroey, P., Fauser, B. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Primary+ovarian+insufficiency.">Primary ovarian insufficiency.</a> Lancet. 376 (9744), 911-921 (2010).</li><li>Scott, R. T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Follicle-stimulating+hormone+levels+on+cycle+day+3+are+predictive+of+in+vitro+fertilization+outcome.">Follicle-stimulating hormone levels on cycle day 3 are predictive of in vitro fertilization outcome.</a> Fertility and Sterility. 51 (4), 651-654 (1989).</li><li>Ferraretti, A. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=ESHRE+consensus+on+the+definition+of+'poor+response'+to+ovarian+stimulation+for+in+vitro+fertilization:+the+Bologna+criteria.">ESHRE consensus on the definition of 'poor response' to ovarian stimulation for in vitro fertilization: the Bologna criteria.</a> Human Reproduction. 26 (7), 1616-1624 (2011).</li><li>Huhtaniemi, I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advances+in+the+Molecular+Pathophysiology,+Genetics,+and+Treatment+of+Primary+Ovarian+Insufficiency.">Advances in the Molecular Pathophysiology, Genetics, and Treatment of Primary Ovarian Insufficiency.</a> Trends in Endocrinology and Metabolism. 29 (6), 400-419 (2018).</li><li>M&#281;czekalski, B., Maciejewska-Jeske, M., Podfigurna, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reproduction+in+premature+ovarian+insufficiency+patients+-+from+latest+studies+to+therapeutic+approach.">Reproduction in premature ovarian insufficiency patients - from latest studies to therapeutic approach.</a> Prz Menopauzalny. 17 (3), 117-119 (2018).</li><li>Baker, V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Life+plans+and+family-building+options+for+women+with+primary+ovarian+insufficiency.">Life plans and family-building options for women with primary ovarian insufficiency.</a> Seminars in Reproductive Medicine. 29 (4), 362-372 (2011).</li><li>Englert, Y., Govaerts, I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Oocyte+donation:+particular+technical+and+ethical+aspects.">Oocyte donation: particular technical and ethical aspects.</a> Human Reproduction. 13, 90-97 (1998).</li><li>Englert, Y., Rodesch, C., Laruelle, C., Govoerts, I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Oocyte+donation:+ethical+aspects+related+to+the+donor.">Oocyte donation: ethical aspects related to the donor.</a> Contraception, Fertilite, Sexualite. 25 (3), 251-257 (1997).</li><li>Storgaard, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Obstetric+and+neonatal+complications+in+pregnancies+conceived+after+oocyte+donation:+a+systematic+review+and+meta-analysis.">Obstetric and neonatal complications in pregnancies conceived after oocyte donation: a systematic review and meta-analysis.</a> BJOG: An International Journal of Obstetrics and Gynaecology. 124 (4), 561-572 (2017).</li><li>Storgaard, M., Malchau, S., Loft, A., Larsen, E., Pinborg, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Oocyte+donation+is+associated+with+an+increased+risk+of+complications+in+the+pregnant+woman+and+the+fetus.">Oocyte donation is associated with an increased risk of complications in the pregnant woman and the fetus.</a> Ugeskrift for Laeger. 179 (11), (2017).</li><li>Kawamura, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hippo+signaling+disruption+and+Akt+stimulation+of+ovarian+follicles+for+infertility+treatment.">Hippo signaling disruption and Akt stimulation of ovarian follicles for infertility treatment.</a> Proceedings of the National Academy of Sciences. 110 (43), 17474-17479 (2013).</li><li>Hsueh, A. J., Kawamura, K., Cheng, Y., Fauser, B. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Intraovarian+control+of+early+folliculogenesis.">Intraovarian control of early folliculogenesis.</a> Endocrine Reviews. 36 (1), 1-24 (2015).</li><li>Li, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Activation+of+dormant+ovarian+follicles+to+generate+mature+eggs.">Activation of dormant ovarian follicles to generate mature eggs.</a> Proceedings of the National Academy of Sciences of the United States of America. 107 (22), 10280-10284 (2010).</li><li>Suzuki, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Successful+fertility+preservation+following+ovarian+tissue+vitrification+in+patients+with+primary+ovarian+insufficiency.">Successful fertility preservation following ovarian tissue vitrification in patients with primary ovarian insufficiency.</a> Human Reproduction. 30 (3), 608-615 (2015).</li><li>Tanaka, Y., Hsueh, A. J., Kawamura, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Surgical+approaches+of+drug-free+in+activation+and+laparoscopic+ovarian+incision+to+treat+patients+with+ovarian+infertility.">Surgical approaches of drug-free in activation and laparoscopic ovarian incision to treat patients with ovarian infertility.</a> Fertility and Sterility. , (2020).</li><li>Kawamura, K., Ishizuka, B., Hsueh, A. J. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Drug-free+in-vitro+activation+of+follicles+for+infertility+treatment+in+poor+ovarian+response+patients+with+decreased+ovarian+reserve.">Drug-free in-vitro activation of follicles for infertility treatment in poor ovarian response patients with decreased ovarian reserve.</a> Reproductive Biomedicine Online. 40 (2), 245-253 (2020).</li><li>Haino, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Determination+of+Follicular+Localization+in+Human+Ovarian+Cortex+for+Vitrification.">Determination of Follicular Localization in Human Ovarian Cortex for Vitrification.</a> Journal of Adolescent and Young Adult Oncology. 7 (1), 46-53 (2018).</li><li>Baird, D. T., Webb, R., Campbell, B. K., Harkness, L. M., Gosden, R. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Long-term+ovarian+function+in+sheep+after+ovariectomy+and+transplantation+of+autografts+stored+at+-196+C.">Long-term ovarian function in sheep after ovariectomy and transplantation of autografts stored at -196 C.</a> Endocrinology. 140 (1), 462-471 (1999).</li><li>Qin, Y., Jiao, X., Simpson, J. L., Chen, Z. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genetics+of+primary+ovarian+insufficiency:+new+developments+and+opportunities.">Genetics of primary ovarian insufficiency: new developments and opportunities.</a> Human Reproduction Update. 21 (6), 787-808 (2015).</li><li>Domniz, N., Meirow, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Premature+ovarian+insufficiency+and+autoimmune+diseases.">Premature ovarian insufficiency and autoimmune diseases.</a> Best Practice &amp; Research: Clinical Obstetrics &amp; Gynaecology. 60, 42-55 (2019).</li><li>Laven, J. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Primary+Ovarian+Insufficiency.">Primary Ovarian Insufficiency.</a> Seminars in Reproductive Medicine. 34 (4), 230-234 (2016).</li><li>Grynberg, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fertility+preservation+in+Turner+syndrome.">Fertility preservation in Turner syndrome.</a> Fertility and Sterility. 105 (1), 13-19 (2016).</li><li>Tomao, F., Spinelli, G. P., Panici, P. B., Frati, L., Tomao, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ovarian+function,+reproduction+and+strategies+for+fertility+preservation+after+breast+cancer.">Ovarian function, reproduction and strategies for fertility preservation after breast cancer.</a> Critical Reviews in Oncology/Hematology. 76 (1), 1-12 (2010).</li><li>Kim, S., Lee, Y., Lee, S., Kim, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ovarian+tissue+cryopreservation+and+transplantation+in+patients+with+cancer.">Ovarian tissue cryopreservation and transplantation in patients with cancer.</a> Obstetrics &amp; Gynecology Science. 61 (4), 431-442 (2018).</li><li>Donnez, J., Dolmans, M. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ovarian+tissue+freezing:+current+status.">Ovarian tissue freezing: current status.</a> Current Opinion in Obstetrics and Gynecology. 27 (3), 222-230 (2015).</li><li>Wu, R. C., Kuo, P. L., Lin, S. J., Liu, C. H., Tzeng, C. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=X+chromosome+mosaicism+in+patients+with+recurrent+abortion+or+premature+ovarian+failure.">X chromosome mosaicism in patients with recurrent abortion or premature ovarian failure.</a> Journal of the Formosan Medical Association. 92 (11), 953-956 (1993).</li><li>De Munck, N., Vajta, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Safety+and+efficiency+of+oocyte+vitrification.">Safety and efficiency of oocyte vitrification.</a> Cryobiology. 78, 119-127 (2017).</li><li>Argyle, C. E., Harper, J. C., Davies, M. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Oocyte+cryopreservation:+where+are+we+now.">Oocyte cryopreservation: where are we now.</a> Human Reproduction Update. 22 (4), 440-449 (2016).</li></ol>

The authors confirm that they have no conflict of interest.

In this manuscript, we showed a detailed laboratory protocol for drug-free IVA. The drug-free IVA is a new approach of infertility treatment for POR patient with diminishing ovarian reserve to promote secondary follicles growth, resulting in yielding more mature oocytes after ovarian stimulation and increasing in successful pregnancy20. In 15 POR patients with diminishing ovarian reserve, this approach achieved one spontaneous pregnancy, in vitro fertilization-embryo transfer allowed four live bir...

Ovarian function declines progressively during aging and some pathophysiological conditions including karyotype abnormality, autoimmune diseases, chemo- and radiation-therapies, and ovarian surgeries. Fertility preservation is one of the best options for unmarried women with severe ovarian dysfunction to preserve their potential for future pregnancy. For fertility preservation, currently two methods are available mostly in the onco-fertility field. Oocyte cryopreservation is a well-established procedure for fertility preservation and many successful cases have been reported1,2. On the other hand, ovarian tissue cryopreservation was also established for fertility preservation in cancer patients but it is still an experimental strategy3,4. In both methods, multiple numbers of mature oocytes are needed for pregnancy to occur. Generally, patients with premature ovarian insufficiency (POI), who become amenorrhea before 40 years of age, and middle-aged women with low ovarian reserve showed poor ovarian response (POR) to ovarian stimulation for yielding mature oocytes5,6,7. Furthermore, young patients with a low number of antral follicles also showed POR to the ovarian stimulation7. These patients have very limited number of retrievable oocytes even after proper ovarian hyperstimulation, thus requiring multiple expensive procedures to ensure a sufficient number of oocytes for pregnancy.
Oocyte donation followed by in vitro fertilization (IVF) with husband&#39;s sperm and embryo transfer (ET) is the only option for these POI and POR patients who have difficulties obtaining their own oocytes8,9,10. However, oocyte donation is complicated by ethical issues as well as autoimmune and pregnancy complications11,12,13,14. To solve these issues, the establishment of infertility treatment using patients&#39; own oocytes is desired. For POI patients, we have developed the in vitro activation (IVA) approach to allow successful follicle growth and the generation of mature oocytes, leading a number of pregnancies and deliveries15. In IVA, we fragmented ovarian cortexes after removal of ovaries under laparoscopic surgery and cultured them for two days to activate follicles by Akt-stimulating drugs and then perform heterotopic grafting back into artificial pouches made beneath the serosa of Fallopian tubes under second laparoscopic surgery15. This procedure promoted growth of primordial, primary and secondary follicles after ovarian cortex fragmentation to promote Hippo signaling disruption16, followed by two days culture with Akt signaling stimulators17.
In contrast to severe POI cases, POR patients with decreased ovarian reserve have multiple secondary follicles. Because Hippo signaling disruption alone is effective in promoting secondary follicle growth16, we recently demonstrated successful pregnancies and deliveries for POR patients using the drug-free IVA procedure involving cortical fragmentation and orthotopic grafting without treatment of the Akt stimulating drugs. Drug-free IVA stimulates early stage of ovarian follicles to develop to the preantral follicle stage after only one surgery and increased the number of retrieved oocytes for IVF-embryo transfer15,18. The drug-free IVA approach has several advantages as compared with our original IVA by 1) avoiding potential follicle loss during culture, 2) minimizing invasiveness and costs of the second surgery, 3) involving only short-term post-surgery bed rest and 4) potential of spontaneous pregnancy due to orthotopic grafting. We recently published a video article showing the surgical procedures of drug-free IVA19 and detailed protocols of ovarian stimulation after the surgery20. Here, we present details of laboratory methods required for drug-free IVA.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>4.5 onz specimen container</td>
			<td>FALCON</td>
			<td>354013</td>
			<td>Other products may also be suitable</td>
		</tr>
		<tr>
			<td>60mm dish</td>
			<td>FALCON</td>
			<td>351007</td>
			<td>Other products may also be suitable</td>
		</tr>
		<tr>
			<td>50 x 50 cm sterile drape</td>
			<td>HOGY Medical</td>
			<td>SR-823</td>
			<td>Any type of sterile produsts may also be suitable</td>
		</tr>
		<tr>
			<td>Disposable pippete</td>
			<td>FALCON</td>
			<td>357575</td>
			<td>Other products may also be suitable</td>
		</tr>
		<tr>
			<td>Fine scissors, Curved</td>
			<td>WPI</td>
			<td>#14224-G</td>
			<td>Although other products may also be suitable, we strongly recommend use this products</td>
		</tr>
		<tr>
			<td>Hot plate</td>
			<td>TOKAI HIT</td>
			<td>TPiE-SP</td>
			<td>Use at operation room to maintain the temperature of dishes containing ovarian tissue before transplantation</td>
		</tr>
		<tr>
			<td>Human Serum Albumin Solution</td>
			<td>Irvine Scientific</td>
			<td>9988</td>
			<td>Medium for handling ovarian tissue</td>
		</tr>
		<tr>
			<td>IVA cannule</td>
			<td>KITAZATO</td>
			<td>446030 IVA-6030E</td>
			<td>Specific cannula for tissue autografting</td>
		</tr>
		<tr>
			<td>KAI medical Disposable scalpel</td>
			<td>WPI</td>
			<td>#5 10-A</td>
			<td>Although other products may also be suitable, we strongly recommend use this products</td>
		</tr>
		<tr>
			<td>Micro scissors, Curved</td>
			<td>WPI</td>
			<td>#503364</td>
			<td>Although other products may also be suitable, we strongly recommend use this products</td>
		</tr>
		<tr>
			<td>Modified HTF Medium-HEPES</td>
			<td>Irvine Scientific</td>
			<td>90126</td>
			<td>Medium for handling ovarian tissue</td>
		</tr>
		<tr>
			<td>Sterile gauze</td>
			<td>Osaki Medical</td>
			<td>15004</td>
			<td>Any type of sterile produsts may also be suitable</td>
		</tr>
		<tr>
			<td>Swiss Tweezers, Curved Tips</td>
			<td>KAI</td>
			<td>#504505</td>
			<td>Although other products may also be suitable, we strongly recommend use this products</td>
		</tr>
	</tbody>
</table>

fertility preservation in patients with severe ovarian dysfunction

Ovarian function progressively declines during aging and in some pathophysiological conditions including karyotype abnormality, autoimmune diseases, chemo- and radiation-therapies, as well as ovarian surgeries. In unmarried women with severe ovarian dysfunction, fertility preservation is important for future pregnancies. Although oocyte cryopreservation is an established method for fertility preservation, these patients could only preserve a limited number of oocytes even after ovarian hyperstimulation, leading to repeated stimulations to ensure sufficient oocytes to guarantee future pregnancy. To solve this issue, we have recently developed a drug-free in vitro activation (IVA) procedure, which enable us to stimulate early stages of ovarian follicles to develop to the preantral follicle stage. These preantral follicles can respond to the unique protocol of gonadotropin stimulation, resulting in increased number of retrieved oocytes per ovarian stimulation for cryopreservation. The drug-free IVA comprised from the surgical approach and ovarian stimulation. We removed a part of cortex from one or both ovaries from patients under laparoscopic surgery. The ovarian cortical tissues were cut into small cubes to disrupt the Hippo signaling pathway and stimulate the development of early stage follicles. These cubes were grafted orthotropically into remaining ovaries as well as beneath the serosa of both Fallopian tubes. We have already published the surgical procedure of the drug-free IVA and the protocol of subsequent ovarian stimulation, but herein we present the details of laboratory methods required for drug-free IVA.

In the first publication of the IVA approach15, we transplanted the ovarian cortical cubes one by one into the grafting sites under laparoscopic surgery (Figure 1A). Because 100-150 ovarian cubes were used, it took 3-4 hours for tissue grafting under laparoscopic surgery. Also, some ovarian cubes were lost before grafting. Because the IVA cannula could transfer 20-30 cubes to a grafting site at one time (Figure 1B), we could shorten the o...

Watch this Scientific Journal Video about Fertility Preservation in Patients with Severe Ovarian Dysfunction at JoVE.com

Fertility Preservation in Patients with Severe Ovarian Dysfunction

We present details of laboratory procedures for drug-free in vitro activation (IVA) of ovarian follicles for patients with severe ovarian dysfunction. This method could increase the number of retrievable oocytes per ovarian hyperstimulation and benefit fertility preservation for those patients.

Ovarian function progressively declines during aging and in some pathophysiological conditions including karyotype abnormality, autoimmune diseases, ...

fertility-preservation-in-patients-with-severe-ovarian-dysfunction
