We acknowledge Dr. Harold Dvorak for helpful discussions including the suggestion to try fixation in 37&#160;&#176;C PFA. This work was supported by NIH grant P01 CA92644 and by a contract from the National Foundation for Cancer Research.

1. Cell Culture on Collagen Coated Glass Disk
<ol>
	<li>Place glass disks (12 mm in diameter) in a glass jar (4 oz) and autoclave to sterilize the discs.</li>
	<li>Put 25 ml 70% ethanol in a 50&#160;ml Falcon tube and place it in a cell culture hood. This solution can be reused multiple times until the level of the solution drops to 20 ml.</li>
	<li>Place a sharp forceps with an extra fine point in the 70% ethanol for 5 min before using it to handle the glass disk.</li>
	<li>Carefully remove the forceps out of the tube and close the cap, then gently place the ethanol treated forceps on top of the tube to air dry for 2 min. Do not allow the tip of the forceps to touch anything in the hood.</li>
	<li>Use the sterile forceps to grab one sterile glass disk&#160;out of the glass jar and place it in a well of the 24-well cell culture plate. Repeat until the desired number of wells has been populated with discs.</li>
	<li>Put 500 &#956;l of Bovine collagen solution (50 ng/ml) into each well that contains a glass disk&#160;and place it in a 37 &#176;C, 5% CO2 cell culture incubator for at least 30 min. There is no harm in a longer incubation.</li>
	<li>Harvest HUVEC (Human Umbilical Vein Endothelial Cells) or PC3 (prostate tumor cells) that were already grown in 150&#160;mm cell culture plate through trypsinization and block the trypsin activity using its complete culture medium. Collect cells into a 15&#160;ml Falcon tube.</li>
	<li>Count the cell number and make sure the viability is greater than 90%.</li>
	<li>Pellet the cells by centrifuging at 200 x g for 10 min at 4 &#176;C. Remove the supernatant.</li>
	<li>Use the culture medium to dilute the cells to 105 cells/ml. Place cells on ice.</li>
	<li>Aspirate the collagen in the cell culture hood and gently place 500 &#956;l of cell suspension to each well in which glass disks were precoated with collagen. 5 x 104 cells/well in the 24-well plate will give 60% confluency for HUVEC and 30% confluency for PC3 cells. Note: add more cell suspension for higher cell density.</li>
	<li>Culture the cells in a 37 &#176;C, 5% CO2 incubator for 1 hr, 2 hr, 4 hr, 6 hr, or 24 hr to track nanopodia activities and cell passage. Typically, cells will attach to the glass disk&#160;in the first 30 min, then start to polarize and migrate in the first hour, and perform intercellular interactions and cell division in the following hours.</li>
</ol>
2. Cell Fixation
<ol>
	<li>Each well will need 500 &#956;l 4% PFA (paraformaldehyde) to fix the cells. Either commercially manufactured or freshly made 4% PFA can be used. Calculate the amount of PFA needed based on the number of wells prepared, and place PFA in a 15-ml falcon tube. CAUTION: paraformaldehyde is a suspected carcinogen.</li>
	<li>Put the falcon tube in a Styrofoam stand that was already in place in a 37 &#176;C incubator. Leave the tube in the incubator for 30 min to warm up the PFA to 37 &#176;C.</li>
	<li>Place a heating pad in the culture hood and turn it on.</li>
	<li>Take out the 24-well cell culture plate and the prewarmed PFA out of the incubator and place it on top of the heating pad.</li>
	<li>Use one hand to aspirate the medium from a well, and immediately after use the other hand to gently slide 500 &#956;l PFA into the well through the well edge. For easier aspiration, tilt the culture plate at about 45&#176;, leaning it against the Styrofoam stand so that it is stable at that angle. This will facilitate the aspiration and adding PFA solution to the well without disturbing the cells in culture. This is the most crucial step to preserve the original cellular structure of cell activities.</li>
	<li>Repeat the process until all wells with a glass disk&#160;have received PFA. Note: all steps that need to change pre-existing solution from the well will apply same aspiration procedures.</li>
	<li>Place the plate in 37 &#176;C for 5&#160;min.</li>
	<li>Take the plate back to the culture hood and tilt against Styrofoam as described in step 2.5. Use one hand to gently transfer the PFA from the well into a collection tube; use the other hand to immediately afterward place at least 500 &#956;l room temperature&#160;PBS in the well. After all wells have been washed, return and repeat the PBS washing once more in every well. Empty the collected PFA into a hazardous waste container.</li>
	<li>Prepare ICC blocking buffer by adding 2% Fetal Bovine Serum to PBS. 0.04% sodium azide (dilute from 20% stock solution) is added as a preservative. CAUTION: sodium azide is a toxic compound. The buffer can be stored in 4 &#176;C for a long period of time without bacterial contamination.</li>
	<li>With the culture plate still tilted against a stand, once again cycle through each well aspirating to remove PBS and immediately afterward adding 500 &#956;l of ICC blocking buffer. Cells are now ready for immunofluorescence staining. If necessary, the fixed cells can be stored in a 4 &#176;C refrigerator for a week without significant loss of TM4SF1 protein.</li>
</ol>
3. TM4SF1 Immunofluorescence Staining of Nanopodia
<ol>
	<li>In each well, replace the 500 &#956;l ICC blocking buffer with a new blocking buffer containing 0.01% Triton X-100 and let it sit at room temperature for 1 hr. Do not use higher than 0.03% Triton X-100 as it will remove TM4SF1 from cell membranes. PBS washed cells from step 2.10 can be directly moved to the blocking buffer containing Triton if the staining is ready to be started right away.</li>
	<li>Dilute primary anti-TM4SF1 (or anti-CD9) antibody to 0.5 &#956;g/ml in ICC blocking buffer.</li>
	<li>In each well, remove the ICC/0.01% Triton buffer and replace it with 300 &#956;l of the anti-TM4SF1-antibody solution. Incubate 2 hr at&#160;room temperature or leave overnight&#160;at 4 &#176;C.</li>
	<li>Wash each well with no less than 500 &#956;l PBS. Repeat 3x; each time give at least 5 min of incubation time.</li>
	<li>Prepare a secondary antibody and phalloidin solution in ICC blocking buffer, using a 1,000 times dilution of Alexa 488&#160;labeled donkey anti-mouse secondary antibody (2 &#956;g/ml final concentration) and 1,000x dilution of phalloidin (50 ng/ml final concentration).</li>
	<li>Remove PBS and add 300 &#956;l of the secondary antibody and phalloidin solution to each well and incubate for 2 hr or leave it overnight&#160;at 4 &#176;C.</li>
	<li>Repeat PBS washing steps with at least a 5 min incubation per wash. In the last wash, leave each well in PBS for 1 hr.</li>
	<li>Drop a single drop (~10 &#956;l) of anti-fade mounting media on a glass slide.</li>
	<li>Bend the tip of a 19 G 1&#160;&#189; in syringe needle 90&#176;&#160;by pressing gently on a hard surface. Use one hand to hold bended needle and gently lift up a glass disk&#160;from the well,&#160;and use the other hand to grasp the disc using the sharp forceps.</li>
	<li>Turn the glass disk&#160;face down letting the cell side contact the mounting media on the glass slide. Gently place the glass disk&#160;and let it dry overnight&#160;in a dark place at&#160;room temperature.</li>
	<li>Proceed to image the immunofluorescence stained nanopodia, or store the slides in a slide box at -20 &#176;C. The slides will remain viewable for a few months in -20 &#176;C.</li>
</ol>

<ol>
	<li>Chhabra, E. S., Higgs, H. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+many+faces+of+actin:+matching+assembly+factors+with+cellular+structures.">The many faces of actin: matching assembly factors with cellular structures.</a> Nat. Cell Biol. 9, 1110-1121 (2007).</li><li>Shih, S. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+L6+protein+TM4SF1+is+critical+for+endothelial+cell+function+and+tumor+angiogenesis.">The L6 protein TM4SF1 is critical for endothelial cell function and tumor angiogenesis.</a> Cancer Res. 69, 3272-3277 (2009).</li><li>Zukauskas, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=TM4SF1:+a+tetraspanin-like+protein+necessary+for+nanopodia+formation+and+endothelial+cell+migration.">TM4SF1: a tetraspanin-like protein necessary for nanopodia formation and endothelial cell migration.</a> Angiogenesis. 14, 345-354 (2011).</li><li>Hellstrom, I., Beaumier, P. L., Hellstrom, K. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Antitumor+effects+of+L6,+an+IgG2a+antibody+that+reacts+with+most+human+carcinomas.">Antitumor effects of L6, an IgG2a antibody that reacts with most human carcinomas.</a> Proc. Natl. Acad. Sci. U.S.A. 83, 7059-7063 (1986).</li><li>Jang, Y. Y., Ye, Z., Cheng, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+imaging+and+stem+cell+research.">Molecular imaging and stem cell research.</a> Mol. Imag. 10, 111-122 (2011).</li><li>Hemler, M. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tetraspanin+functions+and+associated+microdomains.">Tetraspanin functions and associated microdomains.</a> Nat. Rev. Mol. Cell Biol. 6, 801-811 (2005).</li><li>Vasile, E., Tomita, Y., Brown, L. F., Kocher, O., Dvorak, H. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Differential+expression+of+thymosin+beta-10+by+early+passage+and+senescent+vascular+endothelium+is+modulated+by+VPF/VEGF:+evidence+for+senescent+endothelial+cells+in+vivo+at+sites+of+atherosclerosis.">Differential expression of thymosin beta-10 by early passage and senescent vascular endothelium is modulated by VPF/VEGF: evidence for senescent endothelial cells in vivo at sites of atherosclerosis.</a> FASEB. 15, 458-466 (2001).</li><li>Itoh, T. J., Hotani, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microtubule+dynamics+and+the+regulation+by+microtubule-associated+proteins+(MAPs).">Microtubule dynamics and the regulation by microtubule-associated proteins (MAPs).</a> Uchu Seibutsu Kagaku. 18, 116-117 (2004).</li><li>Caplow, M., Shanks, J., Ruhlen, R. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Temperature-jump+studies+of+microtubule+dynamic+instability.">Temperature-jump studies of microtubule dynamic instability.</a> J. Biol. Chem. 263, 10344-10352 (1988).</li><li>Pollice, A. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Sequential+paraformaldehyde+and+methanol+fixation+for+simultaneous+flow+cytometric+analysis+of+DNA,+cell+surface+proteins,+and+intracellular+proteins.">Sequential paraformaldehyde and methanol fixation for simultaneous flow cytometric analysis of DNA, cell surface proteins, and intracellular proteins.</a> Cytometry. 13, 432-444 (1992).</li><li>Macarulla, J. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Membrane+solubilization+by+the+non-ionic+detergent+triton+X-100.+A+comparative+study+including+model+and+cell+membranes.">Membrane solubilization by the non-ionic detergent triton X-100. A comparative study including model and cell membranes.</a> Revista Espanola de Fisiologia. 45 Suppl, 1-8 (1989).</li><li>Koley, D., Bard, A. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Triton+X-100+concentration+effects+on+membrane+permeability+of+a+single+HeLa+cell+by+scanning+electrochemical+microscopy+(SECM).">Triton X-100 concentration effects on membrane permeability of a single HeLa cell by scanning electrochemical microscopy (SECM).</a> Proc. Natl. Acad. Sci. U.S.A. 107, 16783-16787 (2010).</li><li>Chang, Y. W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CD13+(aminopeptidase+N)+can+associate+with+tumor-associated+antigen+L6+and+enhance+the+motility+of+human+lung+cancer+cells.">CD13 (aminopeptidase N) can associate with tumor-associated antigen L6 and enhance the motility of human lung cancer cells.</a> Int. J. Cancer. 116, 243-252 (2005).</li></ol>

No conflicts of interest declared.

Nanopodia are thin cellular membrane channels that firmly attach to matrix through TMED and can extend more than 100 &#956;m from a polarized mobile cell to sense the environment and mediate intercellular interactions2,3. Nanopodia adhere to matrix so firmly that residues are left behind as the cell moves away (Figures 1 and 2). Nanopodia thus allow us to study how cells sense their environment and determine the path of cell movement, and how gene expression or drug treatment ...

During polarization for movement, animal cells extend a variety of dynamic, membrane protrusions from their surfaces, including filopodia, lamellipodia, retraction fibers, and ruffles1. Recently added to this list were nanopodia, a newly recognized type of thin (100-300 &#956;m in diameter), elongated (up to 50-100 &#956;m long) membrane projection that provide membrane channels for the extension of F-actin structures such as filopodia and retraction fiber, and that stain positively with TM4SF1 (Transmembrane-4-L-six-family-1) in cultured endothelial and tumor cells2,3.
TM4SF1 is a protein with tetraspanin-like topology that was originally known as a tumor cell antigen4 before the discovery that the molecule is an endothelial cell biomarker that plays an essential role in endothelial cell proliferation and migration2,3. Immunofluorescence staining revealed that TM4SF1 is localized to perinuclear vesicles and to the plasma membrane, and is enriched in TM4SF1 enriched microdomains (TMED). TMED anchor nanopodia to matrix and present in a regularly spaced banded pattern of 1-3 TMED/&#181;m length of nanopodia. Nanopodia typically extend from a cell's leading front and trailing rear during cell polarization for movement. Due to the firm adherent nature of TMED, nanopodia are unable to retract back into the cell as it moves away; abandoned nanopodia residues thus trace out the path of cellular movement. Nanopodia provide membrane channels for F-actin extension and retraction, and are sites of intercellular interactions and communications2,3. These characteristics mean that nanopodia provide a unique opportunity to study the mechanisms underlying F-actin assembly during cellular polarization, cellular sensing of the environment, determination of the path and direction of cell movement, and intercellular interactions and communications.
Due to the highly hydrophobic nature of TMED and the thin and fragile membranous nature of nanopodia, special care needs to be taken in order to preserve TMED and nanopodia. The destruction of nanopodia and removal of TMED by common laboratory methods is a possible reason why only sixty-three publications have appeared on TM4SF1 since its first discovery in 19861&#160;and for the complete lack of knowledge of TM4SF1 enrichment in 100-300 &#956;m microdomains on the cell surface until the report of TM4SF1 in endothelial cells in 20092.
Conventional immunostaining methods commonly use organic solvents like ethanol, methanol, or acetone to fix cells and use 0.1% or higher Triton X-100 concentration to permeabilize cells5. Studies described here implemented three major changes to the conventional method to reveal TMED and nanopodia: (i) use 37 &#176;C 4% PFA and fix cells in a 37 &#176;C incubator, (ii) apply gentle room temperature PBS washing, and (iii) use less than 0.03% Triton X-100 only briefly to permeabilize cells before addition of primary antibody, as Triton X-100 higher than 0.03% will extract TM4SF1.
All tetraspanins form microdomains on the cell membrane6 and some colocalize with TMED in endothelial and tumor cells2,3. As tetraspanins like CD9, CD81, and CD151 are ubiquitously expressed, the staining protocol described here can be extended to many different cell types that lack TM4SF1 for the studies of nanopodia function.

<table><tbody><tr><td>Glass disks</td><td>Fisher Scientific</td><td>12-545-82</td><td>12 mm diameter</td></tr><tr><td>Glass jar</td><td>Fisher Scientific</td><td>02-912-310</td><td>Certified Clean Clear Glass Straight-Sided Jars, 4 oz</td></tr><tr><td>Glass slide</td><td>Fisher Scientific</td><td>12-544-1</td><td>Fisherfinest Premium Plain Glass Microscope Slides</td></tr><tr><td>50 ml Falcon tube</td><td>BD Falcon</td><td>352070</td><td>50 ml high-clarity polypropylene conical centrifuge tube, 16,000 rcf rating. Sterile.</td></tr><tr><td>15 ml Falcon tube with Styrofoam rack</td><td>Corning</td><td>430790</td><td>Corning 15 ml PP Centrifuge Tubes</td></tr><tr><td>Sharp forceps</td><td>Fisher Scientific</td><td>13-812-42</td><td>Dissecting Extra Fine Pointed Splinter Forceps</td></tr><tr><td>24-well Cell culture plate</td><td>BD Bioscience</td><td>353047</td><td>24-well Cell Culture Plate</td></tr><tr><td>150 mm Cell culture plate</td><td>BD Bioscience</td><td>353025</td><td>150 mm cell culture plate</td></tr><tr><td>19 G 1 &amp;frac12; Syringe needle</td><td>BD Bioscience</td><td>309635</td><td>19 G 1 &amp;frac12;</td></tr><tr><td>Ethanol</td><td>Decon Laboratories, Inc.</td><td>2701</td><td>Decon&#039;s Pure Ethanol 200 Proof</td></tr><tr><td>Collagen solution</td><td>BD Bioscience</td><td>354249</td><td>Collagen I, High Concentration, rat tail, 100 mg</td></tr><tr><td>Trypsin/EDTA</td><td>Cellgro</td><td>25-053-CI</td><td>0.25% Trypsin-EDTA 1x</td></tr><tr><td>DMEM</td><td>Life Technologies</td><td>11965-092</td><td>DMEM high glucose (1x), liquid, with L-glutamine, without sodium pyruvate</td></tr><tr><td>10x PBS</td><td>Affymetrix</td><td>75889 5 LT</td><td>PBS, 10x Solution, pH 7.4</td></tr><tr><td>PFA (paraformaldehyde)</td><td>Affymetrix</td><td>19943 1 LT</td><td>4% in PBS</td></tr><tr><td>FBS</td><td>Sigma-Aldrich</td><td>F4135-500ML</td><td>Fetal Bovine Serum</td></tr><tr><td>EGM2-MV</td><td>Lonza</td><td>CC-3162</td><td>EGM-2 BulletKit, EBM-2 Basal Medium 500 ml and EGM-2 SingleQuot Kit Supplement &amp;amp; Growth Factors</td></tr><tr><td>Triton X-100</td><td>Sigma-Aldrich</td><td>T8787</td><td>Triton X-100</td></tr><tr><td>NaN&lt;sub&gt;3&lt;/sub&gt;</td><td>Sigma-Aldrich</td><td>S2002-25G</td><td>Solubilized in water. 4% stock solution and working concentration is 0.4%.</td></tr><tr><td>Mouse anti-human TM4SF1 antibody&amp;nbsp;</td><td>Millipore</td><td>MAB3127</td><td>Epitope is located in extracellular domain</td></tr><tr><td>Mouse anti-human CD9 antibody&amp;nbsp;</td><td>BD Bioscience</td><td>555370</td><td>Epitope is located in extracellular domain</td></tr><tr><td>Alexa Fluor 488 Donkey anti-mouse 2nd antibody</td><td>Life Technologies</td><td>A-21202</td><td>Alexa Fluor 488 Donkey Anti-Mouse IgG (H+L)</td></tr><tr><td>Phalloidin</td><td>Chemicon</td><td>90324</td><td>Rhodamine-conjugated Phalloidin</td></tr><tr><td>Anti-fade mounting media&amp;nbsp;</td><td>Life Technologies</td><td>P-36931</td><td>ProLong Gold Antifade Reagent with DAPI</td></tr><tr><td>70% Ethanol&amp;nbsp;</td><td></td><td></td><td>17.5 ml of ethanol (200 proof)&lt;br/&gt; 7.5 ml of double-deionized water</td></tr><tr><td>10x PBS (make 200 ml)</td><td></td><td></td><td>20 ml of 10x PBS&lt;br/&gt; 180 ml of double-deionized water</td></tr><tr><td>20% Triton X-100 (make 20 ml)&amp;nbsp;</td><td></td><td></td><td>4 ml Triton X-100&lt;br/&gt; 16 ml double-deionized water</td></tr><tr><td>4% NaN&lt;sub&gt;3&lt;/sub&gt; (make 25 ml)</td><td></td><td></td><td>1 g of NaN&lt;sub&gt;3&lt;/sub&gt;&lt;br/&gt; 25 ml of double-deionized water</td></tr><tr><td>50 ng/ml Bovine collagen solution in PBS (make 5 ml)</td><td></td><td></td><td>Stock solution of 50 &amp;mu;g/ml (50 ml)&lt;br/&gt; 830 &amp;mu;l of Collagen I (3 mg)&lt;br/&gt; 50 ml PBS</td></tr><tr><td>ICC Blocking Buffer (50 ml)</td><td></td><td></td><td>49 ml PBS&lt;br/&gt; 2% FBS (add 1 ml)&lt;br/&gt; 0.04% NaN&lt;sub&gt;3&lt;/sub&gt; (add 100 &amp;mu;l of 4% NaN&lt;sub&gt;3&lt;/sub&gt;)</td></tr><tr><td>ICC Blocking Buffer/0.01% Triton X-100 (make 50 ml)</td><td></td><td></td><td>50 ml of ICC Blocking Buffer&lt;br/&gt; 25 &amp;mu;l of 20% Triton X-100</td></tr><tr><td>HUVEC&amp;nbsp;</td><td>Lonza</td><td>C2517A</td><td>&lt;a href=&quot;http://www.lonza.com/products-services/bio-research/primary-and-stem-cells/human-cells-and-media/endothelial-cells-and-media/huvec-human-umbilical-vein-endothelial-cells.aspx&quot;&gt;www.lonza.com&lt;/a&gt;</td></tr><tr><td>PC3</td><td>ATCC</td><td>CRL-1435</td><td>&lt;a href=&quot;http://www.atcc.org/products/all/CRL-1435.aspx#85786B46AA23451B94BC5D45200673F7&quot;&gt;www.atcc.org&lt;/a&gt;</td></tr><tr><td>Cell culture hood</td><td>NuAIRE</td><td>Nu-425-600</td><td>NU-425 (Series 60) Biological Safety Cabinet&amp;nbsp;</td></tr><tr><td>37 &amp;deg;C, 5% CO&lt;sub&gt;2&lt;/sub&gt; Cell culture incubator&amp;nbsp;</td><td>CellStar</td><td>QWJ300DABA</td><td>Cellstar CO&lt;sub&gt;2&lt;/sub&gt; Water Jacketed Incubator</td></tr><tr><td>Heating pad&amp;nbsp;</td><td>K&amp;amp;H Manufacturing</td><td>1020</td><td>K&amp;amp;H Lectro Kennel Heated Pad with Free Fleece Cover (&lt;a href=&quot;http://www.amazon.com/Lectro-Kennel-Heat-Pad-22-5x28-5-In/dp/B000PSRN20/ref=pd_bxgy_petsupplies_img_y&quot;&gt;www.amazon.com&lt;/a&gt;)</td></tr><tr><td>Centrifuge</td><td>Sorvall</td><td>T6000B</td><td>Sorvall T6000 (B) Benchtop Centrifuge</td></tr><tr><td>Hemocytometer</td><td>Sigma-Aldrich</td><td>Z359629</td><td>Bright-Line Hemocytometer</td></tr></tbody></table>

nanopodia - thin, fragile membrane projections with roles in cell movement and intercellular interactions

Adherent cells in culture maintain a polarized state to support movement and intercellular interactions. Nanopodia are thin, elongated, largely F-actin-negative membrane projections in endothelial and cancer cells that can be visualized through TM4SF1 (Transmembrane-4-L-six-family-1) immunofluorescence staining. TM4SF1 clusters in 100-300 &#956;m diameter TMED (TM4SF1 enriched microdomains) containing 3 to as many as 14 individual TM4SF1 molecules. TMED are arranged intermittently along nanopodia at a regular spacing of 1 to 3 TMED per &#956;m and firmly anchor nanopodia to matrix. This enables nanopodia to extend more than 100 &#956;m from the leading front or trailing rear of polarized endothelial or tumor cells, and causes membrane residues to be left behind on matrix when the cell moves away. TMED and nanopodia have been overlooked because of their extreme fragility and sensitivity to temperature. Routine washing and fixation disrupt the structure. Nanopodia are preserved by direct fixation in paraformaldehyde (PFA) at 37 &#176;C, followed by brief exposure to 0.01% Triton X-100 before staining. Nanopodia open new vistas in cell biology: they promise to reshape our understanding of how cells sense their environment, detect and identify other cells at a distance, initiate intercellular interactions at close contact, and of the signaling mechanisms involved in movement, proliferation, and cell-cell communications. The methods that are developed for studying TM4SF1-derived nanopodia may be useful for studies of nanopodia that form in other cell types through the agency of classic tetraspanins, notably the ubiquitously expressed CD9, CD81, and CD151.

For Step 1:
If cells (such as HUVEC and PC3 used in this study) are able to grow normally, cells will attach to the collagen-coated disc within 30 min after they are seeded, polarize and become mobile soon afterward, and extend nanopodia ahead of their path of movement. Figures 1A and 1B respectively shows a polarized and proliferating HUVEC. Figure 2A shows polarized PC3 cells in a mobile state.
For Step 2:
