This work was supported by NIH grants R01CA238263 and R01CA229784 (VAB).

All studies and experiments described in this protocol were conducted under guidelines according to the Institutional Animal Care and Use Committee (IACUC) of Beth Israel Deaconess Medical Center. Six to ten weeks old C57BL/6 mice of either sex were used to develop this protocol.
1. Surgical excision and tissue preparation
<ol>
	<li>Euthanize the mouse by intraperitoneally injecting 1 mL of tribromoethanol (prepared according to standard protocol; Table of Materials).
	NOTE: CO2 asphyxiation should be avoided in lung studies as it might cause lung injury and alter the features and properties of lung immune cells. Cervical dislocation should also be avoided as it might cause mechanical injury of the lung.</li>
	<li>Transfer the mouse to a clean and dedicated area for surgical operation.</li>
	<li>Stabilize the mouse dorsal side down by using needles or tape on the four extremities. Use 70% ethanol to sanitize the skin of the ventral area.</li>
	<li>Perform an incision in the skin, from the neck to the abdomen. Carefully remove the skin from the thoracic area.</li>
	<li>Carefully remove the sternum and ribs.</li>
	<li>Flush the lungs by injecting 10 mL of cold PBS directly in the right ventricle, using an 18-21 G needle, until the lungs become completely white.</li>
	<li>Carefully remove the thymus and heart without touching the lungs.</li>
	<li>Gently detach the lungs from the surrounding tissues and transfer them to a tube with cold BSA buffer (Table 1).
	NOTE: Effort should be made to remove all adjacent fat from the lungs before further preparing the single-cell suspension, as this could bias the readouts.</li>
</ol>
2. Preparation of single-cell suspension
<ol>
	<li>Transfer the lungs to an empty Petri dish and mince them with two fine scalpels. Transfer all the pieces of the minced lung to a new 50 mL conical tube. Use 5 mL of digestion buffer to wash the plate and add it to the 50 mL tube containing the minced lung (Table 1).
	NOTE: Digestion buffer should be prepared immediately before use. Use 5 mg/mL of collagenase28. Combining 1 or 5 mg of collagenase with BSA buffer or protein-free PBS did not improve results (Supplemental Figure S1).</li>
	<li>Secure the lid of the tube and digest the lung for 30 min on an orbital shaker at a speed of 150 rpm at 37 &#176;C. Stop the reaction by adding 10 mL of cold BSA buffer.</li>
	<li>After digestion, use an 18 G needle to mix and dissolve the lung pieces. Place a 70 &#181;m filter strainer at the top of a new 50 mL conical tube.
	NOTE: Usage of a smaller micron filter might result in the loss of major myeloid populations.</li>
	<li>Slowly transfer the digested lung mixture directly on the strainer. Use the rubber side of a 10 mL syringe plunger to smash the remaining lung pieces on the filter. Wash the processed material on the filter with BSA buffer.</li>
	<li>Centrifuge the single-cell suspension at 350 &#215; g for 8 min at 4 &#176;C.</li>
	<li>Carefully discard the supernatant and resuspend the cells in 1 mL of ACK lysis buffer. Mix well using a 1 mL pipet, and incubate for 90 s at room temperature.</li>
	<li>Add 10 mL of cold BSA buffer to stop the reaction and centrifuge at 350 &#215; g for 7 min at 4 &#176;C.Carefully discard the supernatant and resuspend the pellet in Staining Buffer to count the cells using a hemocytometer.</li>
	<li>Resuspend the cells at a concentration of 5 &#215; 106 cells/mL and use them for surface staining (see section 3).
	NOTE: For this purpose, plate the cells in a 96-well round-bottom plate followed by antibody staining and washes. If a plate centrifuge is not available, use flow tubes instead of plates. With this protocol, ~15-20 &#215; 106 cells per lung can be obtained from a 6-10-week-old C57BL/6 mouse of average size.</li>
</ol>
3. Surface antibody staining
<ol>
	<li>Transfer 1 &#215; 106 cells in 200 &#181;L per well in a 96-well plate. Centrifuge the plate at 350 &#215; g for 7 min at 4 &#176;C. In the meantime, prepare the Fc-block solution by diluting anti-16/32 antibody (1:100) in staining buffer (Table 1).</li>
	<li>Resuspend the cells in 50 &#181;L of the pre-prepared Fc-blocking solution (Table of Materials) and incubate for 15-20 min at 4 &#176;C or on ice.</li>
	<li>Add 150 &#181;L of staining buffer and centrifuge the plate at 350 &#215; g for 5 min at 4 &#176;C. Meanwhile, prepare the surface antibody cocktail by diluting surface antibodies (1:100; Table 2) in staining buffer.
	NOTE: (i) Anti-16/32 antibody for Fc-blocking can be used with the surface antibodies in the same mixture. (ii) If fixable viability dye is used, add it to the surface antibody cocktail at a dilution of 1:1,000.</li>
	<li>Resuspend the cells in 50 &#181;L of the pre-prepared surface antibody cocktail and incubate for 30-40 min at 4 &#176;C in the dark. Wash the cells with staining buffer twice.
	&#8203;NOTE: If no intracellular staining is required, resuspend the cells in 200 &#181;L of staining buffer and proceed directly to the acquisition of data on the flow cytometer. Alternatively, cells might be fixed and stored at 4 &#176;C for acquisition later. We recommend using the cells for flow cytometry within 24 h.</li>
</ol>
4. Cell fixation and intracellular staining
<ol>
	<li>Prepare the fixation/permeabilization buffer (Fix/Perm Buffer) by mixing three parts of fixation/permeabilization concentrate and 1 part of fixation/permeabilization diluent of the FoxP3/Transcription Factor Staining Buffer Set (Table 1).</li>
	<li>Resuspend the cells in 50 &#181;L of the pre-prepared Fix/Perm Buffer per well of the 96-well plate, where cells were plated as described in section 3, and incubate them for 20-25 min at 4 &#176;C in the dark.</li>
	<li>Dilute the 10x permeabilization buffer as 1: 10 in purified deionized water to prepare 1x permeabilization buffer.</li>
	<li>Wash the cells once with 1x permeabilization buffer. Meanwhile, prepare the intracellular antibody cocktail by diluting intracellular antibodies (1:100) in 1 mL of permeabilization buffer.</li>
	<li>Resuspend the cells using 50 &#181;L of the pre-prepared surface antibody cocktail per cell of the 96-well plate and incubate for 40 min at 4 &#176;C in the dark.</li>
	<li>Wash the cells once with permeabilization buffer and once with staining buffer. After the final wash, resuspend the cells in 200 &#181;L of staining buffer.
	NOTE: If no flow cytometer with plate reader is available, transfer the cells into flow cytometry tubes.</li>
	<li>Acquire a minimum of 1.5 &#215; 106 cells per sample on the flow cytometer.
	NOTE: For single colors and unstained control samples, 0.5-1 &#215; 106 cells per sample will be sufficient. It is recommended to titer the individual antibodies used to achieve optimal staining and reduce costs. The present protocol has been optimized using Fix/Perm Buffer prepared using the FoxP3 staining buffer set. Because CD68 is a cytoplasmic and not a nuclear marker, other permeabilization solutions such as a low concentration of paraformaldehyde or cytofix/ cytoperm kits from various vendors might be sufficient.</li>
</ol>

<ol>
	<li>Guilliams, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Alveolar+macrophages+develop+from+fetal+monocytes+that+differentiate+into+long-lived+cells+in+the+first+week+of+life+via+GM-CSF.">Alveolar macrophages develop from fetal monocytes that differentiate into long-lived cells in the first week of life via GM-CSF.</a> Journal of Experimental Medicine. 210 (10), 1977-1992 (2013).</li><li>Tan, S. Y., Krasnow, M. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Developmental+origin+of+lung+macrophage+diversity.">Developmental origin of lung macrophage diversity.</a> Development. 143 (8), 1318-1327 (2016).</li><li>Schyns, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Non-classical+tissue+monocytes+and+two+functionally+distinct+populations+of+interstitial+macrophages+populate+the+mouse+lung.">Non-classical tissue monocytes and two functionally distinct populations of interstitial macrophages populate the mouse lung.</a> Nature Communications. 10 (1), 3964 (2019).</li><li>Gibbings, S. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Three+unique+interstitial+macrophages+in+the+murine+lung+at+steady+state.">Three unique interstitial macrophages in the murine lung at steady state.</a> American Journal of Respiratory Cell and Molecular Biology. 57 (1), 66-76 (2017).</li><li>Ural, B. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Identification+of+a+nerve-associated,+lung-resident+interstitial+macrophage+subset+with+distinct+localization+and+immunoregulatory+properties.">Identification of a nerve-associated, lung-resident interstitial macrophage subset with distinct localization and immunoregulatory properties.</a> Science Immunology. 5 (45), 8756 (2020).</li><li>Chakarov, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Two+distinct+interstitial+macrophage+populations+coexist+across+tissues+in+specific+subtissular+niches.">Two distinct interstitial macrophage populations coexist across tissues in specific subtissular niches.</a> Science. 363 (6432), (2019).</li><li>Liegeois, M., Legrand, C., Desmet, C. J., Marichal, T., Bureau, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+interstitial+macrophage:+A+long-neglected+piece+in+the+puzzle+of+lung+immunity.">The interstitial macrophage: A long-neglected piece in the puzzle of lung immunity.</a> Cellular Immunology. 330, 91-96 (2018).</li><li>Stouch, A. N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=IkappaB+kinase+activity+drives+fetal+lung+macrophage+maturation+along+a+non-M1/M2+paradigm.">IkappaB kinase activity drives fetal lung macrophage maturation along a non-M1/M2 paradigm.</a> Journal of Immunology. 193 (3), 1184-1193 (2014).</li><li>Kopf, M., Schneider, C., Nobs, S. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+development+and+function+of+lung-resident+macrophages+and+dendritic+cells.">The development and function of lung-resident macrophages and dendritic cells.</a> Nature Immunology. 16 (1), 36-44 (2015).</li><li>Plantinga, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Conventional+and+monocyte-derived+CD11b(+)+dendritic+cells+initiate+and+maintain+T+helper+2+cell-mediated+immunity+to+house+dust+mite+allergen.">Conventional and monocyte-derived CD11b(+) dendritic cells initiate and maintain T helper 2 cell-mediated immunity to house dust mite allergen.</a> Immunity. 38 (2), 322-335 (2013).</li><li>Liu, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dendritic+cell+trafficking+and+function+in+rare+lung+diseases.">Dendritic cell trafficking and function in rare lung diseases.</a> American Journal of Respiratory Cell and Molecular Biology. 57 (4), 393-402 (2017).</li><li>Cook, P. C., MacDonald, A. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dendritic+cells+in+lung+immunopathology.">Dendritic cells in lung immunopathology.</a> Seminars in Immunopathology. 38, 449-460 (2016).</li><li>Guilliams, M., Lambrecht, B. N., Hammad, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Division+of+labor+between+lung+dendritic+cells+and+macrophages+in+the+defense+against+pulmonary+infections.">Division of labor between lung dendritic cells and macrophages in the defense against pulmonary infections.</a> Mucosal Immunology. 6 (3), 464-473 (2013).</li><li>Nobs, S. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=PPAR&#947;+in+dendritic+cells+and+T+cells+drives+pathogenic+type-2+effector+responses+in+lung+inflammation.">PPAR&#947; in dendritic cells and T cells drives pathogenic type-2 effector responses in lung inflammation.</a> Journal of Experimental Medicine. 214 (10), 3015-3035 (2017).</li><li>Aegerter, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Influenza-induced+monocyte-derived+alveolar+macrophages+confer+prolonged+antibacterial+protection.">Influenza-induced monocyte-derived alveolar macrophages confer prolonged antibacterial protection.</a> Nature Immunology. 21 (2), 145-157 (2020).</li><li>Misharin, A. V., Morales-Nebreda, L., Mutlu, G. M., Budinger, G. R., Perlman, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Flow+cytometric+analysis+of+macrophages+and+dendritic+cell+subsets+in+the+mouse+lung.">Flow cytometric analysis of macrophages and dendritic cell subsets in the mouse lung.</a> American Journal of Respiratory Cell and Molecular Biology. 49 (4), 503-510 (2013).</li><li>Hoffmann, F. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Distribution+and+interaction+of+murine+pulmonary+phagocytes+in+the+naive+and+allergic+lung.">Distribution and interaction of murine pulmonary phagocytes in the naive and allergic lung.</a> Frontiers in Immunology. 9, 1046 (2018).</li><li>Yu, Y. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+protocol+for+the+comprehensive+flow+cytometric+analysis+of+immune+cells+in+normal+and+inflamed+murine+non-lymphoid+tissues.">A protocol for the comprehensive flow cytometric analysis of immune cells in normal and inflamed murine non-lymphoid tissues.</a> PLoS One. 11 (3), 0150606 (2016).</li><li>Mesnil, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lung-resident+eosinophils+represent+a+distinct+regulatory+eosinophil+subset.">Lung-resident eosinophils represent a distinct regulatory eosinophil subset.</a> Journal of Clinical Investigation. 126 (9), 3279-3295 (2016).</li><li>Zaynagetdinov, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Identification+of+myeloid+cell+subsets+in+murine+lungs+using+flow+cytometry.">Identification of myeloid cell subsets in murine lungs using flow cytometry.</a> American Journal of Respiratory Cell and Molecular Biology. 49 (2), 180-189 (2013).</li><li>Tavares, A. H., Colby, J. K., Levy, B. D., Abdulnour, R. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+model+of+self-limited+acute+lung+injury+by+unilateral+intra-bronchial+acid+instillation.">A model of self-limited acute lung injury by unilateral intra-bronchial acid instillation.</a> Journal of Visualized Experiments: JoVE. (150), e60024 (2019).</li><li>Kreisel, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+vivo+two-photon+imaging+reveals+monocyte-dependent+neutrophil+extravasation+during+pulmonary+inflammation.">In vivo two-photon imaging reveals monocyte-dependent neutrophil extravasation during pulmonary inflammation.</a> Proceedings of the National Academy of Sciences of the United States of America. 107 (42), 18073-18078 (2010).</li><li>Krishnamoorthy, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neutrophil+cytoplasts+induce+TH17+differentiation+and+skew+inflammation+toward+neutrophilia+in+severe+asthma.">Neutrophil cytoplasts induce TH17 differentiation and skew inflammation toward neutrophilia in severe asthma.</a> Science Immunology. 3 (26), (2018).</li><li>Ascon, D. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Normal+mouse+kidneys+contain+activated+and+CD3+CD4-+CD8-+double-negative+T+lymphocytes+with+a+distinct+TCR+repertoire.">Normal mouse kidneys contain activated and CD3+CD4- CD8- double-negative T lymphocytes with a distinct TCR repertoire.</a> Journal of Leukocyte Biology. 84 (6), 1400-1409 (2008).</li><li>Wang, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lung+natural+killer+cells+in+mice:+phenotype+and+response+to+respiratory+infection.">Lung natural killer cells in mice: phenotype and response to respiratory infection.</a> Immunology. 137 (1), 37-47 (2012).</li><li>Cowley, S. C., Meierovics, A. I., Frelinger, J. A., Iwakura, Y., Elkins, K. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lung+CD4-CD8-+double-negative+T+cells+are+prominent+producers+of+IL-17A+and+IFN-gamma+during+primary+respiratory+murine+infection+with+Francisella+tularensis+live+vaccine+strain.">Lung CD4-CD8- double-negative T cells are prominent producers of IL-17A and IFN-gamma during primary respiratory murine infection with Francisella tularensis live vaccine strain.</a> Journal of Immunology. 184 (10), 5791-5801 (2010).</li><li>Gibbings, S. L., Jakubzick, C. V., Alper, S., Janssen, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Isolation+and+characterization+of+mononuclear+phagocytes+in+the+mouse+lung+and+lymph+nodes.+In+Lung+innate+immunity+and+inflammation.">Isolation and characterization of mononuclear phagocytes in the mouse lung and lymph nodes. In Lung innate immunity and inflammation.</a> Methods in Molecular Biology. 1809, (2018).</li><li>Singer, B. D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Flow-cytometric+method+for+simultaneous+analysis+of+mouse+lung+epithelial,+endothelial,+and+hematopoietic+lineage+cells.">Flow-cytometric method for simultaneous analysis of mouse lung epithelial, endothelial, and hematopoietic lineage cells.</a> American Journal of Physiology. Lung Cellular and Molecular Physiology. 310 (9), 796-801 (2016).</li><li>Matsushima, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CD248+and+integrin+alpha-8+are+candidate+markers+for+differentiating+lung+fibroblast+subtypes.">CD248 and integrin alpha-8 are candidate markers for differentiating lung fibroblast subtypes.</a> BMC Pulmonary Medicine. 20 (1), 21 (2020).</li><li>Cong, J., Wei, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Natural+killer+cells+in+the+lungs.">Natural killer cells in the lungs.</a> Frontiers in Immunology. 10, 1416 (2019).</li><li>Daubeuf, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+fast,+easy,+and+customizable+eight-color+flow+cytometric+method+for+analysis+of+the+cellular+content+of+bronchoalveolar+lavage+fluid+in+the+mouse.">A fast, easy, and customizable eight-color flow cytometric method for analysis of the cellular content of bronchoalveolar lavage fluid in the mouse.</a> Current Protocols in Mouse Biology. 7 (2), 88-99 (2017).</li><li>Yi, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Eosinophil+recruitment+is+dynamically+regulated+by+interplay+among+lung+dendritic+cell+subsets+after+allergen+challenge.">Eosinophil recruitment is dynamically regulated by interplay among lung dendritic cell subsets after allergen challenge.</a> Nature Communications. 9 (1), 3879 (2018).</li><li>Langlet, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CD64+expression+distinguishes+monocyte-derived+and+conventional+dendritic+cells+and+reveals+their+distinct+role+during+intramuscular+immunization.">CD64 expression distinguishes monocyte-derived and conventional dendritic cells and reveals their distinct role during intramuscular immunization.</a> Journal of Immunology. 188 (4), 1751-1760 (2012).</li><li>Moran, T. P., Nakano, H., Kondilis-Mangum, H. D., Wade, P. A., Cook, D. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Epigenetic+control+of+Ccr7+expression+in+distinct+lineages+of+lung+dendritic+cells.">Epigenetic control of Ccr7 expression in distinct lineages of lung dendritic cells.</a> Journal of Immunology. 193 (10), 4904-4913 (2014).</li><li>Schyns, J., Bureau, F., Marichal, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lung+interstitial+macrophages:+past,+present,+and+future.">Lung interstitial macrophages: past, present, and future.</a> Journal of Immunology Research. 2018, 5160794 (2018).</li><li>Krljanac, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=RELMalpha-expressing+macrophages+protect+against+fatal+lung+damage+and+reduce+parasite+burden+during+helminth+infection.">RELMalpha-expressing macrophages protect against fatal lung damage and reduce parasite burden during helminth infection.</a> Science Immunology. 4 (35), (2019).</li><li>Ginhoux, F., Guilliams, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tissue-resident+macrophage+ontogeny+and+homeostasis.">Tissue-resident macrophage ontogeny and homeostasis.</a> Immunity. 44 (3), 439-449 (2016).</li><li>Svedberg, F. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+lung+environment+controls+alveolar+macrophage+metabolism+and+responsiveness+in+type+2+inflammation.">The lung environment controls alveolar macrophage metabolism and responsiveness in type 2 inflammation.</a> Nature Immunology. 20 (5), 571-580 (2019).</li><li>Yona, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fate+mapping+reveals+origins+and+dynamics+of+monocytes+and+tissue+macrophages+under+homeostasis.">Fate mapping reveals origins and dynamics of monocytes and tissue macrophages under homeostasis.</a> Immunity. 38 (1), 79-91 (2013).</li><li>Misharin, A. V., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Monocyte-derived+alveolar+macrophages+drive+lung+fibrosis+and+persist+in+the+lung+over+the+life+span.">Monocyte-derived alveolar macrophages drive lung fibrosis and persist in the lung over the life span.</a> Journal of Experimental Medicine. 214 (8), 2387-2404 (2017).</li><li>Koch, C. M., Chiu, S. F., Misharin, A. V., Ridge, K. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lung+Interstitial+Macrophages:+Establishing+Identity+and+Uncovering+Heterogeneity.">Lung Interstitial Macrophages: Establishing Identity and Uncovering Heterogeneity.</a> American Journal of Respiratory Cell and Molecular Biology. 57 (1), 7-9 (2017).</li></ol>

V.A.B. has patents on the PD-1 pathway licensed by Bristol-Myers Squibb, Roche, Merck, EMD-Serono, Boehringer Ingelheim, AstraZeneca, Novartis, and Dako. The authors declare no other competing financial interests.

Identification of pulmonary immune cells can be challenging because of the multiple immune cell types residing in the lung and their unique immunophenotypic characteristics compared to their counterparts residing in other tissues. In several pathologic conditions, cells with distinct phenotypic features appear in the lungs. For example, bleomycin-induced lung injury results in the recruitment of circulating monocyte-derived macrophages in the alveolar space, where they can remain for as long as one year and even persist ...

The murine respiratory tract contains a unique immune system responsible for fighting pathogens and maintaining immune homeostasis. The pulmonary immune system consists of cellular populations with significant heterogeneity in their phenotype, function, origin, and location. Resident alveolar macrophages (AMs), originated mainly from fetal monocytes, reside in the alveolar lumen1, while bone marrow-derived interstitial macrophages (IMs) reside in the lung parenchyma2. IMs can be further subclassified by the expression of CD206. CD206+ IMs populate the peribronchial and perivascular area, while CD206- IMs are located at the alveolar interstitium3. A few subclassifications of IMs have been proposed recently3,4,5,6. Although IMs are less studied than AMs, recent evidence supports their crucial role in the regulation of the immune system of the lung7. In addition, CD206 is also expressed in alternatively activated AMs8.
Pulmonary dendritic cells (DCs) are another heterogeneous group of lung immune cells with respect to their functional properties, location, and origin. Four subcategories of DCs have been described in the lung: conventional CD103+ DCs (also known as cDC1), conventional CD11b+ DCs (also known as cDC2), monocyte-derived DCs (MoDCs), and plasmacytoid DCs9,10,11,12,13. The first three subclasses can be defined as major histocompatibility complex (MHC) II+CD11c+9,10,14,15. Plasmacytoid DCs express MHC II and are intermediately positive for CD11c but express high levels of B220 and PDCA-19,13,16. In na&#239;ve murine lungs, CD103 DCs and CD11b DCs are located in the airway interstitium, whereas plasmacytoid DCs are located in the alveolar interstitium17.
Two major populations of monocytes reside in the lung during steady state: classical monocytes and non-classical monocytes. Classical monocytes are Ly6C+ and are critical for the initial inflammatory response. In contrast, non-classical monocytes are Ly6C- and have been widely viewed as anti-inflammatory cells3,16,18. Recently, an additional population of CD64+CD16.2+ monocytes was described, which originate from Ly6C- monocytes and give rise to CD206+ IMs3.
Eosinophils mainly appear in the lungs during helminth infection or allergic conditions. However, there is a small number of eosinophils in the pulmonary parenchyma during steady state, known as resident eosinophils. In contrast to the resident eosinophils, inflammatory eosinophils are found in the lung interstitium and bronchoalveolar lavage (BAL). In mouse models of house dust mite (HDM), inflammatory eosinophils are recruited into the lung after antigen-mediated stimulation. It has been proposed that resident eosinophils might have a regulatory role in allergy by inhibiting T helper 2 (Th2) sensitization to HDM19.
In contrast to the rest of pulmonary myeloid cells, neutrophils express Ly6G but not CD68 and are characterized by a signature of the CD68-Ly6G+ immunophenotype16,20,21. Visualization studies have shown that during steady state, the lung reserves a pool of neutrophils in the intravascular compartment and hosts a considerable number of extravascular neutrophils22. Similar to eosinophils, neutrophils are not found in BAL at steady state; however, several forms of immune stimulation, such as LPS challenge, asthma, or pneumonia, drive neutrophils into the alveolar lumen, resulting in their presence in BAL21,22,23.
A substantial number of CD45+ cells of the lung represent natural killer (NK), T cells, and B cells and are negative for most myeloid markers24. In the lungs of na&#239;ve mice, these three cell types can be identified based on the expression of CD11b and MHC II18. Around 25% of pulmonary CD45+ cells are B cells, whereas the percentage of NK cells is higher in the lung than other lymphoid and non-lymphoid tissues24,25,26. Among pulmonary T cells, a considerable fraction is CD4-CD8- and plays an important role in respiratory infections26.
Because the lung hosts a very complex and unique immune system, several gating strategies for the identification of lung immune cells have been developed and reported16,18,20,27. The gating strategy described herein provides a comprehensive and reproducible way to identify up to 12 different pulmonary myeloid and non-myeloid immune populations using 9 markers. Additional markers have been used to validate the results. Furthermore, a detailed method is provided for the preparation of a single-cell suspension that minimizes cell death and allows the identification of the most complete profile of the immune cell compartment of the lung. It should be noted that the identification of non-immune cells of the lung, such as epithelial cells (CD45-CD326+CD31-), endothelial cells (CD45-CD326-CD31+), and fibroblasts requires a different approach28,29. Identification of such populations is not included in the protocol and method described here.

<table><tbody><tr><td>10 mL syringe plunger</td><td>EXELINT</td><td>26265</td><td></td></tr><tr><td>18 G needles</td><td>BD Precision Glide Needle</td><td>305165</td><td></td></tr><tr><td>21 G needles</td><td>BD Precision Glide Needle</td><td>305195</td><td></td></tr><tr><td>50 mL conical tubes</td><td>Falcon</td><td>3520</td><td></td></tr><tr><td>70 &amp;mu;m cell strainer</td><td>ThermoFisher</td><td>22363548</td><td></td></tr><tr><td>96-well plates</td><td>Falcon/corning</td><td>3799</td><td></td></tr><tr><td>ACK Lysing Buffer</td><td>ThermoFisher</td><td>A10492-01</td><td></td></tr><tr><td>anti-mouse CD11b</td><td>Biolegend</td><td>101215</td><td>For details see Table 2</td></tr><tr><td>anti-mouse CD11c</td><td>Biolegend</td><td>117339 / 117337</td><td>For details see Table 2</td></tr><tr><td>anti-mouse CD45</td><td>Biolegend</td><td>103115</td><td>For details see Table 2</td></tr><tr><td>anti-mouse CD64</td><td>Biolegend</td><td>139319</td><td>For details see Table 2</td></tr><tr><td>anti-mouse CD68</td><td>Biolegend</td><td>137009</td><td>For details see Table 2</td></tr><tr><td>anti-mouse GR-1</td><td>Biolegend</td><td>108433</td><td>For details see Table 2</td></tr><tr><td>anti-mouse Siglec F</td><td>Biolegend</td><td>155503</td><td>For details see Table 2</td></tr><tr><td>AVERTIN</td><td>Sigma-Aldrich</td><td>240486</td><td></td></tr><tr><td>B220</td><td>Biolegend</td><td>103228</td><td>For details see Table 2</td></tr><tr><td>Bovine Serum Albumin (BSA)</td><td>Sigma-Aldrich</td><td>9048-46-8</td><td></td></tr><tr><td>CD103</td><td>Biolegend</td><td>121405 / 121419</td><td>For details see Table 2</td></tr><tr><td>CD24</td><td>Biolegend</td><td>138503</td><td>For details see Table 2</td></tr><tr><td>CD3</td><td>Biolegend</td><td>100205</td><td>For details see Table 2</td></tr><tr><td>Centrifuge</td><td></td><td></td><td></td></tr><tr><td>Collagenase Type 1</td><td>Worthington Biochemical Corp</td><td>LS004196</td><td></td></tr><tr><td>CX3CR1</td><td>Biolegend</td><td>149005</td><td>For details see Table 2</td></tr><tr><td>DNase I</td><td>Millipore Sigma</td><td>10104159001</td><td></td></tr><tr><td>Ethanol</td><td></td><td></td><td></td></tr><tr><td>F4/80</td><td>Biolegend</td><td>123133</td><td>For details see Table 2</td></tr><tr><td>FcBlock (CD16/32)</td><td>Biolegend</td><td>101301</td><td>For details see Table 2</td></tr><tr><td>Fetal Bovine Serum</td><td>R&amp;amp;D Systems</td><td></td><td></td></tr><tr><td>Fine Serrated Forceps</td><td>Roboz Surgical Instrument Co</td><td></td><td></td></tr><tr><td>Foxp3 / Transcription Factor Staining Buffer Set</td><td>ThermoFisher</td><td>00-5523-00</td><td></td></tr><tr><td>Futura Safety Scalpel</td><td>Merit Medical Systems</td><td>SMS210</td><td></td></tr><tr><td>Live/Dead Fixable Far Read Dead Cell Stain Kit</td><td>ThermoFisher</td><td>L34973</td><td>For details see Table 2</td></tr><tr><td>MERTK</td><td>Biolegend</td><td>151505</td><td>For details see Table 2</td></tr><tr><td>MHC-II</td><td>Biolegend</td><td>107621</td><td>For details see Table 2</td></tr><tr><td>NK1.1</td><td>Biolegend</td><td>108705</td><td>For details see Table 2</td></tr><tr><td>Orbital Shaker</td><td>VWR</td><td>Model 200</td><td></td></tr><tr><td>Petri dish</td><td>Falcon</td><td>351029</td><td></td></tr><tr><td>Refrigerated benchtop centrifuge</td><td>SORVAL ST 16R</td><td></td><td></td></tr><tr><td>Small curved scissor</td><td>Roboz Surgical Instrument Co</td><td></td><td></td></tr></tbody></table>

flow cytometric analysis for identification of the innate and adaptive immune cells of murine lung

The respiratory tract is in direct contact with the outside environment and requires a precisely regulated immune system to provide protection while suppressing unwanted reactions to environmental antigens. Lungs host several populations of innate and adaptive immune cells that provide immune surveillance but also mediate protective immune responses. These cells, which keep the healthy pulmonary immune system in balance, also participate in several pathological conditions such as asthma, infections, autoimmune diseases, and cancer. Selective expression of surface and intracellular proteins provides unique immunophenotypic properties to the immune cells of the lung. Consequently, flow cytometry has an instrumental role in the identification of such cell populations during steady-state and pathological conditions. This paper presents a protocol that describes a consistent and reproducible method to identify the immune cells that reside in the lungs of healthy mice under steady-state conditions. However, this protocol can also be used to identify changes in these cell populations in various disease models to help identify disease-specific changes in the lung immune landscape.

Gating strategy
The first step of our gating strategy is the exclusion of the debris and doublets (Figure 1A). Careful exclusion of doublets is critical to avoid false-positive populations (Supplemental&#160;Figure S2). Then, immune cells are identified using CD45+, a marker for hematopoietic cells (Figure 1B). The live-dead stain can be added to exclude dead cells. However, this protocol results in the death of...

Watch this Scientific Journal Video about Flow Cytometric Analysis for Identification of the Innate and Adaptive Immune Cells of Murine Lung at JoVE.com

Flow Cytometric Analysis for Identification of the Innate and Adaptive Immune Cells of Murine Lung

In this study, we present an effective and reproducible protocol to isolate the immune populations of the murine respiratory system. We also provide a method for the identification of all innate and adaptive immune cells that reside in the lungs of healthy mice, using a 9-color-based flow cytometry panel.

The respiratory tract is in direct contact with the outside environment and requires a precisely regulated immune system to provide protection while ...
