The work was supported by the National Science Foundation (IOS-1901566) to S. Xiao. The authors would like to thank F. Coker and C. Hooks for the maintenance of the plant growth facility, and Jorge Zamora for technical help associated with fabrication of the inoculation box and chamber.

1. Making a standard inoculation box with a removable top lid mounted with a mesh
<ol>
	<li>Purchase a roll of 50 &#181;m nylon membrane mesh or 48 &#181;m stainless steel mesh (recommended) from stores. Make sure to order enough for cutting into multiple pieces of 14 in x 26 in for replacement of worn mesh.</li>
	<li>Purchase one 1/4 in x 2 ft x 4 ft medium density fiberboard or plywood, and cut two 24-1/2 in x 10 in pieces and two 12 in x 10 in pieces for making an inoculation box.Use 8 corner clamps for supporting the four sides.
	NOTE: If facing the broad side of the enclosure, the left 12 in x 10 in side is attached permanently and the right 12 in x 10 in side is a removable door held in place by four magnetic catches (Figure 1A,B).</li>
	<li>Place four 2-in corner braces two in each inside corner of the left side, an inch from the top and an inch from the bottom, mark and drill a hole. Use screws to permanently attach the left short side to two long sides (front and back). The inner distance between the two long sides should be 12 in and not 11-1/2 in.</li>
	<li>With the corner clamps still in place and proper alignment of the right door, mark and drill the location of the 4 magnetic catches to hold the right detachable door in place. Install a button knob to the door. The top of the door catches under the top lid (Figure 1A,B).</li>
	<li>To make a removable top lid with a mesh, cut the long wooden square dowel into 2 sets of 26 in and 12-3/4 in. Glue and nail the four pieces in such a way that it will fit around the box - the inside dimensions of the frame being a little bigger than the outside dimensions of the box, as the screen mesh will be attached to this frame.</li>
	<li>Cut the screen mesh to a little less than 14 in x 26 in. Do not allow the screen to protrude past the frame so as to prevent sharp edges. Have assistance to stretch the screen on the frame. Hold the mesh with the frame by clamps (Figure 1C) and use a stapler gun with the right staples to secure the screen to the frame.</li>
	<li>Cut two sets of shorter wooden square dowel (21 in and 9 in), and use screws to tightly sandwich the mesh along the frame using the 4 shorter pieces of wooden square dowel (Figure 1C, D).</li>
</ol>
2. Making an inoculation chamber
<ol>
	<li>Purchase clear acrylic sheets and hardware items from appropriate stores. Cut a 7 in x 20 in opening window on the front side acrylic sheet of the box as shown in Figure 2C.</li>
	<li>Assemble the left and right sides, front (with window) and rear acrylic sheets into a box using 8 corner clamps as shown in Figure 2A. Ensure that the inner measurements of the chamber are equal to the dimensions of the top sheet.
	NOTE: The right side is there for support and will not be attached to the front or rear sheets. It is &#189; in shorter than the other sheets on purpose. This right side will become a &#34;draw down&#34; &#34;flap&#34; door held in place by a right angle&#160;hinge at the bottom and two magnetic catches at the top as shown in Figure 2C,D.</li>
	<li>Use corner braces to secure the panels together (Figure 2B,C). Hold the braces in place, mark with a sharpie marker, center punch and then drill the hole.
	NOTE: Drilling acrylic is different from drilling anything else, do not force or the side of the hole opposite the drill may crack. Use rivets or screws. Do not overtighten the screws or the acrylic may crack with time.</li>
	<li>Turn the enclosure on its rear side and remove the 4 corner clamps and position the top sheet in place. Mark and drill.</li>
	<li>Install the right angle hinge, made out of a &#190; in angle brace. Use a nylon retaining lock nut as a hinge rod. Do not tighten, leave a gap so the door will rotate on this hinge.</li>
	<li>Mark, center punch, drill and attach the two magnetic door magnets with #6-32x3/4&#34; pan head screws. Then attach the catch plates with #6-32x3/8&#34; flat head screws, see Figure 2C,D.</li>
</ol>
3. Inoculating plants in flats
<ol>
	<li>Prepare fresh powdery mildew spores as inocula (e.g., Arabidopsis powdery mildew Golovinomyces cichoracearum UCSC1). Grow clean Arabidopsis immune-compromised pad4-1 mutant plants 11 in a growth chamber (22 &#176;C, 65% relative humidity for 6-8 weeks), and inoculate one or half flat of pad4-1 plants to build up sufficient fresh powdery mildew spores (Figure 3A).</li>
	<li>Grow the plants for determining infection phenotypes in standard 11 in x 21 in x 2.5 in flats.
	NOTE: Arabidopsis plants grown under short-day (8 h light, 16 h dark; 22 &#176;C) for six to eight weeks are good for infection tests with powdery mildew.</li>
	<li>When fresh powdery mildew spores from infected plants at 8-10 days post-inoculation (dpi) are available, move a flat of plants for infection test into the inoculation box inside the inoculation chamber (Figure 1B,2C).</li>
	<li>Cut 15-20 heavily infected Arabidopsis leaves (or 4-6 infected rosettes, depending on the leaf/rosette size and level of inoculation), let the leaves dry if there is condensed water.</li>
	<li>Grab 1-2 leaves or a rosette with a pair of long forceps using one hand and face the leaves upside down. Then, put both hands through the opening of the chamber and gently hit the arm of the forceps with a pair of scissors while slowly moving the leaves/rosette above the mesh mounted on the inoculation box (Figure 3B). Repeat this until all the leaves or rosettes are used.
	NOTE: Mature spores will dislodge easily from conidiophores of the infected leaves. Try to dislodge spores on the mesh as evenly as possible.</li>
	<li>Use one or two fine fan-blender brushes to gently brush the spores through the mesh (Figure 3C). Ensure to brush the entire surface of the mesh in different directions for four or more times to maximize even distribution of spores onto the plants in the bottom of the inoculation box (Figure 3D). Gently pat the mesh for a few times with the brushes to shake off the spores that are stuck in the mesh.</li>
	<li>Let the spores settle down for half a minute. Then, move out the flat containing the inoculated plants from the inoculation box. Cover the flat with a plastic dome and place it in a growth chamber (22 &#176;C, 65% relative humidity). Disease phenotyping can be performed at 5, or 8 to 12 dpi 12.</li>
</ol>
4. Inoculate plants with smaller inoculation boxes
NOTE: In cases where fewer plants are to be inoculated, the standard inoculation box can still be used. Make sure to place the plants in the middle of the box. Dislodge and brush spores in the area of the mesh that covers the plants to ensure all plants are inoculated while saving inocula. Alternatively, and preferably, smaller inoculation boxes can be used (as described below).
<ol>
	<li>Convert cardboard boxes to an inoculation box. Simply remove the top and bottom sides of the box, tape the corner to firm it if necessary, and mount a suitably sized 50 &#181;m mesh on the top by gluing or stapling (Figure&#160;4A,B).</li>
	<li>Move the flat containing the plants inside the inoculation chamber, place the smaller inoculation box on top of the flat to cover the plants.</li>
	<li>Dislodge and brush spores as described above.</li>
</ol>
5. Inoculate detached leaves in Petri dishes
NOTE: In cases where (i) fresh powdery mildew spores are very limited and/or (ii) plants must be kept clean while disease phenotypes and/or protein subcellular localization in infected cells need to be assessed, detached leaves can be used for infection in MS-agar plates.
<ol>
	<li>Make a mini inoculation box that is only slightly bigger than a Petri dish.</li>
	<li>Prepare &#189;-strength Murashige and Skoog (MS) medium agar (1.5%) plates. Add thiabendazole (40 mg/L) to reduce mold contamination if required. Store the plates at 4 &#176;C in a fridge until use.</li>
	<li>Cut one or two fully expanded leaves from the base of the petiole for each individual plant to be tested. Insert the petiole of the detached leaves into agar medium at an angle of ~30&#176;.
	NOTE: Each plate can contain 20-40 leaves depending on the size of the leaves and the plate used (Figure 4C).</li>
	<li>Inoculate the leaves inside the inoculation chamber as described above. Move the plate with the lid to a growth chamber.</li>
	<li>Cut a small section of a leaf and check the subcellular localization of proteins at specific time-points.</li>
	<li>For assessing infection phenotypes, transfer the leaves to a fresh aseptic MS-agar plate at 4 or 5 dpi. Cut the base of the petiole before inserting the leaves into the fresh agar medium. Assess the disease phenotypes at 8 or 9 dpi.</li>
</ol>

<ol>
	<li>Huckelhoven, R., Panstruga, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cell+bi+ology+of+the+plant-powdery+mildew+interaction.">Cell bi ology of the plant-powdery mildew interaction.</a> Current Opinion in Plant Biology. 14 (6), 738-746 (2011).</li><li>Dean, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+top+10+fungal+pathogens+in+molecular+plant+pathology.">The top 10 fungal pathogens in molecular plant pathology.</a> Molecular Plant Pathology. 13 (4), 414-430 (2012).</li><li>Sakurai, H., Hirata, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Some+observations+on+the+relation+between+the+penetration+hypha+and+haustorium+of+barley+powdery+mildew+and+host+cell.+V.+Influence+of+water+spray+on+the+pathogen+and+host+tissue.">Some observations on the relation between the penetration hypha and haustorium of barley powdery mildew and host cell. V. Influence of water spray on the pathogen and host tissue.</a> Annual Phytopathology Society of Japan. 24, 239-245 (1959).</li><li>Shomari, S. H., Kennedy, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Survival+of+Oidium+anacardii+on+cashew+(Anacardium+occidentale)+in+southern+Tanzania.">Survival of Oidium anacardii on cashew (Anacardium occidentale) in southern Tanzania.</a> Plant Pathology. 48 (4), 505-513 (1999).</li><li>Sitterly, W. R., Spencer, D. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Powdery Mildews. , 369 (1978).</li><li>Reuveni, M., Agapov, V., Reuveni, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Induction+of+systemic+resistance+to+powdery+mildew+and+growth+increase+in+cucumber+by+phosphates.">Induction of systemic resistance to powdery mildew and growth increase in cucumber by phosphates.</a> Biological Agriculture &amp; Horticulture. 9 (4), 305-315 (1993).</li><li>Reifschneider, F. J. B., Boiteux, L. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+vacuum-operated+settling+tower+for+inoculation+of+powdery+mildew+fungi.">A vacuum-operated settling tower for inoculation of powdery mildew fungi.</a> Phytopathology. 78 (11), 1463-1465 (1988).</li><li>Chowdhury, A., Bremer, G. B., Salt, D. W., Miller, P., Ford, M. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+novel+method+of+delivering+Blumeria+graminis+f.+sp+hordei+spores+for+laboratory+experiments.">A novel method of delivering Blumeria graminis f. sp hordei spores for laboratory experiments.</a> Crop Protection. 22 (7), 917-922 (2003).</li><li>Xiao, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Broad-spectrum+mildew+resistance+in+Arabidopsis+thaliana+mediated+by+RPW8.">Broad-spectrum mildew resistance in Arabidopsis thaliana mediated by RPW8.</a> Science. 291 (5501), 118-120 (2001).</li><li>Xiao, S., Ellwood, S., Findlay, K., Oliver, R. P., Turner, J. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Characterization+of+three+loci+controlling+resistance+of+Arabidopsis+thaliana+accession+Ms-0+to+two+powdery+mildew+diseases.">Characterization of three loci controlling resistance of Arabidopsis thaliana accession Ms-0 to two powdery mildew diseases.</a> The Plant Journal. 12 (4), 757-768 (1997).</li><li>Reuber, T. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Correlation+of+defense+gene+induction+defects+with+powdery+mildew+susceptibility+in+Arabidopsis+enhanced+disease+susceptibility+mutants.">Correlation of defense gene induction defects with powdery mildew susceptibility in Arabidopsis enhanced disease susceptibility mutants.</a> The Plant Journal. 16 (4), 473-485 (1998).</li><li>Xiao, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+atypical+resistance+gene,+RPW8,+recruits+components+of+basal+defence+for+powdery+mildew+resistance+in+Arabidopsis.">The atypical resistance gene, RPW8, recruits components of basal defence for powdery mildew resistance in Arabidopsis.</a> The Plant Journal. 42 (1), 95-110 (2005).</li></ol>

The authors have nothing to disclose.

Our meshed-box-based inoculation method has several advantages over other inoculation methods. First, it can achieve even distribution of spores if operated properly, as demonstrated in Figure 5. Second, the use of ~50 &#181;m mesh, plus spore-dislodging by gentle shaking of infected leaves can reduce plant infection by thrips or other plant-infecting insects that are present in source plants. Third, the use of different-sized inoculation boxes for inoculating plants or detached leaves insid...

Powdery mildew is one of the most common and important diseases of numerous food crops and ornamental plants1. Studies of powdery mildew diseases have been very popular, as evidenced by over 10,500 publications as the search result with "powdery mildew" as key word at the Web of Science (as of November 2020). Indeed, powdery mildew (represented by Blumeria graminis) is considered to be one of the top 10 fungal pathogens by the journal of Molecular Plant Pathology2. Quantification of disease susceptibility is a necessary step in characterization of plant genes contributing to disease resistance or susceptibility, or functional identification of candidate effector genes in powdery mildew. However, reliable disease phenotyping is far more challenging with powdery mildew compared to that with most other fungal pathogens, partly because, unlike spores of the latter, spores of powdery mildew species (such as Golovinomyces cichoracearum UCSC1 based on our lab experience) show reduced viability after going through a water-suspension process3,4. Inadequate and/or uneven inoculation of test plants with a particular powdery mildew pathogen may lead to inaccurate phenotyping results.
A number of inoculation methods were reported for powdery mildew studies. These include (i) brushing spores directly from infected leaves to test plants5, (ii) spraying a spore suspension to test plants6, (iii) blowing spores using a vacuum-operated settling tower to plants at the bottom of the tower7, and (iv) spore delivery by the combinatorial use of a nylon mesh membrane and sound-based vibration8. The spore-brushing (or dusting) method is easy to perform but uneven in nature, thus it may not be accurate for quantitative assessment. Spore-spraying is convenient and even, but as stated above may result in poor spore germination4. The latter two (i.e., iii-iv) are much-improved methods capable of achieving even inoculation; however, both are not flexible in adjusting their inoculation capacity in terms of the number of plants to be inoculated in a single event, making either apparatus is not trivial, and their operation is restricted to lab areas where there is a vacuum and/or electricity source.
Our lab has been working with plant-powdery mildew interaction for over 20 years9,10. Over the past decade, we tested a number of inoculation methods and recently developed a simple and yet effective powdery mildew inoculation method. This mesh-based spore-brushing method can ensure even inoculation, and is simple and scalable, thus should be easily adopted by any laboratory working with powdery mildew.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr >
			<td >&#160;48 &#181;m stainless steel grid mesh screen; Size: 24&#34; X 48&#34;&#160;</td>
			<td >Amazon</td>
			<td >NA</td>
			<td >For making the lid of an inoculation box</td>
		</tr>
		<tr >
			<td >#6-32 x &#190;&#34; machine screws, flat washers and nuts&#160;</td>
			<td >Home Depot</td>
			<td >NA</td>
			<td>For making an inoculation chamber</td>
		</tr>
		<tr >
			<td >#6-32 zinc plated nylon lock nut (4-Pack)</td>
			<td >Home Depot</td>
			<td >NA</td>
			<td>For making an inoculation chamber</td>
		</tr>
		<tr >
			<td >#6-32x3/8&#8221; Phillips flat head machine screws, flat washers and nuts&#160;</td>
			<td >Home Depot</td>
			<td >NA</td>
			<td>For securing&#160; magnet door catch plates</td>
		</tr>
		<tr >
			<td >#8-32x1/2&#34; machine screws, flat washers and nuts</td>
			<td >Home Depot</td>
			<td >NA</td>
			<td>For securing corner braces and door hinge</td>
		</tr>
		<tr >
			<td >0.250 thick clear extruded acrylic film-masked sheet;&#160; Size: 17 &#189;&#34; X 20&#34;</td>
			<td >Professional Plastics</td>
			<td >SACR.250CEF</td>
			<td>For making an inoculation chamber</td>
		</tr>
		<tr >
			<td >0.250 thick clear extruded acrylic film-masked sheet; Size: 18&#34; X 20&#34;&#160;&#160;</td>
			<td >Professional Plastics</td>
			<td >&#160;SACR.250CEF</td>
			<td>For making an inoculation chamber</td>
		</tr>
		<tr >
			<td >0.250 thick clear extruded acrylic film-masked sheet; Size: 18&#34; X 30&#34;&#160;</td>
			<td >Professional Plastics</td>
			<td >SACR.250CEF</td>
			<td>For making an inoculation chamber</td>
		</tr>
		<tr >
			<td >0.250 thick clear extruded acrylic film-masked sheet; Size: 20&#34; X 29 &#189; &#34;</td>
			<td >Professional Plastics</td>
			<td >SACR.250CEF</td>
			<td>For making an inoculation chamber</td>
		</tr>
		<tr >
			<td >1-5/8&#34; cabinet door magnetic catch white</td>
			<td >Home Depot</td>
			<td >Model #P110-W</td>
			<td>For making an inoculation chamber</td>
		</tr>
		<tr >
			<td >2&#34; steel zinc-plated corner brace (8-Pack)&#160;</td>
			<td >Home Depot</td>
			<td >&#160;Model #13611&#160;</td>
			<td>For making an inoculation box &#38; chamber</td>
		</tr>
		<tr >
			<td >3&#34; Corner Clamp</td>
			<td>Harbor Freight Tools</td>
			<td>SKU 63653, 1852, 60589</td>
			<td>For making inoculation chamber</td>
		</tr>
		<tr >
			<td >3/4&#34;&#160; steel zinc plated corner brace (4-Pack)</td>
			<td >Home Depot</td>
			<td >Model #13542</td>
			<td>For making an inoculation box &#38; chamber</td>
		</tr>
		<tr >
			<td >4-7/8&#34; zinc-plated light duty door pull handles</td>
			<td >Home Depot</td>
			<td >Model #15184</td>
			<td>For making an inoculation box</td>
		</tr>
		<tr >
			<td >Fine fan-blender brushes</td>
			<td>Michaels Store</td>
			<td>M10472846&#160;</td>
			<td>For inoculation</td>
		</tr>
		<tr >
			<td >Kelleher 3/4&#34; x 3/4&#34; x 36&#34; wood square dowel&#160;</td>
			<td >Home Depot</td>
			<td >NA</td>
			<td>For making the lid of an inoculation box</td>
		</tr>
		<tr >
			<td >Medium density fiberboard (1/4&#34; x 2&#39; x 4&#39;);&#160;</td>
			<td >Home Depot</td>
			<td >Model# 1508104</td>
			<td>For making an inoculation box</td>
		</tr>
		<tr >
			<td >Round glass coverslips with a 500 &#181;m grid</td>
			<td >ibidi USA Inc.</td>
			<td >10816</td>
			<td>For determining&#160; spore density</td>
		</tr>
	</tbody>
</table>

an easy and flexible inoculation method for accurately assessing powdery mildew-infection phenotypes of arabidopsis and other plants

Reducing crop losses due to fungal diseases requires improved understanding of the mechanisms governing plant immunity and fungal pathogenesis, which in turn requires accurate determination of disease phenotypes of plants upon infection with a particular fungal pathogen. However, accurate disease phenotyping with unculturable biotrophic fungal pathogens such as powdery mildew is not easy to achieve and can be a rate-limiting step of a research project. Here, we have developed a safe, efficient, and easy-to-operate disease phenotyping system using the Arabidopsis-powdery mildew interaction as an example. This system mainly consists of three components: (i) a wooden inoculation box fitted with a removable lid mounted with a stainless steel or nylon mesh of ~50 &#181;m pores for inoculating a flat of plants with fungal spores, (ii) a transparent plastic chamber with a small front opening for minimizing spore escape while conducting inoculation inside, and (iii) a spore-dislodging and distribution method for even and effective inoculation. The protocols described here include the steps and parameters for making the inoculation box and the plastic chamber at a low cost, and a video demonstration of how to use the system to enable even inoculation with powdery mildew spores, thereby improving accuracy and reproducibility of disease phenotyping.

Here, we present a new powdery mildew spore inoculation method that is easy to prepare, operate and adjust. Figure 1 shows the assembly of the standard inoculation box with emphasis on the make of the removable lid mounted with a 50 &#181;m membrane mesh. Figure 2 shows the assembly of the inoculation chamber. Figure 3 illustrates the key steps of the inoculation process using this system. Figure 4 show...

Watch this Scientific Journal Video about An Easy and Flexible Inoculation Method for Accurately Assessing Powdery Mildew-Infection Phenotypes of Arabidopsis and Other Plants at JoVE.com

An Easy and Flexible Inoculation Method for Accurately Assessing Powdery Mildew-Infection Phenotypes of Arabidopsis and Other Plants

We present a protocol for constructing a simple spore-distribution system consisting of an inoculation box with a ~50 &#181;m mesh and a transparent plastic chamber. This can be used to evenly inoculate plants with powdery mildew spores, thereby enabling accurate and reproducible assessment of disease phenotypes of plants under study.

Reducing crop losses due to fungal diseases requires improved understanding of the mechanisms governing plant immunity and fungal pathogenesis, which in ...
