Description: Watch this Scientific Journal Video about Induction of Eryptosis in Red Blood Cells Using a Calcium Ionophore at JoVE.com

This work was supported by NIH grant R15ES030140 and NSF grant CBET1903568. Financial support from the Russ College of Engineering and Technology and the Department of Chemical and Biomolecular Engineering at Ohio University is also acknowledged.

All human blood samples used in the protocol described below were purchased as de-identified samples. No human subjects were directly involved or recruited for this study. The guidelines of the Declaration of Helsinki should be used when research involves human subjects.
1. Erythrocyte isolation from whole blood
<ol>
	<li>Add 500 &#181;L of whole blood in acid citrate dextrose (ACD) (stored at 4 &#176;C) to a microcentrifuge tube.
	NOTE: Whole blood was purchased in ACD. According to the company, 1.5 mL of ACD is added to 7 mL of whole blood (8.5 mL total volume).</li>
	<li>Centrifuge the whole blood at 700 x g for 5 min at room temperature (RT) and remove the clear plasma and the thin buffy coat using a pipette to leave the red erythrocyte layer.</li>
	<li>Prepare 1 L of Ringer solution containing 125 mM NaCl, 5 mM KCl, 1 mM MgSO4, 32 mM HEPES, 5 mM glucose, and 1 mM CaCl2. Adjust the pH to 7.4 by adding 2 &#181;L drops of 1.0 M NaOH. To prepare glucose-free Ringer solution, follow the same protocol, but do not include glucose in the solution.</li>
	<li>Wash the erythrocytes 2x in Ringer solution by suspending the cell pellet in 1.5 mL of Ringer solution, centrifuging at 700 x g for 5 min at RT, and removing the supernatant.</li>
	<li>Make a 0.4% hematocrit by resuspending 40 &#181;L of the erythrocyte pellet in 9,960 &#181;L of glucose-free Ringer solution to reach a final volume of 10 mL.
	NOTE: Hematocrit is a term used to refer to the volume fraction of erythrocytes in suspension. A 0.4% hematocrit is a suspension containing 0.4% erythrocytes.</li>
	<li>Incubate the cell suspension at 37 &#176;C for 7 days.</li>
</ol>
2. Treatment of erythrocytes with ionomycin and measurement of hemolysis
<ol>
	<li>Dissolve 1 mg of ionomycin calcium salt in 630 &#181;L of dimethyl sulfoxide (DMSO) to reach a final concentration of 2 mM. Aliquot and store at -20 &#176;C.</li>
	<li>Take 1 mL of the 0.4% hematocrit from step 1.5 and add 0.5 &#181;L of 2 mM ionomycin to reach a final concentration of 1 &#181;M. Incubate for 2 h at 37 &#176;C.
	<ol>
		<li>Use 1 mL of the hematocrit with no ionomycin treatment as a negative control.</li>
	</ol>
	</li>
	<li>Centrifuge the ionomycin-treated and untreated hematocrits at 700 x g for 5 min at RT, and remove their supernatants to leave the cell pellets at the bottom of the tubes.</li>
	<li>Wash the cells 3x with Ringer solution by suspending the cell pellets in 1.5 mL of Ringer solution, centrifuging at 700 x g for 5 min at RT and discarding the supernatants.</li>
	<li>To measure hemolysis, add 1 mL of the untreated 0.4% hematocrit from step 1.5 to a microcentrifuge tube and incubate for 2 h at 37 &#176;C as the negative control for hemolysis (0%).</li>
	<li>Add 1 mL of the untreated 0.4% hematocrit from step 1.5 to a microcentrifuge tube and centrifuge at 700 x g for 5 min at RT. Remove the supernatant and add 1 mL of distilled water to the cell pellet and incubate for 2 h at 37 &#176;C as the positive control for hemolysis (100%).</li>
	<li>Add 1 mL of the ionomycin-treated 0.4% hematocrit from step 2.2 to a microcentrifuge tube.</li>
	<li>Centrifuge the untreated cells, treated cells, and the cells in distilled water at 700 x g for 5 min at RT.</li>
	<li>Take 200 &#181;L of the supernatants and add to a 96-well plate.</li>
	<li>Measure the absorbance at 541 nm using a microplate reader.</li>
	<li>Calculate the hemolysis using Equation 132:

	%Hemolysis = (AT - A0)/(A100 - A0)*100

	where A0 is the absorbance of erythrocytes in Ringer solution, A100 is the absorbance of erythrocytes in water, and AT is the absorbance of treated erythrocytes by ionomycin.</li>
</ol>
3. Annexin-V binding assay
<ol>
	<li>Dilute 2 mL of the 5x annexin V binding buffer in 8 mL of phosphate-buffered saline (PBS) to obtain 1x binding buffer.</li>
	<li>Resuspend the ionomycin-treated and untreated cell pellets from step 2.4 in 1 mL of 1x binding buffer.</li>
	<li>Take 235 &#181;L of the cell suspensions in the binding buffer and add 15 &#181;L of Annexin V-Alexa Flour 488 conjugate.</li>
	<li>Incubate the cells at RT for 20 min in a dark place. Centrifuge at 700 x g for 5 min at RT and remove the supernatant.</li>
	<li>Wash the cells 2x with 1x binding buffer, by suspending the cell pellet in 1.5 mL of the binding buffer, centrifuging at 700 x g for 5 min at RT and removing the supernatant.</li>
	<li>Resuspend the cell pellets in 250 &#181;L of 1x binding buffer for flow cytometry measurements.</li>
</ol>
4. Flow cytometry
<ol>
	<li>Transfer 200 &#181;L of the annexin-V stained erythrocytes to 1 mL round bottom polystyrene tubes compatible with flow cytometry.</li>
	<li>Login to the flow cytometry software and click on the new experiment button. Click on the new tube button. Select the global sheet and choose the apply analysis to measure the fluorescence intensity with an excitation wavelength of 488 nm and an emission wavelength of 530 nm.</li>
	<li>Set number of cells to 20,000 to be collected for fluorescence-activated cell sorting (FACS) analysis.</li>
	<li>Select the desired tube and click on load button. Click on record button for forward scatter and side scatter measurements. Repeat for all samples.</li>
	<li>Right click on specimen button and click on apply batch analysis to generate the result file.</li>
	<li>Right click on specimen button and click on generate FSC files.</li>
	<li>Add the flow cytometry data (FSC files) into the workplace of flow cytometry software.</li>
	<li>Analyze the control data by selecting the cell population of interest and adding statistics for eryptosis value.
	<ol>
		<li>Double click on control and select histogram versus fluorescence intensity.</li>
		<li>Click on gate button to draw a gate on the histogram which indicates the percentage of eryptosis.</li>
	</ol>
	</li>
	<li>Apply the same statistics for all other experimental tubes to obtain the eryptosis values. Right click on control and select copy analysis to group.</li>
	<li>After properly gating all samples, transfer the analyzed data by dragging and dropping them into the layout editor.
	<ol>
		<li>Overlay the analyzed data with control in layout editor.</li>
		<li>Set the desired histograms and intensities by changing the x and y axis of the overlaid graphs.</li>
		<li>Export image files by clicking on export button and save the graphs in desired location.</li>
	</ol>
	</li>
</ol>
5. Confocal microscopy
<ol>
	<li>Transfer 5 &#181;L of annexin-V-stained cells on a microscope slide and cover it with a cover slip. Keep in a dark place to prevent photobleaching.</li>
	<li>Use Argon laser of the confocal fluorescence microscope to observe the cells excited at 488 nm with desired magnifications.
	NOTE: A confocal microscope is not necessarily needed and any microscope with fluorescence capabilities can be used to obtain fluorescence images that demonstrate annexin-V binding.</li>
	<li>Obtain fluorescence images of the control (non-treated cells) and treated cells.
	NOTE: Non-treated cells are expected to show very weak fluorescence signals, whereas treated cells are expected to show bright green fluorescence on their membranes.</li>
</ol>

<ol>
	<li>Bratosin, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Programmed+Cell+Death+in+Mature+Erythrocytes:+A+Model+for+Investigating+Death+Effector+Pathways+Operating+in+the+Absence+of+Mitochondria.">Programmed Cell Death in Mature Erythrocytes: A Model for Investigating Death Effector Pathways Operating in the Absence of Mitochondria.</a> Cell Death and Differentiation. 8 (12), 1143-1156 (2001).</li><li>Lang, E., Lang, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanisms+and+Pathophysiological+Significance+of+Eryptosis,+the+Suicidal+Erythrocyte+Death.">Mechanisms and Pathophysiological Significance of Eryptosis, the Suicidal Erythrocyte Death.</a> Seminars in Cell and Developmental Biology. 39, 35-42 (2015).</li><li>Garnier, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Erythrocyte+Deformability+in+Diabetes+and+Erythrocyte+Membrane+Lipid+Composition.">Erythrocyte Deformability in Diabetes and Erythrocyte Membrane Lipid Composition.</a> Metabolism. 39 (8), 794-798 (1990).</li><li>Verkleij, A. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Asymmetric+Distribution+of+Phospholipids+in+the+Human+Red+Cell+Membrane.+A+Combined+Study+Using+Phospholipases+and+Freeze-Etch+Electron+Microscopy.">The Asymmetric Distribution of Phospholipids in the Human Red Cell Membrane. A Combined Study Using Phospholipases and Freeze-Etch Electron Microscopy.</a> Biochimica et Biophysica Acta (BBA) Biomembranes. 323 (2), 178-193 (1973).</li><li>de Back, D. Z., Kostova, E. B., van Kraaij, M., van den Berg, T. K., van Bruggen, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Of+Macrophages+and+Red+Blood+Cells;+A+Complex+Love+Story.">Of Macrophages and Red Blood Cells; A Complex Love Story.</a> Frontiers in Physiology. 5, 9 (2014).</li><li>Fadok, V. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+Receptor+for+Phosphatidylserine-Specific+Clearance+of+Apoptotic+Cells.">A Receptor for Phosphatidylserine-Specific Clearance of Apoptotic Cells.</a> Nature. 405 (6782), 85-90 (2000).</li><li>Henson, P. M., Bratton, D. L., Fadok, V. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Phosphatidylserine+Receptor:+A+Crucial+Molecular+Switch.">The Phosphatidylserine Receptor: A Crucial Molecular Switch.</a> Nature Reviews Molecular Cell Biology. 2 (8), 627-633 (2001).</li><li>Messmer, U. K., Pfeilschifter, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=New+Insights+into+the+Mechanism+for+Clearance+of+Apoptotic+Cells.">New Insights into the Mechanism for Clearance of Apoptotic Cells.</a> BioEssays. 22 (10), 878-881 (2000).</li><li>Basu, S., Banerjee, D., Chandra, S., Chakrabarti, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Eryptosis+in+Hereditary+Spherocytosis+and+Thalassemia:+Role+of+Glycoconjugates.">Eryptosis in Hereditary Spherocytosis and Thalassemia: Role of Glycoconjugates.</a> Glycoconjugate Journal. 27 (9), 717-722 (2010).</li><li>Kuypers, F. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Detection+of+Altered+Membrane+Phospholipid+Asymmetry+in+Subpopulations+of+Human+Red+Blood+Cells+Using+Fluorescently+Labeled+Annexin+V.">Detection of Altered Membrane Phospholipid Asymmetry in Subpopulations of Human Red Blood Cells Using Fluorescently Labeled Annexin V.</a> Blood. 87 (3), 1179-1197 (1996).</li><li>Lang, F., Lang, E., Fller, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Physiology+and+Pathophysiology+of+Eryptosis.">Physiology and Pathophysiology of Eryptosis.</a> Transfusion Medicine and Hemotherapy. 39 (5), 308-314 (2012).</li><li>Wr&#243;bel, A., Bobrowska-H&#228;gerstrand, M., Lindqvist, C., H&#228;gerstrand, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Monitoring+of+Membrane+Phospholipid+Scrambling+in+Human+Erythrocytes+and+K562+Cells+with+FM1-43+-+a+Comparison+with+Annexin+V-FITC.">Monitoring of Membrane Phospholipid Scrambling in Human Erythrocytes and K562 Cells with FM1-43 - a Comparison with Annexin V-FITC.</a> Cellular and Molecular Biology Letters. 19 (2), 262-276 (2014).</li><li>Mohandas, N., Gallagher, P. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Red+Cell+Membrane:+Past,+Present,+and+Future.">Red Cell Membrane: Past, Present, and Future.</a> Blood. 112 (10), 3939-3948 (2008).</li><li>Barber, L. A., Palascak, M. B., Joiner, C. H., Franco, R. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Aminophospholipid+Translocase+and+Phospholipid+Scramblase+Activities+in+Sickle+Erythrocyte+Subpopulations.">Aminophospholipid Translocase and Phospholipid Scramblase Activities in Sickle Erythrocyte Subpopulations.</a> British Journal of Haematology. 146 (4), 447-455 (2009).</li><li>Pretorius, E., Du Plooy, J. N., Bester, J. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+Comprehensive+Review+on+Eryptosis.">A Comprehensive Review on Eryptosis.</a> Cellular Physiology and Biochemistry. 39 (5), 1977-2000 (2016).</li><li>Suzuki, J., Umeda, M., Sims, P. J., Nagata, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Calcium-Dependent+Phospholipid+Scrambling+by+TMEM16F.">Calcium-Dependent Phospholipid Scrambling by TMEM16F.</a> Nature. 468 (7325), 834-838 (2010).</li><li>Bhuyan, A. A. M., Haque, A. A., Sahu, I., Coa, H., Kormann, M. S. D., Lang, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Inhibition+of+Suicidal+Erythrocyte+Death+by+Volasertib.">Inhibition of Suicidal Erythrocyte Death by Volasertib.</a> Cellular Physiology and Biochemistry. 43 (4), 1472-1486 (2017).</li><li>Chandra, R., Joshi, P. C., Bajpai, V. K., Gupta, C. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Membrane+Phospholipid+Organization+in+Calcium-Loaded+Human+Erythrocytes.">Membrane Phospholipid Organization in Calcium-Loaded Human Erythrocytes.</a> Biochimica et Biophysica Acta. 902 (2), 253-262 (1987).</li><li>Alzoubi, K., Calabr&#242;, S., Egler, J., Faggio, C., Lang, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Triggering+of+Programmed+Erythrocyte+Death+by+Alantolactone.">Triggering of Programmed Erythrocyte Death by Alantolactone.</a> Toxins (Basel). 6 (12), 3596-3612 (2014).</li><li>Jacobi, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stimulation+of+Erythrocyte+Cell+Membrane+Scrambling+by+Mitotane.">Stimulation of Erythrocyte Cell Membrane Scrambling by Mitotane.</a> Cellular Physiology and Biochemistry. 4 (33), 1516-1526 (2014).</li><li>Totino, P. R. R., Daniel-Ribeiro, C. T., Ferreira-da-Cru, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Refractoriness+of+Eryptotic+Red+Blood+Cells+to+Plasmodium+Falciparum+Infection:+A+Putative+Host+Defense+Mechanism+Limiting+Parasitaemia.">Refractoriness of Eryptotic Red Blood Cells to Plasmodium Falciparum Infection: A Putative Host Defense Mechanism Limiting Parasitaemia.</a> PLoS One. 6 (10), e26575 (2011).</li><li>Borst, O., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamic+Adhesion+of+Eryptotic+Erythrocytes+to+Endothelial+Cells+via+CXCL16/SR-PSOX.">Dynamic Adhesion of Eryptotic Erythrocytes to Endothelial Cells via CXCL16/SR-PSOX.</a> American Journal of Physiology - Cell Physiology. 302 (4), C644-C651 (2011).</li><li>Tagami, T., Yanai, H., Terada, Y., Ozeki, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evaluation+of+Phosphatidylserine-Specific+Peptide-Conjugated+Liposomes+Using+a+Model+System+of+Malaria-Infected+Erythrocytes.">Evaluation of Phosphatidylserine-Specific Peptide-Conjugated Liposomes Using a Model System of Malaria-Infected Erythrocytes.</a> Biological and Pharmaceutical Bulletin. 38 (10), 1649-1651 (2015).</li><li>Mahmud, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Suicidal+Erythrocyte+Death,+Eryptosis,+as+a+Novel+Mechanism+in+Heart+Failure-Associated+Anaemia.">Suicidal Erythrocyte Death, Eryptosis, as a Novel Mechanism in Heart Failure-Associated Anaemia.</a> Cardiovascular Research. 98 (1), 37-46 (2013).</li><li>Signoretto, E., Castagna, M., Lang, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stimulation+of+Eryptosis,+the+Suicidal+Erythrocyte+Death+by+Piceatannol.">Stimulation of Eryptosis, the Suicidal Erythrocyte Death by Piceatannol.</a> Cellular Physiology and Biochemistry. 38 (6), 2300-2310 (2016).</li><li>Lange, Y., Ye, J., Steck, T. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Scrambling+of+Phospholipids+Activates+Red+Cell+Membrane+Cholesterol.">Scrambling of Phospholipids Activates Red Cell Membrane Cholesterol.</a> Biochemistry. 46 (8), 2233-2238 (2007).</li><li>Lang, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Eryptosis,+a+Window+to+Systemic+Disease.">Eryptosis, a Window to Systemic Disease.</a> Cellular Physiology and Biochemistry. 22 (6), 373-380 (2008).</li><li>Gil-Parrado, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ionomycin-Activated+Calpain+Triggers+Apoptosis.+A+Probable+Role+for+Bcl-2+Family+Members.">Ionomycin-Activated Calpain Triggers Apoptosis. A Probable Role for Bcl-2 Family Members.</a> Journal of Biological Chemistry. 277 (30), 27217-27226 (2002).</li><li>Liu, C. M., Hermann, T. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Characterization+of+Ionomycin+as+a+Calcium+Ionophore.">Characterization of Ionomycin as a Calcium Ionophore.</a> Journal of Biological Chemistry. 253 (17), 5892-5894 (1978).</li><li>Klarl, B. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Protein+Kinase+C+Mediates+Erythrocyte+"Programmed+Cell+Death"+Following+Glucose+Depletion.">Protein Kinase C Mediates Erythrocyte "Programmed Cell Death" Following Glucose Depletion.</a> American Journal of Physiology - Cell Physiology. 290 (1), C244-C253 (2006).</li><li>Danilov, Y. N., Cohen, C. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Wheat+Germ+Agglutinin+but+Not+Concanavalin+A+Modulates+Protein+Kinase+C-Mediated+Phosphorylation+of+Red+Cell+Skeletal+Proteins.">Wheat Germ Agglutinin but Not Concanavalin A Modulates Protein Kinase C-Mediated Phosphorylation of Red Cell Skeletal Proteins.</a> FEBS Letters. 257 (2), 431-434 (1989).</li><li>Nazemidashtarjandi, S., Farnoud, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Membrane+Outer+Leaflet+Is+the+Primary+Regulator+of+Membrane+Damage+Induced+by+Silica+Nanoparticles+in+Vesicles+and+Erythrocytes.">Membrane Outer Leaflet Is the Primary Regulator of Membrane Damage Induced by Silica Nanoparticles in Vesicles and Erythrocytes.</a> Environmental Science Nano. 6 (4), 1219-1232 (2019).</li><li>Jaroszeski, M. J., Heller, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Flow Cytometry Protocols. , (2003).</li><li>Ghashghaeinia, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Impact+of+Erythrocyte+Age+on+Eryptosis.">The Impact of Erythrocyte Age on Eryptosis.</a> British Journal of Haematology. 157 (5), 1365 (2012).</li><li>Repsold, L., Joubert, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Eryptosis:+An+Erythrocyte's+Suicidal+Type+of+Cell+Death.">Eryptosis: An Erythrocyte's Suicidal Type of Cell Death.</a> Biomed Research International. 2018 (5), 9405617 (2018).</li><li>Tait, J. F., Gibson, D., Fujikawa, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Phospholipid+Binding+Properties+of+Human+Placental+Anticoagulant+Protein-I,+a+Member+of+the+Lipocortin+Family.">Phospholipid Binding Properties of Human Placental Anticoagulant Protein-I, a Member of the Lipocortin Family.</a> Journal of Biological Chemistry. 264 (14), 7944-7949 (1989).</li><li>Andree, H. A. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Binding+of+Vascular+Anticoagulant+&#945;+(VAC&#945;)+to+Planar+Phospholipid+Bilayers.">Binding of Vascular Anticoagulant &#945; (VAC&#945;) to Planar Phospholipid Bilayers.</a> Journal of Biological Chemistry. 265 (9), 4923-4928 (1990).</li><li>Tait, J. F., Gibson, D. F., Smith, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Measurement+of+the+Affinity+and+Cooperativity+of+Annexin+V-Membrane+Binding+under+Conditions+of+Low+Membrane+Occupancy.">Measurement of the Affinity and Cooperativity of Annexin V-Membrane Binding under Conditions of Low Membrane Occupancy.</a> Analytical Biochemistry. 329 (1), 112-119 (2004).</li><li>Jiang, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Eryptosis+as+an+Underlying+Mechanism+in+Systemic+Lupus+Erythematosus-Related+Anemia.">Eryptosis as an Underlying Mechanism in Systemic Lupus Erythematosus-Related Anemia.</a> Cellular Physiology and Biochemistry. 40 (6), 1391-1400 (2016).</li><li>Chakrabarti, A., Halder, S., Karmakar, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Erythrocyte+and+Platelet+Proteomics+in+Hematological+Disorders.">Erythrocyte and Platelet Proteomics in Hematological Disorders.</a> Proteomics - Clinical Applications. 10 (4), 403-414 (2016).</li></ol>

The authors have nothing to disclose.

The goal of this procedure is to provide optimal values for ionophore concentration, treatment time, and extracellular glucose concentration, which are important factors in ensuring successful induction of eryptosis. A critical step in the protocol is the depletion of extracellular glucose, which, despite its importance, has not been sufficiently emphasized in the literature. The sugar content in normal Ringer solution (5 mM) has an inhibitory effect on eryptosis. Glucose depletion in the extracellular environment induce...

Programmed cell death in erythrocytes, also known as eryptosis, is common in many clinical conditions and hematological disorders. Eryptosis is associated with cell shrinkage and the loss of phospholipid asymmetry in the cell plasma membrane1,2. Loss of asymmetry results in the translocation of phosphatidylserine (PS), a lipid normally localized in the inner leaflet3,4, to the cell outer leaflet, which signals to macrophages to phagocytose and remove defective erythrocytes5,6,7,8. At the end of the normal life span of erythrocytes, removal of eryptotic cells by macrophages ensures the balance of erythrocytes in circulation. However, in diseased conditions, such as sickle cell disease and thalassemia9,10,11, enhanced eryptosis may result in severe anemia2. Due to its importance in hematological diseases, there is significant interest in examining the factors inducing or inhibiting eryptosis and the molecular mechanisms underlying this process.
The plasma membrane of healthy erythrocytes is asymmetric, with different phospholipids localizing at the outer and inner leaflets. Membrane asymmetry is primarily regulated by the action of membrane enzymes. Aminophospholipid translocase facilitates the transport of aminophospholipids, PS and phosphatidylethanolamine (PE), by directing these lipids to the cell inner leaflet. On the other hand, floppase transports the choline containing phospholipids, phosphatidylcholine (PC) and sphingomyelin (SM), from the inner to the outer leaflet of the cell membrane12. However, unlike healthy cells, the membrane of eryptotic erythrocytes is scrambled. This is due to the action of a third enzyme, scramblase, which disrupts phospholipid asymmetry by facilitating the bidirectional transport of aminophospholipids13,14,15,16. Scramblase is activated by elevated intracellular levels of Ca2+. Therefore, calcium ionophores, which facilitate the transport of Ca2+ across the cell membrane12, are efficient inducers of eryptosis.
Ionomycin, a calcium ionophore, has been widely used to induce eryptosis in erythrocytes12,17,18,19,20,21,22,23,24,25,26. Ionomycin has both hydrophilic and hydrophobic groups, which are necessary to bind and capture Ca2+ ion, and transport it to the cytosolic space27,28,29. This leads to the activation of scramblase and translocation of PS to the outer leaflet, which can be easily detected using annexin-V, a cellular protein with a high affinity to PS12. Although triggering eryptosis by ionomycin is commonly reported, there is considerable method discrepancy in the literature (Table 1). The population of erythrocytes undergoing eryptosis depends on different factors such as ionophore concentration, treatment time with ionophore, and the sugar content of extracellular environment (glucose depletion activates cation channels and facilitates the entry of Ca2+ into the cytosolic space)30,31. However, there is little consistency in these factors in the literature, making it difficult to perform eryptosis reproducibly in vitro.
In this protocol, we present a step-by-step procedure to induce eryptosis in human erythrocytes. Factors affecting successful eryptosis including Ca2+ concentration, ionophore concentration, treatment time, and pre-incubation in glucose-depleted buffer are examined and optimal values are reported. This procedure demonstrates that pre-incubation of erythrocytes in a glucose-free buffer significantly increases the percentage of eryptosis compared to glucose-containing buffer. This protocol can be used in the laboratory to produce eryptotic erythrocytes for various applications.

<table><tbody><tr><td>96-well plate</td><td>Fisher Scientific</td><td>12-565-331</td><td></td></tr><tr><td>Annexin V Alexa Fluor 488 - apoptosis kit</td><td>Fisher Scientific</td><td>A10788</td><td>Store at 4 &amp;deg;C</td></tr><tr><td>BD FACSAria II flow cytometer</td><td>BD Biosciences</td><td>643177</td><td></td></tr><tr><td>CaCl&lt;sub&gt;2&lt;/sub&gt;</td><td>Fisher Scientific</td><td>C79-500</td><td></td></tr><tr><td>Centrifuge</td><td>Millipore Sigma</td><td>M7157</td><td>Model Eppendorf 5415C</td></tr><tr><td>Confocal fluorescence microscopy</td><td>Zeiss, LSM Tek Thornwood</td><td></td><td>Model LSM 510, Argon laser excited at 488 nm for taking images</td></tr><tr><td>Cover glasses circles</td><td>Fisher Scientific</td><td>12-545-100</td><td></td></tr><tr><td>Disposable round bottom flow cytometry tube</td><td>VWR</td><td>VWRU47729-566</td><td></td></tr><tr><td>DMSO</td><td>Sigma-Aldrich</td><td>472301-100ML</td><td></td></tr><tr><td>DPBS</td><td>VWR Life Science</td><td>SH30028.02</td><td></td></tr><tr><td>Glucose monohydrate</td><td>Sigma-Aldrich</td><td>Y0001745</td><td></td></tr><tr><td>HEPES Buffer (1 M)</td><td>Fisher Scientific</td><td>50-751-7290</td><td>Store at 4 &amp;deg;C</td></tr><tr><td>Ionomycin calcium salt</td><td>EMD Milipore Corp.</td><td>407952-1MG</td><td>Dissolve in DMSO to reach 2 mM. Store at -20 &amp;deg;C</td></tr><tr><td>KCl</td><td>Fisher Scientific</td><td>P330-500</td><td></td></tr><tr><td>MgSO&lt;sub&gt;4&lt;/sub&gt;</td><td>Fisher Scientific</td><td>M65-500</td><td></td></tr><tr><td>Microcentrifuge tube</td><td>Fisher Scientific</td><td>02-681-5</td><td></td></tr><tr><td>NaCl</td><td>Fisher Scientific</td><td>S271-500</td><td></td></tr><tr><td>Plain glass microscope slides</td><td>Fisher Scientific</td><td>12-544-4</td><td></td></tr><tr><td>Synergy HFM microplate reader</td><td>BioTek</td><td></td><td></td></tr><tr><td>Whole blood in ACD</td><td>Zen-Bio</td><td></td><td>Store at 4 &amp;deg;C and warm to 37 &amp;deg;C prior to use</td></tr></tbody></table>

induction of eryptosis in red blood cells using a calcium ionophore

Eryptosis, erythrocyte programmed cell death, occurs in a number of hematological diseases and during injury to erythrocytes. A hallmark of eryptotic cells is the loss of compositional asymmetry of the cell membrane, leading to the translocation of phosphatidylserine to the membrane outer leaflet. This process is triggered by increased intracellular concentration of Ca2+, which activates scramblase, an enzyme that facilitates bidirectional movement of phospholipids between membrane leaflets. Given the importance of eryptosis in various diseased conditions, there have been efforts to induce eryptosis in vitro. Such efforts have generally relied on the calcium ionophore, ionomycin, to enhance intracellular Ca2+ concentration and induce eryptosis. However, many discrepancies have been reported in the literature regarding the procedure for inducing eryptosis using ionomycin. Herein, we report a step-by-step protocol for ionomycin-induced eryptosis in human erythrocytes. We focus on important steps in the procedure including the ionophore concentration, incubation time, and glucose depletion, and provide representative result. This protocol can be used to reproducibly induce eryptosis in the laboratory.

Optimization of ionomycin concentration
While ionomycin is required to induce eryptosis, increased ionomycin concentrations can lead to hemolysis (i.e. lysis of erythrocytes and release of hemoglobin), which needs to be avoided. Treatment of erythrocytes with 1 &#181;M ionomycin in Ringer solution for 2 h is enough to induce eryptosis, as evidenced by successful labeling with annexin-V Alexa Flour 488 conjugate ...

Watch this Scientific Journal Video about Induction of Eryptosis in Red Blood Cells Using a Calcium Ionophore at JoVE.com

Induction of Eryptosis in Red Blood Cells Using a Calcium Ionophore

A protocol for the induction of eryptosis, programmed cell death in erythrocytes, using the calcium ionophore, ionomycin, is provided. Successful eryptosis is evaluated by monitoring the localization phosphatidylserine in the membrane outer leaflet. Factors affecting the success of the protocol have been examined and optimal conditions provided.

Eryptosis, erythrocyte programmed cell death, occurs in a number of hematological diseases and during injury to erythrocytes. A hallmark of eryptotic ...
