The authors would like to thank Research Foundation - Flanders (FWO) for supporting this work (Grant number: G027815N).

The protocol has been approved by the Animal Ethics Committee at the University of Ghent (ECD 15/44Aanv), and all experiments were conducted in accordance with the guidelines of the European Commission (Directive 2010/63/EU).
1. Animal preparation and helmet attachment
<ol>
	<li>Weigh a female Wistar H rat (&#177; 250 g or 12 weeks of age) and anesthetize in a small induction chamber filled with a mixture of isoflurane (5%) and O2 for at least 1 min.</li>
	<li>Inject the rat with 0.05 mg/kg buprenorphine subcutaneously in the neck, return it to the home cage, and allow pre-emptive analgesia for at least 30 min to take an effect.
	NOTE: During the 30 min wait, the surgical site can be prepared.</li>
	<li>Place a heating pad kept at 37 &#176;C under the surgical field.&#160;Place the sterilized surgical instruments on the surgical field that was disinfected with 70% ethanol.</li>
	<li>Place the rat back in the induction chamber and anesthetize the rat until it is non-responsive to a paw or tail pinch.</li>
	<li>Place the rat on the surgical field and insert a catheter in the lateral tail vein.&#160;Next, shave the rat&#8217;s head, remove excess fur and disinfect the scalp and the rest of the surgical area with chlorohexidine.&#160;</li>
	<li>Inject 100 &#956;L of 2% lidocaine locally in the scalp.</li>
	<li>Make a midline incision using a scalpel size 11 to expose the skull, removing any excess membranes with small scissors. Retract the skin using an ocular speculum with a maximum spread of 1 cm.&#160;&#160;Additionally, remove the periosteum by gently rubbing a sterile cotton bud across the skull until the periosteum is no longer present.</li>
	<li>Put one drop of tissue glue on the skull and one on the sterilized metallic disc (diameter of 10 mm and 3 mm thickness), which acts as the helmet. Glue the disc approximately one-third before and two-thirds behind the bregma. Allow the glue to dry for 1 min.</li>
</ol>
2. Induction of traumatic brain injury (TBI)
<ol>
	<li>Place the rat on the custom-made bed with a foam mattress of certain spring constant (see Table of Materials). Position the rat directly under a transparent plastic tube with a 450 g brass weight with the helmet as horizontal as possible. Detach the rat from anesthesia.</li>
	<li>Pull the weight up to 1 m and release when ready. Ensure that a second experimenter is present to move the rat away from the plastic tube immediately after impact to prevent a second impact.
	NOTE: The sham injured rats receive the same experimental procedure (steps 1.1&#8211;2.7), except for step 2.2.</li>
	<li>Re-attach the rat to the anesthesia and inject 1 mL of physiological solution (0.9% NaCl) via the catheter to reduce the hemodynamic shock.
	NOTE: It is possible that the rat briefly stops breathing because of the impact. Gently compress the thorax if the rat does not spontaneously breathe after 2 s to encourage the breathing reflex.</li>
	<li>Remove the helmet by gently pulling it from the skull. Remove any remaining glue from the skull and skin and close the incision with surgical suture. Apply local analgesia gel using a sterile applicator tip.&#160;</li>
	<li>Place the rat on the bed of the CT scanner. Confirm the correct position using a scout scan. Adjust the field of view to enable imaging of the whole head within one bed position. Administer a general purpose, low dose CT scan to rule out skull fractures.
	NOTE: Skull fracture is a criterium for euthanasia.</li>
	<li>Place the rat in a clean cage on a heating pad (37 &#176;C). Monitor the time to regain consciousness. Once the rat is able to sit upright, the rat can be returned to the home cage.</li>
	<li>Administer a second dose of 0.05 mg/kg buprenorphine one day following TBI induction.</li>
</ol>
3. Diffusion magnetic resonance imaging (MRI)
NOTE: Diffusion-weighted imaging is performed before and 1 day following trauma induction.
<ol>
	<li>Anesthetize the rat in a small induction chamber filled with a mixture of isoflurane (5%) and O2. When the rat is non-responsive to a paw or tail pinch reduce the anesthesia to 2% with a flow rate of 500 mL/min. Transfer the animal to the scanner bed in head-first prone position.</li>
	<li>Position the rat in the head holder with the teeth bar and nose cone, delivering the anesthesia, and slide the head forwards until the center of the brain is at the level of the center of the quadrature volume MRI coil. Apply lubricating ointment to the eyes in small amounts to prevent any damage to the cornea. Fixate the head with a small piece of tape to avoid movement during scanning.</li>
	<li>Place a pressure pad under the thorax of the rat to monitor respiration and cover the rat with a circulating warm water heating blanket and bubble wrap to keep the rat warm. Before the scanning, check the respiratory monitor to ensure that the signal is clear without noise and that the respiratory cycle is consistent. Relocate the pressure pad, if necessary.
	NOTE: The respiratory rate should be kept between 1 breath per 1,200&#8211;1,700 ms by adjusting the level of anesthesia between 1%&#8211;2%.</li>
	<li>Slide the quadrature volume coil over the head. Adjust the tuning and matching capacitors of the coil to the proper frequency and impedance according to the instructions provided by the coil vendor. Advance the scanner bed into the scanner bore to start scanning.</li>
	<li>Obtain a default three-plane scout scan (&#8220;tripilot&#8221;) to ensure correct positioning.
	<ol>
		<li>Load the tripilot sequence into the Scan Control by clicking New Scan and selecting the tripilot sequence from the protocol list. Next, click the traffic light button to start the scan.</li>
		<li>When the scan is finished, load the scan in the image display and ensure that 1) the head is lying straight and 2) the brain is positioned in the center of the magnet and coil. Adjust the position of the head and/or the scanner bed, if necessary, and acquire a new tripilot scan.</li>
	</ol>
	</li>
	<li>Adjust the local magnetic field using an automated second-order shimming protocol: load the second-order shim protocol into the Scan Control as described in step 3.5.1. Next, click on the Acq tab | Current Adjustments | Method specific adjustment for the Local Field Homogeneity in the Spectrometer Control Tool window to start automated shimming.</li>
	<li>Load a new T2 Rapid imaging with Refocused Echoes (RARE) sequence into the Scan control as described in step 3.5.1.
	<ol>
		<li>Acquire T2 weighted images using the default settings, except for the following parameters:</li>
		<li>Open the Edit Scan tab and adjust the repetition time (TR) and echo time (TE) to 5,500 ms and 37 ms, respectively. Also, modify the field of view and matrix size to allow for a higher in-plane resolution of 109 &#956;m x 109 &#956;m (default resolution = 156 &#956;m x 156 &#956;m). Make sure that the slice thickness is 600 &#956;m, number of slices is set to 45, and RARE factor is set to 8.</li>
		<li>Open the Geometry editor and place the slice package in the correct position including the bulbus of the brain and the cerebellum.</li>
	</ol>
	</li>
	<li>Load three new echo-planar diffusion-weighted spin-echo sequence (DtiEpi) from the B_DIFFUSION folder into the Scan Control protocol as described in step 3.5.1.
	NOTE: Using three different diffusion &#8220;shells&#8221;, the diffusion tensor imaging (DTI) model4,16, diffusion kurtosis imaging (DKI) model17, and white matter tract integrity (WMTI) model18 can all be estimated. It is recommended to use at least three different b-values, with the highest b-value having a maximum of 3000 s/mm2 with at least 15 evenly spaced directions per imaging shell17.
	<ol>
		<li>Acquire diffusion weighted images (DWIs) using default settings, apart from the following settings:</li>
		<li>Open the Edit Scan tab and adjust the geometrical parameters under the Geometry tab. Adjust the field of view and matrix size to 105 x 105 to ensure a resolution of 333 &#956;m x 333 &#956;m.</li>
		<li>Set the slice orientation to axial and the number of slices to 25, resulting in a slice thickness of 500 &#956;m and interslice distance of 600 &#956;m. Amend the readout direction into left-right.</li>
		<li>Click the Contrast tab to adjust the echo time to 24 ms and repetition time to 6,250 ms.</li>
		<li>Set the bandwidth to 250,000 Hz and turn the fat suppression on. Adjust the number of averages to one.</li>
		<li>Click on the Research tab and change the number of averages (EPI segments) to 4.</li>
		<li>Click on the Diffusion tab within the research tab. Perform this step separately for each of the three diffusion shells.
		<ol>
			<li>Adjust the number of diffusion directions to 32 for the first shell, 46 for the second shell, and 64 for the third shell.</li>
			<li>Adjust the gradient directions with custom gradient directions files.</li>
			<li>Change the number of B0 images to 5 for the first shell, 5 for the second shell, and 7 for the third shell.</li>
			<li>Adjust the b-value per direction to 800 s/mm2 for the first shell, 1500 s/mm2 for the second shell, and 2000 s/mm2 for the third shell.
			NOTE: Adjusting the gradient directions with a custom gradient directions file can be done manually by setting Enter Diffusion Directions to yes or automatically by using the DTI_SET_DIRECTIONS macro.</li>
		</ol>
		</li>
		<li>Open the Geometry editor and place the field of view between the bulbus and cerebellum containing only the cerebrum to reduce artifact and scan time. Position six saturation bands of 5 mm outside the brain to reduce artifacts by clicking on Saturation and sliding the bands in the preferred position using the scroll bars.
		NOTE: The bulbus and cerebellum can be identified based on anatomical landmarks and the three images of the tripilot scan.</li>
	</ol>
	</li>
	<li>Acquire the imported sequences by clicking on the traffic light symbol. Using the settings of the parameters described above, the acquisition time of the T2-RARE scan is 12 min, of the first DWI shell 15 min, of the second DWI shell 21 min and of the third shell 30 min. The total acquisition time is approximately 80 min (on a single receiver channel system).</li>
	<li>At the completion of the scanning protocol, remove the animal from the scanner bed, and place the animal in a clean cage with a heating pad at 37 &#176;C. Return the animal to the home cage when it regains consciousness.</li>
</ol>
4. Image processing
NOTE: In the following sections, the processing of the diffusion images is described in MRtrix3, ExploreDTI19 and Amide software20 which are open access toolboxes. However, the preprocessing steps can be performed in other toolboxes (e.g., FSL, MedInria, DTIStudio).
<ol>
	<li>Transfer the acquired data from the acquisition console by exporting the 2dseq file.</li>
	<li>Convert the 2dseq files (raw DWI files) into the .mif format, which is the standard formatting of MRtrix3, to allow for further preprocessing steps in MRtrix3. Moreover, concatenate the three diffusion shells using the following commands in the shell:
	convert_bruker pdata/1/2dseq ratID_T2.mih (for the T2-weighted images)
	convert_bruker pdata/1/2dseq ratID_dwi1.mih (for the first diffusion shell)
	convert_bruker pdata/1/2dseq ratID_dwi2.mih (for the second diffusion shell)
	convert_bruker pdata/1/2dseq ratID_dwi3.mih (for the third diffusion shell)
	mrcat ratID_dwi1.mif ratID_dwi2.mif ratID_dwi3.mif ratID_dwi.mif</li>
	<li>Perform noise correction and Gibbs ringing correction on the DWIs in MRtrix321,22. Also, convert the corrected DWI images and T2 image to NIFTI format using the following commands:
	dwidenoise ratID_dwi.mif ratID_dwi_denoised.mif
	mrdegibbs ratID_dwi_denoised.mif ratID_dwi_denoised_gr.mif
	mrconvert ratID_dwi_denoised_gr.mif ratID.nii
	mrconvert ratID_T2.mif ratID_T2.nii</li>
	<li>Perform correction for EPI, motion and Eddy current distortions in ExploreDTI:
	<ol>
		<li>Convert the NIFTI images to a .mat file by clicking Calculate DTI*.mat file | Convert raw data to DTI*.mat file. Change the diffusion tensor estimation to weighed linear and the b-value to NaN. Adjust the voxel size to 0.333 0.333 0.6, number of non-DWI images to 17, number of DWI images to 142, and matrix size to 105 105 25.
		NOTE: By setting the b-value to NaN, ExploreDTI will regard the dataset as a kurtosis data set.</li>
		<li>Click on the Settings tab to adjust the settings for EPI correction (this is turned off by default). Select SM/EC/EPI correction, also register to other data? and click on Yes, to do the EPI correction (non-rigid). Specify the suffix of the anatomical T2 image corresponding to the diffusion data set.
		NOTE: ExploreDTI corrects for EPI distortions using image registration between the undistorted anatomical image and the diffusion image.</li>
		<li>Click on the Plugins tab and select Correction for subject motion &#38; EC/EPI distortions and select the preprocessed diffusion data file from step 2.3. Make sure that the T2 image is in the same folder and has the same base as the diffusion data file name (e.g., rat1.nii for the DWI and rat1_T2.nii for the anatomical image). This step will generate a &#8220;native&#8221; (*native.mat) and &#8220;transformed&#8221; file (*trafo.mat).</li>
	</ol>
	</li>
	<li>Calculate the DTI metrics for each rat by clicking Plugins and Export stuff to *.nii and selecting the parametric maps of the DTI model: fractional anisotropy (FA), mean diffusivity (MD), radial diffusivity (RD), and axial diffusivity (AD; denoted as &#8220;largest eigenvalue L1&#8221;).</li>
	<li>Additionally, export the parametric maps for the kurtosis model (MK, AK, and RK) and WMTI model (AWF, AxEAD, RadEAD and TORT). Processing of the diffusion images will result in 12 parametric maps (Figure 1, Figure 2, Figure 3) that can be used for further microstructural analysis.</li>
	<li>Create a mask file for the hippocampus of each rat using MRtrix3.
	<ol>
		<li>Load the FA image of the rat in the MRtrix viewer by clicking Tool and ROI editor.</li>
		<li>Create a new ROI by clicking the &#8220;+&#8221; button and press Edit to draw the ROI on each slice that includes the hippocampus (Figure 4). To erase unwanted areas from the ROI drawn, press the right mouse button.</li>
		<li>When the drawing of the ROI is completed, save the mask image by clicking the Save button.
		NOTE: This mask file will be a binary NIFTI image file with voxels of value 1 containing the hippocampal tissue, and remaining voxels will have values of 0. To standardize the region of the hippocampus across rats, the parametric maps can be co-registered with a study specific template with predefined regions of interest delineated23 or a rat brain atlas.</li>
	</ol>
	</li>
	<li>To extract the diffusion metrics of the hippocampus of the rat, use the created mask file of step 4.6 and open the Amide software.
	<ol>
		<li>Open the parametric maps and mask image of the rat.</li>
		<li>To add the ROI of the mask file into Amide, select the mask file image, click Edit | Add ROI | 3D Isocontour and click on the ROI displayed in the mask image. Give the ROI a meaningful name and confirm that this volume should only contain voxels having a value of one.</li>
		<li>To calculate the mean values of the diffusion metrics in the hippocampus, click Tools | Calculate ROI Statistics and indicate the images and ROI that should be included. After clicking Execute, another screen will pop up with computed values that can be used for further statistical analysis. This file can either be saved or copied into a preferred data format (e.g., .xlsx or .csv file).</li>
	</ol>
	</li>
</ol>
5. Statistical analysis
NOTE: In the following sections, we describe processing of the diffusion images in SPSS Statistics 24; however, the statistical analysis can be performed in other statistical toolboxes.
<ol>
	<li>Load the data in the wide format in an SPSS *.sav file.</li>
	<li>To test for statistical differences between the two groups for each timepoint (i.e., baseline or 1-day post-injury), click Analyze | Nonparametric tests | Legacy Dialogs | 2 Independent Samples Tests. Load the variables that need to be tested and specify the groups (i.e., TBI and sham groups). Indicate the Mann-Whitney U as the test type.</li>
	<li>To test for statistical differences between the 2 time point within each group the data file needs to be split. Go to Go to Data, Split File and indicate Compare groups. Next, click on Analyze, Nonparametric tests, Legacy Dialogs, 2 Related Samples Tests, load the variables that need to be compared and indicate Wilcoxon as test type.
	NOTE: To correct for multiple comparisons, p-values are adjusted for each diffusion model using Bonferroni correction [i.e., p-value divided by the number of parameters compared (DTI 4, DKI 3, and WMTI 4)]. More specifically, p &#60; 0.0125 is considered significant for the DTI and WMTI models, and p &#60; 0.016 is considered significant for the DKI model.</li>
</ol>

<ol>
	<li>Carroll, L. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Systematic+Review+of+the+Prognosis+After+Mild+Traumatic+Brain+Injury+in+Adults.">Systematic Review of the Prognosis After Mild Traumatic Brain Injury in Adults.</a> Cognitive, Psychiatric, and Mortality Outcomes: Results of the International Collaboration on Mild Traumatic Brain Injury Prognosis. Archives of Physical Medicine and Rehabilitation. 95 (3), S152-S173 (2014).</li><li>Buck, P. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mild+Traumatic+Brain+Injury:+A+Silent+Epidemic+in+Our+Practices.">Mild Traumatic Brain Injury: A Silent Epidemic in Our Practices.</a> Health &amp; Social Work. 36 (4), 299-302 (2011).</li><li>Bodanapally, U. K., Sours, C., Zhuo, J., Shanmuganathan, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+of+Traumatic+Brain+Injury.">Imaging of Traumatic Brain Injury.</a> Radiologic Clinics of North America. 53 (4), 695-715 (2015).</li><li>Basser, P. J., Mattiello, J., LeBihan, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=MR+diffusion+tensor+spectroscopy+and+imaging.">MR diffusion tensor spectroscopy and imaging.</a> Biophysical Journal. 66 (1), 259-267 (1994).</li><li>Hulkower, M. B., Poliak, D. B., Rosenbaum, S. B., Zimmerman, M. E., Lipton, M. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+Decade+of+DTI+in+Traumatic+Brain+Injury:+10+Years+and+100+Articles+Later.">A Decade of DTI in Traumatic Brain Injury: 10 Years and 100 Articles Later.</a> American Journal of Neuroradiology. 34 (11), 2064-2074 (2013).</li><li>Hutchinson, E. B., Schwerin, S. C., Avram, A. V., Juliano, S. L., Pierpaoli, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Diffusion+MRI+and+the+detection+of+alterations+following+traumatic+brain+injury.">Diffusion MRI and the detection of alterations following traumatic brain injury.</a> Journal of Neuroscience Research. 96 (4), 612-625 (2018).</li><li>Wallace, E. J., Mathias, J. L., Ward, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Diffusion+tensor+imaging+changes+following+mild,+moderate+and+severe+adult+traumatic+brain+injury:+a+meta-analysis.">Diffusion tensor imaging changes following mild, moderate and severe adult traumatic brain injury: a meta-analysis.</a> Brain Imaging and Behavior. , 1-15 (2018).</li><li>Rutgers, D. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=White+Matter+Abnormalities+in+Mild+Traumatic+Brain+Injury:+A+Diffusion+Tensor+Imaging+Study.">White Matter Abnormalities in Mild Traumatic Brain Injury: A Diffusion Tensor Imaging Study.</a> American Journal of Neuroradiology. 29 (3), 514-519 (2008).</li><li>Bondi, C. O., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Found+in+translation:+Understanding+the+biology+and+behavior+of+experimental+traumatic+brain+injury.">Found in translation: Understanding the biology and behavior of experimental traumatic brain injury.</a> Neuroscience &amp; Biobehavioral Reviews. 58, 123-146 (2015).</li><li>Shultz, S. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+potential+for+animal+models+to+provide+insight+into+mild+traumatic+brain+injury:+Translational+challenges+and+strategies.">The potential for animal models to provide insight into mild traumatic brain injury: Translational challenges and strategies.</a> Neuroscience &amp; Biobehavioral Reviews. 76, 396-414 (2017).</li><li>Osier, N. D., Dixon, C. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Controlled+Cortical+Impact+Model:+Applications,+Considerations+for+Researchers,+and+Future+Directions.">The Controlled Cortical Impact Model: Applications, Considerations for Researchers, and Future Directions.</a> Frontiers in Neurology. 7 (AUG), (2016).</li><li>Lyeth, B. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Historical+Review+of+the+Fluid-Percussion+TBI+Model.">Historical Review of the Fluid-Percussion TBI Model.</a> Frontiers in Neurology. 7 (DEC), 1-7 (2016).</li><li>Marmarou, A., Foda, M. A. A. -. E., van den Brink, W., Campbell, J., Kita, H., Demetriadou, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+model+of+diffuse+brain+injury+in+rats.">A new model of diffuse brain injury in rats.</a> Journal of Neurosurgery. 80 (2), 291-300 (1994).</li><li>Heim, L. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Invisibility+of+Mild+Traumatic+Brain+Injury:+Impaired+Cognitive+Performance+as+a+Silent+Symptom.">The Invisibility of Mild Traumatic Brain Injury: Impaired Cognitive Performance as a Silent Symptom.</a> Journal of Neurotrauma. 34 (17), 2518-2528 (2017).</li><li>Zohar, O., Rubovitch, V., Milman, A., Schreiber, S., Pick, C. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Behavioral+consequences+of+minimal+traumatic+brain+injury+in+mice.">Behavioral consequences of minimal traumatic brain injury in mice.</a> Acta Neurobiol Exp (Wars. 71 (1), 36-45 (2011).</li><li>Pierpaoli, C., Basser, P. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Toward+a+quantitative+assessment+of+diffusion+anisotropy.">Toward a quantitative assessment of diffusion anisotropy.</a> Magnetic resonance in medicine&#8239;: official journal of the Society of Magnetic Resonance in Medicine / Society of Magnetic Resonance in Medicine. 36 (6), 893-906 (1996).</li><li>Jensen, J. H., Helpern, J. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=MRI+quantification+of+non-Gaussian+water+diffusion+by+kurtosis+analysis.">MRI quantification of non-Gaussian water diffusion by kurtosis analysis.</a> NMR in Biomedicine. 23 (7), 698-710 (2010).</li><li>Fieremans, E., Jens, H., Jensen, J. A. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=White+matter+characterization+with+diffusional+kurtosis+imaging.">White matter characterization with diffusional kurtosis imaging.</a> NeuroImage. 58, 177-188 (2011).</li><li>Leemans, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Explore DTI. , (2019).</li><li>Loening, A. M., Gambhir, S. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=AMIDE:+A+Free+Software+Tool+for+Multimodality+Medical+Image+Analysis.">AMIDE: A Free Software Tool for Multimodality Medical Image Analysis.</a> Molecular Imaging. 2 (3), 131-137 (2003).</li><li>Veraart, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Denoising+of+diffusion+MRI+using+random+matrix+theory.">Denoising of diffusion MRI using random matrix theory.</a> NeuroImage. 142, 394-406 (2016).</li><li>Veraart, J., Fieremans, E., Novikov, D. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Diffusion+MRI+noise+mapping+using+random+matrix+theory.">Diffusion MRI noise mapping using random matrix theory.</a> Magnetic Resonance in Medicine. 76 (5), 1582-1593 (2016).</li><li>Braeckman, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamic+changes+in+hippocampal+diffusion+and+kurtosis+metrics+following+experimental+mTBI+correlate+with+glial+reactivity.">Dynamic changes in hippocampal diffusion and kurtosis metrics following experimental mTBI correlate with glial reactivity.</a> NeuroImage: Clinical. 21 (August 2018), 101669 (2019).</li><li>Jones, D. K., Kn&#246;sche, T. R., Turner, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=White+matter+integrity,+fiber+count,+and+other+fallacies:+The+do's+and+don'ts+of+diffusion+MRI.">White matter integrity, fiber count, and other fallacies: The do's and don'ts of diffusion MRI.</a> NeuroImage. 73, 239-254 (2013).</li><li>. Matlab code DKI and WMTI model Available from: <a target="_blank" href="https://github.com/NYU-DiffusionMRI/Diffusion-Kurtosis-Imaging">https://github.com/NYU-DiffusionMRI/Diffusion-Kurtosis-Imaging</a> (2019)</li></ol>

The authors have no conflicts of interest to disclose.

Since mTBI often is the result of a diffuse and subtle injury that shows no abnormalities on CT and conventional MRI scans, the evaluation of microstructural damage after a mild trauma remains a challenge. Therefore, more advanced imaging techniques are needed to visualize the full extent of the trauma. The application of diffusion magnetic resonance imaging in TBI research has gained more interest during the last decade, where diffusion tensor imaging is most frequently used5. A limitation of the...

Traumatic brain injury (TBI) has gained more attention in recent years, as it has become clear that these brain injuries can result in lifelong cognitive, physical, emotional, and social consequences1. Despite this increasing awareness, mild TBI (mTBI, or concussion) is still often underreported and undiagnosed. MTBI has been referred to as a silent epidemic, and individuals with a history of mTBI show higher rates of substance abuse or psychiatric problems2. Several patients with mTBI go undiagnosed every year due to the diffuse and subtle nature of the injuries, which are often not visible on conventional computed tomography (CT) or magnetic resonance imaging (MRI) scans. This lack of radiological evidence of brain injury has led to the development of more advanced imaging techniques such as diffusion MRI, which are more sensitive to microstructural changes3.
Diffusion MRI allows in vivo mapping of the microstructure, and this MRI technique has been used extensively in TBI studies4,5,6. From the diffusion tensor, fractional anisotropy (FA) and mean diffusivity (MD) are computed to quantify alteration in the microstructural organization following injury. Recent reviews in mTBI patients report increases in FA and decreases in MD following injury, which can be indicative of axonal swelling7. Contrary, increases in MD and decreases in FA are also found and have been suggested to underlie disruptions in parenchymal structure following edema formation, axonal degeneration, or fiber misalignment/disruption8. These mixed findings can be partially explained by the significant clinical heterogeneity of mTBI caused by different types of impact and severity (e.g., rotation-acceleration, blunt force trauma, blast injury or combination of the former). However, currently there is no clear consensus about the underlying pathology and biological/cellular basis underpinning alterations in the microstructural organization.
Animal models provide a standardized and controlled setting to investigate biological mechanisms of injury and repair following TBI in greater detail. Several experimental models for TBI have been developed and represent different aspects of human TBI (e.g., focal vs. diffuse trauma or trauma caused by rotational forces)9,10. Commonly used animal models include the controlled cortical impact (CCI) and lateral fluid percussion injury (LFPI) models11,12. Although the experimental parameters can be well-controlled, these models make use of a craniotomy to expose the brain. Craniotomies or skull fractures are not commonly seen in mTBI; therefore, these experimental models are not valid to mimic mTBI. The impact acceleration model developed by Marmarou et al.13 makes use of a weight that is dropped from a certain height onto the rat&#39;s head, which is protected by a helmet. This animal model induces similar microstructural alterations and cognitive impairments as seen in patients who sustain mild trauma. Therefore, this Marmarou weight drop model is appropriate to investigate imaging biomarkers for diffuse mTBI14,15.
This report demonstrates the application of advanced diffusion MRI in an mTBI rat model using the Marmarou weight drop model. First shown is how to induce a mild and diffuse trauma, and analysis using diffusion tensor imaging (DTI) model is then provided. Specific biological information is obtained with the use of more advanced diffusion models [i.e., diffusion kurtosis imaging (DKI) and white matter tract integrity (WMTI) model]. Specifically, mild trauma is inflicted and microstructural changes are then evaluated in the hippocampus using conventional T2-weighted MRI and an advanced diffusion imaging protocol.

<table>
	<tbody>
		<tr>
			<td>Induction of trauma</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>0.9% NaCl physiologic solution</td>
			<td>B Braun</td>
			<td>394496</td>
			<td></td>
		</tr>
		<tr>
			<td>brass weight 450g</td>
			<td>custom made</td>
			<td>custom made</td>
			<td>diamter 18mm and 210 mm height</td>
		</tr>
		<tr>
			<td>catheter</td>
			<td>Terumo</td>
			<td>Versatus-W</td>
			<td>26G</td>
		</tr>
		<tr>
			<td>ethilon II</td>
			<td>Ethicon</td>
			<td>EH7824</td>
			<td>FS-3, 4-0, 3/8, 16mm</td>
		</tr>
		<tr>
			<td>Matrass</td>
			<td>Foam to Size</td>
			<td>Type E</td>
			<td></td>
		</tr>
		<tr>
			<td>Plexiglas tube</td>
			<td>ISPA Plastics</td>
			<td>416564</td>
			<td>M1 PMMA XT GOO tube 25x19 mm (inner diamter 19 mm, minimal length of 1.50 m)</td>
		</tr>
		<tr>
			<td>Preclinical CT scanner</td>
			<td>Molecubes</td>
			<td>X-cube</td>
			<td></td>
		</tr>
		<tr>
			<td>Steel helmet</td>
			<td>custom made</td>
			<td>custom made</td>
			<td>diameter 10 mm and 3 mm thickness</td>
		</tr>
		<tr>
			<td>Vetbond Tissue Adhesive</td>
			<td>3M</td>
			<td>1469SB</td>
			<td></td>
		</tr>
		<tr>
			<td>Vetergesic (buprenorphin)</td>
			<td>EcuPhar</td>
			<td>VETERG20</td>
			<td>0.05 mk/kg</td>
		</tr>
		<tr>
			<td>Xylocaine 2% gel</td>
			<td>AstraZeneca</td>
			<td>Xylocaine 2%</td>
			<td>gel</td>
		</tr>
		<tr>
			<td>Xylocaine (lidocain 2%)</td>
			<td>Aspen/AstraZeneca</td>
			<td>Xylocaine 2% gel</td>
			<td>100 &#956;l injection</td>
		</tr>
		<tr>
			<td>Diffusion MRI</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Preclinical MRI acquisition software</td>
			<td>Bruker Biospin MRI GmbH</td>
			<td>Z400_PV51_CENTOS55</td>
			<td>ParaVision 5.1 MRI software</td>
		</tr>
		<tr>
			<td>Preclinical MRI scanner</td>
			<td>Bruker Biospin MRI GmbH</td>
			<td>PharmaScan 70/16</td>
			<td>7T MRI scanner</td>
		</tr>
		<tr>
			<td>Quadrature volume coil</td>
			<td>Bruker Biospin MRI GmbH</td>
			<td>RF RES 300 1H 075/040 QSN TR</td>
			<td>Model No: 1P T13161C3</td>
		</tr>
		<tr>
			<td>Small animal physiological monitoring unit</td>
			<td>Rapid Biomedical</td>
			<td>EKGHR02-0571-043C01</td>
			<td>Unit for respiratory monitoring</td>
		</tr>
		<tr>
			<td>Water-based heating unit</td>
			<td>Thermo Fisher Scientific</td>
			<td>Haake S 5P</td>
			<td>Model No: 1523051</td>
		</tr>
		<tr>
			<td>Anaesthesia</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Anaesthesia movable unit</td>
			<td>Veterenary technics</td>
			<td></td>
			<td>BDO - Medipass, Ijmuiden</td>
		</tr>
		<tr>
			<td>isoflurane: Isoflo</td>
			<td>Zoetis</td>
			<td>B506</td>
			<td></td>
		</tr>
		<tr>
			<td>Oxygen generator</td>
			<td>Veterenary technics</td>
			<td>7F-3</td>
			<td>BDO - Medipass, Ijmuiden</td>
		</tr>
		<tr>
			<td>Diffusion image processing</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Amide</td>
			<td>http://amide.sourceforge.net</td>
			<td>Version 1.0.5.</td>
			<td>Medical Imaging Data Examiner Toolbox (Loening AM, Gambhir SS, &#34; AMIDE: A Free Software Tool for Multimodality Medical Image Analysis&#34;, Molecular Imaging, 2(3):131-137, 2003)</td>
		</tr>
		<tr>
			<td>ExploreDTI</td>
			<td>http://www.exploredti.com</td>
			<td>Version 4.8.6</td>
			<td>Toolbox for (pre-)processing and analysis of diffusion weighted MR images (Leemans A, Jeurissen B, Sijbers J, and Jones DK. ExploreDTI: a graphical toolbox for processing, analyzing, and visualizing diffusion MR data. In: 17th Annual Meeting of Intl Soc Mag Reson Med, p. 3537, Hawaii, USA, 2009)</td>
		</tr>
		<tr>
			<td>MRtrix3</td>
			<td>http://www.mrtrix.org</td>
			<td>Version 3.0_RC3-86-g4b523b41</td>
			<td>Toolbox for (pre-)processing and analysis of diffusion weighted MR images</td>
		</tr>
	</tbody>
</table>

advanced diffusion imaging in the hippocampus of rats with mild traumatic brain injury

Mild traumatic brain injury (mTBI) is the most common type of acquired brain injury. Since patients with traumatic brain injury show a tremendous variability and heterogeneity (age, gender, type of trauma, other possible pathologies, etc.), animal models play a key role in unraveling factors that are limitations in clinical research. They provide a standardized and controlled setting to investigate the biological mechanisms of injury and repair following TBI. However, not all animal models mimic the diffuse and subtle nature of mTBI effectively. For example, the commonly used controlled cortical impact (CCI) and lateral fluid percussion injury (LFPI) models make use of a craniotomy to expose the brain and induce widespread focal trauma, which are not commonly seen in mTBI. Therefore, these experimental models are not valid to mimic mTBI. Thus, an appropriate model should be used to investigate mTBI. The Marmarou weight drop model for rats induces similar microstructural alterations and cognitive impairments as seen in patients who sustain mild trauma; therefore, this model was selected for this protocol. Conventional computed tomography and magnetic resonance imaging (MRI) scans commonly show no damage following a mild injury, because mTBI induces often only subtle and diffuse injuries. With diffusion weighted MRI, it is possible to investigate microstructural properties of brain tissue, which can provide more insight into the microscopic alterations following mild trauma. Therefore, the goal of this study is to obtain quantitative information of a selected region-of-interest (i.e., hippocampus) to follow up disease progression after obtaining a mild and diffuse brain injury.

In the study, all TBI rats (n = 10) survived the impact and were able to recover from the impact and anesthesia within 15 min after detachment from anesthesia23. On the CT images, there was no evidence of skull fractures and the T2 images did not show any abnormalities such as bleeding, enlarged ventricles, or edema formation at the contusion site 1 day after trauma (Figure 5). Thus, based on these visual inspections of the anatomical images, large focal lesions were ...

Watch this Scientific Journal Video about Advanced Diffusion Imaging in The Hippocampus of Rats with Mild Traumatic Brain Injury at JoVE.com

Advanced Diffusion Imaging in The Hippocampus of Rats with Mild Traumatic Brain Injury

The overall goal of this procedure is to obtain quantitative microstructural information of the hippocampus in a rat with mild traumatic brain injury. This is done using an advanced diffusion-weighted magnetic resonance imaging protocol and region-of-interest based analysis of parametric diffusion maps.

Mild traumatic brain injury (mTBI) is the most common type of acquired brain injury. Since patients with traumatic brain injury show a tremendous ...

advanced-diffusion-imaging-hippocampus-rats-with-mild-traumatic-brain

Universidad de Cartagena UDEC

Research

JoVE Journal

Neuroscience

8.4K Views.  Ghent University. The overall goal of this procedure is to obtain quantitative microstructural information of the hippocampus in a rat with mild traumatic brain injury. This is done using an advanced diffusion-weighted magnetic resonance imaging protocol and region-of-interest based analysis of parametric diffusion maps.

Video: Advanced Diffusion Imaging in The Hippocampus of Rats with Mild Traumatic Brain Injury

Lateral Fluid Percussion: Model of Traumatic Brain Injury in Mice

Traumatic brain injury (TBI) research has attained renewed momentum due to the increasing awareness of head injuries, which result in morbidity and mortality. Based on the nature of primary injury following TBI, complex and heterogeneous secondary consequences result, which are followed by regenerative processes 1,2. Primary injury can be induced by a direct contusion to the brain from skull fracture or from shearing and stretching of tissue causing displacement of brain due to movement 3,4. The resulting hematomas and lacerations cause a vascular response 3,5, and the morphological and functional damage of the white matter leads to diffuse axonal injury 6-8. Additional secondary changes commonly seen in the brain are edema and increased intracranial pressure 9. Following TBI there are microscopic alterations in biochemical and physiological pathways involving the release of excitotoxic neurotransmitters, immune mediators and oxygen radicals 10-12, which ultimately result in long-term neurological disabilities 13,14. Thus choosing appropriate animal models of TBI that present similar cellular and molecular events in human and rodent TBI is critical for studying the mechanisms underlying injury and repair.
Various experimental models of TBI have been developed to reproduce aspects of TBI observed in humans, among them three specific models are widely adapted for rodents: fluid percussion, cortical impact and weight drop/impact acceleration 1. The fluid percussion device produces an injury through a craniectomy by applying a brief fluid pressure pulse on to the intact dura. The pulse is created by a pendulum striking the piston of a reservoir of fluid. The percussion produces brief displacement and deformation of neural tissue 1,15. Conversely, cortical impact injury delivers mechanical energy to the intact dura via a rigid impactor under pneumatic pressure 16,17. The weight drop/impact model is characterized by the fall of a rod with a specific mass on the closed skull 18. Among the TBI models, LFP is the most established and commonly used model to evaluate mixed focal and diffuse brain injury 19. It is reproducible and is standardized to allow for the manipulation of injury parameters. LFP recapitulates injuries observed in humans, thus rendering it clinically relevant, and allows for exploration of novel therapeutics for clinical translation 20.
We describe the detailed protocol to perform LFP procedure in mice. The injury inflicted is mild to moderate, with brain regions such as cortex, hippocampus and corpus callosum being most vulnerable. Hippocampal and motor learning tasks are explored following LFP.

Lateral fluid percussion (LFP), an established model of traumatic brain injury in mice, is demonstrated. LFP fulfills three major criteria for animal models: validity, reliability and clinical relevance. The procedure, consisting of surgical craniotomy, fixation of hub followed by induction of injury, resulting in focal and diffuse injuries, is described.

Traumatic brain injury (TBI) research has attained renewed momentum due to the increasing awareness of head injuries, which result in morbidity and ...

Investigations on Alterations of Hippocampal Circuit Function Following Mild Traumatic Brain Injury

Traumatic Brain Injury (TBI) afflicts more than 1.7 million people in the United States each year and even mild TBI can lead to persistent neurological impairments 1. Two pervasive and disabling symptoms experienced by TBI survivors, memory deficits and a reduction in seizure threshold, are thought to be mediated by TBI-induced hippocampal dysfunction 2,3. In order to demonstrate how altered hippocampal circuit function adversely affects behavior after TBI in mice, we employ lateral fluid percussion injury, a commonly used animal model of TBI that recreates many features of human TBI including neuronal cell loss, gliosis, and ionic perturbation 4-6.
	Here we demonstrate a combinatorial method for investigating TBI-induced hippocampal dysfunction. Our approach incorporates multiple ex vivo physiological techniques together with animal behavior and biochemical analysis, in order to analyze post-TBI changes in the hippocampus. We begin with the experimental injury paradigm along with behavioral analysis to assess cognitive disability following TBI. Next, we feature three distinct ex vivo recording techniques: extracellular field potential recording, visualized whole-cell patch-clamping, and voltage sensitive dye recording. Finally, we demonstrate a method for regionally dissecting subregions of the hippocampus that can be useful for detailed analysis of neurochemical and metabolic alterations post-TBI.
	These methods have been used to examine the alterations in hippocampal circuitry following TBI and to probe the opposing changes in network circuit function that occur in the dentate gyrus and CA1 subregions of the hippocampus (see Figure 1). The ability to analyze the post-TBI changes in each subregion is essential to understanding the underlying mechanisms contributing to TBI-induced behavioral and cognitive deficits.
	The multi-faceted system outlined here allows investigators to push past characterization of phenomenology induced by a disease state (in this case TBI) and determine the mechanisms responsible for the observed pathology associated with TBI.

A multi-faceted approach to investigating functional changes to hippocampal circuitry is explained. Electrophysiological techniques are described along with the injury protocol, behavioral testing and regional dissection method. The combination of these techniques can be applied in similar fashion for other brain regions and scientific questions.

Traumatic Brain Injury (TBI) afflicts more than 1.7 million people in the United States each year and even mild TBI can lead to persistent neurological ...

Effects of Blast-induced Neurotrauma on Pressurized Rodent Middle Cerebral Arteries

Though there have been studies on the histopathological and behavioral effects of blast exposure, fewer have been dedicated to blast&#39;s cerebral vascular effects. Impact (i.e., non-blast) traumatic brain injury (TBI) is known to decrease pressure autoregulation in the cerebral vasculature in both humans and experimental animals. The hypothesis that blast-induced traumatic brain injury (bTBI), like impact TBI, results in impaired cerebral vascular reactivity was tested by measuring myogenic dilatory responses to reduced intravascular pressure in rodent middle cerebral arterial (MCA) segments from rats subjected to mild bTBI using an Advanced Blast Simulator (ABS) shock tube. Adult, male Sprague-Dawley rats were anesthetized, intubated, ventilated and prepared for Sham bTBI (identical manipulation and anesthesia except for blast injury) or mild bTBI. Rats were randomly assigned to receive Sham bTBI or mild bTBI followed by sacrifice 30 or 60 min post-injury. Immediately after bTBI, righting reflex (RR) suppression times were assessed, euthanasia at the time points post-injury was completed, the brain was harvested and the individual MCA segments were collected, mounted and pressurized. As the intraluminal pressure perfused through the arterial segments was reduced in 20 mmHg increments from 100 to 20 mmHg, MCA diameters were measured and recorded. With decreasing intraluminal pressure, MCA diameters steadily increased significantly above baseline in the Sham bTBI groups while MCA dilator responses were significantly reduced (p &#60; 0.05) in both bTBI groups as evidenced by the impaired, smaller MCA diameters recorded for the bTBI groups. In addition, RR suppression in the bTBI groups was significantly (p &#60; 0.05) higher than in the Sham bTBI groups. MCA&#39;s collected from the Sham bTBI groups exhibited typical vasodilatory properties to decreases in intraluminal pressure while MCA&#39;s collected following bTBI exhibited significantly impaired myogenic vasodilatory responses to reduced pressure that persisted for at least 60 min after bTBI.

Here, we present a protocol to describe methods for ex vivo vascular reactivity determination following a primary blast traumatic brain injury (bTBI) using isolated, pressurized, rodent middle cerebral arterial (MCA) segments. bTBI induction is accomplished using a shock tube, also known as an Advanced Blast Simulator (ABS) device.

Though there have been studies on the histopathological and behavioral effects of blast exposure, fewer have been dedicated to blast&#39;s cerebral ...

Investigating Alterations in Caecum Microbiota After Traumatic Brain Injury in Mice

Increasing evidence shows that the microbiota-gut-brain axis plays an important role in the pathogenesis of brain diseases. Several studies also demonstrate that traumatic brain injuries cause changes to the gut microbiota. However, mechanisms underlying the bidirectional regulation of the brain-gut axis remain unknown. Currently, few models exist for studying the changes in gut microbiota after traumatic brain injury. Therefore, the presented study combines protocols for inducing traumatic brain injury using a lateral fluid percussion device and analysis of caecum samples following injury for investigating alterations in the gut microbiome. Alterations of the gut microbiota composition after traumatic brain injury are determined using 16S-rDNA sequencing. This protocol provides an effective method for studying the relationships between enteric microorganisms and traumatic brain injury.

Presented here is a protocol to induce diffuse traumatic brain injury using a lateral fluid percussion device followed by the collection of the caecum content for gut microbiome analysis.

Increasing evidence shows that the microbiota-gut-brain axis plays an important role in the pathogenesis of brain diseases. Several studies also ...

Laser-Induced Brain Injury in the Motor Cortex of Rats

A common technique for inducing stroke in experimental rodent models involves the transient (often denoted as MCAO-t) or permanent (designated as MCAO-p) occlusion of the middle cerebral artery (MCA) using a catheter. This generally accepted technique, however, has some limitations, thereby limiting its extensive use. Stroke induction by this method is often characterized by high variability in the localization and size of the ischemic area, periodical occurrences of hemorrhage, and high death rates. Also, the successful completion of any of the transient or permanent procedures requires expertise and often lasts for about 30 minutes. In this protocol, a laser irradiation technique is presented that can serve as an alternative method for inducing and studying brain injury in rodent models.
When compared to rats in the control and MCAO groups, the brain injury by laser induction showed reduced variability in body temperature, infarct volume, brain edema, intracranial hemorrhage, and mortality. Furthermore, the use of a laser-induced injury caused damage to the brain tissues only in the motor cortex unlike in the MCAO experiments where destruction of both the motor cortex and striatal tissues is observed.
Findings from this investigation suggest that laser irradiation could serve as an alternative and effective technique for inducing brain injury in the motor cortex. The method also shortens the time for completing the procedure and does not require expert handlers.

The protocol presented here shows a technique to create a rodent model of brain injury. The method described here uses laser irradiation and targets motor cortex.

A common technique for inducing stroke in experimental rodent models involves the transient (often denoted as MCAO-t) or permanent (designated as MCAO-p) ...

Induction of Diffuse Axonal Brain Injury in Rats Based on Rotational Acceleration

Traumatic brain injury (TBI) is a major cause of death and disability. Diffuse axonal injury (DAI) is the predominant mechanism of injury in a large percentage of TBI patients requiring hospitalization. DAI involves widespread axonal damage from shaking, rotation or blast injury, leading to rapid axonal stretch injury and secondary axonal changes that are associated with a long-lasting impact on functional recovery. Historically, experimental models of DAI without focal injury have been difficult to design. Here we validate a simple, reproducible and reliable rodent model of DAI that causes widespread white matter damage without skull fractures or contusions.

This protocol validates a reliable, easy-to-perform and reproducible rodent model of brain diffuse axonal injury (DAI) that induces widespread white matter damage without skull fractures or contusions.

Traumatic brain injury (TBI) is a major cause of death and disability. Diffuse axonal injury (DAI) is the predominant mechanism of injury in a large ...

Low-intensity Blast Wave Model for Preclinical Assessment of Closed-head Mild Traumatic Brain Injury in Rodents

Traumatic brain injury (TBI) is a large-scale public health problem. Mild TBI is the most prevalent form of neurotrauma and accounts for a large number of medical visits in the United States. There are currently no FDA-approved treatments available for TBI. The increased incidence of military-related, blast-induced TBI further accentuates the urgent need for effective TBI treatments. Therefore, new preclinical TBI animal models that recapitulate aspects of human blast-related TBI will greatly advance the research efforts into the neurobiological and pathophysiological processes underlying mild to moderate TBI as well as the development of novel therapeutic strategies for TBI.
Here we present a reliable, reproducible model for the investigation of the molecular, cellular, and behavioral effects of mild to moderate blast-induced TBI. We describe a step-by-step protocol for closed-head, blast-induced mild TBI in rodents using a bench-top setup consisting of a gas-driven shock tube equipped with piezoelectric pressure sensors to ensure consistent test conditions. The benefits of the setup that we have established are its relative low-cost, ease of installation, ease of use and high-throughput capacity. Further advantages of this non-invasive TBI model include the scalability of the blast peak overpressure and the generation of controlled reproducible outcomes. The reproducibility and relevance of this TBI model has been evaluated in a number of downstream applications, including neurobiological, neuropathological, neurophysiological and behavioral analyses, supporting the use of this model for the characterization of processes underlying the etiology of mild to moderate TBI.

We present here a protocol of a blast wave model for rodents to investigate neurobiological and pathophysiological effects of mild to moderate traumatic brain injury. We established a gas-driven, bench-top setup equipped with pressure sensors allowing for reliable and reproducible generation of blast-induced mild to moderate traumatic brain injury.

Traumatic brain injury (TBI) is a large-scale public health problem. Mild TBI is the most prevalent form of neurotrauma and accounts for a large number of ...

A Metric Test for Assessing Spatial Working Memory in Adult Rats Following Traumatic Brain Injury

Impairments to sensory, short-term, and long-term memory are common side effects after traumatic brain injury (TBI). Due to the ethical limitations of human studies, animal models provide suitable alternatives to test treatment methods, and to study the mechanisms and related complications of the condition. Experimental rodent models have historically been the most widely used due to their accessibility, low cost, reproducibility, and validated approaches. A metric test, which tests the ability to recall the placement of two objects at various distances and angles from one another, is a technique to study impairment in spatial working memory (SWM) after TBI. The significant advantages of metric tasks include the possibility of dynamic observation, low cost, reproducibility, relative ease of implementation, and low stress environment. Here, we present a metric test protocol to measure impairment of SWM in adult rats after TBI. This test provides a feasible way to evaluate physiology and pathophysiology of brain function more effectively.

Traumatic brain injury (TBI) is commonly associated with memory impairment. Here, we present a protocol to assess spatial working memory after TBI via a metric task. A metric test is a useful tool to study spatial working memory impairment after TBI.

Impairments to sensory, short-term, and long-term memory are common side effects after traumatic brain injury (TBI). Due to the ethical limitations of ...

Electromagnetic Controlled Closed-Head Model of Mild Traumatic Brain Injury in Mice

Highly reproducible animal models of traumatic brain injury (TBI), with well-defined pathologies, are needed for testing therapeutic interventions and understanding the mechanisms of how a TBI alters brain function. The availability of multiple animal models of TBI is necessary to model the different aspects and severities of TBI seen in people. This manuscript describes the use of a midline closed head injury (CHI) to develop a mouse model of mild TBI. The model is considered mild because it does not produce structural brain lesions based on neuroimaging or gross neuronal loss. However, a single impact creates enough pathology that cognitive impairment is measurable at least 1 month after injury. A step-by-step protocol to induce a CHI in mice using a stereotaxically guided electromagnetic impactor is defined in the paper. The benefits of the mild midline CHI model include the reproducibility of the injury-induced changes with low mortality. The model has been temporally characterized up to 1 year after the injury for neuroimaging, neurochemical, neuropathological, and behavioral changes. The model is complementary to open skull models of controlled cortical impact using the same impactor device. Thus, labs can model both mild diffuse TBI and focal moderate-to-severe TBI with the same impactor.

The protocol describes mild traumatic brain injury in a mouse model. In particular, a step-by-step protocol to induce a mild midline closed head injury and the characterization of the animal model is fully explained.

Highly reproducible animal models of traumatic brain injury (TBI), with well-defined pathologies, are needed for testing therapeutic interventions and ...

Assessing Changes in Synaptic Plasticity Using an Awake Closed-Head Injury Model of Mild Traumatic Brain Injury

Mild traumatic brain injuries (mTBIs) are a prevalent health issue in North America. There is increasing pressure to utilize ecologically valid models of closed-head mTBI in the preclinical setting to increase translatability to the clinical population. The awake closed-headed injury (ACHI) model uses a modified controlled cortical impactor to deliver closed-headed injury, inducing clinically relevant behavioral deficits without the need for a craniotomy or the use of an anesthetic.
This technique does not normally induce fatalities, skull fractures, or brain bleeds, and is more consistent with being a mild injury. Indeed, the mild nature of the ACHI procedure makes it ideal for studies investigating repetitive mTBI (r-mTBI). Growing evidence indicates that r-mTBI can result in a cumulative injury that produces behavioral symptoms, neuropathological changes, and neurodegeneration. r-mTBI is common in youths playing sports, and these injuries occur during a period of robust synaptic reorganization and myelination, making the younger population particularly vulnerable to the long-term influences of r-mTBI.
Further, r-mTBI occurs in cases of intimate partner violence, a condition for which there are few objective screening measures. In these experiments, synaptic function was assessed in the hippocampus in juvenile rats that had experienced r-mTBI using the ACHI model. Following the injuries, a tissue slicer was utilized to make hippocampal slices to evaluate bidirectional synaptic plasticity in the hippocampus at either 1 or 7 days following the r-mTBI. Overall, the ACHI model provides researchers with an ecologically valid model to study changes in synaptic plasticity following mTBI and r-mTBI.

Here, it is demonstrated how an awake closed-head injury model can be used for examining the effects of repeated mild traumatic brain injury (r-mTBI) on synaptic plasticity in the hippocampus. The model replicates important features of r-mTBI in patients and is used in conjunction with in vitro electrophysiology.

Mild traumatic brain injuries (mTBIs) are a prevalent health issue in North America. There is increasing pressure to utilize ecologically valid models of ...
