This work was supported by the Czech Science Foundation (18-10035S), the National Sustainability Program I (LO1419), institutional support (RVO68378050), the European Regional Development Fund (CZ.02.1.01/0.0/0.0/16_013/0001775) and the Grant Agency of Charles University (GAUK 134516). We further acknowledge the Light Microscopy Core Facility, IMG CAS, Prague, Czech Republic (supported by grants (Czech-Bioimaging - LM2015062).

1. Preparation of snRNAs for Microinjection
<ol>
	<li>Prepare a DNA template containing the full-length or truncated/mutated version of snRNA by PCR using a following PCR setup: 98 &#176;C for 60 s, 98 &#176;C for 15 s, 68 &#176;C for 30 s, 72 &#176;C for 1 min, 98 &#176;C for 15 s for 35x, and 72 &#176;C for 5 min.</li>
	<li>The forward primer must contain a promoter sequence for in vitro transcription just upstream of the first transcribed nucleotide. Amplify U2 snRNA sequence using the forward primer containing the T7 promoter and the reverse primer, which ends with the last transcribed nucleotide (see Table of Materials for details).</li>
	<li>Synthesize snRNA using a kit for short RNA synthesis (see&#160;Table of Materials&#160;for details) containing T7 RNA polymerase. Add 1 mM ATP, 1 mM CTP, 1 mM GTP, 0.8 mM UTP, 0.2 mM UTP-Alexa488, 1.8 mM trimethylguanosine cap analogue (m32,2,7G(5&#8217;)ppp(5&#8217;)G), 1 &#956;L of an RNA inhibitor and 500-700 ng of the DNA template to the reaction mixture and incubate at 37 &#730;C overnight.</li>
	<li>Add 1 &#181;L (2U) of DNase into the reaction and incubate for additional 15 min at 37 &#730;C.</li>
	<li>Isolate snRNA by acidic phenol/chloroform extraction. Remove the top water phase and add 1/10 of the original volume of 3 M sodium acetate (pH = 5.2), 3 &#181;L of glycogen for better pellet visualization and 2.5 volumes of 100% ethanol. Incubate for 1 h at -80 &#730;C, centrifuge for 10 min at 14,000 x g and 4 &#176;C.</li>
	<li>Wash the pellet with 70% ethanol and dissolve in 12 &#181;L of nuclease-free water. The usual RNA yield was around 600 ng/&#956;L. Store at -80 &#176;C.</li>
	<li>Monitor the integrity of in vitro transcribed snRNAs by agarose gel electrophoreses.</li>
	<li>Before microinjection, dilute RNA to the final concentration 200 ng/&#956;L in water containing 10 &#181;g/&#181;L dextran-TRITC 70 kDa.</li>
</ol>
2. Cells
<ol>
	<li>Before the use, treat the coverslips with 1 M HCl for 1 h, wash thoroughly in distilled water and store in 100% ethanol. Acidic treatment promotes cells adhesion to prevent cell peeling during or after injection. For easier identification of injected cells, use a coverslip with a grid.</li>
	<li>Seed HeLa or other adherent cells 1 day before microinjection on 12 mm coverslips (no. 1 or no. 1.5) to reach 50% confluency at the time of microinjection.</li>
</ol>
3. Injection
NOTE: HeLa cells were microinjected in the Dulbecco&#39;s Modified Eagle Medium (D-MEM, 4.5 g/L D-glucose containing phenol red and antibiotics). Injection was carried out using an injector and a micromanipulator equipped with the sterile needle (see Table of Materials for details). The whole microscopic/micromanipulator system was pre-heated to 37 &#176;C for at least 4 h to prevent fluctuation of individual parts of the microscope and the microinjector.
<ol>
	<li>Put the Petri dish (30 mm) containing 2 mL of culture media with the coverslip in the middle into the holder of the microscope. Load 3 &#181;L of snRNA mixture into the needle using a microloader. Install the needle into the holder of the microinjector in 45&#176; with respect to the surface of the Petri dish.</li>
	<li>To find the needle, use a 10x long distance objective. First, set the speed COARSE on the injector and lower the needle until it touches the culture medium. Using the microscope binoculars, find the bright spot, which is the place where the needle touches the culture medium.</li>
	<li>Change the speed to FINE and further lower the needle while looking into the microscope until the tip of the needle is observed. Move the needle in the middle of visual field and switch to a 40x long distance objective.</li>
	<li>After changing the objective, select the cell and move the needle above this cell. Set the pressures and time for the cell contact (see Tips and troubleshooting in discussion).</li>
	<li>Move the needle down into the cell and then set the lower limit on the micromanipulator. Be careful not to move the needle below the cell.</li>
	<li>After setting the lower limit, move the needle back above the cell and press the injection button on the joystick of the injector. The needle moves automatically inside the cell to the place where the limit is set and injects the RNA mixture.</li>
	<li>To finish, push the button MENU on the injector and remove the needle from the holder. Then disconnect the tube from the injector before switching off the injector and the micromanipulator.</li>
</ol>
4. Cell Fixation and Staining
<ol>
	<li>After the microinjection, return the cells into a CO2 incubator and incubate at 37 &#176;C for 1 h.</li>
	<li>After the incubation, rinse the cells three times with phosphate buffered saline solution (PBS) at room temperature, fix for 20 min with 4% paraformaldehyde in 0.1 M PIPES pH 6.9, and wash three times with room temperature PBS. If only snRNA localization is analyzed, briefly rinse the cells in water and mount in a mounting medium with DAPI.</li>
	<li>In case of additional protein localization, permeabilize the cells with 0.5% Triton-X100 in PBS for 5 min at room temperature. After three rinses with PBS, incubate the cells with primary and secondary antibodies and after final washes in PBS and brief rinse in water, mount in a mounting medium with DAPI.</li>
</ol>
5. Microscopy
<ol>
	<li>If not imaged immediately after mounting, store the slides at 4 &#176;C until imaging.</li>
	<li>Acquire images using a high-end fluorescence microscopic system equipped with an immersion objective (60X or 100x/1.4NA).</li>
	<li>Once microinjected cells are identified, collect a stack of 20 z-sections with 200 nm z steps per sample and subject to mathematical deconvolution. Maximal projections or individual z stacks were then presented.</li>
	<li>To quantify the fluorescent signal, draw Region of Interest (ROI) around a Cajal body identified by coilin immunostaining. Measure the intensity of the snRNA signal in the coilin-defined ROI. Next determine the intensity of snRNA fluorescence in ROI randomly placed in the nucleoplasm and calculate the ratio of RNA signal in the Cajal body and nucleoplasm.</li>
</ol>

<ol>
	<li>Ishikawa, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Identification+of+truncated+forms+of+U1+snRNA+reveals+a+novel+RNA+degradation+pathway+during+snRNP+biogenesis.">Identification of truncated forms of U1 snRNA reveals a novel RNA degradation pathway during snRNP biogenesis.</a> Nucleic Acids Research. 42 (4), 2708-2724 (2014).</li><li>Stanek, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cajal+bodies+and+snRNPs+-+friends+with+benefits.">Cajal bodies and snRNPs - friends with benefits.</a> RNA Biology. 14 (6), 671-679 (2017).</li><li>Stanek, D., Fox, A. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nuclear+bodies:+news+insights+into+structure+and+function.">Nuclear bodies: news insights into structure and function.</a> Curentr Opinion in Cell Biology. 46, 94-101 (2017).</li><li>Novotny, I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=SART3-Dependent+Accumulation+of+Incomplete+Spliceosomal+snRNPs+in+Cajal+Bodies.">SART3-Dependent Accumulation of Incomplete Spliceosomal snRNPs in Cajal Bodies.</a> Cell Reports. 10, 429-440 (2015).</li><li>Roithova, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Sm-core+mediates+the+retention+of+partially-assembled+spliceosomal+snRNPs+in+Cajal+bodies+until+their+full+maturation.">The Sm-core mediates the retention of partially-assembled spliceosomal snRNPs in Cajal bodies until their full maturation.</a> Nucleic Acids Research. 46 (7), 3774-3790 (2018).</li><li>Fischer, U., Sumpter, V., Sekine, M., Satoh, T., Luhrmann, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nucleo-cytoplasmic+transport+of+U+snRNPs:+definition+of+a+nuclear+location+signal+in+the+Sm+core+domain+that+binds+a+transport+receptor+independently+of+the+m3G+cap.">Nucleo-cytoplasmic transport of U snRNPs: definition of a nuclear location signal in the Sm core domain that binds a transport receptor independently of the m3G cap.</a> EMBO Journal. 12 (2), 573-583 (1993).</li><li>Shukla, S., Parker, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Quality+control+of+assembly-defective+U1+snRNAs+by+decapping+and+5&#39;-to-3&#39;+exonucleolytic+digestion.">Quality control of assembly-defective U1 snRNAs by decapping and 5&#39;-to-3&#39; exonucleolytic digestion.</a> Proceeding of the National Academy of U S A. 111 (32), E3277-E3286 (2014).</li><li>Weil, T. T., Parton, R. M., Davis, I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Making+the+message+clear:+visualizing+mRNA+localization.">Making the message clear: visualizing mRNA localization.</a> Trends in Cell Biology. 20 (7), 380-390 (2010).</li><li>Klingauf, M., Stanek, D., Neugebauer, K. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Enhancement+of+U4/U6+small+nuclear+ribonucleoprotein+particle+association+in+Cajal+bodies+predicted+by+mathematical+modeling.">Enhancement of U4/U6 small nuclear ribonucleoprotein particle association in Cajal bodies predicted by mathematical modeling.</a> Molecular Biology of the Cell. 17 (12), 4972-4981 (2006).</li><li>Mhlanga, M. M., Vargas, D. Y., Fung, C. W., Kramer, F. R., Tyagi, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=tRNA-linked+molecular+beacons+for+imaging+mRNAs+in+the+cytoplasm+of+living+cells.">tRNA-linked molecular beacons for imaging mRNAs in the cytoplasm of living cells.</a> Nucleic Acids Research. 33 (6), 1902-1912 (2005).</li></ol>

The authors have nothing to disclose.

We employed microinjection of fluorescently labelled snRNAs to determine sequences important for snRNA localization into nuclear Cajal bodies. Due to rapid and rather simple preparation of labelled RNAs (preparation of DNA template by PCR followed by in vitro transcription) the method offers effective analysis of how various sequences contribute to RNA localization. In relatively short time, we were able to analyze ten different deletions or substitutions of the U2 snRNA (reference5 and data not s...

RNA splicing is one of the crucial steps in gene expression, which is catalyzed by a large ribonucleoprotein complex called the spliceosome. In total, more than 150 proteins and 5 small nuclear RNAs (snRNAs) are integrated into the spliceosome at different stages of the splicing pathway. U1, U2, U4, U5 and U6 snRNAs are participating in splicing of major GU-AG introns. These snRNAs join the spliceosome as pre-formed small nuclear ribonucleoprotein particles (snRNPs) that contain snRNA, seven Sm proteins associated with snRNA (or Like-Sm proteins, which associate with the U6 snRNA) and 1-12 proteins specific for each snRNP.
Assembly of snRNPs involves cytoplasmic and nuclear stages. Newly transcribed snRNA is exported to the cytoplasm where it acquires a ring assembled from seven Sm proteins. The Sm ring subsequently serves as a signal for snRNA re-import back to the nucleus. Defective snRNAs that fail to associate with Sm proteins are retained in the cytoplasm1. Newly imported snRNPs first appear in the Cajal body where they meet snRNP-specific proteins and finish their maturation (reviewed in reference2,3). We recently showed that inhibition of final maturation steps results in sequestration of immature snRNPs in Cajal bodies4,5. We proposed a model where the final snRNP maturation is under quality control that monitors addition of snRNP-specific proteins and the formation of active snRNPs. However, molecular details of how cells distinguish between correctly assembled mature and aberrant immature particles remain elusive.
To determine snRNA sequences that are essential for targeting and accumulation of snRNAs in nuclear Cajal bodies, we decided to employ microinjection of fluorescently labelled snRNAs. Microinjection was a method of choice because: 1) it does not require an additional sequence tag to distinguish synthetic snRNAs form their endogenous counterparts which is especially important for short RNAs with little space for insertion of extra tag sequence; 2) it allows analysis of sequences that are important for biogenesis. For example, the Sm sequence is essential for Sm ring assembly and re-import into the nucleus6. When snRNAs are expressed in the cell, snRNAs lacking the Sm sequence are degraded in the cytoplasm and do not reach the nucleus and Cajal bodies7. However, snRNAs without the Sm sequence can be directly microinjected into the nucleus and thus a potential role of the Sm sequence in Cajal body localization assayed.
Here, we describe in detail a microinjection method that we applied to determine snRNA sequences necessary to target snRNAs into the Cajal body5. We showed that Sm and SMN binding sites are together necessary and sufficient to localize not only snRNAs but various short non-coding RNAs into the Cajal body. Based on microinjection as well as other evidence, we proposed that the Sm ring assembled on the Sm binding site is the Cajal body localization signal.

<table>
	<tbody>
		<tr>
			<td>ChromaTide Alexa fluor 488-5-UTP</td>
			<td>ThermoFisher</td>
			<td>C11403</td>
			<td>Stock concentration 1 mM</td>
		</tr>
		<tr>
			<td>Dulbecco&#39;s Modified Eagle Medium - high glucose</td>
			<td>Sigma-Aldrich</td>
			<td>D5796</td>
			<td>Containing 4.5 g&#8260;L D-glucose, Phenol red and antibiotics</td>
		</tr>
		<tr>
			<td>FemtoJet express Injector</td>
			<td>Eppendorf</td>
			<td>5247000013</td>
			<td></td>
		</tr>
		<tr>
			<td>Femtotips II</td>
			<td>Eppendorf</td>
			<td>930000043</td>
			<td>Microinjection needle of 0.5 &#181;m inner and 0.7 &#181;m outer diameter</td>
		</tr>
		<tr>
			<td>Fluoromont G with DAPI</td>
			<td>SouthernBiotech</td>
			<td>0100-20</td>
			<td></td>
		</tr>
		<tr>
			<td>Glycogen</td>
			<td>ThermoFisher</td>
			<td>AM9510</td>
			<td>Stock concentration 5 mg/mL</td>
		</tr>
		<tr>
			<td>Gridded Glass Coverslips</td>
			<td>Ibidi</td>
			<td>10817</td>
			<td>Coverslips with a grid, no direct experience with them</td>
		</tr>
		<tr>
			<td>InjectMan NI 2 Micromanipulator</td>
			<td>Eppendorf</td>
			<td>5181000017</td>
			<td></td>
		</tr>
		<tr>
			<td>m3-2,2,7G(5&#39;)ppp(5&#39;)G trimethyled cap analogue</td>
			<td>Jena Bioscience</td>
			<td>NU-853-1</td>
			<td>Stock concentration 40 mM</td>
		</tr>
		<tr>
			<td>MEGAshortscript T7 Transcription Kit</td>
			<td>ThermoFisher</td>
			<td>AM1354</td>
			<td></td>
		</tr>
		<tr>
			<td>Microscope Cover Glasses 12 mm, No. 1</td>
			<td>Paul Marienfeld GmbH</td>
			<td>111520</td>
			<td>For routine work</td>
		</tr>
		<tr>
			<td>Microscope Cover Glasses 12 mm, No. 1.5</td>
			<td>Paul Marienfeld GmbH</td>
			<td>117520</td>
			<td>For high resolution images</td>
		</tr>
		<tr>
			<td>Microscope DeltaVision</td>
			<td>GE Healthcare</td>
			<td></td>
			<td>For image acquisition</td>
		</tr>
		<tr>
			<td>Microscope DMI6000</td>
			<td>Leica</td>
			<td></td>
			<td>For microinjection</td>
		</tr>
		<tr>
			<td>Paraformaldehyde 32% solution EM grade</td>
			<td>EMS</td>
			<td>15714</td>
			<td>Dissolved in PIPES to the final concentration 4%</td>
		</tr>
		<tr>
			<td>Phenol:Chloroform 5:1</td>
			<td>Sigma-Aldrich</td>
			<td>P1944</td>
			<td></td>
		</tr>
		<tr>
			<td>Primers for U2 amplification: Forward: 5&#8217;-TAATACGACTCACTATAGGGATCGCTTCTCGGCCTTTTGG,
			Reverse: 5&#180; TGGTGCACCGTTCCTGGAGGT</td>
			<td>Sigma-Aldrich</td>
			<td></td>
			<td>T7 rpromoter sequence in italics</td>
		</tr>
		<tr>
			<td>Phusion High Fidelity DNA polymerase</td>
			<td>BioLab</td>
			<td>M0530L</td>
			<td></td>
		</tr>
		<tr>
			<td>RNasin Plus</td>
			<td>Promega</td>
			<td>N2615</td>
			<td>Stock concentration 40 mM</td>
		</tr>
		<tr>
			<td>Tetramethylrhodamine isothiocyanate Dextran 65-85 kDa</td>
			<td>Sigma-Aldrich</td>
			<td>T1162</td>
			<td>Dissolved in water, stock concentration 1 mg/mL</td>
		</tr>
		<tr>
			<td>Triton-X100</td>
			<td>Serva</td>
			<td>37240</td>
			<td>Dissolved in water, stock concentration 10%</td>
		</tr>
	</tbody>
</table>

analysis of spliceosomal snrna localization in human hela cells using microinjection

Biogenesis of spliceosomal snRNAs is a complex process involving both nuclear and cytoplasmic phases and the last step occurs in a nuclear compartment called the Cajal body. However, sequences that direct snRNA localization into this subnuclear structure have not been known until recently. To determine sequences important for accumulation of snRNAs in Cajal bodies, we employed microinjection of fluorescently labelled snRNAs followed by their localization inside cells. First, we prepared snRNA deletion mutants, synthesized DNA templates for in vitro transcription and transcribed snRNAs in the presence of UTP coupled with Alexa488. Labelled snRNAs were mixed with 70 kDa-Dextran conjugated with TRITC, and microinjected to the nucleus or the cytoplasm of human HeLa cells. Cells were incubated for 1 h and fixed and the Cajal body marker coilin was visualized by indirect immunofluorescence, while snRNAs and dextran, which serves as a marker of nuclear or cytoplasmic injection, were observed directly using a fluorescence microscope. This method allows for efficient and rapid testing of how various sequences influence RNA localization inside cells. Here, we show the importance of the Sm-binding sequence for efficient localization of snRNAs into the Cajal body.

To monitor snRNA localization and the role of the Sm binding site in Cajal body targeting, we prepared a DNA template containing the T7 promoter and either the full-length U2 snRNA or U2 snRNA lacking the seven nucleotides (AUUUUUG) forming the Sm binding site. snRNAs were in vitro transcribed, isolated and mixed with TRITC-coupled dextran-70kDa. We microinjected the mixture containing in vitro transcribed snRNA into the nucleus or the cytoplasm of HeLa cells.
It has been previously shown that...

Watch this Scientific Journal Video about Analysis of Spliceosomal snRNA Localization in Human Hela Cells Using Microinjection at JoVE.com

Analysis of Spliceosomal snRNA Localization in Human Hela Cells Using Microinjection

Biogenesis of spliceosomal snRNAs is a complex process involving various cellular compartments. Here, we employed microinjection of fluorescently labelled snRNAs in order to monitor their transport inside the cell.

Biogenesis of spliceosomal snRNAs is a complex process involving both nuclear and cytoplasmic phases and the last step occurs in a nuclear compartment ...
