We want to thank Wladislaw Maier (BMG Labtech GmbH) for his support in establishing the self-written script for the plate reader. This work was supported by the Austrian &#34;Fonds zur F&#246;rderung der wissenschaftlichen Forschung&#34; (FWF) to PM (P24189) and the PhD program &#34;DK Molecular Enzymology&#34; (W901) to PM.

1. Design, Preparation, and Expression of the lux Operon in Escherichia coli
Note: See Table of Materials for information on commercial kits used in this section.
<ol>
	<li>For transferring the lux operon into E. coli choose a standard pET vector with appropriate restriction sites and antibiotic resistance gene of interest (e.g., pET28a; NcoI, XhoI, kanamycin).</li>
	<li>Design the fragments and overlapping primers for Gibson assembly based on the DNA sequence of Photobacterium mandapamensis 27561 (GenBank: DQ988878.2).</li>
	<li>Set up a standard PCR reaction with the designed primers and the isolated genomic DNA of Photobacterium mandapamensis 27561 as template (see Supplemental Material for primers and conditions).
	NOTE: Isolation of genomic DNA of the respective bacterial strain enhances PCR efficacy.</li>
	<li>Purify the PCR product via spin-column purification.</li>
	<li>Perform a restriction digestion of the isolated pET28a vector with NcoI and XhoI at 37 &#176;C for 45 min.</li>
	<li>Purify the linearized vector and the PCR fragments via agarose gel electrophoresis and subsequent spin-column purification.</li>
	<li>Determine the DNA concentration of each fragment and the linearized vector and calculate the optimal quantities for the assembly according to the protocol20,21.
	NOTE: Efficacy of assembly depends on fragment size and number and has to be adjusted according to manufacturer&#39;s protocol20,21.</li>
	<li>After combining all fragments and the buffer in a PCR tube, incubate the assembly mixture in a PCR machine at 50 &#176;C for 1 h.</li>
	<li>Transform the assembled vector product according to standard transformation protocols for E. coli bacterial plasmid transformation into an appropriate E. coli system for high yield plasmid replication (e.g., E. coli TOP10 or XL-1).</li>
	<li>Pick colonies from the transformation plate and streak on new plates for DNA isolation.</li>
	<li>Isolate plasmid DNA according to standard protocols.</li>
	<li>To verify the correct assembly of the plasmid including all fragments, first perform a colony PCR according to standard protocols using primers specific for every assembled fragment.</li>
	<li>Additionally to the colony PCR and subsequent agarose gel electrophoresis, prepare all isolated assembly vectors for DNA sequencing to verify the correct assembly and the correct DNA sequences.</li>
	<li>Transform the verified plasmid according to standard transformation protocols for E. coli bacterial plasmid transformation into an appropriate E. coli system for high yield protein production (e.g.,E. coli BL21).
	NOTE: Continue directly with expression protocol below. For longer storage, the preparation of a glycerol stock is recommended.</li>
</ol>
2. Expression of Modified E. coli Strains
<ol>
	<li>Prepare an overnight culture (ONC) for expression by inoculation of an appropriate volume of LB medium (e.g., 100 mL) with the previously prepared glycerol stock of the E. coli BL21 cells transformed with the assembled plasmid or directly from a transformation plate. Add 100 &#181;L of kanamycin (50 mg/mL; antibiotic resistance gene of pET28a) and incubate the ONC at 37 &#176;C and 120 rpm in an incubator shaker overnight.</li>
	<li>Inoculate the main expression culture (e.g., 800 mL of LB medium) with 8 mL of the ONC and add 800 &#181;L of kanamycin (50 mg/mL).</li>
	<li>Incubate the main culture at 37 &#176;C and 120 rpm in an incubator shaker until the cell density reaches an OD600 of 0.6 - 0.8 (approximately 2.5 h).</li>
	<li>Reduce the incubation temperature to 28 &#176;C.</li>
	<li>Induce protein expression by adding IPTG to a final concentration of 0.1 mM.
	NOTE: Empirical tests showed that the reduction of the temperature to 28 &#176;C gave the highest light intensity.</li>
	<li>Observe cells until they start shining (approximately 1 h).
	NOTE: Depending on the purpose of the expression, the cells are grown until the next day and are then harvested, or the cells can be kept shaking as long as they are shining (maximum 48 h). Harvesting the cells and purification of any proteins can be done according to standard procedures.</li>
</ol>
3. Expression of Bacterial Bioluminescent Strains
NOTE: Bacterial bioluminescent strains require specific growth medium/artificial sea water medium for growth and light production.
<ol>
	<li>Prepare artificial sea water medium, composed of two separately prepared medium components.
	&#8203;NOTE: The preparation of the artificial sea water medium was adapted from the original protocol22. The following amounts are for 1 L liquid medium or 1 L agar medium.
	<ol>
		<li>For artificial sea water medium, weigh in the following salts: 28.13 g NaCl, 0.77 g KCl, 1.60 g CaCl2 &#183; 2H2O, 4.80 g MgCl2 &#183; 6H2O, 0.11 g NaHCO3, and 3.50 g MgSO4 &#183; 7H2O.</li>
		<li>Add 1 L of distilled water and dissolve all components.</li>
		<li>For LB medium, weigh in the following ingredients: 10 g yeast extract, 10 g peptone, and for agar plates, an additional&#160;20 g agar.</li>
		<li>Add 250 mL of tap water and dissolve components.</li>
		<li>Autoclave both prepared media separately at 121 &#176;C for 20 min.</li>
		<li>For agar plates, combine 250 mL of LB medium with 750 mL of artificial sea water medium directly after autoclaving and prepare plates.</li>
		<li>For liquid medium, combine 250 mL of LB medium with 750 mL of artificial sea water medium either directly after autoclaving or when cooled down.
		NOTE: The artificial sea water medium may get turbid through&#160;salt precipitation.</li>
	</ol>
	</li>
	<li>Streak the bacterial bioluminescent strains on artificial sea water medium agar plates and incubate overnight at 24 - 30 &#176;C.
	NOTE: Long time storage of bacterial strains is normally achieved through freezing glycerol stocks of the bacterial culture. Strains should always be streaked on agar plates first to assure uniform&#160;starting conditions for all strains, prior to usage for liquid cultures, due to a lag phase in growth after thawing.</li>
	<li>Prepare an ONC by inoculating 100 mL artificial sea water medium with a single colony from the plate. Incubate the ONC at 24 - 30 &#176;C and 120 rpm in an incubator shaker overnight.</li>
	<li>Inoculate 800 mL of artificial sea water medium with 8 mL of ONC.</li>
	<li>Incubate the bacterial cells at 24 - 30 &#176;C and 120 rpm in an incubator shaker.
	NOTE: The light intensity profile of bioluminescent bacteria strongly varies with temperature. Depending on the regulatory mechanisms of the light production of the respective bacterial strain, light emission may start after approximately 1 - 6 h.</li>
	<li>Observe bacterial cell culture&#160;until they start shining (approximately 1 - 6 h).
	NOTE: Depending on the purpose of the expression, the cells are grown until the next day and are then harvested, or the cells can be kept shaking as long as they are shining. Harvesting the cells and purification of any proteins can be done according to standard procedures.</li>
</ol>
4. In Vivo Activity Assay for Bacterial Bioluminescent Strains and Modified E. coli Strains
NOTE: Long time storage of strains is normally acieved&#160;through freezing glycerol stocks of the bacterial culture. Strains should always be streaked on agar plates first to assure uniform&#160;starting conditions for all strains, prior to usage for liquid cultures, due to a lag phase in growth after thawing.
<ol>
	<li>Streak the desired bioluminescent bacterial strain or modified E. coli strain on an agar plate and incubate at 28 &#176;C overnight.
	NOTE: The incubation temperature can vary from strain to strain and has to be evaluated empirically. To be able to compare bioluminescent bacterial strains and modified E. coli strains, growth conditions have to be identical.</li>
	<li>Inoculate 3 mL of medium with the respective strain with a single colony from an agar plate and incubate the cells at 28 &#176;C and 180 rpm in an incubator shaker for approximately 1 - 2 h.</li>
	<li>Measure the cell density of a 1:10 dilution of the liquid culture at 650 nm. Calculate the ratio and volume for 1 mL culture with an OD650 of 0.05.
	NOTE: The subsequent plate reader assay will determine the cell density at 650 nm to avoid interference by the light emission of the strains.</li>
	<li>Pipette the calculated volume of culture and medium into a 24-well black-walled plate with glass bottom. For the modified E. coli strain, add 1 &#181;L of kanamycin (antibiotic resistance of pET28a vector) and 1 &#181;L of IPTG (induction of gene expression) to the samples. Place a lid on the plate to avoid evaporation during the measurements.
	NOTE: To assure that the pET28a vector containing the whole lux operon does not get lost by the E. coli culture, kanamycin must be added to each E. coli sample in the plate wells and to assure that light production of the E. coli cells can be measured, the gene expression must be induced by IPTG. To avoid crosstalk and measurement interference, black-walled well plates with glass bottom and transparent lid showed best results. Nevertheless, crosstalk can be observed and well positions have to be chosen carefully.</li>
	<li>Start the measurement in a plate reader.
	NOTE: The plate reader protocol is based on a script specially developed for this assay (see Supplemental Material) that combines two measurements, absorbance and bioluminescence. Data points are collected every 10 min with permanent shaking between the measurements and a constant temperature of 28 &#176;C.</li>
</ol>

<ol>
	<li>Widder, E. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bioluminescence+in+the+Ocean:+Origins+of+Biological+Chemical,+and+Ecological+Diversity.">Bioluminescence in the Ocean: Origins of Biological Chemical, and Ecological Diversity.</a> Science. 328 (5979), 704-708 (2010).</li><li>Dunlap, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bioluminescence,+Microbial.">Bioluminescence, Microbial.</a> Encycl Microbiol. , 45-61 (2009).</li><li>Ulitzur, S., Hastings, J. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evidence+for+tetradecanal+as+the+natural+aldehyde+in+bacterial+bioluminescence.">Evidence for tetradecanal as the natural aldehyde in bacterial bioluminescence.</a> Proc Natl Acad Sci USA. 76 (1), 265-267 (1979).</li><li>Kurf&#252;rst, M., Ghisla, S., Hastings, J. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Characterization+and+postulated+structure+of+the+primary+emitter+in+the+bacterial+luciferase+reaction.">Characterization and postulated structure of the primary emitter in the bacterial luciferase reaction.</a> Proc Natl Acad Sci USA. 81, 2990-2994 (1984).</li><li>Dunlap, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Biochemistry+and+genetics+of+bacterial+bioluminescence.">Biochemistry and genetics of bacterial bioluminescence.</a> Biolumin Fundam Appl Biotechnol. 1, 37-64 (2014).</li><li>Meighen, E. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bacterial+Bioluminescence:+Organization,+regulation,+and+application+of+the+lux+genes.">Bacterial Bioluminescence: Organization, regulation, and application of the lux genes.</a> FASEB J. 7, 1016-1022 (1993).</li><li>Moore, S. A., James, M. N. G., O'Kane, D. J., Lee, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Crystallization+of+Photobacterium+leiognathi+non-fluorescent+flavoprotein+with+limited+sequence+identity+to+bacterial+luciferase.">Crystallization of Photobacterium leiognathi non-fluorescent flavoprotein with limited sequence identity to bacterial luciferase.</a> J Mol Biol. 224, 523-526 (1992).</li><li>Moore, S. A., James, M. N. G., O'Kane, D. J., Lee, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Crystal+structure+of+a+flavoprotein+related+to+the+subunits+of+bacterial+luciferase.">Crystal structure of a flavoprotein related to the subunits of bacterial luciferase.</a> EMBO J. 12 (5), 1767-1774 (1993).</li><li>Moore, S. A., James, M. N. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Common+structural+features+of+the+luxF+protein+and+the+subunits+of+bacterial+luciferase:+Evidence+for+a+(&#946;&#945;)8+fold+in+luciferase.">Common structural features of the luxF protein and the subunits of bacterial luciferase: Evidence for a (&#946;&#945;)8 fold in luciferase.</a> Protein Sci. 3, 1914-1926 (1994).</li><li>Moore, S. A., James, M. N. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structural+refinement+of+the+non-fluorescent+flavoprotein+from+Photobacterium+leiognathi+at+1.60+&#197;+resolution.">Structural refinement of the non-fluorescent flavoprotein from Photobacterium leiognathi at 1.60 &#197; resolution.</a> J Mol Biol. 249, 195-214 (1995).</li><li>Kita, A., Kasai, S., Miyata, M., Miki, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structure+of+flavoprotein+FP390+from+a+luminescent+bacterium+Photobacterium+phosphoreum+refined+at+2.7+&#197;+resolution.">Structure of flavoprotein FP390 from a luminescent bacterium Photobacterium phosphoreum refined at 2.7 &#197; resolution.</a> Acta Crystallogr Sect D Biol Crystallogr. 52 (1), 77-86 (1996).</li><li>Bergner, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structural+and+biochemical+properties+of+LuxF+from+Photobacterium+leiognathi.">Structural and biochemical properties of LuxF from Photobacterium leiognathi.</a> Biochim Biophys Acta - Proteins Proteomics. 1854 (10), 1466-1475 (2015).</li><li>Defoirdt, T., Boon, N., Sorgeloos, P., Verstraete, W., Bossier, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Quorum+sensing+and+quorum+quenching+in+Vibrio+harveyi:+Lessons+learned+from+in+vivo+work.">Quorum sensing and quorum quenching in Vibrio harveyi: Lessons learned from in vivo work.</a> ISME J. 2 (1), 19-26 (2008).</li><li>Meighen, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genetics+of+bacterial+bioluminescence.">Genetics of bacterial bioluminescence.</a> Annu Rev Genet. 28, 117-139 (1994).</li><li>Kelkar, M., De, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bioluminescence+based+in+vivo+screening+technologies.">Bioluminescence based in vivo screening technologies.</a> Curr Opin Pharmacol. 12 (5), 592-600 (2012).</li><li>Waidmann, M. S., Bleichrodt, F. S., Laslo, T., Riedel, C. U. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bacterial+luciferase+reporters:+The+Swiss+army+knife+of+molecular+biology.">Bacterial luciferase reporters: The Swiss army knife of molecular biology.</a> Bioeng Bugs. 2 (1), 8-16 (2011).</li><li>Wilson, T., Hastings, J. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Bioluminescence living lights, lights for living. , (2013).</li><li>Gibson, D. G., Young, L., Chuang, R. Y., Venter, J. C., Hutchison, C. A., Smith, H. O. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Enzymatic+assembly+of+DNA+molecules+up+to+several+hundred+kilobases.">Enzymatic assembly of DNA molecules up to several hundred kilobases.</a> Nat Methods. 6 (5), 343-345 (2009).</li><li>Gibson, D. G., Smith, H. O., Hutchison, C. A., Venter, J. C., Merryman, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chemical+synthesis+of+the+mouse+mitochondrial+genome.">Chemical synthesis of the mouse mitochondrial genome.</a> Nat Methods. 7 (11), 901-903 (2010).</li><li>Gibson, D. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Enzymatic+assembly+of+overlapping+DNA+fragments.">Enzymatic assembly of overlapping DNA fragments.</a> Methods Enzymol. 498, 349-361 (2011).</li><li>. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> NEB NEBuilder HiFi DNA Assembly Reaction. , (2015).</li><li>Atlas, R. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Handbook of Microbiological Media, Third Edition. , (2004).</li></ol>

The authors have nothing to disclose.

The construction of an expression plasmid containing four fragments composing the whole lux-rib operon of P. mandapamensis 27561 was achieved via Gibson cloning. This E. coli based lux gene expression enables E. coli cells to emit light. Avoiding quorum sensing regulation and non-standard growth conditions are substantial advantages of this system.
The advantages of using Gibson cloning strategy are the easy assembly of multiple linear DNA fragments, high flexibility and no need for specific restriction sites18,19,20. This method allows to easily change a lux operon, excluding single genes or gene clusters or introducing new genes or exchanging genes from one strain with another. A prerequisite for the application of this method is the availability of the respective lux operon gene sequence. Only for a small number of bioluminescent bacteria is the complete DNA sequence of the respective lux operon known and/or available. Many of these sequences are fragmented because they were generated using shotgun sequencing. In the case of the investigated P. mandapamensis 27561 the complete DNA sequence of the lux operon is known and available from the NCBI gene database (GenBank: DQ988878.2).
One critical step in the protocol of the Gibson assembly is the calculation of the DNA concentration of the single fragments. In the assembly protocol of the manufacturer it was recommended to use 0.2 - 0.5 pmols and a total volume of 20 &#181;L for 4 - 6 fragments20,21. In our case, where luxCDABFEG-ribEBH is comprised of 4 fragments, the concentrations and total volumes were 0.1 pmol and 45 &#181;L, respectively, depending on the yield of PCR products. On the one hand, the concentration had to be reduced and on the other hand, the volume had to be increased. Nevertheless, the assembly worked very well and DNA sequencing confirmed the correct insertion at the first attempt. This finding confirmed Gibson assembly as a robust and appropriate method for our investigations, which can easily be modified18,19,20.
The newly established plate reader assay is an easy to handle method. It enables a simple primary analysis of new or (un-)known bioluminescent bacterial strains and gives already a first hint on the regulatory mechanism of light production (e.g., lag in luminescence at low cell densities). Additionally, growth conditions in combination with light production can easily be evaluated by simply changing growth medium or temperature.
The measurements with the plate reader were performed at 28 &#176;C. The reason for this unusual setting is the temperature sensitivity of bioluminescent bacterial strains, where temperatures above 30 &#176;C lead to less or even no growth and/or light emission. Note, that the plate reader is capable of keeping a defined temperature over time with the limitation of a missing active cooling system. Therefore, the ambient temperature has to be below the temperature of the measurement.
As a proof of concept, the comparison of the E. coli construct with the bioluminescent strain P. mandapamensis (Figure 5) on the one hand and the reference measurements (Figure 4) on the other hand were performed and confirm the reliability of this newly established system. Additionally, the long-term measurement assured the longevity of the light emission (Figure 6). But one has to consider that OD values are not reliable above a certain optical density, depending on the characteristics of the used measurement device (approximately 15 h in the present case) where an appropriate dilution would be needed for a measurement in the linear range of the detector. These high variances in OD values make these long time measurements not reliable. Therefore, shorter measurements such as 10 h are recommended using the experimental setup reported here.
Limitations of the established plate reader assay can be seen in Figure 7. The difficulty is to find an appropriate setting of the measurement. The &#39;gain value&#39; adjusts the sensitivity of the photo multiplier tube (PMT). The gain is the amplification of the signal in the PMT, meaning that a higher gain factor will increase the signal. If the gain is set too low, the signal to noise ratio becomes bigger and light intensities of &#34;low&#34; shining bioluminescent bacteria cannot be measured any more (signals close to zero, data not shown). The challenge in a bioluminescent assay is to set the gain so the measurement results for all bacterial strains stay within the range of the instrument. Additionally, the measurement range for luminescence depends on the measurement interval time (e.g., maximum of 2,000,000 for 1 s).
The gain was set to 2800, which was empirically tested and chosen for the specific plate reader used for the establishment of this method. The used gain setting allows the recording of maximum emitted light by the bioluminescent E. coli system, P. mandapamensis 27561, and P. mandapamensis S1 without an overflow, but for the strains P. mandapamensis TH1 and V. harveyi 14126 the gain was too high. Therefore, these latter strains exceed the detection limit and the real maximal light intensity cannot be measured. This technical limitation might prevent the comparison of bioluminescent bacteria, which show high variations in maximum light emission, although growth conditions and cell densities might be comparable.
Positioning of the analyzed bacterial strains within the used well plates has to be evaluated empirically. Although black well plates with glass bottoms were used, crosstalk between the samples was observed. The light intensity of specific strains is so high, that all neighboring wells will show false positive light emissions (e.g., blank). Therefore, it is important to measure two different strains either separately or with a certain spatial separation to each other.
There are already many modified E. coli strains known that contain parts of the lux operon and are mainly application-oriented15,16,17. The methods described here, aim at fundamental research, for example the possibility of analyzing each lux gene separately. Although research of bioluminescence has a long history, there are still many open questions. By excluding or introducing genes from the lux operon, exchanging the luxAB genes with genes from another strain, or analyzing protein complexes, embedded in the easy to handle E. coli system and further application of the plate reader assay, it might be possible to gain more information on regulatory processes and the functions of lux genes.

The emission of light by living organisms (bioluminescence) is a fascinating process found in bacteria, fungi, insects, nematodes, fish, and squids1. Bioluminescent light emission emerges from a chemiluminescent reaction in which chemical energy is (partially) transformed into light energy (&#34;cold light&#34;). In bioluminescent bacteria, the heterodimeric enzyme luciferase catalyzes the monooxygenation of long chain, aliphatic aldehydes, such as tetradecanal, to the corresponding acids accompanied by light emission with a maximum at 490 nm2,3.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/57881/57881fig1v2.jpg" />
Figure 1: General reaction scheme of bacterial luciferase. The bacterial luciferase (LuxAB) catalyzes the monooxygenation of long chain aldehydes (CH3(CH2)nCHO) by utilizing reduced flavin mononucleotide (FMNH2) and molecular oxygen (O2), yielding the products long chain acids (CH3(CH2)nCOOH), flavin mononucleotide (FMN), water (H2O), and the emission of light centered at 490 nm. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/57881/57881fig1v2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
The energy released during this oxidation causes an excited state FMN-4a-hydroxide, which serves as the light emitting luciferin4. The proteins involved in bacterial bioluminescence, namely LuxCDABEG, are encoded by the lux operon and are highly conserved over various bacterial strains2,5. The genes luxA and luxB encode for the heterodimeric luciferase; luxC&#39;s, luxD&#39;s, and luxE&#39;s gene products are components of a fatty acid reductase complex; and luxG encodes for a flavin reductase6. A number of bioluminescent Photobacteria (e.g.,Photobacterium mandapamensis 27561) carry the additional luxF gene. It was reported that LuxF is a homodimeric protein that binds the unusual flavin derivative 6-(3&#39;-(R)-myristyl)-FMN (myrFMN)7,8,9,10,11,12. Additional genes have been identified that are responsible for riboflavin synthesis (e.g., ribEBH) and furthermore regulatory genes have been reported, that play a role in quorum sensing regulation of bioluminescence, especially for Vibrio fischeri and Vibrio harveyi6,13. Despite the highly conserved gene order, bioluminescent bacteria show high variations in characteristics like growth behavior, intensity of light emission, or regulation of bioluminescence2,5,14.
Several modified strains or plasmids containing parts or whole lux operons are known, exploiting bioluminescence as reporter systems. Various applications such as determining promoter activity, monitoring of bacterial contaminations in environment or food samples, Bioluminescence Resonance Energy Transfer (BRET), in vivo imaging of infections in eukaryotic organisms, pyrosequencing, and so forth were established15,16,17. Interestingly, the three most frequently used bioluminescent reporter systems are derived from the North American firefly (Photinus pyralis), the enteric pathogen of nematodes (Photorhabdus luminescens), and the sea pansy (Renilla reniformis). None of those systems has a bacterial origin, but the use of lux genes and operons from bacterial origins is gaining more interest for applied research16. The less abundant application of bioluminescence proteins from bacterial sources is mainly due to lower stability and longevity of bacteria derived luminescent proteins which can be related to their marine habitats. Bioluminescent bacteria of marine habitats are not cultivable under standard lab conditions. These bacteria require specific growth media and conditions, such as artificial sea water medium and lower growth/incubation temperatures (e.g., 28 &#176;C).
To simplify comparison of lux operon characteristics or single lux genes of a range of different bioluminescent bacterial strains, a method to standardize lux operon expression and analysis is a prerequisite. Thus, the idea of integrating the whole lux-rib operon into the standard-research bacterium Escherichia coli (E. coli) emerged. For this purpose, Gibson assembly proved to be a useful tool to integrate multiple linear, overlapping fragments into one expression vector without the need for specific restriction sites. This method is also suitable when DNA inserts are too large (e.g.,P. mandapamensis 27561 luxCDABFEG-ribEBH; ~ 9 kb operon size) to be amplified via PCR. A lux operon can be separated into multiple overlapping fragments, then be assembled into one expression plasmid and finally the sequence verified assembly product can be directly transformed into an appropriate E. coli system for high yield protein expression18,19,20. In addition to the easy to handle E. coli based lux gene expression, a simple method combining recording of cell growth and bioluminescent light emission remained to be established. The method described here allows the in situ measurement and correlation of cell density and light emission of bioluminescent bacteria.
The analysis of lux genes and lux operon order and regulation of various bioluminescent bacteria with, on the one hand, an artificial bioluminescent E. coli system containing the whole lux-rib operon of P. mandapamensis 27561 and, on the other hand, a newly developed plate reader assay combining the in situ recording of cell density and light emission, helps to gain more information on the various bacterial lux systems. This fundamental characterization and comparison of luciferases and related enzymes may lead to alternatives to the already established reporter systems with enhanced stability and activity.

<table border="0" cellpadding="0" cellspacing="0" style="width:896px;" width="895">
	<colgroup>
		<col />
		<col />
		<col />
		<col />
	</colgroup>
	<tbody>
		<tr height="63">
			<td height="63" style="height:63px;width:335px;">NEBuilder High-Fidelity DNA Assembly Cloning Kit</td>
			<td style="width:171px;">New England Biolabs Inc.</td>
			<td style="width:115px;">E2621S</td>
			<td style="width:276px;">for 10 rxn
			dx.doi.org/10.17504/protocols.io.cwaxad</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Phusion Polymerase&#160;</td>
			<td style="width:171px;">Thermo Scientific</td>
			<td style="width:115px;">F530S</td>
			<td></td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:335px;">Q5 High Fidelity DNA Polymerase</td>
			<td style="width:171px;">New England Biolabs Inc.</td>
			<td style="width:115px;">M0491S</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">GeneJet Genomic DNA Purififcation Kit</td>
			<td style="width:171px;">Thermo Scientific</td>
			<td style="width:115px;">K0721</td>
			<td>for 50 rxn</td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:335px;">Restriction enzymes and buffer (NcoI, XhoI)</td>
			<td style="width:171px;">New England Biolabs Inc.</td>
			<td style="width:115px;">R3193S/R0146S</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Wizard SV Gel and PCR Clean-Up kit&#160;</td>
			<td style="width:171px;">Promega</td>
			<td>A9282</td>
			<td>for 250 rxn</td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;">Monarch DNA Gel Extraction Kit&#160;</td>
			<td style="width:171px;">New England Biolabs Inc.</td>
			<td style="width:115px;">#T1020S</td>
			<td>for 50 rxn</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">GeneJet Plasmid Miniprep Kit&#160;</td>
			<td style="width:171px;">Thermo Scientific</td>
			<td>K0503</td>
			<td>for 250 rxn</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">GoTaq G2 DNA Polymerase</td>
			<td style="width:171px;">Promega</td>
			<td style="width:115px;">M7841</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">24-well black sensoplate with glass bottom</td>
			<td style="width:171px;">Greiner Bio One</td>
			<td style="width:115px;">662892</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">FLUOStar Omega plate reader&#160;</td>
			<td style="width:171px;">BMG Labtech</td>
			<td style="width:115px;"></td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:335px;">OPTIMA/Mars Analysis Software</td>
			<td style="width:171px;">BMG Labtech</td>
			<td style="width:115px;"></td>
			<td>Version 2.20</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:335px;">Microsoft Excel 2010</td>
			<td style="width:171px;">Microsoft</td>
			<td style="width:115px;"></td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:335px;">Multitron Standard Incubator Shaker</td>
			<td style="width:171px;">Infors AG</td>
			<td style="width:115px;"></td>
			<td></td>
		</tr>
	</tbody>
</table>

in situ measurement and correlation of cell density and light emission of bioluminescent bacteria

There is a considerable number of bacterial species capable of emitting light. All of them share the same gene cluster, namely the lux operon. Despite this similarity, these bacteria show extreme variations in characteristics like growth behavior, intensity of light emission or regulation of bioluminescence. The method presented here is a newly developed assay that combines recording of cell growth and bioluminescent light emission intensity over time utilizing a plate reader. The resulting growth and light emission characteristics can be linked to important features of the respective bacterial strain, such as quorum sensing regulation. The cultivation of a range of bioluminescent bacteria requires a specific medium (e.g., artificial sea water medium) and defined temperatures. The easy to handle, non-bioluminescent standard-research bacterium Escherichia coli (E. coli), on the other hand, can be cultivated inexpensively in high quantities in laboratory scale. Exploiting E. coli by introducing a plasmid containing the whole lux operon can simplify experimental conditions and additionally opens up many possibilities for future applications. The expression of all lux genes utilizing an E. coli expression strain was achieved by construction of an expression plasmid via Gibson cloning and insertion of four fragments containing seven lux genes and three rib genes of the lux-rib operon into a pET28a vector. E. coli based lux gene expression can be induced and controlled via Isopropyl-&#946;-D-thiogalactopyranosid (IPTG) addition resulting in bioluminescent E. coli cells. The advantages of this system are to avoid quorum sensing regulation restrictions and complex medium compositions along with non-standard growth conditions, such as defined temperatures. This system enables analysis of lux genes and their interplay, by the exclusion of the respective gene from the lux operon, or even addition of novel genes, exchanging the luxAB genes from one bacterial strain by another, or analyzing protein complexes, such as luxCDE.

The gene order of the lux operon -&#160;luxCDABFEG - is highly conserved over various strains2,5,14. For the design of the plasmid, the sequence information was taken from the bioluminescent bacterial strain Photobacterium mandapamensis 27561 and its gene order was kept the same, and, also, noncoding sequences between single genes were considered. A schematic overview of the applied Gibson cloning strategy is depicted in Figure 2. Four fragments in total, luxCDAB, luxF, luxEG, and ribEBH, with 20 - 40 base pair overlapping sequences were generated. After following all steps of the Gibson assembly20, DNA sequencing confirmed the correct assembly of the plasmid, including all fragments. The vector map of the final assembly product pET28a containing the lux-rib operon is depicted in Figure 3. A significant advantage of this modified pET28a vector is the utilization of standardized E. coli growth conditions and controlled induction with IPTG.
To measure light emission of bioluminescent bacteria and the respective cell density, a plate reader based method was developed. The method for the plate reader was generated combining single measurement scripts for light intensity and cell density. This novel script enabled the measurement of OD650 and light intensity every 10 min for a user defined time frame, which has to be adjusted to the generation time of the bacteria used for the respective analysis (e.g., 10 h). The measurement of the optical density was performed at 650 nm to avoid interference with the light emission. As a proof of concept and to assure the health and the correct growth behavior of the E. coli cells, reference measurements were performed. In Figure 4 the comparison of E. coli BL21 cells, E. coli BL21 cells containing an empty pET28a vector, and E. coli BL21 cells containing the pET28a vector with the lux-rib operon insert are presented. For the latter strain, no IPTG was added to analyze the light emission due to the leakiness of the T7 promoter. All three reference measurements show a sigmoidal growth curve with three growth phases (lag, exponential, and stationary phase). Only the E. coli BL21 cells containing the pET28a vector with the lux-rib operon insert start to emit light, but in contrast to the measurements where expression is induced by addition of IPTG and light is emitted after 30 min, the non-induced cells only start to shine after approximately 5 h and show a much lower light emission (ca. 4-fold) compared to the induced system.
Figure 5&#160;gives a comparison of growth curves and light intensities of the lux operon expressed in E. coli and the bioluminescent bacterial strain P. mandapamensis 27561, either in LB medium or in artificial sea water medium, using the novel established in situ method. To compare these bacteria, the measurements were performed at an incubation temperature of 28 &#176;C. This temperature decreases the growth rate of the modified E. coli strain in LB medium as well as artificial sea water medium, but for bioluminescent bacterial strains lower temperatures are crucial. This temperature dependence is visible in Figure 5A, as P. mandapamensis 27561 shows a much higher cell density than E. coli. Furthermore, while for E. coli strains, LB medium allows generation of higher cell densities, for natural bioluminescent bacterial strains, artificial sea water medium is preferred and essential for bioluminescence. The recorded cell densities correlate with the respective light intensities, as shown in Figure 5B. Noteworthy, the bioluminescent E. coli cells reach similar light emission maxima in both LB medium as well as artificial sea water medium, although the highest intensities were recorded at different time points. In contrast to this observation, P. mandapamensis 27561 is viable with highly reduced growth rates in LB medium, but the bacterial cells did not emit light at all (Figure 5B). In artificial sea water medium, P. mandapamensis 27561 shows a maximum of light emission at around 1 x 104 counts per second, which is nearly a factor of 200 lower than E. coli. Figure 5C represents relative light units where the bioluminescence is normalized by the OD. These results confirm that not only was the insertion of a plasmid containing the lux operon into E. coli successful and functional, but also that this modified E. coli strain is a valid alternative with even higher light emission yields and without the limitation of bacterial bioluminescence of marina bacteria, such as a complex seawater medium and lower temperatures.
Additionally, a long-term measurement of the E. coli based lux-rib gene expression over 24 h was performed to analyze the longevity of the light emission (Figure 6). Light emission lasted for 19.5 h, much longer than the bacterial strains (e.g., P. mandapamensis 27561) where a gradual decrease was observed resulting in very low light emission after 10 h.
To illustrate the limitations of the developed assay, Figure 7 shows the measurement results of three bioluminescent bacterial strains, namely Photobacterium mandapamensis S1, Photobacterium mandapamensis TH1 and Vibrio harveyi 14126. For the first strain (S1), the method works very well and shows a maximal bioluminescence intensity of nearly 2 x 106. For the other two strains (TH1 and 14126), the maximal light intensity cannot be determined because the light intensity generated by both exceeded the detection limit of the used instrument settings. The gain value defined for the developed method (script) for these two strains was set too high. Nevertheless, the onset of bioluminescence activity can be compared with each other. P. mandapamensis TH1 and P. mandapamensis S1 start shining after approximately 1 h and an OD650 value of 0.1 - 0.2, respectively. In contrast, V. harveyi 14126 starts to emit light after approximately 5.5 h at an OD650 value of 1.0. The observed onset of light emission is accompanied by an exponential increase in OD as well as bioluminescence. It is known that bioluminescence of V. harveyi 14126 underlies quorum sensing regulation and therefore a specific cell density allowing the activation of the lux operon, which can be clearly observed in Figure 713. This result demonstrates that with this novel in situ plate reader assay it is possible to easily compare bioluminescent bacteria and also roughly define a regulatory mechanism of these strains by determining whether a quorum sensing regulation can be observed or not.
Figure 8&#160;shows an example of an expression culture of E. coli BL21 cells harboring the assembled pET28a plasmid containing the lux operon after induction with IPTG. After approximately one h after induction, the E. coli cells start shining with a blue-green color. Figure 8A shows the E. coli expression culture photographed in the light and Figure 8B gives the same culture in the dark. Figure 8C depicts an agar plate of artificial sea water medium with P. mandapamensis S1 glowing in the dark in the same blue-green color characteristic for bacterial bioluminescence.
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/57881/57881fig2v3.jpg" />
Figure 2: Schematic representation of the applied Gibson cloning strategy. Step (I): Overlapping primers (colored arrows; ca. 20 - 40 base pair overlap) are designed. Overlapping primers contain annealing sequences consisting of the respective 5&#39; and 3&#39; region of one fragment and the respective 3&#39; and 5&#39; region of the adjacent segment. Step (II): The designed fragments for assembly are generated via standard PCR reactions. Step (III): The target vector is linearized by restriction digestion (e.g., NcoI, XhoI). Step (IV): The DNA concentrations of all fragments and the linearized vector have to be determined to adjust concentration appropriate for Gibson assembly (according to the manufacturer&#39;s protocol). Step (V): All fragments and the linearized vector with optimized DNA concentrations are combined with the Gibson assembly master mix (T5 exonuclease, DNA polymerase, and DNA ligase) and are incubated at 50 &#176;C for 1 h. Step (VI): The assembly product is transformed according to standard protocols into an appropriate E. coli strain for high yield plasmid replication (e.g., E. coli TOP10 or XL-1). Step (VII): To verify the correct assembly of the plasmid, DNA sequencing of the assembled plasmid has to be performed. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/57881/57881fig2v3large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/57881/57881fig3v2.jpg" />
Figure 3: Vector map of pET28a containing the lux-rib operon. The lux-rib operon of P. mandapamensis 27561 is inserted in the multiple cloning site of pET28a in the original gene order (luxCDABFEG-ribEBH). Restriction sites used for cloning are NcoI and XhoI. Fragments used for Gibson assembly of the operon are luxCDAB in orange, luxF in green, luxEG in blue and ribEBH in lavender; genes within a fragment are shown as a separate box. Noncoding sequences between each gene of the operon are included in the applied cloning strategy. The final plasmid size of pET28a containing the whole lux-rib operon is 14,625 base pairs. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/57881/57881fig3v2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 4" class="xfigimg" src="/files/ftp_upload/57881/57881fig4v2.jpg" />
Figure 4:&#160;Comparison of growth curves and light intensities of reference strains. The OD at 650 nm and the bioluminescence intensity in counts per second were measured every 10 min over 10 h at 28 &#176;C. All measurements are mean values of three biological replicates with four technical replicates each. Error bars represent standard deviations. E. coli BL21 cells (grey squares), E. coli BL21 cells containing an empty pET28a vector (grey circles), and E. coli BL21 cells containing the pET28a vector with the lux-rib operon insert (black diamond) were analyzed to assure correct growth behavior of our E. coli cells. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/57881/57881fig4v2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 5" class="xfigimg" src="/files/ftp_upload/57881/57881fig5v2.jpg" />
Figure 5: Comparison of growth curves and light intensities of the lux operon expressed in E. coli (squares) and P. mandapamensis 27561 (circles) in LB medium (open symbols) or artificial sea water medium (filled symbols). All measurements are mean values of three biological replicates with four technical replicates each. Error bars represent standard deviations. All experiments were performed at an incubation temperature of 28 &#176;C. (A) Optical density (OD) measurements at 650 nm were performed every 10 min for 10 h. E. coli lux operon expression (left panel) is compared to P. mandapamensis 27561 (right panel) in LB medium and artificial sea water medium. Cell densities are determined at 650 nm to avoid bioluminescence-interference. (B) Measurement of light intensity (bioluminescence [counts/s]) was performed every 10 min for 10 h. E. coli lux operon expression (left panel) is compared to P. mandapamensis 27561 (right panel) in LB medium and artificial sea water medium. (C) Relative light intensities (RLU/OD) of the lux operon expressed in E. coli (left panel) and P. mandapamensis 27561 (right panel) are determined by normalizing bioluminescence to cell density. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/57881/57881fig5v2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 6" class="xfigimg" src="/files/ftp_upload/57881/57881fig6v2.jpg" />
Figure 6: Comparison of growth curves and light intensities of E. coli based lux gene expression for 24 h. The OD at 650 nm and the bioluminescence intensity in counts per second were measured every 10 min over 24 h at 28 &#176;C. All measurements are mean values of three biological replicates with four technical replicates each. Error bars represent standard deviations. Additionally, the relative light intensities (RLU/OD) where bioluminescence is normalized by cell density are represented. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/57881/57881fig6v2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 7" class="xfigimg" src="/files/ftp_upload/57881/57881fig7v2.jpg" />
Figure 7: Comparison of bioluminescent bacteria to evaluate potential quorum sensing regulation. Light emission and cell density are measured every 10 min for 10 h and represent mean values of three biological replicates with four technical replicates each. Error bars represent standard deviations.Measurements of&#160;Photobacterium mandapamensis TH1 (black squares), Vibrio harveyi 14126 (grey circles) and Photobacterium mandapamensis S1 (grey diamonds) were compared to each other; (A) depicts the optical density (OD) at 650 nm, (B) the light intensity (bioluminescence [counts/s]), and (C) relative light intensities (RLU/OD). <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/57881/57881fig7v2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 8" class="xfigimg" src="/files/ftp_upload/57881/57881fig8.jpg" />
Figure 8: Bioluminescence in liquid media and on agar plates. (A) 5 L flask with 2 L LB medium inoculated with E. coli BL21 cells expressing the pET28a lux operon plasmid photographed in light. (B) The same culture as in (A) photographed in the dark. Pictures A and B were taken approximately 2&#160;h after induction of expression. (C) Artificial sea water medium agar plate with streaked culture of P. mandapamensis S1 photographed in the dark. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/57881/57881fig8large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>

Watch this Scientific Journal Video about In Situ Measurement and Correlation of Cell Density and Light Emission of Bioluminescent Bacteria at JoVE.com

In Situ Measurement and Correlation of Cell Density and Light Emission of Bioluminescent Bacteria

Bioluminescent bacteria regulate light production through a variety of mechanisms, such as quorum sensing. This novel method allows the in situ investigation of bioluminescence and the correlation of light emission to cell density. An artificial bioluminescent Escherichia coli system allows the characterization of lux operons, Lux proteins, and their interplay.

In Situ Measurement and Correlation of Cell Density and Light Emission of Bioluminescent Bacteria

There is a considerable number of bacterial species capable of emitting light. All of them share the same gene cluster, namely the lux operon. Despite ...

in-situ-measurement-correlation-cell-density-light-emission

Research

JoVE Journal

Biochemistry

11.5K Views.  Graz University of Technology. Bioluminescent bacteria regulate light production through a variety of mechanisms, such as quorum sensing. This novel method allows the in situ investigation of bioluminescence and the correlation of light emission to cell density. An artificial bioluminescent Escherichia coli system allows the characterization of lux operons, Lux proteins, and their interplay.

Video: In Situ Measurement and Correlation of Cell Density and Light Emission of Bioluminescent Bacteria

Visualization of Protein-protein Interaction in Nuclear and Cytoplasmic Fractions by Co-immunoprecipitation and In Situ Proximity Ligation Assay

Protein-protein interactions are involved in thousands of cellular processes and occur in distinct spatial context. Traditionally, co-immunoprecipitation is a popular technique to detect protein-protein interactions. Subsequent Western blot analysis is the most common method to visualize co-immunoprecipitated proteins. Recently, the proximity ligation assay has become a powerful tool to visualize protein-protein interactions in situ and provides the possibility to quantify protein-protein interactions by this method. Similar to conventional immunocytochemistry, the proximity ligation assay technique is also based on the accessibility of primary antibodies to the antigens, but in contrast, proximity ligation assay detects protein-protein interactions with a unique technique involving rolling-circle PCR, while conventional immunocytochemistry only shows co-localization of proteins.
Nuclear factor 90 (NF90) and RNA-binding motif protein 3 (RBM3) have been previously demonstrated as interacting partners. They are predominantly localized in the nucleus, but also migrate into the cytoplasm and regulate signaling pathways in the cytoplasmic compartment. Here, we compared NF90-RBM3 interaction in both the nucleus and the cytoplasm by co-immunoprecipitation and proximity ligation assay. In addition, we discussed the advantages and limitations of these two techniques in visualizing protein-protein interactions in respect to spatial distribution and the properties of protein-protein interactions.

Visualization of Protein-protein Interaction in Nuclear and Cytoplasmic Fractions by Co-immunoprecipitation and In Situ Proximity Ligation Assay

Protein-protein interactions can occur in both the nucleus and the cytoplasm of a cell. To investigate these interactions, traditional co-immunoprecipitation and modern proximity ligation assay are applied. In this study, we compare these two methods to visualize the distribution of NF90-RBM3 interactions in the nucleus and the cytoplasm.

Protein-protein interactions are involved in thousands of cellular processes and occur in distinct spatial context. Traditionally, co-immunoprecipitation ...

Measurement of Basal and Forskolin-stimulated Lipolysis in Inguinal Adipose Fat Pads

Lipolysis is a process by which the lipid stored as triglycerides in adipose tissues are hydrolyzed into glycerol and fatty acids. This article describes the method for the measurement of basal and forskolin (FSK)-stimulated lipolysis in the inguinal fat pads isolated from wild type mice fed either normal chow diet (NCD), high fat diet (HFD) or a high fat diet containing 0.01% of capsaicin (CAP; transient receptor potential vanilloid subfamily 1 (TRPV1) agonist) for 32 weeks. The method described here for performing ex vivo lipolysis is adopted from Schweiger et al.1 We present a detailed protocol for measuring glycerol levels by UV-Visible (UV/VIS) spectrophotometry. The method described here can be used to successfully isolate inguinal fat pads for lipolysis measurements to obtain consistent results. The protocol described for inguinal fat pads can readily be extended to measure lipolysis in other tissues.

This protocol describes the method of determining basal and forskolin-stimulated lipolysis in inguinal fat pads obtained from normal chow diet (NCD) or high fat diet (HFD) &plusmn; capsaicin fed wild type mice. As an index for lipolysis, glycerol release was measured from inguinal adipose fat pads.

Lipolysis is a process by which the lipid stored as triglycerides in adipose tissues are hydrolyzed into glycerol and fatty acids. This article describes ...

Biochemical and Structural Characterization of the Carbohydrate Transport Substrate-binding-protein SP0092

Development of new antimicrobials and vaccines for Streptococcus pneumoniae (pneumococcus) are necessary to halt the rapid rise in multiple resistant strains. Carbohydrate substrate binding proteins (SBPs) represent viable targets for the development of protein-based vaccines and new antimicrobials because of their extracellular localization and the centrality of carbohydrate import for pneumococcal metabolism, respectively. Described here is a rationalized integrated protocol to carry out a comprehensive characterization of SP0092, which can be extended to other carbohydrate SBPs from the pneumococcus and other bacteria. This procedure can aid the structure-based design of inhibitors for this class of proteins. Presented in the first part of this manuscript are protocols for biochemical analysis by thermal shift assay, multi angle light scattering (MALS), and size exclusion chromatography (SEC), which optimize the stability and homogeneity of the sample directed to crystallization trials and so enhance the probability of success. The second part of this procedure describes the characterization of the SBP crystals using a tunable wavelength anomalous diffraction synchrotron beamline, and data collection protocols for measuring data that can be used to resolve the crystallized protein structure.

A streamlined protocol for performing an extensive biochemical and structural characterization of a carbohydrate substrate binding protein from Streptococcus pneumoniae is presented.

Development of new antimicrobials and vaccines for Streptococcus pneumoniae (pneumococcus) are necessary to halt the rapid rise in multiple resistant ...

Growing Protein Crystals with Distinct Dimensions Using Automated Crystallization Coupled with In Situ Dynamic Light Scattering

The automated crystallization device is a patented technique1 especially developed for monitoring protein crystallization experiments with the aim to precisely maneuver the nucleation and crystal growth towards desired sizes of protein crystals. The controlled crystallization is based on sample investigation with in situ Dynamic Light Scattering (DLS) while all visual changes in the droplet are monitored online with the help of a microscope coupled to a CCD camera, thus enabling a full investigation of the protein droplet during all stages of crystallization. The use of in situ DLS measurements throughout the entire experiment allows a precise identification of the highly supersaturated protein solution transitioning to a new phase &#8211; the formation of crystal nuclei. By identifying the protein nucleation stage, the crystallization can be optimized from large protein crystals to the production of protein microcrystals. The experimental protocol shows an interactive crystallization approach based on precise automated steps such as precipitant addition, water evaporation for inducing high supersaturation, and sample dilution for slowing induced homogeneous nucleation or reversing phase transitions.

Growing Protein Crystals with Distinct Dimensions Using Automated Crystallization Coupled with In Situ Dynamic Light Scattering

Here we present a protocol for controlled production of protein microcrystals. The process uses an automated device allowing controlled manipulation of several crystallization parameters. The protein crystallization is carried-out by controlled and automated addition of crystallization solutions while monitoring and investigating the radius distribution of particles in the crystallization droplet.

The automated crystallization device is a patented technique1 especially developed for monitoring protein crystallization experiments with the aim to ...

Analysis of SEC-SAXS data via EFA deconvolution and Scatter

BioSAXS is a popular technique used in molecular and structural biology to determine the solution structure, particle size and shape, surface-to-volume ratio and conformational changes of macromolecules and macromolecular complexes. A high quality SAXS dataset for structural modeling must be from monodisperse, homogeneous samples and this is often only reached by a combination of inline chromatography and immediate SAXS measurement. Most commonly, size-exclusion chromatography is used to separate samples and exclude contaminants and aggregations from the particle of interest allowing SAXS measurements to be made from a well-resolved chromatographic peak of a single protein species. Still, in some cases, even inline purification is not a guarantee of monodisperse samples, either because multiple components are too close to each other in size or changes in shape induced through binding alter perceived elution time. In these cases, it may be possible to deconvolute the SAXS data of a mixture to obtain the idealized SAXS curves of individual components. Here, we show how this is achieved and the practical analysis of SEC-SAXS data is performed on ideal and difficult samples. Specifically, we show the SEC-SAXS analysis of the vaccinia E9 DNA polymerase exonuclease minus mutant.

SEC-BioSAXS measurements of biological macromolecules are a standard approach for determining solution structure of macromolecules and their complexes. Here, we analyze SEC-BioSAXS data from two types of commonly encountered SEC traces&#8212;chromatograms with fully resolved and partially resolved peaks. We demonstrate the analysis and deconvolution using scatter and BioXTAS RAW.

BioSAXS is a popular technique used in molecular and structural biology to determine the solution structure, particle size and shape, surface-to-volume ...

Optimizing the Growth of Endothiapepsin Crystals for Serial Crystallography Experiments

Here, a protocol is presented to facilitate the creation of large volumes (&#62; 100 &#181;L) of micro-crystalline slurries suitable for serial crystallography experiments at both synchrotrons and XFELs. The method is based upon an understanding of the protein crystal phase diagram, and how that knowledge can be utilized. The method is divided into three stages: (1) optimizing crystal morphology, (2) transitioning to batch, and (3) scaling. Stage 1 involves finding well diffracting, single crystals, hopefully but not necessarily, presenting in a cube-like morphology. In Stage 2, the Stage 1 condition is optimized by crystal growth time. This strategy can transform crystals grown by vapor diffusion to batch. Once crystal growth can occur within approximately 24 h, a morphogram of the protein and precipitant mixture can be plotted and used as the basis for a scaling strategy (Stage 3). When crystals can be grown in batch, scaling can be attempted, and the crystal size and concentration optimized as the volume is increased. Endothiapepsin has been used as a demonstration protein for this protocol. Some of the decisions presented are specific to endothiapepsin. However, it is hoped that the way they have been applied will inspire a way of thinking about this procedure that others can adapt to their own projects.

The aim of this article is to give the viewer a solid understanding of how to transform their small-volume, vapor-diffusion protocol, for growing large, single protein crystals, into a large-volume batch micro-crystallization method for serial crystallography.

Here, a protocol is presented to facilitate the creation of large volumes (&#62; 100 &#181;L) of micro-crystalline slurries suitable for serial ...

Cell Fractionation of U937 Cells by Isopycnic Density Gradient Purification

This protocol describes a method to obtain subcellular protein fractions from mammalian cells using a combination of detergents, mechanical lysis, and isopycnic density gradient centrifugation. The major advantage of this procedure is that it does not rely on the sole use of solubilizing detergents to obtain subcellular fractions. This makes it possible to separate the plasma membrane from other membrane-bound organelles of the cell. This procedure will facilitate the determination of protein localization in cells with a reproducible, scalable, and selective method. This method has been successfully used to isolate cytosolic, nuclear, mitochondrial, and plasma membrane proteins from the human monocyte cell line, U937. Although optimized for this cell line, this procedure may serve as a suitable starting point for the subcellular fractionation of other cell lines. Potential pitfalls of the procedure and how to avoid them are discussed as are alterations that may need to be considered for other cell lines.

This fractionation protocol will allow researchers to isolate cytoplasmic, nuclear, mitochondrial, and membrane proteins from mammalian cells. The latter two subcellular fractions are further purified via isopycnic density gradient.

This protocol describes a method to obtain subcellular protein fractions from mammalian cells using a combination of detergents, mechanical lysis, and ...

Sample Preparation and Transfer Protocol for In-Vacuum Long-Wavelength Crystallography on Beamline I23 at Diamond Light Source

Long-wavelength macromolecular crystallography (MX) exploits the anomalous scattering properties of elements, such as sulfur, phosphorus, potassium, chlorine, or calcium, that are often natively present in macromolecules. This enables the direct structure solution of proteins and nucleic acids via experimental phasing without the need of additional labelling. To eliminate the significant air absorption of X-rays in this wavelength regime, these experiments are performed in a vacuum environment. Beamline I23 at Diamond Light Source, UK, is the first synchrotron instrument of its kind, designed and optimized for MX experiments in the long wavelength range towards 5 &#197;.
To make this possible, a large vacuum vessel encloses all endstation components of the sample environment. The necessity to maintain samples at cryogenic temperatures during storage and data collection in vacuum requires the use of thermally conductive sample holders. This facilitates efficient heat removal to ensure sample cooling to approximately 50 K. The current protocol describes the procedures used for sample preparation and transfer of samples into vacuum on beamline I23. Ensuring uniformity in practices and methods already established within the macromolecular crystallography community, sample cooling to liquid nitrogen temperature can be performed in any laboratory setting equipped with standard MX tools.
Cryogenic storage and transport of samples only require standard commercially available equipment. Specialized equipment is required for the transfer of cryogenically cooled crystals from liquid nitrogen into the vacuum endstation. Bespoke sample handling tools and a dedicated Cryogenic Transfer System (CTS) have been developed in house. Diffraction data collected on samples prepared using this protocol show excellent merging statistics, indicating that the quality of samples is unaltered during the procedure. This opens unique opportunities for in-vacuum MX in a wavelength range beyond standard synchrotron beamlines.

Here, we present a protocol for cryogenic sample preparation and transfer of crystals into the vacuum endstation on beamline I23 at Diamond Light Source, for long-wavelength macromolecular X-ray crystallography experiments.

Long-wavelength macromolecular crystallography (MX) exploits the anomalous scattering properties of elements, such as sulfur, phosphorus, potassium, ...

Bioluminescent Optogenetics 2.0: Harnessing Bioluminescence to Activate Photosensory Proteins In Vitro and In Vivo

Bioluminescence - light emitted by a luciferase enzyme oxidizing a small molecule substrate, a luciferin - has been used in vitro and in vivo to activate light-gated ion channels and pumps in neurons. While this bioluminescent optogenetics (BL-OG) approach confers a chemogenetic component to optogenetic tools, it is not limited to use in neuroscience. Rather, bioluminescence can be harnessed to activate any photosensory protein, thus enabling the manipulation of a multitude of light-mediated functions in cells. A variety of luciferase-luciferin pairs can be matched with photosensory proteins requiring different wavelengths of light and light intensities.
Depending on the specific application, efficient light delivery can be achieved by using luciferase-photoreceptor fusion proteins or by simple co-transfection. Photosensory proteins based on light-dependent dimerization or conformational changes can be driven by bioluminescence to effect cellular processes from protein localization, regulation of intracellular signaling pathways to transcription. The protocol below details the experimental execution of bioluminescence activation in cells and organisms and describes the results using bioluminescence-driven recombinases and transcription factors. The protocol provides investigators with the basic procedures for carrying out bioluminescent optogenetics in vitro and in vivo. The described approaches can be further extended and individualized to a multitude of different experimental paradigms.

Bioluminescent Optogenetics 2.0: Harnessing Bioluminescence to Activate Photosensory Proteins In Vitro and In Vivo

Bioluminescence-light emitted by a luciferase enzyme oxidizing a small-molecule substrate, a luciferin-can be harnessed to activate photosensory proteins, thereby adding another dimension to light stimulation and enabling the manipulation of a multitude of light-mediated functions in cells across temporal and spatial scales.

Bioluminescence - light emitted by a luciferase enzyme oxidizing a small molecule substrate, a luciferin - has been used in vitro and in vivo to activate ...

An In-House-Built and Light-Emitting-Diode-Based Photodynamic Therapy Device for Enhancing Verteporfin Cytotoxicity in a 2D Cell Culture Model

This paper describes a novel, simple, and low-cost device to perform in vitro photodynamic therapy (PDT) assays, named the PhotoACT. The device was built using a set of conventional programmable light-emitting diodes (LEDs), a liquid crystal display (LCD) module, and a light sensor connected to a commercial microcontroller board. The box-based structure of the prototype was made with medium-density fiberboards (MDFs). The internal compartment can simultaneously allocate four cell culture multiwell microplates.
As a proof of concept, we studied the cytotoxic effect of the photosensitizer (PS) verteporfin against the HeLa cell line in two-dimensional (2D) culture. HeLa cells were treated with increasing concentrations of verteporfin for 24 h. The drug-containing supernatant medium was discarded, the adherent cells were washed with phosphate-buffered saline (PBS), and drug-free medium was added. In this study, the effect of verteporfin on cells was examined either without light exposure or after exposure for 1 h to light using red-green-blue (RGB) values of 255, 255, and 255 (average fluence of 49.1 &#177; 0.6 J/cm2). After 24 h, the cell viability was assessed by the 3-(4,5-dimethyl-2-thiazolyl)-2,5-diphenyltetrazolium bromide (MTT) assay.
Experimental results showed that exposure of cells treated with verteporfin to the light from the device enhances the drug&#39;s cytotoxic effect via a mechanism mediated by reactive oxygen species (ROS). In addition, the use of the prototype described in this work was validated by comparing the results with a commercial PDT device. Thus, this LED-based photodynamic therapy prototype represents a good alternative for in vitro studies of PDT.

Here, we describe a novel, simple, and low-cost device to successfully perform in vitro photodynamic therapy (PDT) assays using two-dimensional HeLa cell culture and verteporfin as a photosensitizer.

This paper describes a novel, simple, and low-cost device to perform in vitro photodynamic therapy (PDT) assays, named the PhotoACT. The device was built ...

In Situ Measurement and Correlation of Cell Density and Light Emission of Bioluminescent Bacteria

Summary

Explore More Videos

Chapters in this video

Visualization of Protein-protein Interaction in Nuclear and Cytoplasmic Fractions by Co-immunoprecipitation and In Situ Proximity Ligation Assay

Measurement of Basal and Forskolin-stimulated Lipolysis in Inguinal Adipose Fat Pads

Biochemical and Structural Characterization of the Carbohydrate Transport Substrate-binding-protein SP0092

Growing Protein Crystals with Distinct Dimensions Using Automated Crystallization Coupled with In Situ Dynamic Light Scattering

Analysis of SEC-SAXS data via EFA deconvolution and Scatter

Optimizing the Growth of Endothiapepsin Crystals for Serial Crystallography Experiments

Cell Fractionation of U937 Cells by Isopycnic Density Gradient Purification

Sample Preparation and Transfer Protocol for In-Vacuum Long-Wavelength Crystallography on Beamline I23 at Diamond Light Source

Bioluminescent Optogenetics 2.0: Harnessing Bioluminescence to Activate Photosensory Proteins In Vitro and In Vivo

An In-House-Built and Light-Emitting-Diode-Based Photodynamic Therapy Device for Enhancing Verteporfin Cytotoxicity in a 2D Cell Culture Model
