Part of this work was conducted through collaboration with Prof. Hiroki R. Ueda (University of Tokyo), Prof. Etsuo A. Susaki (Juntendo University), Prof. Tetsuhiro Tanaka (Tohoku University), Prof. Masafumi Fukagawa, Dr. Takehiko Wada, and Dr. Hirotaka Komaba (Tokai University).

All experiments were approved by the University of Tokyo Institutional Review Board. All animal procedures were performed according to the National Institutes of Health guidelines. Male C57BL/6NJcl mice, 8 weeks old, were used for the present study. The mice were obtained from commercial sources (see Table of Materials).
1. Animal preparation and kidney fixation
<ol>
	<li>Perform perfusion fixation following the steps below.
	<ol>
		<li>Anesthetize the mouse by inhalation of isoflurane (3%, 2.0 L/min) and intraperitoneal administration of medetomidine hydrochloride (0.3 mg/kg), butorphanol tartrate (5 mg/kg), and midazolam (4 mg/kg) (see Table of Materials).</li>
		<li>Perfuse the animal with 20 mL of PBS (pH 7.4) and 30 mL of 4% PFA in phosphate buffer (PB) through the left ventricle of the heart12.</li>
	</ol>
	</li>
	<li>Perform the immersion fixation just after the perfusion fixation and kidney sampling9.
	<ol>
		<li>Immerse the kidney in 4% PFA at 4 &#176;C for an additional 16 h, then wash it with PBS for 2 h (three times)9 (Figure 1).
		&#8203;CAUTION: Formaldehyde and paraformaldehyde are toxic irritants. Handle reagents in a fume hood with appropriate personal protective equipment.</li>
	</ol>
	</li>
</ol>
2. Decolorization and delipidation
<ol>
	<li>Prepare CUBIC-L for decolorization and delipidation consisting of 10 wt% of Triton X-100 and 10 wt% of N-buthyldiethanolamine (see Table of Materials), following previously published reports4,8,9.</li>
	<li>Perform decolorization and delipidation by CUBIC-L following the steps below.
	<ol>
		<li>Immerse the fixed kidney in 7 mL of 50% (v/v) CUBIC-L (1:1 mixture of water and CUBIC-L) in a 14 mL round bottom tube (see Table of Materials) with gentle shaking at room temperature for 6 h (Figure 2A). Then, immerse it in 7 mL of CUBIC-L in a 14 mL round bottom tube with gentle shaking at 37 &#176;C for 5 days.</li>
		<li>Refresh CUBIC-L every day during this process. After the decolorization and delipidation process, wash the kidney with PBS at room temperature for 2 h (three times)9 (Figure 1). Use a dispensing spoon for sample handling (Figure 2B).</li>
	</ol>
	</li>
</ol>
3. Whole-mount immunofluorescent staining
<ol>
	<li>Prepare the staining buffers.
	<ol>
		<li>Prepare the staining buffer for primary antibodies by mixing 0.5% (v/v) Triton X-100, 0.5% casein in PBS, and 0.05% sodium azide9.</li>
		<li>Prepare the staining buffer for secondary antibodies by mixing 0.5% (v/v) Triton X-100, 0.1% casein in PBS, and 0.05% sodium azide9.</li>
	</ol>
	</li>
	<li>Perform staining with primary antibodies.
	<ol>
		<li>Immunostain the delipidated kidney with primary antibodies (1:100 or 1:200, see Table of Materials) in the staining buffer at 37 &#176;C with gentle shaking for 7 days.
		NOTE: The amount of the staining buffer needed for one kidney is 500-600 &#181;L (Figure 2C).</li>
		<li>Wash the kidney with 0.5% (v/v) Triton X-100 in PBS (PBST) at room temperature for 1 day9 (Figure 1).</li>
	</ol>
	</li>
	<li>Perform staining with secondary antibodies.
	<ol>
		<li>Immunostain the kidney with secondary antibodies (1:100 or 1:200, see Table of Materials) in the staining buffer at 37 &#176;C with gentle shaking for 7 days. Wash the kidney with PBST at room temperature for 1 day9 (Figure 1).</li>
		<li>Post fixation9, immerse the kidney in 1% formaldehyde in PB (1:36 mixture of 37% formaldehyde and PB) for 3 h, and wash it with PBS at room temperature for 6 h (Figure 1).</li>
	</ol>
	</li>
</ol>
4. Refractive index (RI) matching
<ol>
	<li>Prepare CUBIC-R+.
	<ol>
		<li>Prepare CUBIC-R by mixing 45 wt% of 2,3-dimethyl-1-phenyl-5-pyrazolone/antipyrine and 30 wt% of nicotinamide (see Table of Materials).</li>
		<li>Prepare CUBIC-R+ for refractive index (RI) matching by adding 0.5 v% of N-buthyldiethanolamine to CUBIC-R following the previously published reports4,8,9.</li>
	</ol>
	</li>
	<li>Perform the RI matching.
	<ol>
		<li>Immerse the kidney in 7 mL of 50% (v/v) CUBIC-R+ (1:1 mixture of water and CUBIC-R+) in a 14 mL round bottom tube with gentle shaking at room temperature for 1 day. Then, immerse it in 7 mL of CUBIC-R+ in a 14 mL round bottom tube with gentle shaking at room temperature for 2 days9 (Figure 1).
		NOTE: Although the kidney floats in 50% CUBIC-R+ at the beginning of the RI matching, it sinks and becomes transparent in CUBIC-R+ at the end of the process (Figure 2D).</li>
	</ol>
	</li>
</ol>
5. Image acquisition and reconstruction
<ol>
	<li>Immerse the RI-matched kidney in a mixture of silicon oil (RI = 1.555) and mineral oil (RI = 1.467) (55:45) during image acquisition (RI = 1.51)5 (Figure 3).</li>
	<li>Acquire 3D images of the whole kidney with a custom-built9 light-sheet fluorescent microscope (see Table of Materials). Collect all raw image data in a 16-bit TIFF format. Visualize and capture the 3D-rendered images with the imaging analysis software (Imaris, see Table of Materials).</li>
</ol>

<ol>
	<li>Velez-Fort, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+stimulus+selectivity+and+connectivity+of+layer+six+principal+cells+reveals+cortical+microcircuits+underlying+visual+processing.">The stimulus selectivity and connectivity of layer six principal cells reveals cortical microcircuits underlying visual processing.</a> Neuron. 83 (6), 1431-1443 (2014).</li><li>Susaki, E. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Whole-brain+imaging+with+single-cell+resolution+using+chemical+cocktails+and+computational+analysis.">Whole-brain imaging with single-cell resolution using chemical cocktails and computational analysis.</a> Cell. 157 (3), 726-739 (2014).</li><li>Erturk, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Three-dimensional+imaging+of+solvent-cleared+organs+using+3DISCO.">Three-dimensional imaging of solvent-cleared organs using 3DISCO.</a> Nature Protocols. 7 (11), 1983-1995 (2012).</li><li>Tainaka, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chemical+Landscape+for+Tissue+Clearing+Based+on+Hydrophilic+Reagents.">Chemical Landscape for Tissue Clearing Based on Hydrophilic Reagents.</a> Cell Reports. 24 (8), 2196-2210 (2018).</li><li>Susaki, E. A., Ueda, H. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Whole-body+and+whole-organ+clearing+and+imaging+techniques+with+single-cell+resolution:+toward+organism-level+systems+biology+in+mammals.">Whole-body and whole-organ clearing and imaging techniques with single-cell resolution: toward organism-level systems biology in mammals.</a> Cell Chemical Biology. 23 (1), 137-157 (2016).</li><li>Keller, P. J., Dodt, H. U. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Light+sheet+microscopy+of+living+or+cleared+specimens.">Light sheet microscopy of living or cleared specimens.</a> Current Opinion in Neurobiology. 22 (1), 138-143 (2012).</li><li>Susaki, E. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advanced+CUBIC+protocols+for+whole-brain+and+whole-body+clearing+and+imaging.">Advanced CUBIC protocols for whole-brain and whole-body clearing and imaging.</a> Nature Protocols. 10 (11), 1709-1727 (2015).</li><li>Kubota, S. I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Whole-body+profiling+of+cancer+metastasis+with+single-cell+resolution.">Whole-body profiling of cancer metastasis with single-cell resolution.</a> Cell Reports. 20 (1), 236-250 (2017).</li><li>Hasegawa, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comprehensive+three-dimensional+analysis+(CUBIC-kidney)+visualizes+abnormal+renal+sympathetic+nerves+after+ischemia/reperfusion+injury.">Comprehensive three-dimensional analysis (CUBIC-kidney) visualizes abnormal renal sympathetic nerves after ischemia/reperfusion injury.</a> Kidney International. 96 (1), 129-138 (2019).</li><li>Hasegawa, S., Inoue, T., Inagi, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neuroimmune+interactions+and+kidney+disease.">Neuroimmune interactions and kidney disease.</a> Kidney Research and Clinical Practice. 38 (3), 282-294 (2019).</li><li>Hasegawa, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+oral+hypoxia-inducible+factor+prolyl+hydroxylase+inhibitor+enarodustat+counteracts+alterations+in+renal+energy+metabolism+in+the+early+stages+of+diabetic+kidney+disease.">The oral hypoxia-inducible factor prolyl hydroxylase inhibitor enarodustat counteracts alterations in renal energy metabolism in the early stages of diabetic kidney disease.</a> Kidney International. 97 (5), 934-950 (2020).</li><li>Gage, G. J., Kipke, D. R., Shain, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Whole+animal+perfusion+fixation+for+rodents.">Whole animal perfusion fixation for rodents.</a> Journal of Visualized Experiments. (65), e3564 (2012).</li><li>Hasegawa, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Activation+of+sympathetic+signaling+in+macrophages+blocks+systemic+inflammation+and+protects+against+renal+ischemia-reperfusion+injury.">Activation of sympathetic signaling in macrophages blocks systemic inflammation and protects against renal ischemia-reperfusion injury.</a> Journal of the American Society of Nephrology. 32 (7), 1599-1615 (2021).</li><li>Renier, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=iDISCO:+a+simple,+rapid+method+to+immunolabel+large+tissue+samples+for+volume+imaging.">iDISCO: a simple, rapid method to immunolabel large tissue samples for volume imaging.</a> Cell. 159 (4), 896-910 (2014).</li><li>Klingberg, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fully+automated+evaluation+of+total+glomerular+number+and+capillary+tuft+size+in+nephritic+kidneys+using+lightsheet+microscopy.">Fully automated evaluation of total glomerular number and capillary tuft size in nephritic kidneys using lightsheet microscopy.</a> Journal of the American Society of Nephrology. 28 (2), 452-459 (2017).</li><li>Zhao, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cellular+and+molecular+probing+of+intact+human+organs.">Cellular and molecular probing of intact human organs.</a> Cell. 180 (4), 796-812 (2020).</li><li>Susaki, E. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Versatile+whole-organ/body+staining+and+imaging+based+on+electrolyte-gel+properties+of+biological+tissues.">Versatile whole-organ/body staining and imaging based on electrolyte-gel properties of biological tissues.</a> Nature Communications. 11 (1), 1-22 (2020).</li></ol>

The authors have nothing to disclose.

The present protocol allowed whole-kidney 3D imaging of various structures such as sympathetic nerves, collecting ducts, arteries, proximal tubules, and glomeruli9,10,11. This staining method offered macroscopic observation and led to new biological discoveries, by visualizing the alteration in renal sympathetic nerves after ischemia-reperfusion injury9,10 and glomerulom...

The kidney is composed of various cell populations. Although conventional pathology gives us much information about the kidney microenvironment, three-dimensional (3D) imaging is needed to precisely understand the intercellular crosstalk during kidney disease progression. In the past, a huge number of serial sectioning and image reconstruction needed to be performed for the whole-organ 3D imaging1. However, this method required too much effort and had problems in terms of reproducibility.
Optical clearing is a good strategy to overcome this hurdle2,3. Tissue opacity is mainly due to light scattering and absorption because each organ consists of various substances, including water, protein, and lipids. Thus, the basic strategy of tissue clearing is replacing water and lipids in tissues with refractive index (RI) matching reagents that have the same optical properties as proteins4. In order to observe a transparent specimen, a light sheet fluorescent microscopy is useful5. Light sheets illuminate the transparent specimen from the side, and excitation signals are acquired through the objective lens located in a vertical position6. This microscopy obtains cross-section information in a single sweep, which is different from the confocal or multiphoton fluorescent microscopy. Thus, it can quickly acquire z-stack images with a low level of photobleaching.
Clear, Unobstructed Brain/Body Imaging Cocktails and Computational Analysis (CUBIC) is one of the tissue clearing methods which enables whole-organ imaging by light sheet fluorescent microscopy2,7,8. CUBIC and whole-mount immunofluorescent staining are optimized in the present study to visualize mouse kidney 3D structures9,10,11. Using this whole-mount staining method, the alteration in renal sympathetic nerves is visualized after ischemia-reperfusion injury9,10 and glomerulomegaly in the early stage of diabetic kidney disease11, as well as blood vessels, proximal tubules, and collecting ducts in a whole kidney9.

<table><tbody><tr><td>14 mL Round Bottom High Clarity PP Test Tube</td><td>Falcon</td><td>352059</td><td>Tissue clearing, staining, wash</td></tr><tr><td>2,3-dimethyl-1-phenyl-5-pyrazolone/antipyrine</td><td>Tokyo Chemical Industry</td><td>D1876</td><td>CUBIC-R+</td></tr><tr><td>37%-Formaldehyde Solution</td><td>Nacalai Tesque</td><td>16223-55</td><td>Post fixation</td></tr><tr><td>4%-Paraformaldehyde Phosphate Buffer Solution</td><td>Nacalai Tesque</td><td>09154-85</td><td>Kidney fixation</td></tr><tr><td>Alexa Flour 555-conjugated donkey anti-sheep IgG antibody</td><td>Invitrogen</td><td>A-21436</td><td>Secondary antibody (1:100)</td></tr><tr><td>Alexa Flour 647-conjugated donkey anti-rabbit IgG antibody</td><td>Invitrogen</td><td>A-31573</td><td>Secondary antibody (1:200)</td></tr><tr><td>Anti-aquaporin 2 (AQP2) antibody</td><td>Abcam</td><td>ab199975</td><td>Primary antibody (1:100)</td></tr><tr><td>Anti-podocin antibody</td><td>Sigma-Aldrich</td><td>P0372</td><td>Primary antibody (1:100)</td></tr><tr><td>Anti-sodium glucose cotransporter 2 (SGLT2) antibody</td><td>Abcam</td><td>ab85626</td><td>Primary antibody (1:100)</td></tr><tr><td>Anti-tyrosine hydroxylase (TH) antibody</td><td>Abcam</td><td>ab113</td><td>Primary antibody (1:100)</td></tr><tr><td>Anti-&amp;alpha;-smooth muscle actin (&amp;alpha;-SMA) antibody</td><td>Abcam</td><td>ab5694</td><td>Primary antibody (1:200)</td></tr><tr><td>Blocker Casein in PBS</td><td>Thermo Fisher Scientific</td><td>37528</td><td>Staining buffer</td></tr><tr><td>Butorphanol Tartrate</td><td>Meiji</td><td>005526</td><td>Anesthetic</td></tr><tr><td>C57BL/6NJcl</td><td>Nippon Bio-Supp.Center</td><td>N/A</td><td>Mouse strain</td></tr><tr><td>Imaris</td><td>Bitplane</td><td>N/A</td><td>Imaging analysis software</td></tr><tr><td>Macro-zoom microscope</td><td>OLYMPUS</td><td>MVX10</td><td>The observation unit of the custom-built microscope</td></tr><tr><td>Medetomidine Hydrochloride</td><td>Kyoritsu-Seiyaku</td><td>008656</td><td>Anesthetic</td></tr><tr><td>Midazolam</td><td>SANDOZ</td><td>27803229</td><td>Anesthetic</td></tr><tr><td>Mineral oil</td><td>Sigma-Aldrich</td><td>M8410</td><td>Immersion oil</td></tr><tr><td>N-buthyldiethanolamine</td><td>Tokyo Chemical Industry</td><td>B0725</td><td>CUBIC-L, CUBIC-R+</td></tr><tr><td>Nicotinamide</td><td>Tokyo Chemical Industry</td><td>N0078</td><td>CUBIC-R+</td></tr><tr><td>Polyethylene glycol mono-p-isooctylphenyl ether/Triton X-100</td><td>Nacalai Tesque</td><td>12967-45</td><td>CUBIC-L, PBST</td></tr><tr><td>Silicon oil HIVAC-F4</td><td>Shin-Etsu Chemical</td><td>50449832</td><td>Immersion oil</td></tr><tr><td>Sodium azide</td><td>Wako</td><td>195-11092</td><td>Staining buffer</td></tr></tbody></table>

whole-kidney three-dimensional staining with cubic

Although conventional pathology provided numerous information about kidney microstructure, it was difficult to know the precise structure of blood vessels, proximal tubules, collecting ducts, glomeruli, and sympathetic nerves in the kidney due to the lack of three-dimensional (3D) information. Optical clearing is a good strategy to overcome this big hurdle. Multiple cells in a whole organ can be analyzed at single-cell resolution by combining tissue clearing and 3D imaging technique. However, cell labeling methods for whole-organ imaging remain underdeveloped. In particular, whole-mount organ staining is challenging because of the difficulty in antibody penetration. The present protocol developed a whole-mount mouse kidney staining for 3D imaging with the CUBIC (Clear, Unobstructed Brain/Body Imaging Cocktails and Computational analysis) tissue clearing method. The protocol has enabled visualizing renal sympathetic denervation after ischemia-reperfusion injury and glomerulomegaly in the early stage of diabetic kidney disease from a comprehensive viewpoint. Thus, this technique can lead to new discoveries in kidney research by providing a macroscopic perspective.

Using this staining method, sympathetic nerves [anti-tyrosine hydroxylase (TH) antibody] and arteries [anti-&#945;-smooth muscle actin (&#945;SMA) antibody] in a whole kidney (Figure 4A,B and Video 1) were visualized9. Abnormal renal sympathetic nerves were also visualized after ischemia/reperfusion injury (IRI)9,10 (Figure 4C). Moreover, visualiz...

Watch this Scientific Journal Video about Whole-Kidney Three-Dimensional Staining with CUBIC at JoVE.com

Whole-Kidney Three-Dimensional Staining with CUBIC

The present protocol describes a tissue clearing method and whole-mount immunofluorescent staining for three-dimensional (3D) kidney imaging. This technique can offer macroscopic perspectives in kidney pathology, leading to new biological discoveries.

Although conventional pathology provided numerous information about kidney microstructure, it was difficult to know the precise structure of blood ...
