This work was supported by National Natural Science Foundation of China (No. 81922076, 81973951, 81873373), Construction project of collaborative innovation of shanghai (No. ZYJKFW201811010, ZYJKFW201701005).

All animal experiments were reviewed and approved by the Committee on the Ethics of Animal Experiments of Shanghai University of Traditional Chinese Medicine (Ethical clearance number PZSHUTCM190308020).
1. Fabrication of the high platform
<ol>
	<li>Set the length and width of the supporting device to 86 cm x 17 cm (Figure 1).</li>
	<li>Fix the connecting device vertically to the supporting device. The connecting device should be approximately 30 cm long to prevent the rat from running to the top surface of the high platform and have a width of 14 cm.</li>
	<li>Fix the horizontal pedal (5 cm x 5 cm) to the connecting device. The suspended height at the bottom of the horizontal pedal should be greater than or equal to 50 cm.
	NOTE: Depending on the number of experimental rats, multiple horizontal pedals can be used, with one rat placed on each pedal.</li>
</ol>
2. Establishment of a rat model of asthma
<ol>
	<li>Sensitizing the rats with OVA
	<ol>
		<li>Prepare the sensitization solution on day 0. Prepare each 1 mL of the sensitization solution with 1 mg of OVA and 10 mg of aluminum hydroxide, with normal saline as the solvent.</li>
		<li>Intraperitoneally inject each rat with 1 mL of the sensitization solution on day 0. Draw the sensitizing solution with a suitable syringe for later use.</li>
		<li>Grab the tail and lift up the rat, place it on a rough surface, and gently pull the tail back. Grasp the skin of both ears and neck with the left thumb and index finger while tightly holding the back skin with the remaining three fingers and palms (be careful to refrain from applying excess force that will suffocate the rat).</li>
		<li>With the right hand, perform an intraperitoneal injection in the rat with the prepared syringe with 1 mL of the sensitization solution.</li>
	</ol>
	</li>
	<li>Challenging rats with OVA
	<ol>
		<li>Select a box with a lid (the length, width and height are 39 cm x 28 cm x 23 cm), and drill a small hole in the side. Connect the sealed box, nebulizing cup and the compression nebulizer with a rubber tube (Supplementary Figure 1).
		NOTE: The nebulized particle size of the compressed nebulizer is 1 - 5 &#956;m, the nebulization rate is greater than 0.2 mL/min, and the ultimate pressure is 205 kPa.</li>
		<li>On the 14th day after sensitization, open the lid of the homemade sealed box and place the rat in the box (the box can accommodate 5 rats), and then put the sealed box in a biosafety cabinet.</li>
		<li>Prepare the challenge solution. Thoroughly mix 300 mg of OVA with 30 mL of normal saline.</li>
		<li>Turn on the ultrasonic nebulizer and add 30 mL of the challenge solution into the nebulizing cup. Adjust the dosage of challenge solution and the number of rats according to the volume of the homemade sealed box.</li>
		<li>Repeat nebulization several times (once a day) or adjust the procedure according to the severity of asthma symptoms.</li>
	</ol>
	</li>
</ol>
3. Acupuncture treatment
<ol>
	<li>Select acupoints, including GV14, bilateral BL12 and bilateral BL13, according to the theory of traditional Chinese medicine for treating asthma (Supplementary Figure 2). Administer manual acupuncture on day 2 and perform once every other day for a total of 7 session (Figure 2).
	<ol>
		<li>Acupuncture the GV14 located between the seventh cervical vertebra and the first thoracic vertebra (the hollow of the scapula), on the midline of the back (Figure 3).</li>
		<li>Acupuncture the BL13 located below the third thoracic vertebra, on both sides of the intercostal spaces (lower edge of the scapula).</li>
		<li>Acupuncture the BL12 located below the second thoracic vertebra, on both sides of the intercostal spaces (below the scapula, position identified according to BL13).</li>
	</ol>
	</li>
	<li>Grasp the rats and place them on the high platform.</li>
	<li>Hold the disposable stainless-steel needle (0.3 mm x&#160;13.0 mm, Supplementary Figure 3) handle with the thumb and index finger of the right hand, and press the back of the rat with the palm of the right hand.
	NOTE: Disposable needles must be one-time-use only. Because repeated use will blunt the needle, which leads to increased pain in rats.</li>
	<li>Touch the depression in the middle of the upper edge (GV14) or the lower edge of the scapula (BL12 and BL13), and then gently prick the skin of the rat with the needle tip to locate the acupoints.</li>
	<li>Quickly insert the needle after determining the specific location of the acupoint and rapidly remove the right hand.</li>
	<li>Evenly twisted the needles approximately 360&#176; at a rate of 60 times/min for 10 - 20 s, manipulate them every 5 min, and then withdraw them after 20 - 30 min (Supplementary Figure 4).</li>
</ol>
4. The Penh measurement
<ol>
	<li>Prepare methacholine: Place 100 mg of methacholine into a 5 mL centrifuge tube and add PBS to a volume of 2 mL (50 mg/mL methacholine). Then, dilute the 50 mg/mL methacholine solution to 25 mg/mL, 12.5 mg/mL, 6.25 mg/mL and 3.125 mg/mL.</li>
	<li>Instrument inspection
	<ol>
		<li>Turn on the signal amplifier (the aerosol distribution system and the rodent bias flow supply system are all turned off, and the nebulization connector is closed).</li>
		<li>Check the channels: Click Calibrate, return the coarse adjustment baseline to 0 and switch to the direct current (DC) position. Fine-tune the baseline to 0 and inject 5 mL of gas with a syringe. Then, switch to the alternating current (AC) position.</li>
		<li>After checking the channels, ensure that the error value is less than 0.5%.</li>
	</ol>
	</li>
	<li>Setting parameters
	<ol>
		<li>Turn on the aerosol distribution system and the rodent bias flow supply system. Adjust the flow rate to 4.5 mL according to the liquid level on the mercury ball.</li>
		<li>Click Create Study Options and select Dose Response Study, select Rat of species and click Next.</li>
		<li>Select Simple Dose List, set the Number of Doses to 6 and click Next.</li>
		<li>Select the Penh and Area parameters: Set the animal adaptation time to 5 min, the nebulization time to 2 min, the response time to 3 min, and the recovery time to 2 min.</li>
		<li>Sequentially add the following solutions to the nebulizer (200 &#956;L per rat): methacholine (0 mg/mL, 3.125 mg/mL, 6.25 mg/mL, 12.5 mg/mL, 25 mg/mL and 50 mg/mL). Real-time changes in Penh can be observed (Figure 4).</li>
		<li>After all 6 solutions with different concentrations have been reacted, click File and End Session to complete the experiment.</li>
	</ol>
	</li>
</ol>

<ol>
	<li>Papi, A., Brightling, C., Pedersen, S. E., Reddel, H. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Asthma.">Asthma.</a> Lancet. 391 (10122), 783-800 (2018).</li><li>. Global strategy for asthma management and prevention Available from: <a target="_blank" href="https://ginasthma.org/gina-reports/">https://ginasthma.org/gina-reports/</a> (2019)</li><li>Enilari, O., Sinha, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Global+Impact+of+Asthma+in+Adult+Populations.">The Global Impact of Asthma in Adult Populations.</a> Annals of Global Health. 85 (1), (2019).</li><li>. Global strategy for asthma management and prevention Available from: <a target="_blank" href="https://ginasthma.org/gina-reports/">https://ginasthma.org/gina-reports/</a> (2020)</li><li>Zhuang, Y., Xing, J. J., Li, J., Zeng, B. Y., Liang, F. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=History+of+acupuncture+research.">History of acupuncture research.</a> International Review of Neurobiology. 111, 1-23 (2013).</li><li>Yang, Y. Q., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Considerations+for+use+of+acupuncture+as+supplemental+therapy+for+patients+with+allergic+asthma.">Considerations for use of acupuncture as supplemental therapy for patients with allergic asthma.</a> Clinical Reviews in Allergy &amp; Immunology. 44 (3), 254-261 (2013).</li><li>Nurwati, I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reduction+of+interleukin-17+level+by+acupuncture+at+Feishu+(BL13)+is+strengthened+by+acupuncture+at+Zusanli+(ST36)+in+a+mouse+model+of+chronic+asthma:+An+experimental+study.">Reduction of interleukin-17 level by acupuncture at Feishu (BL13) is strengthened by acupuncture at Zusanli (ST36) in a mouse model of chronic asthma: An experimental study.</a> Medical Acupuncture. 27 (4), 278-282 (2015).</li><li>Nurwati, I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Improvement+in+inflammation+and+airway+remodelling+after+acupuncture+at+BL13+and+ST36+in+a+mouse+model+of+chronic+asthma.">Improvement in inflammation and airway remodelling after acupuncture at BL13 and ST36 in a mouse model of chronic asthma.</a> Acupuncture in Medicine. 37 (4), 228-236 (2019).</li><li>Reddy, A. T., Lakshmi, S. P., Reddy, R. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Murine+model+of+allergen+induced+asthma.">Murine model of allergen induced asthma.</a> Journal of Visualized Experiments. (63), e3771 (2012).</li><li>Zhou, D. D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Metallothionein-2+is+associated+with+the+amelioration+of+asthmatic+pulmonary+function+by+acupuncture+through+protein+phosphorylation.">Metallothionein-2 is associated with the amelioration of asthmatic pulmonary function by acupuncture through protein phosphorylation.</a> Biomedicine &amp; Pharmacotherapy. 123, 109785 (2020).</li><li>Yin, L. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transgelin-2+as+a+therapeutic+target+for+asthmatic+pulmonary+resistance.">Transgelin-2 as a therapeutic target for asthmatic pulmonary resistance.</a> Science Translational Medicine. 10 (427), (2018).</li><li>Shin, Y. S., Takeda, K., Gelfand, E. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Understanding+asthma+using+animal+models.">Understanding asthma using animal models.</a> Allergy Asthma &amp; Immunology Research. 1 (1), 10-18 (2009).</li><li>Cui, K. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Electro-acupuncture+relieves+chronic+visceral+hyperalgesia+in+rats.">Electro-acupuncture relieves chronic visceral hyperalgesia in rats.</a> Neuroscience Letters. 376 (1), 20-23 (2005).</li><li>Tobin, J. R., Martin, L. D., Breslow, M. J., Traystman, R. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Selective+anesthetic+inhibition+of+brain+nitric+oxide+synthase.">Selective anesthetic inhibition of brain nitric oxide synthase.</a> Anesthesiology. 81 (5), 1264-1269 (1994).</li><li>Dimitrov, N., Sivrev, D., Atanasova, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Method+of+rat+immobilization+during+experimental+acupuncture.">Method of rat immobilization during experimental acupuncture.</a> Scripta Scientifica Medica. 45, 105-108 (2013).</li><li>Aguilar, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=emotional+reactivity+and+fear+of+heights:+a+factor+analytic+map+from+a+large+F(2)+intercross+of+Roman+rat+strains.">emotional reactivity and fear of heights: a factor analytic map from a large F(2) intercross of Roman rat strains.</a> Brain Research Bulletin. 57 (2), 17-26 (2002).</li><li>Lai, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Proteomic+response+to+acupuncture+treatment+in+spontaneously+hypertensive+rats.">Proteomic response to acupuncture treatment in spontaneously hypertensive rats.</a> PloS One. 7 (9), 44216 (2012).</li><li>Niu, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+novel+uni-acupoint+electroacupuncture+stimulation+method+for+pain+relief.">A novel uni-acupoint electroacupuncture stimulation method for pain relief.</a> Evidence-Based Complementary and Alternative Medicine. 2011, 209879 (2011).</li><li>McFadden, E. R., Luparello, T., Lyons, H. A., Bleecker, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+mechanism+of+action+of+suggestion+in+the+induction+of+acute+asthma+attacks.">The mechanism of action of suggestion in the induction of acute asthma attacks.</a> Psychosomatic Medicine. 31 (2), 134-143 (1969).</li><li>Savov, J. D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ozone-induced+acute+pulmonary+injury+in+inbred+mouse+strains.">Ozone-induced acute pulmonary injury in inbred mouse strains.</a> American Journal of Respiratory Cell and Molecular Biology. 31 (1), 69-77 (2004).</li></ol>

The authors have nothing to disclose.

The GV14, bilateral BL12 and bilateral BL13 acupoints used in this study are located on the back, and thus the high platform is suitable for fixing rats. In other studies, an adequate fixation method should be selected according to the position of the acupoints15. For acupoints on the abdomen, the rat can be placed downward in a black cone (similar to a pastry bag used by bakers)17. A chain is attached to the restraint cone for fixation, and the hind leg of the rat is also ...

Asthma is a chronic disease characterized by bronchoconstriction and airway hyper-responsiveness1. Approximately 339.4 million people worldwide are diagnosed with asthma2. The prevalence of asthma is increasing globally, with 100 million new cases expected in the next decade3. Inhaled corticosteroids and long-acting &#946;2-agonists do not effectively control the symptoms of all patients4. Therefore, the use of alternative therapies such as acupuncture to treat asthma has been receiving increased attention5. An effective method for treating asthma is to needle GV14 (Dazhui), bilateral BL12 (Fengmen) and bilateral BL13 (Feishu)6. Acupuncture significantly reduces the levels of secretory immunoglobulin A (SIgA) in the saliva and nasal secretions of patients with allergic asthma and reduces peripheral blood eosinophil counts with a total effective rate of 85%6. Acupuncture at BL13 and ST36 (Zusanli) in mice with chronic asthma decreases the level of IL-17 by 40% and decreases the smooth muscle thickness by 33% compared with that of the ovalbumin (OVA) group, and thus relieving inflammation symptoms7,8. However, the mechanism of acupuncture treatment for asthma is not completely clear.
Animal models are an important tool for asthma research9 because the animal model can be used for the continuous measurement of respiratory function to assess the effectiveness of the asthma treatment10. Meanwhile, studies of the pathophysiology of asthma require test samples, including samples from the trachea, lung and bronchoalveolar lavage to verify changes in the levels of key factors11. Rat models of asthma are commonly used to assess asthma pathophysiology because they produce long-lasting airway responses and show immediate and late-phase airway responses12. However, due to repeated experimental stimulation, the rats often become irritable. Therefore, a suitable method to fix rats is needed. Commonly used methods for rat fixation include anesthesia and binding13. Although the anesthesia method provides better exposure of the acupoints, it may affect nerve conduction and ultimately affect the experimental results14. The binding method does not induce the same physiological effects as anesthesia, but restrained rats will experience skeletal muscle tension. Also, the needle cannot easily reach the designated position15. Here, we introduce a high platform that can be used to fix rats without restricting them and fully expose the acupoints on the back. The rats can be placed on the high platform during the administration of acupuncture. The high platform is able to accommodate the rat only while it is standing, and as it is placed a certain distance from the ground, the rats will not move because of a fear of heights16.
This article describes in detail the fabrication of the high platform, the establishment of a rat model of asthma, the operation of needling a rat on the high platform and the measurement of respiratory function using a whole-body plethysmography (WBP) system.

<table><tbody><tr><td>0.3 mm x 13.0 mm acupuncture needle</td><td>China Suzhou Medical Device Factory</td><td></td><td></td></tr><tr><td>Al(OH)&lt;sub&gt;3&lt;/sub&gt;</td><td>American Thermo</td><td>77161</td><td></td></tr><tr><td>Compression nebulizer</td><td>Jiangsu Lude Medical Electronics Co., Ltd.</td><td>NB-212C</td><td></td></tr><tr><td>Fine Pointe V2.0</td><td>American Buxco</td><td></td><td></td></tr><tr><td>Laboratory gas drying unit</td><td>American Drierite</td><td>26800</td><td></td></tr><tr><td>Methacholine</td><td>American Sigma</td><td>MKCF6054</td><td></td></tr><tr><td>Ovalbumin</td><td>American Sigma</td><td>A5503-25G</td><td></td></tr><tr><td>Phosphate Buffer solution (1x)</td><td>Gelifesciences</td><td>SH30256.01</td><td></td></tr><tr><td>Seal box</td><td>IRIS Corporation of Japan</td><td></td><td></td></tr><tr><td>Whole-body plethysmography respiratory function measurement system</td><td>American Buxco</td><td></td><td></td></tr></tbody></table>

acupuncture in a rat model of asthma

A high platform can fix rats without restriction and completely expose the acupoints on the back during acupuncture manipulation. This article describes methods for the fabrication of the high platform, establishes a rat model of asthma and measures changes in respiratory function using a noninvasive and real-time whole-body plethysmography (WBP) system.

With acupuncture at the GV14, bilateral BL12 and bilateral BL13 points, the rat maintains a prone position. The rat can twist its head only to the outside and not the inside because one direction is blocked with a wooden board (Figure 5).
As the methacholine concentration increased, Penh shows an increasing trend and the growth rate gradually increases. At concentrations of 3.125 mg/mL, 6.25 mg/mL, 12.5 mg/mL, 25 mg/mL and 50 mg/mL, Penh increased by 18.40% &#177;...
