VJ和HS承认NIH R01 GM094246支持VJ。 HS承认克莱姆森大学创意咨询计划和克莱姆森大学光学材料科学和工程技术中心的创业资金。该项目还得到了墨西哥湾沿岸联盟跨学科生物科学培训凯克中心（NIGMS Grant No.1 T32GM089657-05）的训练奖学金和Schissler基金会DD普通人类疾病转化研究奖学金的支持。内容完全是作者的责任，并不一定代表美国国立卫生研究院的官方观点。

所有作者都宣称与本文的内容没有竞争的经济利益。

在这项工作中，提出了使用PIE-MFD单分子FRET实验以高精度对准，校准和测量干涉距离的方案。通过仔细校准所有仪器参数，可以提高测量距离的精度并达到Angstrom精度。为了做到这一点，使用各种多维直方图来分析和识别人群以进一步表征。使用平均宏观时间来验证测量样品的稳定性，可以基于化学计量参数来校正供体和受体光漂白并选择FRET群体。然而，受体的光物理性质可以根据标签的位置而?...

结构生物学研究的一个基本目标是揭示生物分子机器的结构与功能之间的关系。生物分子（ 例如，蛋白质和核酸）的第一个视觉印象发生在20世纪50年代，通过开发X射线晶体学1,2 。 X射线晶体学提供了由晶体包装约束的高分辨率静态结构信息。因此，X射线结构模型的固有不动性可以避免生物分子的动态性质，这是影响大多数生物学功能的因素3,4,5 。核磁共振（NMR） 6,7,8提供了解决水溶液中结构模型的问题的替代方案。一个很大的优势的NMR是其恢复生物分子和构象集合的内在动力学特性的能力，有助于阐明结构，动力学和功能之间的内在关系3,4,5。然而，由样品量和大量样品限制的NMR对较大系统需要复杂的标记策略。因此，迫切需要开发结构生物学中的替代方法。 历史上，Förster共振能量转移（FRET） 9在结构生物学中没有发挥重要作用，因为FRET提供了低精度距离测量的误解。该协议的目的是重新审视FRET确定纳米尺度的距离，使得这些距离可用于构建生物分子的结构模型。第一个实验验证通过测量各种长度的聚合物作为"光谱尺"，1967年10号由Stryer在FRET效率方面的依赖性。在2005年的单分子水平上完成了类似的实验11 。聚脯氨酸分子被证明是非理想的，因此后来使用双链DNA分子12 。这打开了精确距离测量的窗口和使用FRET识别生物分子的结构特性的想法。 当干涉距离范围为〜0.6-1.3 R 0时，FRET最佳，其中R 0是Förster距离。对于在单分子FRET实验中使用的典型荧光团， R 0为〜50。通常，与其他方法相比，FRET在解决和区分结构和动态的能力方面提供了许多优势异质系统:（i）由于荧光的最终灵敏度，单分子FRET实验13,14,15,16可以通过直接计数和同时表征其各个成员的结构来解析异质集合。 （ii）复合反应途径可以在单分子FRET研究中直接解密，因为不需要整体的同步。 （iii）FRET可以及时访问跨越十多年的各种时间领域，涵盖各种各样的生物相关动态。 （iv）FRET实验可以在体外和体内的任何溶液条件下进行 。 FRET与荧光显微镜的组合允许直接在活细胞中研究分子结构和相互作用15,16 ， </<html> sup&gt; 17，18，19 ，甚至高精度20 。 （v）FRET可以应用于几乎任何大小的系统（ 例如，聚脯氨酸低聚物21,22,23,24，Hsp90 25 ，HIV逆转录酶26和核糖体27 ）。 （vi）最后，包含生物分子的所有维度的距离网络可用于导出静态或动态分子的结构模型18,28,29,30,31,32,33,34 ，参考"&gt; 35,36,37。 因此，单分子FRET光谱可用于导出足够精确的距离以用于距离限制结构建模26 。这可以通过利用八维尺寸的荧光信息（ 即激发光谱，荧光光谱，各向异性，荧光寿命，荧光量子产率等）的多参数荧光检测（MFD）28,38,39,40,41,42的优点，宏观时间，荧光强度和荧光团之间的距离）精确而准确地提供距离限制。另外，脉冲交错激励（PIE）与MFD组合（PIE-MFD） 42以监测直接激发受体荧光并选择由含有1:1供体 - 受体化学计量的样品产生的单分子事件。典型的PIE-MFD设置使用连接到共聚焦显微镜主体的双脉冲交错激光激光器，其中光子检测在不同光谱窗口和偏振特性中分为四个不同的通道。更多细节见图1 。 重要的是要注意，FRET必须结合计算方法来实现与FRET结果26,30相符合的类原子结构模型。目前的协议的目的不在于使用FRET衍生距离来构建结构模型的相关方法。然而，这些方法已经与其他技术（ 例如，小角度X射线散射）结合使用或电子顺磁共振），产生了整合结构生物学领域43,44,45,46。目前的目标是为FRET作为结构生物学的定量工具铺平道路。作为示例，该方法用于鉴定N-甲基-D-天冬氨酸（NMDA）受体的配体结合结构域（LBD）中的三种构象状态。最终的目标是克服上述限制，并通过提供高精度的测量距离将FRET引入用于结构测定生物分子的综合方法。

<table><tbody><tr><td>charcoal</td><td>Merck KGaA</td><td>K42964486 320</td><td></td></tr><tr><td>syringe filter</td><td>Fisherbrand</td><td>09-719C</td><td>size: 0.20 &amp;micro;m</td></tr><tr><td>chambered coverglass</td><td>Fisher Scientific</td><td>155409</td><td>1.5 borosilicate glass, 8 wells</td></tr><tr><td>microscope cover glass</td><td>Fisher Scientific</td><td>063014-9</td><td>size: 24 x 60-1.5</td></tr><tr><td>Nuclease free water</td><td>Fisher Scientific</td><td>148859</td><td>nuclease free</td></tr><tr><td>tween-20</td><td>Thermo Scientific</td><td>28320</td><td>10% solution of Polysorbate 20</td></tr><tr><td>acceptor DNA strand (High FRET)</td><td>Integrated DNA Technologies</td><td>178124895</td><td>5&amp;acute;-d(CGG CCT ATT TCG GAG TTG TAA ACA GAG AT(Cy5)C GCC TTA AAC GTT CGC CTA GAC TAG TCC AAG TAT TGC)</td></tr><tr><td>acceptor DNA strand (Low FRET)</td><td>Integrated DNA Technologies</td><td>177956424</td><td>5&amp;acute;-d(CGG CCT ATT TCG GAG TTG TAA ACA GAG ATC GCC TT(Cy5)A AAC GTT CGC CTA GAC TAG TCC AAG TAT TGC)</td></tr><tr><td>donor DNA strand</td><td>Integrated DNA Technologies</td><td>177951437</td><td>5&amp;acute; -d(GCA ATA CTT GGA CTA GTC TAG GCG AAC GTT TAA GGC GAT CTC TGT TT(Alexa488)A CAA CTC CGA AAT AGG CCG)</td></tr><tr><td>DNA strand (No FRET)</td><td>Integrated DNA Technologies</td><td></td><td>5&amp;acute; -d(CGG CCT ATT TCG GAG TTG TAA ACA GAG ATC GCC TTA AAC GTT CGC CTA GAC TAG TCC AAG TAT TGC)</td></tr><tr><td>thermal cycler</td><td>Eppendorf</td><td>E6331000025</td><td>nexus gradient</td></tr><tr><td>Alexa Fluor 488 C5&amp;nbsp;Maleimide</td><td>Thermo Scientific</td><td>A10254</td><td>termed cyan-green fluorophore in the manuscript</td></tr><tr><td>Alexa Fluor 647 C2&amp;nbsp;Maleimide</td><td>Thermo Scientific</td><td>A20347</td><td>termed far-red fluorophore in the manuscript</td></tr><tr><td>Rhodamine 110</td><td>Sigma-Aldrich</td><td>83695-250MG</td><td></td></tr><tr><td>Rhodamine 101</td><td>Sigma-Aldrich</td><td>83694-500MG</td><td></td></tr><tr><td>LB Broth, Miller</td><td>Fisher Scientific</td><td>BP1426</td><td>For culture of &lt;em&gt;E. coli&lt;/em&gt;</td></tr><tr><td>Ampicillin</td><td>Sigma-Aldrich</td><td>A0166</td><td>Used at 100 &amp;micro;g/mL final concentration in selective LB medium to maintain plasmid selection</td></tr><tr><td>Tetracyline&amp;nbsp;</td><td>Calbiochem</td><td>58346</td><td>Used at 12.5 &amp;micro;g/mL final concentration in selective LB medium to maintain gor (flutathione reductase) mutation in Origami B(DE3) strains to facilitate disulfide bond oxidation</td></tr><tr><td>Kanamycin</td><td>Fisher Scientific</td><td>BP906-5</td><td>Used at 15 &amp;micro;g/mL final concentration in selective LB medium to maintain trxB (rhioredoxin reductase) mutation in B(DE3) stains to facilitate disulfide bond oxidation</td></tr><tr><td>Origami B(DE3) Competent Cells</td><td>Millipore</td><td>70837-3</td><td>Competent &lt;em&gt;E. coli&lt;/em&gt; cells for expression of protein with disulfide bridges</td></tr><tr><td>Isopropyl-&amp;beta;-D-thiogalactopyranoside (IPTG)</td><td>Fisher Scientific</td><td>BP1755</td><td>For induction of &lt;em&gt;E. coli&lt;/em&gt; protein expression</td></tr><tr><td>HiTrap Chelating HP</td><td>GE Life Sciences</td><td>17-0409-01</td><td>For Large-scale FPLC Purification of His-tagged protein</td></tr><tr><td>Imidazole</td><td>Sigma-Aldrich</td><td>56749</td><td></td></tr><tr><td>Ni-NTA Agarose&amp;nbsp;</td><td>Qiagen</td><td>30210</td><td></td></tr><tr><td>PD-10 Desalting Column</td><td>GE Life Sciences</td><td>17-0851-01</td><td></td></tr><tr><td>AktaPurifier</td><td>GE Life Sciences</td><td>28406264</td><td>FPLC Instrument</td></tr><tr><td>Dialysis tubing</td><td>Spectrum labs</td><td>132562</td><td>15 kD MWCO 24 mm Flath width, 10 meters/roll</td></tr><tr><td>Dichroics</td><td>Semrock</td><td>FF500/646-Di01-25x36</td><td>500/646 BrightLight</td></tr><tr><td>50/50 Beam splitter polarizer</td><td>Qioptiq Linos&amp;nbsp;</td><td>G33 5743 000</td><td>10 x 10 film polarizer</td></tr><tr><td>Green pass filer</td><td>Chroma</td><td>ET525/50m</td><td>ET525/50m 25 mm diameter mount</td></tr><tr><td>Red pass filter</td><td>Chroma</td><td>ET720/150m</td><td>ET720/150m 25 mm diameter mount</td></tr><tr><td>Power Meter</td><td>ThorLabd</td><td>PM200</td><td></td></tr><tr><td>UV-Vis spectrophotometer</td><td>Varian</td><td>Cary300Bio</td><td></td></tr><tr><td>Fluorolog 3 fluorometer</td><td>Horiba</td><td>FL3-22-R3</td><td></td></tr><tr><td>Fluorohub TCSPC controller</td><td>Horiba</td><td>Fluorohub-B</td><td>TCSPC electronics for ensemble measurements</td></tr><tr><td>NanoLed 485L</td><td>Horiba</td><td>485L</td><td>Blue diode laser</td></tr><tr><td>NanoLed 635L</td><td>Horiba</td><td>635L</td><td>Red diode laser</td></tr><tr><td>Olympus IX73 Microscope</td><td>Olympus</td><td>IX73P2F</td><td>Microscope frame</td></tr><tr><td>PMA 40 Hybrid Detector</td><td>PicoQuant GmbH</td><td>932200, PMA 40</td><td>Optimized for green detection</td></tr><tr><td>PMA 50 Hybrid Detector</td><td>PicoQuant GmbH</td><td>932201, PMA 50</td><td>Optimized for ed shifter sensitivity</td></tr><tr><td>485 nm laser</td><td>PicoQuant GmbH</td><td>LDH-D-C-485</td><td></td></tr><tr><td>640 nm laser</td><td>PicoQuant GmbH</td><td>LDH-D-C-640</td><td></td></tr><tr><td>Hydraharp 400 and TTTR acqusition software</td><td>PicoQuant</td><td>930021</td><td>Picosecond event timer and Time Correlated Single Photon Coutning Unit, includes TTTR acqusition software</td></tr><tr><td>SEPIA II SLM 828 and SEPIA software</td><td>PicoQuant</td><td>910028</td><td>Laser driver for picosecond pulses , includes SEPIA software controller.</td></tr><tr><td>computer</td><td>Dell</td><td>optiplex 7010</td><td>cpu: i7-3770 ram:16GB</td></tr><tr><td>FRET Positioning and Screening (FPS) software</td><td>Heinrich Heine Unviersity</td><td></td><td>It include the Accesibel Volume clacualtor available at http://www.mpc.hhu.de/software/fps.html</td></tr><tr><td>MFD suite</td><td>Heinrich Heine Unviersity</td><td></td><td>It includes the BIFL software package Paris; Margarita for visualization of the multiparameter hisotrams, and Probability Distribution Analysis software availabel at http://www.mpc.hhu.de/software/software-package.html</td></tr></tbody></table>

high precision fret at single-molecule level for biomolecule structure determination

这里介绍了如何在多参数荧光检测（MFD）模式下以单分子水平进行Förster共振能量转移（FRET）进行高精度间距距离测量的协议。 MFD最大化荧光的所有"尺寸"的使用，以减少光物理和实验伪像，并允许在刚性生物分子中以高达±1的精度测量间距距离。该方法用于鉴定N-甲基-D-天冬氨酸（NMDA）受体的配体结合结构域的三个构象状态，以解释配体结合时受体的活化。当将已知的结晶结构与实验测量结果进行比较时，对于更多的动态生物分子，他们认为不到3Å。收集覆盖生物分子的整体维度的一套距离约束将使得有可能提供动态生物分子的结构模型ES。

在使用MFD设置（激光线:485nm在60μW和640nm，23μW，5.1节）的典型smFRET实验中，将荧光样品稀释至低皮摩尔浓度（10 -12M = 1pM）并放置在共焦显微镜中，亚纳秒激光脉冲激发标记分子通过激发体自由扩散。典型的共焦体积&lt;4毫升（fL）。在这样低的浓度下，一次只能检测到一个分子。通过目标收集来自标记分子的发射荧光，并使用针孔进行空间过滤。此步骤定义了有效的共聚?...

Watch this Scientific Journal Video about High Precision FRET at Single-molecule Level for Biomolecule Structure Determination at JoVE.com

High Precision FRET at Single-molecule Level for Biomolecule Structure Determination

本文介绍了单分子水平高精度FRET实验方案。此外，该方法可用于鉴定N-甲基-D-天冬氨酸（NMDA）受体的配体结合结构域中的三种构象状态。确定精确的距离是建立基于FRET实验的结构模型的第一步。

单分子水平的高精度FRET用于生物分子结构测定

A protocol on how to perform high-precision interdye distance measurements using F&#246;rster resonance energy transfer (FRET) at the single-molecule ...
