APL acknowledges support by a Humboldt Research Fellowship for Experienced Researchers and from the National Science Foundation (1939310 and 1817909) and National Institutes of Health (R01 EB030031).

1. Preparation of oil-lipid-mixture
NOTE: The step needs to be performed in a fume hood following all the safety guidelines for handling chloroform.
<ol>
	<li>Take 0.5 mL of chloroform in a 15 mL glass vial. Add 88 &#181;L of 25 mg/mL dioleoyl-phosphocholine (DOPC), 9.3 &#181;L of 50 mg/mL cholesterol, and 5 &#181;L of 1 mg/mL dioleoyl-phosphoethanolamine-lissamine rhodamine B (rhodamine PE) (see Table of Materials) into the 15 ml glass vial.
	NOTE: The final mole fractions of DOPC and cholesterol in silicone oil/mineral oil are 69.9% and 30%, respectively. It was established that 20-30 mol% cholesterol is an optimized concentration for membrane fluidity and stability of GUVs generated using the presented technique25,26. Physiologically, these values are well within the cholesterol concentration range found in mammalian cell plasma membranes6. Lipid stocks are acquired as solutions in chloroform and stored at -20 &#176;C. Lipid stock vials should be acclimated to room temperature before they are opened.</li>
	<li>Pipette 7.2 mL of silicone oil and 1.8 mL of mineral oil in a second 15 mL vial (see Table of Materials). Generally, this needs to be done in a low-humidity glove box, mainly if the mineral oil is reused.</li>
	<li>Mix the oils by vortexing at the maximum rotational speed (3200 rpm) for 10 s, add the mixture to the vial containing the lipid-in-chloroform mixture and immediately place it on the vortex mixer. Vortex for 10-15 s at the maximum rotational speed (3200 rpm). The resulting lipids-in-oil mix should be slightly cloudy, as the lipids are not fully dissolved in the oil but rather dispersed as small aggregates24.</li>
	<li>Put the lipid-in-oil dispersion in a bath sonicator (see Table of Materials) with ultrasonic power of 80 W and operating frequency of 40 kHz at room temperature for 30 min. Use the mixture immediately or store at 4 &#176;C for a maximum of 24 h.</li>
</ol>
2. Vesicle generation
<ol>
	<li>Mount the 3D-printed shaft (Supplementary File 1) made from black resin (see Table of Materials) on the benchtop stir plate and set rotational speed to 1200 rpm.</li>
	<li>Mount the 3D-printed cDICE chamber (Supplementary File 2) made from clear resin (see Table of Materials) on the shaft (Figure 1A,B).</li>
	<li>Prepare actin and actin-binding proteins (ABP) solutions separately in a total volume of 20 &#181;L.
	<ol>
		<li>Prepare 1-10 &#181;M of actin in globular actin buffer (G-buffer), including 10% ATTO 488 actin (see Table of Materials).
		NOTE: 1x G-buffer comprises 5 mM of Tris-HCl, pH 8.0, and 0.2 mM of CaCl2.</li>
		<li>Add filamentous actin polymerization buffer (F-buffer) to begin actin polymerization on ice. Keep the solutions on ice to slow down actin polymerization before the addition of a crosslinker.
		NOTE: The 1x F-buffer contains 50 mM of KCl, 2 mM of MgCl2, and 3 mM of ATP in 10&#160;mM of Tris, pH 7.5.</li>
		<li>Wait for 15 min to allow for initiation of actin polymerization on ice before adding crosslinkers of interest at the desired molar ratio. Keep the solution on ice until encapsulation.</li>
		<li>Prepare actin-binding proteins (ABPs) separately in a microtube (Figure 1C).
		NOTE: This step is performed when a combination of ABPs (e.g., myosin, &#945;-actinin, fascin, Arp2/3 complex) encapsulates with actin25,26,27. In such cases, the desired amount of each ABP is drawn from its stock and added into the microtube designated for ABPs. As the total solution is to be 20 &#181;L, stock aliquots of ABPs must be prepared so that the desired amount of the total ABP mixture does not exceed 5-6 &#181;L. The only ABP used in the representative results here is fascin, the preparation of which is mentioned below.
		<ol>
			<li>Aliquot 1.57 &#181;L of fascin from a 1.75 mg/mL of fascin stock (see Table of Materials), and directly add to the actin solution in step 2.7. This corresponds to 2.5 &#181;M of fascin in the solution.</li>
		</ol>
		</li>
	</ol>
	</li>
	<li>Add 7.5% of density gradient medium (see Table of Materials) into the actin solution to create a density gradient between the outer and the inner aqueous phase to facilitate GUV sedimentation.</li>
	<li>Dispense 700 &#181;L of the outer solution of 200 mM of glucose into the chamber (Figure 1D, left).
	NOTE: The osmolarity of the inner solution determines the concentration of glucose. For these experiments, the osmolarity of the inner solution is ~200 mOsm, so a 200 mM glucose solution is used as the outer solution.</li>
	<li>Add a sufficient amount of lipid-oil mixture (&#62;3 mL based on the chamber size) into the chamber until 60%-80% of the chamber is filled (Figure 1D, right). An interface will be formed between the lipid-oil mixture and the outer solution.</li>
	<li>Transfer ABPs (prepared in step 2.3.4) into the actin solution. Using a regular 100-1000 &#181;L pipette, immediately transfer the 700 &#181;L of the lipid-oil mixture into the actin-ABP mixture (Figure 1E, left). Pipette up and down 8 times to generate cell-sized lipid-monolayer droplets with diameter in the range of 7-100 &#181;m (Figure 1E, middle).
	NOTE: Step 2.7 needs to be completed in a few seconds to avoid any actin network assembly before encapsulation. Thus, before performing the step, ensure that pipette tips are already inserted into the pipettes and ready to transfer the mixtures.</li>
	<li>Using the same 100-1000 &#181;L pipette, immediately dispense the entire emulsion into the rotating chamber. Droplets will acquire a second leaflet of lipids by crossing the lipid monolayer at the oil-outer solution interface, thereby forming GUVs (Figure 1E, right).</li>
	<li>Remove the chamber from the stir plate and discard most of the lipid-oil mixture by tilting the chamber in the waste container so that a large portion of the lipid-oil mixture is drained from the large opening at the center of the chamber.
	NOTE: This way, the lipid-oil mixture is drawn off the chamber, avoiding mixing of lipid-oil mixture with the outer solution in the next step.</li>
	<li>Hold the chamber with its lid facing towards the user. Open the chamber lid and slightly tilt the chamber towards the user. The interface between the outer solution containing GUVs and the lipid-oil mixture is visible from the chamber opening (where the lid is located).</li>
	<li>Using a pipette, collect enough outer solution containing GUVs and dispense 50-300 &#181;L of the outer solution into a 96-well plate to obtain an appropriate density of GUVs.
	NOTE: Following this protocol, a total of about 2 x 105 GUVs are released in the outer solution inside the chamber. The GUV dispersity was not quantified; however, the diameter of about 90% of GUVs is in the range of 12-30&#160;&#181;m. GUVs with any diameter in the range of 7-50 &#181;m can be found in the population. Depending on the encapsulated density gradient medium, GUV size, and solution depth in the well plate, it takes 2-15 min for GUVs to settle down on the surface. The yield of GUVs with reconstituted actin bundles is about 90%.</li>
</ol>
3. Imaging and 3D image reconstruction
<ol>
	<li>Set up the 96 well plate on the stage of an inverted microscope equipped with a spinning disk (or laser scanning) confocal unit, an EMCCD or an sCMOS camera, and an oil immersion 60x objective lens (see Table of Materials).</li>
	<li>Focus on any region of interest (ROI) and take a z-stack image sequence from the ROI with a z-step interval of 0.5 &#181;m.
	NOTE: Because GUVs can be slightly displaced on the surface over time, it is recommended to capture a multi-wavelength set of images at each z-plane if multiple fluorophores are being imaged, i.e., take a group of 561 nm and 488 nm images at each z-lane at a time to capture ATTO 488 actin and Rhod PE images.</li>
	<li>Save each z-stack image sequence in .tiff format.</li>
	<li>Open an image sequence of interest in an image processing software (ImageJ/Fiji). Identify the image with the highest intensity. Hold &#34;ctrl+shift+c&#34; to open the Brightness &#38; Contrast window and click on Reset.</li>
	<li>From the ImageJ/Fiji menu, go to Analyze &#62; Set Scale and enter the known physical distance and its unit for each image pixel.</li>
	<li>From the ImageJ/Fiji menu, go to Image &#62; Stacks &#62; 3D project to reconstruct a 3D image from the z-stack. Set &#34;Projection method&#34; as Brightness Point, &#34;Slice Spacing (&#181;m)&#34; as 0.5, and checkmark Interpolate. The default options can be used for the rest of the settings.
	NOTE: z-intervals in some microscopes might not be calibrated, and the actual movement in z-direction might slightly differ from the entered z-interval (i.e., 0.5 &#181;m). In such cases, a 3D calibration specimen such as fluorescent microspheres with a known diameter can be used to obtain the actual z-interval. This value will thus be used as &#34;Slice Spacing (&#181;m)&#34; for 3D projection.</li>
</ol>

<ol>
	<li>Groaz, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Engineering+spatiotemporal+organization+and+dynamics+in+synthetic+cells.">Engineering spatiotemporal organization and dynamics in synthetic cells.</a> Wiley Interdisciplinary Reviews: Nanomedicine and Nanobiotechnology. 13 (3), 1685 (2021).</li><li>Diltemiz, S. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Use+of+artificial+cells+as+drug+carriers.">Use of artificial cells as drug carriers.</a> Materials Chemistry Frontiers. 5, 6672-6692 (2021).</li><li>Liu, A. P., Fletcher, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Biology+under+construction:+In+vitro+reconstitution+of+cellular+function.">Biology under construction: In vitro reconstitution of cellular function.</a> Nature Reviews Molecular Cell Biology. 10 (9), 644-650 (2009).</li><li>Ganzinger, K. A., Schwille, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=More+from+less+-+bottom-up+reconstitution+of+cell+biology.">More from less - bottom-up reconstitution of cell biology.</a> Journal of Cell Science. 132 (4), 227488 (2019).</li><li>Bashirzadeh, Y., Liu, A. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Encapsulation+of+the+cytoskeleton:+Towards+mimicking+the+mechanics+of+a+cell.">Encapsulation of the cytoskeleton: Towards mimicking the mechanics of a cell.</a> Soft Matter. 15 (42), 8425-8436 (2019).</li><li>Blanchoin, L., Boujemaa-Paterski, R., Sykes, C., Plastino, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Actin+dynamics,+architecture,+and+mechanics+in+cell+motility.">Actin dynamics, architecture, and mechanics in cell motility.</a> Physiol reviews. 94 (1), 235-263 (2014).</li><li>Angelova, M. I., Dimitrov, D. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Liposome+electroformation.">Liposome electroformation.</a> Faraday Discussions of the Chemical Society. 81, 303-311 (1986).</li><li>Tsumoto, K., Matsuo, H., Tomita, M., Yoshimura, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Efficient+formation+of+giant+liposomes+through+the+gentle+hydration+of+phosphatidylcholine+films+doped+with+sugar.">Efficient formation of giant liposomes through the gentle hydration of phosphatidylcholine films doped with sugar.</a> Colloids and Surfaces B: Biointerfaces. 68 (1), 98-105 (2009).</li><li>Bailey, A. L., Cullis, P. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Membrane+fusion+with+cationic+liposomes:+Effects+of+target+membrane+lipid+composition.">Membrane fusion with cationic liposomes: Effects of target membrane lipid composition.</a> Biochemistry. 36 (7), 1628-1634 (1997).</li><li>Haluska, C. K., Riske, K. A., Marchi-Artzner, V., Lehn, J. M., Lipowsky, R., Dimova, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Time+scales+of+membrane+fusion+revealed+by+direct+imaging+of+vesicle+fusion+with+high+temporal+resolution.">Time scales of membrane fusion revealed by direct imaging of vesicle fusion with high temporal resolution.</a> Proceedings of the National Academy of Sciences. 103 (43), 15841-15846 (2006).</li><li>Nishimura, K., Suzuki, H., Toyota, T., Yomo, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Size+control+of+giant+unilamellar+vesicles+prepared+from+inverted+emulsion+droplets.">Size control of giant unilamellar vesicles prepared from inverted emulsion droplets.</a> Journal of Colloid and Interface Science. 376 (1), 119-125 (2012).</li><li>Pautot, S., Frisken, B. J., Weitz, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Production+of+unilamellar+vesicles+using+an+inverted+emulsion.">Production of unilamellar vesicles using an inverted emulsion.</a> Langmuir. 19 (7), 2870-2879 (2003).</li><li>Stachowiak, J. C., Richmond, D. L., Li, T. H., Liu, A. P., Parekh, S. H., Fletcher, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Unilamellar+vesicle+formation+and+encapsulation+by+microfluidic+jetting.">Unilamellar vesicle formation and encapsulation by microfluidic jetting.</a> Proceedings of the National Academy of Sciences. 105 (12), 4697-4702 (2008).</li><li>Noireaux, V., Liu, A. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+new+age+of+cell-free+biology.">The new age of cell-free biology.</a> Annual Review of Biomedical Engineering. 22, 51-77 (2020).</li><li>Ho, K. K. Y., Murray, V. L., Liu, A. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Engineering+artificial+cells+by+combining+HeLa-based+cell-free+expression+and+ultrathin+double+emulsion+template.">Engineering artificial cells by combining HeLa-based cell-free expression and ultrathin double emulsion template.</a> Methods in Cell Biology. , 303-318 (2015).</li><li>Akashi, K., Miyata, H., Itoh, H., Kinosita, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preparation+of+giant+liposomes+in+physiological+conditions+and+their+characterization+under+an+optical+microscope.">Preparation of giant liposomes in physiological conditions and their characterization under an optical microscope.</a> Biophysical Journal. 71 (6), 3242-3250 (1996).</li><li>M&#233;l&#233;ard, P., Bagatolli, L. A., Pott, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Giant+unilamellar+vesicle+electroformation:+From+lipid+mixtures+to+native+membranes+under+physiological+conditions.">Giant unilamellar vesicle electroformation: From lipid mixtures to native membranes under physiological conditions.</a> Methods in Enzymology. 465, 161-176 (2009).</li><li>Walde, P., Cosentino, K., Engel, H., Stano, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Giant+vesicles:+Preparations+and+applications.">Giant vesicles: Preparations and applications.</a> ChemBioChem. 11 (7), 848-865 (2010).</li><li>P&#233;cheur, E. I., Martin, I., Ruysschaert, J. M., Bienven&#252;e, A., Hoekstra, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Membrane+fusion+induced+by+11-mer+anionic+and+cationic+peptides:+A+structure&#8722;+function+study.">Membrane fusion induced by 11-mer anionic and cationic peptides: A structure&#8722; function study.</a> Biochemistry. 37 (8), 2361-2371 (1998).</li><li>Morigaki, K., Walde, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Giant+vesicle+formation+from+oleic+acid/sodium+oleate+on+glass+surfaces+induced+by+adsorbed+hydrocarbon+molecules.">Giant vesicle formation from oleic acid/sodium oleate on glass surfaces induced by adsorbed hydrocarbon molecules.</a> Langmuir. 18 (26), 10509-10511 (2002).</li><li>Majumder, S., Wubshet, N., Liu, A. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Encapsulation+of+complex+solutions+using+droplet+microfluidics+towards+the+synthesis+of+artificial+cells.">Encapsulation of complex solutions using droplet microfluidics towards the synthesis of artificial cells.</a> Journal of Micromechanics and Microengineering. 29 (8), 83001 (2019).</li><li>Abkarian, M., Loiseau, E., Massiera, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Continuous+droplet+interface+crossing+encapsulation+(cDICE)+for+high+throughput+monodisperse+vesicle+design.">Continuous droplet interface crossing encapsulation (cDICE) for high throughput monodisperse vesicle design.</a> Soft Matter. 7 (10), 4610-4614 (2011).</li><li>Van de Cauter, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimized+cDICE+for+efficient+reconstitution+of+biological+systems+in+giant+unilamellar+vesicles.">Optimized cDICE for efficient reconstitution of biological systems in giant unilamellar vesicles.</a> ACS Synthetic Biology. 10 (7), 1690-1702 (2021).</li><li>Claudet, C., In, M., Massiera, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Method+to+disperse+lipids+as+aggregates+in+oil+for+bilayers+production.">Method to disperse lipids as aggregates in oil for bilayers production.</a> The European Physical Journal E. 39 (1), 1-6 (2016).</li><li>Bashirzadeh, Y., Wubshet, N. H., Liu, A. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Confinement+Geometry+tunes+fascin-actin+bundle+structures+and+consequently+the+shape+of+a+lipid+bilayer+vesicle.">Confinement Geometry tunes fascin-actin bundle structures and consequently the shape of a lipid bilayer vesicle.</a> Frontiers in Molecular Biosciences. 7, 610277 (2020).</li><li>Bashirzadeh, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Actin+crosslinker+competition+and+sorting+drive+emergent+GUV+size-dependent+actin+network+architecture.">Actin crosslinker competition and sorting drive emergent GUV size-dependent actin network architecture.</a> Communications Biology. 4, 1136 (2021).</li><li>Bashirzadeh, Y., Moghimianavval, H., Liu, A. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Encapsulated+actomyosin+patterns+drive+cell-like+membrane+shape+changes.">Encapsulated actomyosin patterns drive cell-like membrane shape changes.</a> bioRxiv. , (2021).</li><li>Litschel, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reconstitution+of+contractile+actomyosin+rings+in+vesicles.">Reconstitution of contractile actomyosin rings in vesicles.</a> Nature Communications. 12 (1), 1-10 (2021).</li><li>Vitale, S. A., Katz, J. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Liquid+droplet+dispersions+formed+by+homogeneous+liquid&#8722;+liquid+nucleation:&amp;#34;The+Ouzo+effect.&amp;#34.">Liquid droplet dispersions formed by homogeneous liquid&#8722; liquid nucleation:&amp;#34;The Ouzo effect.&amp;#34.</a> Langmuir. 19 (10), 4105-4110 (2003).</li><li>Pautot, S., Frisken, B. J., Weitz, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Engineering+asymmetric+vesicles.">Engineering asymmetric vesicles.</a> Proceedings of the National Academy of Sciences. 100 (19), 10718-10721 (2003).</li><li>Deshpande, S., Dekker, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=On-chip+microfluidic+production+of+cell-sized+liposomes.">On-chip microfluidic production of cell-sized liposomes.</a> Nature Protocols. 13 (5), 856-874 (2018).</li><li>Deshpande, S., Caspi, Y., Meijering, A. E. C., Dekker, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Octanol-assisted+liposome+assembly+on+chip.">Octanol-assisted liposome assembly on chip.</a> Nature Communications. 7, 10447 (2016).</li><li>Wubshet, N. H., Bashirzadeh, Y., Liu, A. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fascin-induced+actin+protrusions+are+suppressed+by+dendritic+networks+in+GUVs.">Fascin-induced actin protrusions are suppressed by dendritic networks in GUVs.</a> Molecular Biology of the Cell. 32 (18), 1634-1640 (2021).</li></ol>

The authors declare no conflicts of interest.

Different methods of generating GUVs have been explored for the creation of synthetic cells&#160;However, the complexity of the procedures, extended time to attain encapsulation, restriction of lipid types and molecular composition of the encapsulant, need for non-physiological chemicals to facilitate encapsulation, low GUV yield, and inconsistencies in encapsulation efficiency have continued to challenge researchers in this field. Considering the wide range of potential studies that can be embarked in bottom-up syntheti...

Lipid bilayer compartments are used as model synthetic cells for studying enclosed organic reactions and membrane-based processes or as carrier modules in drug delivery applications1,2. Bottom-up biology with purified components requires minimal experimental systems to explore properties and interactions between biomolecules, such as proteins and lipids3,4. However, with the advancement of the field, there is an increased need for more complex experimental systems that better imitate the conditions in biological cells. Encapsulation in GUVs is a practical approach that can offer some of these cell-like properties by providing a deformable and selectively permeable lipid bilayer and a confined reaction space. In particular, in vitro reconstitution of cytoskeletal systems, as models of synthetic cells, can benefit from encapsulation in membrane compartments5. Many cytoskeletal proteins bind and interact with the cell membrane. As most cytoskeletal assemblies form structures that span the entirety of the cell, their shape is naturally determined by cell-sized confinement6.
Different methods are used to generate GUVs, such as the swelling7,8, small vesicle fusion9,10, emulsion transfer11,12, pulsed jetting13, and other microfluidic approaches14,15. Although these methods are still utilized, each has its limitations. Thus, a robust and straightforward approach with a high yield of GUV encapsulation is highly desirable. Although techniques such as spontaneous swelling and electroswelling are widely adopted for the formation of GUVs, these methods are primarily compatible with specific lipid compositions16, low salt concentration buffers17, smaller encapsulant molecular size18, and require a high volume of the encapsulant. Fusing multiple small vesicles into a GUV is inherently energetically unfavorable, thus requiring specificity in charged lipid compositions9 and/or external fusion-inducing agents, such as peptides19&#160;or other chemicals. Emulsion transfer and microfluidic methods, on the other hand, may require droplet stabilization through surfactant and solvent removal after bilayer formation, respectively18,20. The complexity of experimental setup and device in microfluidic techniques such as pulsed jetting impose an additional challenge21. cDICE is an emulsion-based method derived from similar principles governing emulsion transfer22,23. An aqueous solution (outer solution) and a lipid-oil mixture are stratified by centrifugal forces in a rotating cylindrical chamber (cDICE chamber) forming a lipid saturated interface. Shuttling lipid monolayered aqueous droplets into the rotating cDICE chamber results in zipping of a bilayer as droplets cross the lipid-saturated interface into the outer aqueous solution22,24. The cDICE approach is a robust technique for GUV encapsulation. With the presented modified method, not only the high vesicle yield typical for cDICE with a significantly shorter encapsulation time (a few seconds) is achieved but GUV generation time that allow for the observation of time-dependent processes (e.g., actin cytoskeletal network formation) is significantly reduced. The protocol takes about 15-20 min from the start to GUV collection and imaging. Here, GUV generation is described using the modified cDICE method for encapsulating actin and actin-binding proteins (ABPs). However, the presented technique is applicable for encapsulating a wide range of biological reactions and membrane interactions, from the assembly of biopolymers to cell-free protein expression to membrane fusion-based cargo transfer.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>18:1 Liss Rhod PE lipid in chloroform</td>
			<td>Avanti Polar Lipids</td>
			<td>810150C</td>
			<td></td>
		</tr>
		<tr>
			<td>96 Well Optical Btm Pit PolymerBase</td>
			<td>ThermoFisher Scientific</td>
			<td>165305</td>
			<td></td>
		</tr>
		<tr>
			<td>Actin from rabbit skeletal muscle</td>
			<td>Cytoskeleton</td>
			<td>AKL99-A</td>
			<td></td>
		</tr>
		<tr>
			<td>ATTO 488-actin from rabbit skeletal muscle</td>
			<td>Hypermol</td>
			<td>8153-01</td>
			<td></td>
		</tr>
		<tr>
			<td>Axygen microtubes (200 &#181;L)</td>
			<td>Fisher Scientific</td>
			<td>14-222-262</td>
			<td>for handling ABPs</td>
		</tr>
		<tr>
			<td>Black resin</td>
			<td>Formlabs</td>
			<td>RS-F2-GPBK-04</td>
			<td></td>
		</tr>
		<tr>
			<td>Cholesterol (powder)</td>
			<td>Avanti Polar Lipids</td>
			<td>700100P</td>
			<td></td>
		</tr>
		<tr>
			<td>Choloroform</td>
			<td>Sigma Aldrich</td>
			<td>67-66-3</td>
			<td></td>
		</tr>
		<tr>
			<td>Clear resin</td>
			<td>Formlabs</td>
			<td>RS-F2-GPCL-04</td>
			<td></td>
		</tr>
		<tr>
			<td>CSU-X1 Confocal Scanner Unit</td>
			<td>YOKOGAWA</td>
			<td>CSU-X1</td>
			<td></td>
		</tr>
		<tr>
			<td>Density gradient medium (Optiprep)</td>
			<td>Sigma-Aldrich</td>
			<td>D1556</td>
			<td></td>
		</tr>
		<tr>
			<td>DOPC lipid in chloroform</td>
			<td>Avanti Polar Lipids</td>
			<td>850375C</td>
			<td></td>
		</tr>
		<tr>
			<td>Fascin</td>
			<td>homemade</td>
			<td>N/A</td>
			<td></td>
		</tr>
		<tr>
			<td>F-buffer</td>
			<td>homemade</td>
			<td>N/A</td>
			<td></td>
		</tr>
		<tr>
			<td>Fisherbrand microtubes (1.5 mL)</td>
			<td>Fisher Scientific</td>
			<td>05-408-129</td>
			<td></td>
		</tr>
		<tr>
			<td>FS02 Sonicator</td>
			<td>Fischer Scientific</td>
			<td>FS20</td>
			<td></td>
		</tr>
		<tr>
			<td>G-buffer</td>
			<td>homemade</td>
			<td>N/A</td>
			<td></td>
		</tr>
		<tr>
			<td>Glucose</td>
			<td>Sigma-Aldrich</td>
			<td>158968</td>
			<td></td>
		</tr>
		<tr>
			<td>iXon X3 camera</td>
			<td>Andor</td>
			<td>DU-897E-CS0</td>
			<td></td>
		</tr>
		<tr>
			<td>Mineral oil</td>
			<td>Acros Organics</td>
			<td>8042-47-5</td>
			<td></td>
		</tr>
		<tr>
			<td>Olympus IX81 Inverted Microscope</td>
			<td>Olympus</td>
			<td>IX21</td>
			<td></td>
		</tr>
		<tr>
			<td>Olympus PlanApo N 60x Oil Microscope Objective</td>
			<td>Olumpus</td>
			<td>1-U2B933</td>
			<td></td>
		</tr>
		<tr>
			<td>Silicone oil</td>
			<td>Sigma-Aldrich</td>
			<td>317667</td>
			<td></td>
		</tr>
	</tbody>
</table>

rapid encapsulation of reconstituted cytoskeleton inside giant unilamellar vesicles

Giant unilamellar vesicles (GUVs) are frequently used as models of biological membranes and thus are a great tool to study membrane-related cellular processes in vitro. In recent years, encapsulation within GUVs has proven to be a helpful approach for reconstitution experiments in cell biology and related fields. It better mimics confinement conditions inside living cells, as opposed to conventional biochemical reconstitution. Methods for encapsulation inside GUVs are often not easy to implement, and success rates can differ significantly from lab to lab. One technique that has proven to be successful for encapsulating more complex protein systems is called continuous droplet interface crossing encapsulation (cDICE). Here, a cDICE-based method is presented for rapidly encapsulating cytoskeletal proteins in GUVs with high encapsulation efficiency. In this method, first, lipid-monolayer droplets are generated by emulsifying a protein solution of interest in a lipid/oil mixture. After being added into a rotating 3D-printed chamber, these lipid-monolayered droplets then pass through a second lipid monolayer at a water/oil interface inside the chamber to form GUVs that contain the protein system. This method simplifies the overall procedure of encapsulation within GUVs and speeds up the process, and thus allows us to confine and observe the dynamic evolution of network assembly inside lipid bilayer vesicles. This platform is handy for studying the mechanics of cytoskeleton-membrane interactions in confinement.

To demonstrate the successful generation of cytoskeletal GUVs using the current protocol, fascin-actin bundle structures in GUVs were reconstituted. Fascin is a short crosslinker of actin filaments which forms stiff parallel-aligned actin bundles and is purified from E. coli as Glutathione-S-Transferase (GST) fusion protein26. 5 &#181;M of actin was first reconstituted, including 0.53 &#181;M of ATTO488 actin in the actin polymerization buffer and 7.5% of the density gradient medium. Upon...

Watch this Scientific Journal Video about Rapid Encapsulation of Reconstituted Cytoskeleton Inside Giant Unilamellar Vesicles at JoVE.com

Rapid Encapsulation of Reconstituted Cytoskeleton Inside Giant Unilamellar Vesicles

This article introduces a simple method for expeditious production of giant unilamellar vesicles with encapsulated cytoskeletal proteins. The method proves to be useful for bottom-up reconstitution of cytoskeletal structures in confinement and cytoskeleton-membrane interactions.

Giant unilamellar vesicles (GUVs) are frequently used as models of biological membranes and thus are a great tool to study membrane-related cellular ...
