This work was supported by a grant from the NIH R01 GM128983-01.

1. Assembly of Platform Incubator with Movable XY stage
NOTE: The new platform includes the incubation system, the positioning stage and controllers, the peristaltic pumps, the 248 nm KrF excimer laser, and the optical mirrors assembled on an Imperial optical breadboard.
<ol>
	<li>Assemble the incubation system: the temperature unit, carbon dioxide unit, humidifier, air pump, and touch monitoring system (Figure 2A-E).
	NOTE: Detailed assembly instructions are provided by the manufacturer. The incubation system must stabilize to 5% CO2, 37 &#176;C, and 85% humidity before growing cells within the incubator. These parameters may depend on the cell line.</li>
	<li>Assemble the custom six-well plate incubator, nanopositioning drive stage, and XY drive stage. The former screws into the latter, respectively.
	NOTE: Detailed assembly instructions provided by the manufacturer.</li>
	<li>Connect the four peristaltic pumps in a &#34;daisy chain&#34; sequence via RS-232 cables, with an RS-232 to USB cable connected to the controlling computer. Connect 3.18 mm ID polymer tubing (e.g., Tygon) to every channel on each pump channel roller.
	NOTE: Each pump has four rollers. Direction and flow rate of rollers are manually manipulated.</li>
	<li>Insert 1/16&#34; x 1/8&#34; connectors at the end of each 3.18 mm ID polymer tube. Insert the 1/16&#39;&#39; end of the connector into 1.59 ID polymer tubing, then insert the polymer tubing into the incubator via custom ports. Place the other end of the tube in the solution that will be infused during IC-FPOP experimentation.
	NOTE: For the perfusion lines, the incubator has 36 custom ports for tubing lines all around the periphery to accommodate all the reagents used.</li>
	<li>Screw one 50 mm, 248 nm, 45&#176; excimer laser line mirror within a kinematic mirror mount for &#216;2&#34; optics into the breadboard 10-11 grid points from the 248 nm laser aperture. Place the second mirror at a 90&#176; angle to the first on the other side of the incubator. Angle the second mirror downward at approximately 45&#176; for laser beam guidance to the incubator (Figure 2F-J).</li>
</ol>
2. Synchronization and initial automation of system via integration software
<ol>
	<li>Install the latest version of the integration software needed to control the drivers and pumps.</li>
	<li>Referring to the pump manual, rename the pumps starting with &#39;5&#39; and increasing in value. The commands can be sent to the pump system using the Manual Control sub-program in the integration software.
	NOTE: Setting a pump to Channel Mode automatically changes the pump naming convention into the set, 1, 2, 3 and 4, corresponding to the four pump channels.</li>
	<li>Open the integration software program for the automation of the platform incubator.</li>
	<li>Choose the appropriate USB comport device name (e.g., COM4) corresponding to the pump system USB cable from the connection dropdown menu labelled Comport for pumps.</li>
	<li>Click the Script Builder button to edit/create a script for the automated platform incubator platform. Click Save Script to save the sequence as a text file (Figure 3A).
	NOTE: The script builder has a user interface for defining the script with definitions of pump number, direction, rate, volume, tubing diameter, channel mode, and timed delay.</li>
	<li>If channel mode is desired in the making of the script, a step in the script must be dedicated to changing the pump in and out of channel mode, and the following steps corresponding to the pump channels must be labelled as pumps 1-4.
	NOTE: This ensures that no two pumps can simultaneously be in channel mode during a platform incubator script and that each pump is switched back to legacy mode after the commands have been sent to the needed channels.</li>
	<li>Click the Read Script button and choose the appropriate script file desired for the platform incubator operation.</li>
	<li>Switch the Run Sequence button to the ON position (green) to run the script and then click the START button (Figure 3B) .</li>
</ol>
3. Grow cells in the platform incubator
NOTE: Cells must be placed in the platform incubator under sterile conditions in a cell culture hood the day before experimentation.
<ol>
	<li>Unscrew the platform incubator from the nanopositioning stage and disconnect the temperature, gas, and humidifier lines. After spraying the incubator with 70% ethanol, place it in a cell culture hood.</li>
	<li>Grow cells in a T-175 to about 80-90% confluency prior to transfer.
	NOTE: The term confluency is used as a measure of the number/coverage of the cells in a cell culture dish or a flask.</li>
	<li>Remove media and rinse with buffer.</li>
	<li>Detach cells using trypsin-EDTA using manufacturer&#39;s protocol.</li>
	<li>Resuspend in 8 mL of media and count the cells.</li>
	<li>Seed fibronectin/collagen14 coated six-well plates with approximately 90-95 &#956;L of resuspended cells in each well. This volume will be appropriate to achieve 80-90% confluency (~1.2 million cells) in each well on the next day.
	NOTE: Six-well plates must be coated with collagen prior to seeding. The reagents used during IC-FPOP are infused with fast flow rates. Coated plates ensure cells are not prematurely detached due to infusion of reagents.</li>
	<li>Place the seeded plate into the platform incubator and cover with the quartz lid.
	NOTE: During design and development, a glass incubator lid was changed to quartz, so it is compatible with the ultraviolet laser light.</li>
	<li>Replace and secure the platform incubator back on the nanopositioning drive stage. Reconnect the temperature, gas, and humidifier lines.</li>
	<li>Let cells grow to confluency overnight.
	NOTE: The following cell culture steps are optional and are intended for experiments in which human cells are transiently transfected. These steps assess transfection efficiency under cell culture conditions.</li>
	<li>Transfect the plasmid containing the gene for the chimeric protein GCaMP2 into HEK 293 cells using a commercial cationic-lipid transfection kit.</li>
	<li>Perform transient transfections of GCaMP2 in HEK293T cells in two six-well plates.</li>
	<li>Incubate one six-well plate in the platform incubator, and the second six-well plate in a standard CO2 incubator.</li>
	<li>Compare transfection efficiency within each plate by fluorescence imaging using a fluorescence microscope.</li>
</ol>
4. Make quench buffer and H2O2
<ol>
	<li>Make 100 mL of quench buffer containing 125 mM N-tert-Butyl-&#945;-phenylnitrone (PBN) and 125 mM N, N&#8242;-Dimethylthiourea (DMTU).
	NOTE: DMTU and PBN are free radical scavengers and are cell permeable.</li>
	<li>Dilute H2O2 to 200 mM. Each sample requires 6 mL of H2O2 to fully immerse the layer of cells at the bottom of each well.
	&#8203;NOTE: The quench buffer is made the day before and stored at 4 &#176;C overnight, protected from light. Dilute the H2O2 on the day of the experiment.</li>
</ol>
5. Set up the platform incubator for IC-FPOP
NOTE: The platform incubator must be assembled under sterile conditions. Assemble the incubator in a sterile cell culture hood.
<ol>
	<li>Unscrew the platform incubator from the positioning stage and disconnect the temperature, gas, and humidifier lines.</li>
	<li>After spraying the incubator with 70% ethanol, place it in the cell culture hood.</li>
	<li>Remove the six-well plate from the platform incubator, secure the plate&#39;s original lid, and confirm cell confluency using a microscope.</li>
	<li>After cell confluency has been confirmed, replace the six-well plate with confluent cells back in the platform incubator inside the cell culture hood.</li>
	<li>Insert three precut (15 cm) 1.59 ID polymer tubes in each well via the embedded ports. Flush the tubes to the well walls and hold with custom 3D printed rings.
	NOTE: Six 33 mm PLA filament 3D printed rings were custom designed to secure the tubing to the walls of the plate without disturbing the cells or getting in the way of the laser pulse.</li>
	<li>Cover the platform incubator with its quartz lid. Replace and secure the stage top incubator on the positioning system. Reconnect the temperature, gas, and humidifier lines.</li>
	<li>Connect 1.59 ID polymer tubing to 1/16&#34; end of the 1/16x1/8&#34; connectors.</li>
</ol>
6. Performing IC-FPOP in the platform incubator
<ol>
	<li>Prepare an integration software script for pump withdrawal. Use one peristaltic pump (Pump 8) to completely remove cell media from all six wells.</li>
	<li>Prime solvents in each channel of the other three peristaltic pumps (Pumps 5-7). Infuse H2O2 and quench buffer in their respective alternating tubes until the reagents reach the incubator ports.</li>
	<li>Confirm that the laser beam has been angled correctly by the mirrors and reaches the incubator uninhibited.
	NOTE: Laser safety goggles must be worn whenever the laser is in use. Do not prematurely irradiate the cells during the angling/alignment process. Use cardboard to completely cover the quartz lid when aligning the beam. Also, use a printed outline on white paper of a six-well plate to further confirm the laser beam is hitting the center of each well. Use the Continuous pulse setting at the lowest frequency and energy for alignment.</li>
	<li>Check laser energy using an external sensor. Use one single laser pulse of 160 mJ at 50 Hz and 27 kV.
	NOTE: A timer is needed for the following steps.</li>
	<li>Prepare the integration software script for pump infusion after confirming beam alignment.</li>
	<li>Begin the timer and press the Start button on the integration software pump script at the same time.</li>
	<li>Infuse 200 mM H2O2 at 35 mL/min into the first well (6-10 second mark on timer).
	NOTE: There is a five second delay before a pump begins to infuse. It also takes the laser seven seconds before the pulse is triggered. The laser pulse must come immediately after H2O2 infusion.</li>
	<li>Press the Start button on the laser software at the 5 second mark to trigger the pulse at the 11 second mark on the timer.</li>
	<li>Infuse 125 mM quench solution at 35 mL/min into the first well immediately after the laser pulse. Manually move the positioning stage to align the next well with the laser beam.</li>
	<li>Repeat the above steps 6.5-6.9 until each well has been processed.
	NOTE: IC-POP is performed in technical triplicate of three laser and three non-laser samples. One processed six-well plate serves as one biological replicate.</li>
	<li>In a cell culture hood, use a cell scraper to transfer the cells from each well into individual 15 mL conical tubes. Centrifuge cells at 1,200 x g for 5 minutes.</li>
	<li>Discard the supernatant and resuspend cells in 100 &#956;L of RIPA lysis buffer.</li>
	<li>Transfer cells to individual 1.2 mL polypropylene tubes.</li>
	<li>Flash freeze all samples in liquid nitrogen and place in a -80 &#176;C freezer until use.
	&#8203;NOTE: The protocol can be paused here.</li>
</ol>
7. Protein extraction, purification, and proteolysis
<ol>
	<li>Thaw the samples and heat at 95 &#176;C in a heat block for 5 minutes.</li>
	<li>After heating, cool on ice for 5 minutes.</li>
	<li>Add 25 units of nuclease to the cell lysate to degrade single-stranded, double-stranded, linear and circular DNA and RNA and incubate at room temperate for 15 minutes.</li>
	<li>Centrifuge samples at 16,000 x g for 10 minutes at 4 &#176;C.</li>
	<li>Collect the supernatant and transfer to a clean polypropylene tube.</li>
	<li>Check the protein concentration using a colorimetric protein assay.</li>
	<li>Transfer 100 &#181;g of sample to a clean polypropylene tube and bring to 100 &#181;L with cell lysis buffer.</li>
	<li>Reduce samples with 10 mM dithiothreitol (DTT) at 50 &#176;C for 45 minutes.</li>
	<li>Cool samples at room temperature for 10 minutes.</li>
	<li>Alkylate with 50 mM iodoacetamide (IAA) at room temperature for 20 minutes.
	NOTE: Protect IAA from light</li>
	<li>Add 460 &#181;L of pre-chilled (-20 &#176;C) acetone. Vortex samples and place at -20 &#176;C overnight.
	NOTE: The protocol can be paused here.</li>
	<li>Next day, centrifuge samples at 16,000 x g for 10 minutes at 4 &#176;C.</li>
	<li>Remove acetone without disrupting the protein pellet.</li>
	<li>Add 50 &#181;L of 90% pre-chilled (-20 &#176;C) acetone. Vortex samples to mix and centrifuge at 16,000 x g for an additional 5 minutes at 4 &#176;C.</li>
	<li>Remove acetone and let samples dry for 2-3 minutes.</li>
	<li>Resuspend protein pellet with 10 mM Tris buffer pH 8.</li>
	<li>Resuspend MS grade trypsin (20 &#181;g stock) in 40 &#181;L of 10 mM Tris buffer pH 8 and add 2.5 &#181;g of trypsin to each sample.</li>
	<li>Incubate samples at 37 &#176;C overnight.
	&#8203;NOTE: The protocol can be paused here.</li>
	<li>Assess peptide concentration using a colorimetric peptide assay.</li>
	<li>Quench the samples with 5% formic acid.</li>
	<li>Transfer 10 &#181;g of sample to a clean polypropylene tube.</li>
	<li>Dry the sample using a vacuum centrifuge and resuspend with 20 &#181;L of MS grade 0.1% formic acid (FA) in water.</li>
	<li>Transfer each sample to clean autosampler vials with pre-slit caps.</li>
</ol>
8. High performance Liquid Chromatography-Tandem Mass Spectrometry (LC-MS/MS)
<ol>
	<li>To localize FPOP modifications, analyze the digested cell lysate using LC-MS/MS analysis.</li>
	<li>Use mobile phases of 0.1% FA in water (A) and 0.1% FA in acetonitrile (ACN) (B).</li>
	<li>Load 0.5 &#181;g of sample onto a 180 &#181;m x 20 mm C18 (5 &#181;m and 100 &#197;) trapping column and wash the column with 99% (A) and 1% (B) for 15 minutes.</li>
	<li>Using a 75 &#181;m x 30 cm C18 (5 &#181;m and 125 &#197;) analytical column, elute and separate digested peptides with a flow rate of 0.300 &#181;L/min for 120 minutes.</li>
	<li>Run LC gradient as follows: 0&#8722;1 min, 3% solvent B; 2&#8722;100 min, 10&#8722;45% B;100&#8722;110 min, 45-100% B; 110&#8722;115 min, 100% B.</li>
	<li>Recondition the column at 3% (B) from 115-116 minutes and hold at 3% (B) from 116-120 minutes.</li>
	<li>Analyze eluted peptides in positive ion mode with nano electrospray ionization.</li>
	<li>Acquire MS1 spectra over a m/z scan range of 375-1500 at a resolution of 60,000.</li>
	<li>Set the automatic gain control (AGC) target to 5.0e5 with a maximum injection time of 50 ms and 5.0e4 intensity threshold.</li>
	<li>Isolate precursor ions with charge states 2-6 via data dependent acquisition (DDA) with an isolation window of 1.2 m/z and a cycle time of 4 seconds.</li>
	<li>Subject MS2 ions to high-energy collisional dissociation (HCD) (32% normalized energy).</li>
	<li>Exclude peptides after 1 MS/MS acquisition for 60 seconds.</li>
	<li>Set MS/MS resolution to 15,000 with an AGC target of 5.0e4 and a maximum injection time of 35 ms.</li>
</ol>
9. Proteome discoverer/data processing
<ol>
	<li>Search tandem raw data files on available bottom-up proteomics analysis software against a relevant Homo sapiens protein database and digest enzyme.</li>
	<li>Set the protein analysis search parameters.</li>
	<li>Set fragment tolerance to 0.02 Da and parent ion tolerance to 10 ppm.</li>
	<li>Set enzyme specificity to trypsin and allow for one missed cleavage.</li>
	<li>Set mass range to 375-1500 m/z.</li>
	<li>Establish peptide confidence at 95% (medium) and residue confidence at 99% (high).</li>
	<li>Accept proteins if at least two distinct peptides are identified with the 5% discovery rate (FDR) filter.</li>
	<li>Set carbamidomethylation as a static modification and all known hydroxyl radical side-chain modifications15,16&#160;as dynamic modifications.</li>
	<li>Once files are finished searching, export sequence, modification locations, protein accession, spectrum file, precursor abundance, and retention time information to an electronic database.</li>
	<li>Calculate the extent of modification per peptide or residue from this equation:
	<img alt="Equation 1" src="/files/ftp_upload/62153/62153eq01.jpg" />
	NOTE: EIC area modified is the extracted ion chromatographic area (EIC) of the peptide or residue with an oxidative modification, and EIC area is the total area of the same peptide or residue with and without the oxidative modification. Over time, protein in the presence of hydrogen peroxide will oxidize, resulting in background oxidations. To calculate the extent of modification, the area of the modified peptide is divided by the total area. A non-irradiated control sample accounts for background oxidation. The background oxidation from the control sample is subtracted out from the laser treated sample to identify an FPOP modification.</li>
</ol>

<ol>
	<li>Johnson, D. T., Di Stefano, L. H., Jones, L. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fast+photochemical+oxidation+of+proteins+(FPOP):+A+powerful+mass+spectrometry+based+structural+proteomics+tool.">Fast photochemical oxidation of proteins (FPOP): A powerful mass spectrometry based structural proteomics tool.</a> Journal of Biological Chemistry. 294 (32), 11969-11979 (2019).</li><li>Liu, X. R., Zhang, M. M., Gross, M. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mass+Spectrometry-Based+Protein+Footprinting+for+Higher-Order+Structure+Analysis:+Fundamentals+and+Applications.">Mass Spectrometry-Based Protein Footprinting for Higher-Order Structure Analysis: Fundamentals and Applications.</a> Chemical Reviews. 120 (10), 4355-4454 (2019).</li><li>Li, J., Chen, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+use+of+fast+photochemical+oxidation+of+proteins+coupled+with+mass+spectrometry+in+protein+therapeutics+discovery+and+development.">The use of fast photochemical oxidation of proteins coupled with mass spectrometry in protein therapeutics discovery and development.</a> Drug Discovery Today. 24 (3), 829-883 (2019).</li><li>Zhao, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Covalent+Labeling+with+an+&#945;,&#946;-Unsaturated+Carbonyl+Scaffold+for+Studying+Protein+Structure+and+Interactions+by+Mass+Spectrometry.">Covalent Labeling with an &#945;,&#946;-Unsaturated Carbonyl Scaffold for Studying Protein Structure and Interactions by Mass Spectrometry.</a> Analytical Chemistry. 92 (9), 6637-6644 (2020).</li><li>Hambly, D. M., Gross, M. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Laser+Flash+Photolysis+of+Hydrogen+Peroxide+to+Oxidize+Protein+Solvent-Accessible+Residues+on+the+Microsecond+Timescale.">Laser Flash Photolysis of Hydrogen Peroxide to Oxidize Protein Solvent-Accessible Residues on the Microsecond Timescale.</a> Journal of the American Society for Mass Spectrometry. 16 (12), 2057-2063 (2005).</li><li>Li, K. S., Shi, L., Gross, M. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mass+Spectrometry-Based+Fast+Photochemical+Oxidation+of+Proteins+(FPOP)+for+Higher+Order+Structure+Characterization.">Mass Spectrometry-Based Fast Photochemical Oxidation of Proteins (FPOP) for Higher Order Structure Characterization.</a> Accounts of Chemical Research. 51 (3), 736-744 (2018).</li><li>Chea, E. E., Jones, L. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Modifications+generated+by+fast+photochemical+oxidation+of+proteins+reflect+the+native+conformations+of+proteins.">Modifications generated by fast photochemical oxidation of proteins reflect the native conformations of proteins.</a> Protein Science. 27 (6), 1047-1056 (2018).</li><li>Hambly, D., Gross, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Laser+flash+photochemical+oxidation+to+locate+heme+binding+and+conformational+changes+in+myoglobin.">Laser flash photochemical oxidation to locate heme binding and conformational changes in myoglobin.</a> International Journal of Mass Spectrometry. 259 (1), 124-129 (2007).</li><li>Yan, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fast+photochemical+oxidation+of+proteins+(FPOP)+maps+the+epitope+of+EGFR+binding+to+adnectin.">Fast photochemical oxidation of proteins (FPOP) maps the epitope of EGFR binding to adnectin.</a> Journal of the American Society for Mass Spectrometry. 25 (12), 2084-2092 (2014).</li><li>Zhang, Y., Wecksler, A. T., Molina, P., Deperalta, G., Gross, M. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mapping+the+Binding+Interface+of+VEGF+and+a+Monoclonal+Antibody+Fab-1+Fragment+with+Fast+Photochemical+Oxidation+of+Proteins+(FPOP)+and+Mass+Spectrometry.">Mapping the Binding Interface of VEGF and a Monoclonal Antibody Fab-1 Fragment with Fast Photochemical Oxidation of Proteins (FPOP) and Mass Spectrometry.</a> Journal of the American Society for Mass Spectrometry. 28 (5), 850-858 (2017).</li><li>Espino, J. A., Mali, V. S., Jones, L. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+Cell+Footprinting+Coupled+with+Mass+Spectrometry+for+the+Structural+Analysis+of+Proteins+in+Live+Cells.">In Cell Footprinting Coupled with Mass Spectrometry for the Structural Analysis of Proteins in Live Cells.</a> Analytical Chemistry. 87 (15), 7971-7978 (2015).</li><li>Rinas, A., Mali, V. S., Espino, J. A., Jones, L. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development+of+a+Microflow+System+for+In-Cell+Footprinting+Coupled+with+Mass+Spectrometry.">Development of a Microflow System for In-Cell Footprinting Coupled with Mass Spectrometry.</a> Analytical Chemistry. 88 (20), 10052-10058 (2016).</li><li>Johnson, D. T., Punshon-Smith, B., Espino, J. A., Gershenson, A., Jones, L. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Implementing+In-Cell+Fast+Photochemical+Oxidation+of+Proteins+in+a+Platform+Incubator+with+a+Movable+XY+Stage.">Implementing In-Cell Fast Photochemical Oxidation of Proteins in a Platform Incubator with a Movable XY Stage.</a> Analytical Chemistry. 92 (2), 1691-1696 (2019).</li><li>Bangel-Ruland, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cystic+fibrosis+transmembrane+conductance+regulator-mRNA+delivery:+a+novel+alternative+for+cystic+fibrosis+gene+therapy.">Cystic fibrosis transmembrane conductance regulator-mRNA delivery: a novel alternative for cystic fibrosis gene therapy.</a> The Journal of Gene Medicine. 15 (11-12), 414-426 (2013).</li><li>Gau, B. C., Chen, H., Zhang, Y., Gross, M. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Sulfate+Radical+Anion+as+a+New+Reagent+for+Fast+Photochemical+Oxidation+of+Proteins.">Sulfate Radical Anion as a New Reagent for Fast Photochemical Oxidation of Proteins.</a> Analytical Chemistry. 82 (18), 7821-7827 (2010).</li><li>Xu, G. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hydroxyl+Radical-Mediated+Modification+of+Proteins+as+Probes+for+StructuralProteomics.">Hydroxyl Radical-Mediated Modification of Proteins as Probes for StructuralProteomics.</a> Chemical Reviews. American Chemical Society. 107 (8), 3514-3543 (2007).</li><li>Espino, J. A., Jones, L. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Illuminating+Biological+Interactions+with+In+Vivo+Protein+Footprinting.">Illuminating Biological Interactions with In Vivo Protein Footprinting.</a> Analytical Chemistry. 9 (10), 6577-6584 (2019).</li><li>Gau, B. C., Sharp, J. S., Rempel, D. L., Gross, M. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fast+Photochemical+Oxidation+of+Protein+Footprints+Faster+than+Protein+Unfolding.">Fast Photochemical Oxidation of Protein Footprints Faster than Protein Unfolding.</a> Analytical Chemistry. 81 (16), 6563-6571 (2009).</li><li>Kaur, U., Johnson, D. T., Jones, L. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Validation+of+the+Applicability+of+In-Cell+Fast+Photochemical+Oxidation+of+Proteins+across+Multiple+Eukaryotic+Cell+Lines.">Validation of the Applicability of In-Cell Fast Photochemical Oxidation of Proteins across Multiple Eukaryotic Cell Lines.</a> Journal of the American Society for Mass Spectrometry. 31 (7), 1372-1379 (2020).</li></ol>

The authors declare no competing financial interest.
The research presented herein is associated with the below referenced patent application:
U.S. Non-Provisional Patent Application Number: 17/042,565
Title: &#34;Device and Method for Determining Protein Folding&#34;
UMB Docket Number: LJ-2018-104 UMass Ref: UMA 18-059.

Proteins perform much of the work in living cells. Given this importance, detailed data on protein function and higher order structure (HOS) in the cellular environment is needed to deepen understanding of the intricacies in larger complexes and enzymatic reactions in cells as opposed to purified systems. To do this, a hydroxyl radical protein foot printing (HRFP) method was adopted entitled In-Cell Fast Photochemical Oxidation of Proteins (IC-FPOP). Most FPOP studies have been done in vitro in relatively pure protein systems, which markedly contrasts with the crowded molecular environment which affects binding interactions and protein conformational dynamics. As a result, there is a chasm between the findings from in vitro experiments18 and those that would be obtained in an actual cellular environment. To bridge the gap between the idealized conditions of an in vitro FPOP experiment&#160;and the complex nature of the cell, a new automated six-well plate-based in cell-FPOP platform has been developed. This novel FPOP technology is capable of identifying and characterizing these molecular species and tracing their dynamic molecular interactions in both healthy and diseased states. This new platform is called Platform Incubator with Movable XY stage (PIXY).
FPOP has been successfully used to characterize the structural information within the proteome. However, every biological technique has certain limitations that require further improvement. Specific reagents are required during laser photolysis and to efficiently quench unreacted hydroxyl radicals. Separation of digested peptides can require large amounts of time to maximize structural information.This wealth of information can also require extensive quantitation during post-MS data analysis1. The platform incubator, including the peripheral machinery needed for cell culture and IC-FPOP at the laser platform, comes with a large cost that may not be feasible for some labs. As progress continues to be made, robust software and analysis tools should advance the technique further; some of which is showcased in this study. Current studies in this platform incubator have been performed on HEK293T cells and in C. elegans. The IC-FPOP method has been shown to be compatible with a wide variety of cell lines including Chinese hamster ovary (CHO), Vero, MCF-7, and MCF10-A cells19. Since the general IC-FPOP method is translatable to this static platform, these cell lines should be amenable for study using PIXY as well.
IC-FPOP utilizes H2O2 to oxidatively modify solvent accessible side chains of amino acids, to then further discern protein interactions, structure, and metabolic effects within viable cells which is significant in providing biological context. It is essential before an IC-FPOP experiment to confirm that the cells are viable after H2O2 addition. Cell viability studies demonstrated that the cells were viable in the presence of H2O2 concentrations up to 200 mM 13. It is also important to make sure H2O2 is infused at a final concentration of 200 mM directly on cells after media is removed. Failure to completely remove cell culture media will cause varying concentrations of H2O2. Compared to standard conditions, increasing the incubation time to 10 seconds along with increasing the H2O2 concentration led to a higher number of proteins modified by IC-FPOP in the platform incubator. It is imperative to prime peristaltic pumps before use to ensure pumps are working properly and liquid is being dispersed. Failure to do so may cause air bubbles in the tubing, insufficient volume of H2O2 to immerse cells, and/or insufficient volume of quench solution.
Another issue that may arise is unwanted delays in the system. An example of this is the process of verifying received commands for the pump systems which adds significant delays on the order of 1000 or more milliseconds using the integration software. This problem can be fixed by minimizing the communication with the pumps during the experiment and using pre-set commands ahead of time as much as possible.
In the future, the goal for PIXY is producing a fully automated and integrated system. In addition to the peristaltic pumps, the triggering of the laser pulse will be automated. A new positioning system will also be utilized for the rapid movement of the platform incubator to enhance speed and accuracy. All components of the system will continue to be programmed using the integration software to further increase throughput.

Protein footprinting techniques can reveal profound information on the organization of proteins. These essential structural biology MS-based techniques are a component of the mass spectrometry toolbox. These methods probe protein higher order structure (HOS) and synergy via covalent labeling1,2,3,4. Fast photochemical oxidation of proteins (FPOP) employs hydroxyl radicals to oxidatively modify solvent accessible side chains of amino acids5,6 (Table 1). The method utilizes an excimer laser at 248 nm for photolysis of hydrogen peroxide (H2O2) to generate hydroxyl radicals. Theoretically, 19 of the 20 amino acids can be oxidatively modified with Gly being the lone exception. However, owing to the varying&#160;reactivity rates of amino acids with hydroxyl radicals, modification of only a subset of these has been observed experimentally. Still, the method does have the potential for analysis over the length of a protein sequence5. FPOP modifies proteins on the microsecond timescale, making it useful in studying weak interactions with fast off rates. Solvent accessibility changes upon ligand-binding or a change in protein conformation, thus, the power of the method lies in the comparison of the labeling pattern of a protein in multiple states (i.e., ligand-free compared to ligand-bound). As a result, FPOP has been successful in identifying protein-protein and protein-ligand interaction sites and regions of conformational change7,8,9,10. The FPOP method has been extended from the study of purified protein systems to in-cell analysis. In-cell FPOP (IC-FPOP) can oxidatively modify over a thousand proteins in cells to provide structural information across the proteome11,12. The conventional IC-FPOP platform utilizes a flow system to flow cells single file past the laser beam. The development of this system allowed individual cells to have equal exposure to laser irradiation. This led to a 13-fold rise in the number of oxidatively labeled proteins12. However, a limitation of the flow system is the length of a single sample experiment consisting of a 10-minute irradiation interval during which modification takes place and an additional 10-minute wash cycle. The time constraints of IC-FPOP makes it unsuitable for studying short lived protein folding intermediates or changes that exist among interaction networks in biochemical signaling cascades. This temporal limitation inspired the design of a new IC-FPOP platform equipped with higher throughput.
To accurately measure protein higher order structure in the native cell environment, the new design allows cell culture to be accomplished directly at the laser platform, which enables IC-FPOP to be high throughput. This setup also allows minimized perturbations to the cellular environment, in contrast to IC-FPOP using flow where adherent cells must be removed from the substrate. The new platform permits IC-FPOP to occur in a sterile incubation system using a CO2 and temperature-controlled stage top chamber while utilizing configured mirror optics for laser beam guidance, a positioning system for XY motion, and peristaltic pumps for chemical exchange. The new platform for conducting IC-FPOP is entitled Platform Incubator with Movable XY Stage (PIXY) (Figure 1). In PIXY, IC-FPOP is carried out on human cells grown in six-well plates within the platform incubator chamber. For this configuration, the laser beam is reflected downward onto the plate using beam compatible mirrors as a positioning stage that holds the incubator is moved, in the XY-plane, so the laser beam is strategically aligned to only irradiate one well at a time. Validation studies show that IC-FPOP can be performed faster in PIXY than in the flow system and leads to increased amino acid modifications per protein. The development of this new IC-FPOP platform will expound upon the knowledge that can be gained from cellular experiments13.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Ismatec Reglo ICC Peristaltic Pumps</td>
			<td>Cole-Palmer</td>
			<td>122270050</td>
			<td></td>
		</tr>
		<tr>
			<td>&#160;Kinematic Mirror Mount for &#216;2&#34; Optics</td>
			<td>Thor Labs</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>10X trypsin&#8722;EDTA</td>
			<td>Corning</td>
			<td>AB00490-00005</td>
			<td></td>
		</tr>
		<tr>
			<td>50.0mm 248nm 45&#176;, Excimer Laser Line Mirror</td>
			<td>Edmond Optics</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Acetone, HPLC Grade</td>
			<td>Fisher Scientific</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Acetonitrile with 0.1% Formic Acid (v/v), LC/MS Grade</td>
			<td>Fisher Scientific</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>ACQUITY UPLC M-Class Symmetry C18 Trap Column, 100&#197;, 5 &#181;m, 180 &#181;m x 20 mm, 2G, V/M, 1/pkg</td>
			<td>Waters</td>
			<td>23275</td>
			<td>other high resolution instruments (e.g. Q exactive Orbitrap or Orbitrap Fusion) can be used</td>
		</tr>
		<tr>
			<td>ACQUITY UPLC M-Class System</td>
			<td>Waters</td>
			<td>A53225</td>
			<td></td>
		</tr>
		<tr>
			<td>Afinia H480 3D Printer</td>
			<td>(Innovation Space University of Maryland Baltimore Campus Library)</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>air pump</td>
			<td>OKOlabs</td>
			<td>D12345</td>
			<td></td>
		</tr>
		<tr>
			<td>Aluminum Foil</td>
			<td>Fisher Scientific</td>
			<td>Stock #63-120</td>
			<td></td>
		</tr>
		<tr>
			<td>Aqua 5 &#181;m C18 125 &#197; packing material</td>
			<td>Phenomenex</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>carbon dioxide unit</td>
			<td>OKOlabs</td>
			<td>MadMotor&#174;-UHV</td>
			<td></td>
		</tr>
		<tr>
			<td>Centrifuge</td>
			<td>Eppendorf</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>connectors (Y PP 1/16&#8221; and 1/16x1/8&#8221;)</td>
			<td>Cole-Palmer</td>
			<td>116891000</td>
			<td></td>
		</tr>
		<tr>
			<td>Delicate Task Wipers</td>
			<td>Fisher Scientific</td>
			<td>022625501</td>
			<td></td>
		</tr>
		<tr>
			<td>Dithiothreiotol (DTT)</td>
			<td>AmericanBio</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>DMSO, Anhydrous</td>
			<td>Invitrogen</td>
			<td>LS118-500</td>
			<td></td>
		</tr>
		<tr>
			<td>Dulbecco&#8217;s phosphate-buffered saline (DPBS)</td>
			<td>Corning</td>
			<td>SK-78001-82</td>
			<td></td>
		</tr>
		<tr>
			<td>EX350 excimer laser</td>
			<td>GAM Laser</td>
			<td>PI89900</td>
			<td></td>
		</tr>
		<tr>
			<td>Fetal bovine serum (FBS)</td>
			<td>Corning</td>
			<td>SK-12023-78</td>
			<td></td>
		</tr>
		<tr>
			<td>Formic Acid, LC/MS Grade</td>
			<td>Fisher Scientific</td>
			<td>A929-4</td>
			<td>4 L quantity is not necessary</td>
		</tr>
		<tr>
			<td>HEK293T cells</td>
			<td>Paul Shapiro Lab (University of Maryland Baltimore)</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>humidifier</td>
			<td>OKOlabs</td>
			<td>Nano-LPMW stage</td>
			<td></td>
		</tr>
		<tr>
			<td>HV3-2 VALVE</td>
			<td>Hamilton</td>
			<td>BP152-500</td>
			<td></td>
		</tr>
		<tr>
			<td>Hydrogen Peroxide</td>
			<td>Fisher Scientific</td>
			<td>LS120-500</td>
			<td></td>
		</tr>
		<tr>
			<td>Iodoacetamide (IAA)</td>
			<td>ACROS Organics</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>LABVIEW Professional 2018</td>
			<td>National Instruments</td>
			<td>86728</td>
			<td></td>
		</tr>
		<tr>
			<td>MadMotor Positioning system and controllers</td>
			<td>Mad City Labs</td>
			<td>W6-4</td>
			<td></td>
		</tr>
		<tr>
			<td>Methanol, LC/MS Grade</td>
			<td>Fisher Scientific</td>
			<td>01-213-100</td>
			<td>any brand is sufficient</td>
		</tr>
		<tr>
			<td>Microcentrifuge</td>
			<td>Thermo Scientific</td>
			<td>H301-T Unit-BL-PLUS</td>
			<td></td>
		</tr>
		<tr>
			<td>N,N&#8242;-Dimethylthiourea (DMTU)</td>
			<td>ACROS Organics</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Nanopositioinging stage</td>
			<td>Mad City Labs</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>N-tert-Butyl-&#945;-phenylnitrone (PBN)</td>
			<td>ACROS Organics</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>OKO Touch Monitoring System</td>
			<td>OKOlabs</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Orbitrap Fusion Lumos Tribrid Mass Spectrometer</td>
			<td>Thermo Scientific</td>
			<td>7Z02936</td>
			<td></td>
		</tr>
		<tr>
			<td>PE50-C pyroelectric energy meter</td>
			<td>Ophir Optronics</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Penicillin-streptomycin</td>
			<td>Corning</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Pierce Quantitative Colorimetric Peptide Assay</td>
			<td>Thermo Scientific</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Pierce Rapid Gold BCA Protein Assay Kit</td>
			<td>Thermo Scientific</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Pierce Trypsin Protease, MS Grade</td>
			<td>Thermo Scientific</td>
			<td>75002436</td>
			<td></td>
		</tr>
		<tr>
			<td>Pierce Universal Nuclease for Cell Lysis</td>
			<td>Fisher Scientific</td>
			<td>06-666A</td>
			<td></td>
		</tr>
		<tr>
			<td>pressure gauge</td>
			<td>OKOlabs</td>
			<td>OKO-AIR-PUMP-BL</td>
			<td></td>
		</tr>
		<tr>
			<td>PTFE filter</td>
			<td>OKOlabs</td>
			<td>CO2-UNIT-BL</td>
			<td></td>
		</tr>
		<tr>
			<td>Six 33 mm PLA filament rings</td>
			<td>(Innovation Space University of Maryland Baltimore Campus Library)</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>sterile incubator</td>
			<td>OKOlabs</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>temperature unit</td>
			<td>OKOlabs</td>
			<td>OKO-TOUCH</td>
			<td></td>
		</tr>
		<tr>
			<td>Thermo Scientific Pierce RIPA Buffer</td>
			<td>Fisher Scientific</td>
			<td>A117-50</td>
			<td></td>
		</tr>
		<tr>
			<td>TiNKERcad</td>
			<td>(Innovation Space University of Maryland Baltimore Campus Library)</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Tris Base</td>
			<td>Fisher Scientific</td>
			<td>H325-100</td>
			<td>any 30% hydrogen peroxide is sufficient</td>
		</tr>
		<tr>
			<td>tubing (Tygon 3.18 and 1.59 ID)</td>
			<td>Cole-Palmer</td>
			<td>177350250</td>
			<td></td>
		</tr>
		<tr>
			<td>Water with 0.1% Formic Acid (v/v), LC/MS Grade</td>
			<td>Fisher Scientific</td>
			<td>A454SK-4</td>
			<td>4 L quantity is not necessary</td>
		</tr>
		<tr>
			<td>Water, LC/MS Grade</td>
			<td>Fisher Scientific</td>
			<td>88702</td>
			<td></td>
		</tr>
		<tr>
			<td></td>
			<td></td>
			<td>90058</td>
			<td></td>
		</tr>
		<tr>
			<td></td>
			<td></td>
			<td>KM200</td>
			<td></td>
		</tr>
		<tr>
			<td></td>
			<td></td>
			<td>186007496</td>
			<td></td>
		</tr>
	</tbody>
</table>

platform incubator with movable xy stage: a new platform for implementing in-cell fast photochemical oxidation of proteins

Fast Photochemical Oxidation of proteins (FPOP) coupled with mass spectrometry (MS) has become an invaluable tool in structural proteomics to interrogate protein interactions, structure, and protein conformational dynamics as a function of solvent accessibility. In recent years, the scope of FPOP, a hydroxyl radical protein foot printing (HRPF) technique, has been expanded to protein labeling in live cell cultures, providing the means to study protein interactions in the convoluted cellular environment. In-cell protein modifications can provide insight into ligand induced structural changes or conformational changes accompanying protein complex formation, all within the cellular context. Protein footprinting has been accomplished employing a customary flow-based system and a 248 nm KrF excimer laser to yield hydroxyl radicals via photolysis of hydrogen peroxide, requiring 20 minutes of analysis for one cell sample.To facilitate time-resolved FPOP experiments, the use of a new 6-well plate-based IC-FPOP platform was pioneered. In the current system, a single laser pulse irradiates one entire well, which truncates the FPOP experimental time frame resulting in 20 seconds of analysis time, a 60-fold decrease. This greatly reduced analysis time makes it possible to research cellular mechanisms such as biochemical signaling cascades, protein folding, and differential experiments (i.e., drug-free vs. drug bound) in a time-dependent manner. This new instrumentation, entitled Platform Incubator with Movable XY Stage (PIXY), allows the user to perform cell culture and IC-FPOP directly on the optical bench using a platform incubator with temperature, CO2 and humidity control. The platform also includes a positioning stage, peristaltic pumps, and mirror optics for laser beam guidance. IC-FPOP conditions such as optics configuration, flow rates, transient transfections, and H2O2 concentration in PIXY have been optimized and peer-reviewed. Automation of all components of the system will reduce human manipulation and increase throughput.

To confirm that the platform incubator conditions are sufficient for cell culture at the laser platform, GCaMP2 was transiently transfected into HEK293T and transfection efficiency for both plates was assessed via fluorescence imaging (Figure 4A). GCaMP2 is a calcium sensing fluorescent protein used as a genetically encoded intracellular calcium indicator. It is a fusion of green fluorescent protein (GFP) and the calcium-binding protein, calmodulin. A luciferase assay was performed on HEK 293 cells transfected with plasmid prl-TK in order to quantify transfection efficiency (Figure 4B). These results show that the platform incubator exceeded the performance of the standard incubator, with a 1.13-fold increase in transfection efficiency, providing a quantitative benchmark for optimal cell culture environment.
FPOP modifications in HEK293T cells labeled in the flow system were compared to those labeled in the platform incubator and showed that the platform incubator outperforms the flow system both in the number of proteins modified (Figure 5)&#160;and the total FPOP coverage in those proteins. The number of FPOP modified proteins acquired in the platform incubator was approximately 1051, 2.2- fold more than those acquired in a typical experiment. Modifications were combined between two biological replicates for each experiment. Furthermore, PIXY provides higher throughput.
To demonstrate the advantage of higher modification coverage across a protein, IC-FPOP modifications were localized on the peptide level and the extent of modification was quantified to distinguish differences in outcomes between the systems for actin, a 375 amino acid protein. In the flow system, two modified peptides were detected, providing limited structural information (Figure 6A). However, five modified peptides spanning the actin sequence were detected in the platform incubator. Tandem mass spectra indicate that residue Pro322 was both modified and detected in each experiment (Figure 6B). The five peptides modified in the platform incubator samples contained twelve modified residues, while only four residues were modified with the flow system (Figure 6C). The increase in oxidation coverage provides more structural information across the protein.
Espino et al. demonstrated the capacity of FPOP to be performed in vivo (IV-FPOP) within C. elegans, a worm model for human disease states17.While IV-FPOP is also performed via a flow system, the PIXY system was tested for compatibility with the worms. Approximately 10,000 worms were incubated in each well in the platform incubator at 20 &#176;C. LC&#8722;MS/MS analysis revealed that 792 proteins were modified by IV-FPOP in the platform incubator compared to the 545 proteins modified with the flow system (Figure 7). These results demonstrate that in addition to 2D cell culture, this new methodology is also compatible with the study of other biological systems such as C. elegans.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/62153/62153fig01.jpg" />
Figure 1. Schematic of PIXY System. System components: (A) stage-top incubator, (B) positioning system , (C) peristaltic pumps, and (D) perfusion lines. Cell culture media is removed from each well via pumps before H2O2 and quench solutions are infused at calculated timepoints. Laser path for irradiation showcased in white. Reprinted with permission from Johnson, D. T., Punshon-Smith, B., Espino, J. A., Gershenson, A., Jones, L. M., Implementing In-Cell Fast Photochemical Oxidation of Proteins in a Platform Incubator with a Movable XY Stage. Analytical Chemistry, 92(2), 1691-1696 2019. Copyright 2020 American Chemical Society. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/62153/62153fig01large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/62153/62153fig02.jpg" />
Figure 2. Fully Assembled PIXY system. (A) Touch monitoring system, (B) carbon dioxide unit, (C) temperature unit, (D) air pump, (E) humidifier, (F) optical mirrors, (G) platform incubator, (H) positioning stage, (I) 248nm KrF excimer laser, and (J) peristaltic pumps. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/62153/62153fig02large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/62153/62153fig03.jpg" />
Figure 3.&#160;Automation of Peristaltic Pumps. (A) Example command script in LABVIEW. Command options include volume, flow rate, pauses, flow direction. Speed, stage distance, and location are currently being automated. (B) Script reader in LABVIEW. Here, command scripts are uploaded then Run Sequence and START are pressed to initiate pumps. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/62153/62153fig03large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 4" class="xfigimg" src="/files/ftp_upload/62153/62153fig04.jpg" />
Figure 4. HEK cell transfection efficiency. (A) Mean fluorescent intensity of GCaMP2 transfection comparison between standard incubator (Control) and stage-top incubator (PIXY). Dots and squares represent each point in a well where a measure was taken. (B) Transfection efficiency quantitated and validated with a different vector plasmid, pRL-TK. P-value&#60; 0.005. Reprinted with permission from Johnson, D. T., Punshon-Smith, B., Espino, J. A., Gershenson, A., Jones, L. M., Implementing In-Cell Fast Photochemical Oxidation of Proteins in a Platform Incubator with a Movable XY Stage. Analytical Chemistry, 92(2), 1691-1696 2019. Copyright 2020 American Chemical Society. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/62153/62153fig04large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 5" class="xfigimg" src="/files/ftp_upload/62153/62153fig05.jpg" />
Figure 5. Comparison of proteins modified in the single cell flow system and PIXY. Venn diagram of proteins modified using in the flow system (purple) and in PIXY (green). Reprinted with permission from Johnson, D. T., Punshon-Smith, B., Espino, J. A., Gershenson, A., Jones, L. M., Implementing In-Cell Fast Photochemical Oxidation of Proteins in a Platform Incubator with a Movable XY Stage. Analytical Chemistry, 92(2), 1691-1696 2019. Copyright 2020 American Chemical Society. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/62153/62153fig05large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 6" class="xfigimg" src="/files/ftp_upload/62153/62153fig06.jpg" />
Figure 6. Localization of IC-FPOP modifications. Comparison of IC-FPOP modifications between systems. (A) Bar graph of oxidatively modified peptides within actin from the flow system (purple) vs platform incubator (green). (B) Tandem MS spectra of actin (peptide 316-326) with modified proline in both systems and unmodified actin peptide (C) FPOP modified residues of actin (PDB: 6ZXJ, chain A 11 modified residues in platform incubator (green), 3 modified residues in the flow system (purple), 1 overlapping modified residue (yellow). Reprinted with permission from Johnson, D. T., Punshon-Smith, B., Espino, J. A., Gershenson, A., Jones, L. M., Implementing In-Cell Fast Photochemical Oxidation of Proteins in a Platform Incubator with a Movable XY Stage. Analytical Chemistry, 92(2), 1691-1696 2019. Copyright 2020 American Chemical Society. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/62153/62153fig06large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 7" class="xfigimg" src="/files/ftp_upload/62153/62153fig07.jpg" />
Figure 7.&#160;Comparison of FPOP modified proteins in C. elegans by flow vs PIXY. There is a 1.5-fold increase in oxidatively modified proteins using PIXY when compared to the flow system. Reprinted with permission from Johnson, D. T., Punshon-Smith, B., Espino, J. A., Gershenson, A., Jones, L. M., Implementing In-Cell Fast Photochemical Oxidation of Proteins in a Platform Incubator with a Movable XY Stage. Analytical Chemistry, 92(2), 1691-1696 2019. Copyright 2020 American Chemical Society. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/62153/62153fig07large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
Table 1. Workflow modification distribution and mass shifts (Da). <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/62153/Table 1.docx" target="_blank">Please click here to download&#160;this table.</a>

Watch this Scientific Journal Video about Platform Incubator with Movable XY Stage: A New Platform for Implementing In-Cell Fast Photochemical Oxidation of Proteins at JoVE.com

Platform Incubator with Movable XY Stage: A New Platform for Implementing In-Cell Fast Photochemical Oxidation of Proteins

A new static platform is used to characterize protein structure and interaction sites in the native cell environment utilizing a protein footprinting technique called in-cell fast photochemical oxidation of proteins (IC-FPOP).

Fast Photochemical Oxidation of proteins (FPOP) coupled with mass spectrometry (MS) has become an invaluable tool in structural proteomics to interrogate ...

platform-incubator-with-movable-xy-stage-new-platform-for

Universidad de Cartagena UDEC

Research

JoVE Journal

Biochemistry

3.2K Views.  University of Maryland Baltimore. A new static platform is used to characterize protein structure and interaction sites in the native cell environment utilizing a protein footprinting technique called in-cell fast photochemical oxidation of proteins (IC-FPOP).

Video: Platform Incubator with Movable XY Stage: A New Platform for Implementing In-Cell Fast Photochemical Oxidation of Proteins

Fabricating a UV-Vis and Raman Spectroscopy Immunoassay Platform

Immunoassays are used to detect proteins based on the presence of associated antibodies. Because of their extensive use in research and clinical settings, a large infrastructure of immunoassay instruments and materials can be found. For example, 96- and 384-well polystyrene plates are available commercially and have a standard design to accommodate ultraviolet-visible (UV-Vis) spectroscopy machines from various manufacturers. In addition, a wide variety of immunoglobulins, detection tags, and blocking agents for customized immunoassay designs such as enzyme-linked immunosorbent assays (ELISA) are available.
Despite the existing infrastructure, standard ELISA kits do not meet all research needs, requiring individualized immunoassay development, which can be expensive and time-consuming. For example, ELISA kits have low multiplexing (detection of more than one analyte at a time) capabilities as they usually depend on fluorescence or colorimetric methods for detection. Colorimetric and fluorescent-based analyses have limited multiplexing capabilities due to broad spectral peaks. In contrast, Raman spectroscopy-based methods have a much greater capability for multiplexing due to narrow emission peaks. Another advantage of Raman spectroscopy is that Raman reporters experience significantly less photobleaching than fluorescent tags1. Despite the advantages that Raman reporters have over fluorescent and colorimetric tags, protocols to fabricate Raman-based immunoassays are limited. The purpose of this paper is to provide a protocol to prepare functionalized probes to use in conjunction with polystyrene plates for direct detection of analytes by UV-Vis analysis and Raman spectroscopy. This protocol will allow researchers to take a do-it-yourself approach for future multi-analyte detection while capitalizing on pre-established infrastructure.

Nanoparticle-based optical probes have been designed as a vehicle for detecting antigens using Raman and UV-Vis spectroscopy. Here we describe a protocol for preparing such probes for a UV-Vis/Raman spectroscopy immunoassay in such a way to incorporate future multiplexing capabilities.

Immunoassays are used to detect proteins based on the presence of associated antibodies. Because of their extensive use in research and clinical settings, ...

Protein Film Infrared Electrochemistry Demonstrated for Study of H2 Oxidation by a [NiFe] Hydrogenase

Understanding the chemistry of redox proteins demands methods that provide precise control over redox centers within the protein. The technique of protein film electrochemistry, in which a protein is immobilized on an electrode surface such that the electrode replaces physiological electron donors or acceptors, has provided functional insight into the redox reactions of a range of different proteins. Full chemical understanding requires electrochemical control to be combined with other techniques that can add additional structural and mechanistic insight. Here we demonstrate a technique, protein film infrared electrochemistry, which combines protein film electrochemistry with infrared spectroscopic sampling of redox proteins. The technique uses a multiple-reflection attenuated total reflectance geometry to probe a redox protein immobilized on a high surface area carbon black electrode. Incorporation of this electrode into a flow cell allows solution pH or solute concentrations to be changed during measurements. This is particularly powerful in addressing redox enzymes, where rapid catalytic turnover can be sustained and controlled at the electrode allowing spectroscopic observation of long-lived intermediate species in the catalytic mechanism. We demonstrate the technique with experiments on E. coli hydrogenase 1 under turnover (H2 oxidation) and non-turnover conditions.

Protein Film Infrared Electrochemistry Demonstrated for Study of H2 Oxidation by a [NiFe] Hydrogenase

Here, we describe a technique, protein film infrared electrochemistry, which allows immobilized redox proteins to be studied spectroscopically under direct electrochemical control at a carbon electrode. Infrared spectra of a single protein sample can be recorded at a range of applied potentials and under a variety of solution conditions.

Understanding the chemistry of redox proteins demands methods that provide precise control over redox centers within the protein. The technique of protein ...

Multiplexed Isothermal Amplification Based Diagnostic Platform to Detect Zika, Chikungunya, and Dengue 1

Zika, dengue, and chikungunya viruses are transmitted by mosquitoes, causing diseases with similar patient symptoms. However, they have different downstream patient-to-patient transmission potentials, and require very different patient treatments. Thus, recent Zika outbreaks make it urgent to develop tools that rapidly discriminate these viruses in patients and trapped mosquitoes, to select the correct patient treatment, and to understand and manage their epidemiology in real time.
Unfortunately, current diagnostic tests, including those receiving 2016 emergency use authorizations and fast-track status, detect viral RNA by reverse transcription polymerase chain reaction (RT-PCR), which requires instrumentation, trained users, and considerable sample preparation. Thus, they must be sent to &#34;approved&#34; reference laboratories, requiring time. Indeed, in August 2016, the Center for Disease Control (CDC) was asking pregnant women who had been bitten by a mosquito and developed a Zika-indicating rash to wait an unacceptable 2 to 4 weeks before learning whether they were infected. We very much need tests that can be done on site, with few resources, and by trained but not necessarily licensed personnel.
This video demonstrates an assay that meets these specifications, working with urine or serum (for patients) or crushed mosquito carcasses (for environmental surveillance), all without much sample preparation. Mosquito carcasses are captured on paper carrying quaternary ammonium groups (Q-paper) followed by ammonia treatment to manage biohazards. These are then directly, without RNA isolation, put into assay tubes containing freeze-dried reagents that need no chain of refrigeration. A modified form of reverse transcription loop-mediated isothermal amplification with target-specific fluorescently tagged displaceable probes produces readout, in 30 min, as a three-color fluorescence signal. This is visualized with a handheld, battery-powered device with an orange filter. Forward contamination is prevented with sealed tubes, and the use of thermolabile uracil DNA glycosylase (UDG) in the presence of dUTP in the amplification mixture.

Current multiplexed diagnostics to detect Zika, chikungunya, and dengue viruses require complex sample preparation and expensive instrumentation, and are difficult to use in low resource environments. We show a diagnostic that uses isothermal amplification with target-specific strand displaceable probes to detect and differentiate these viruses with high sensitivity and specificity.

Zika, dengue, and chikungunya viruses are transmitted by mosquitoes, causing diseases with similar patient symptoms. However, they have different ...

A Rat Methyl-Seq Platform to Identify Epigenetic Changes Associated with Stress Exposure

As genomes of a wider variety of animals become available, there is an increasing need for tools that can capture dynamic epigenetic changes in these animal models. The rat is one particular model animal where an epigenetic tool can complement many pharmacological and behavioral studies to provide insightful mechanistic information. To this end, we adapted the SureSelect Target Capture System (referred to as Methyl-Seq) for the rat, which can assess DNA methylation levels across the rat genome. The rat design targeted promoters, CpG islands, island shores, and GC-rich regions from all RefSeq genes.
To implement the platform on a rat experiment, male Sprague Dawley rats were exposed to chronic variable stress for 3 weeks, after which blood samples were collected for genomic DNA extraction. Methyl-Seq libraries were constructed from the rat DNA samples by shearing, adapter ligation, target enrichment, bisulfite conversion, and multiplexing. Libraries were sequenced on a next-generation sequencing platform and the sequenced reads were analyzed to identify DMRs between DNA of stressed and unstressed rats. Top candidate DMRs were independently validated by bisulfite pyrosequencing to confirm the robustness of the platform.
Results demonstrate that the rat Methyl-Seq platform is a useful epigenetic tool that can capture methylation changes induced by exposure to stress.

Here, we describe the protocol and implementation of Methyl-Seq, an epigenomic platform, using a rat model to identify epigenetic changes associated with chronic stress exposure. Results demonstrate that the rat Methyl-Seq platform is capable of detecting methylation differences that arise from stress exposure in rats.

As genomes of a wider variety of animals become available, there is an increasing need for tools that can capture dynamic epigenetic changes in these ...

Use of Recombinant Fusion Proteins in a Fluorescent Protease Assay Platform and Their In-gel Renaturation

Proteases are intensively studied enzymes due to their essential roles in several biological pathways of living organisms and in pathogenesis; therefore, they are important drug targets. We have developed a magnetic-agarose-bead-based assay platform for the investigation of proteolytic activity, which is based on the use of recombinant fusion protein substrates. In order to demonstrate the use of this assay system, a protocol is presented on the example of human immunodeficiency virus type 1 (HIV-1) protease. The introduced assay platform can be utilized efficiently in the biochemical characterization of proteases, including enzyme activity measurements in mutagenesis, kinetic, inhibition, or specificity studies, and it may be suitable for high-throughput substrate screening or may be adapted to other proteolytic enzymes.
In this assay system, the applied substrates contain N-terminal hexahistidine (His6) and maltose-binding protein (MBP) tags, cleavage sites for tobacco etch virus (TEV) and HIV-1 proteases, and a C-terminal fluorescent protein. The substrates can be efficiently produced in Escherichia coli cells and easily purified using nickel (Ni)-chelate-coated beads. During the assay, the proteolytic cleavage of bead-attached substrates leads to the release of fluorescent cleavage fragments, which can be measured by fluorimetry. Additionally, cleavage reactions can be analyzed by sodium dodecyl sulfate-polyacrylamide gel electrophoresis (SDS-PAGE). A protocol for the in-gel renaturation of assay components is also described, as partial renaturation of fluorescent proteins enables their detection based on molecular weight and fluorescence.

Here, we present the detailed procedure of a recently developed protease assay platform utilizing N-terminal hexahistidine/maltose-binding protein and fluorescent protein-fused recombinant substrates attached to the surface of nickel-nitrilotriacetic acid magnetic agarose beads. A subsequent in-gel analysis of the assay samples separated by sodium dodecyl sulfate-polyacrylamide gel electrophoresis is also presented.

Proteases are intensively studied enzymes due to their essential roles in several biological pathways of living organisms and in pathogenesis; therefore, ...

Measuring Interactions between Fluorescent Probes and Lignin in Plant Sections by sFLIM Based on Native Autofluorescence

In lignocellulosic biomass (LB), the activity of enzymes is limited by the appearance of non-specific interactions with lignin during the hydrolysis process, which maintains enzymes far from their substrate. Characterization of these complex interactions is thus a challenge in complex substrates such as LB. The method here measures molecular interactions between fluorophore-tagged molecules and native autofluorescent lignin, to be revealed by F&#246;rster resonance energy transfer (FRET). Contrary to FRET measurements in living cells using two exogenous fluorophores, FRET measurements in plants using lignin is not trivial due to its complex autofluorescence. We have developed an original acquisition and analysis pipeline with correlated observation of two complementary properties of fluorescence: fluorescence emission and lifetime. sFLIM (spectral and fluorescent lifetime imaging microscopy) provides the quantification of these interactions with high sensitivity, revealing different interaction levels between biomolecules and lignin.

This protocol describes an original setup combining spectral and fluorescence lifetime measurements to evaluate F&#246;rster resonance energy transfer (FRET) between rhodamine-based fluorescent probes and lignin polymer directly in thick plant sections.

In lignocellulosic biomass (LB), the activity of enzymes is limited by the appearance of non-specific interactions with lignin during the hydrolysis ...

Characterizing Cellular Proteins with In-cell Fast Photochemical Oxidation of Proteins

Fast photochemical oxidation of proteins (FPOP) is a hydroxyl radical protein footprinting method used to characterize protein structure and interactions. FPOP uses a 248 nm excimer laser to photolyze hydrogen peroxide producing hydroxyl radicals. These radicals oxidatively modify solvent exposed side chains of 19 of the 20 amino acids. Recently, this method has been used in live cells (IC-FPOP) to study protein interactions in their native environment. The study of proteins in cells accounts for intermolecular crowding and various protein interactions that are disrupted for in vitro studies. A custom single cell flow system was designed to reduce cell aggregation and clogging during IC-FPOP. This flow system focuses the cells past the excimer laser individually, thus ensuring consistent irradiation. By comparing the extent of oxidation produced from FPOP to the protein&#39;s solvent accessibility calculated from a crystal structure, IC-FPOP can accurately probe the solvent accessible side chains of proteins.

Here, we characterize protein structure and interaction sites in living cells using a protein footprinting technique termed in-cell fast photochemical oxidation of proteins (IC-FPOP).

Fast photochemical oxidation of proteins (FPOP) is a hydroxyl radical protein footprinting method used to characterize protein structure and interactions. ...

A Hydrogen-Deuterium Exchange Mass Spectrometry (HDX-MS) Platform for Investigating Peptide Biosynthetic Enzymes

Hydrogen-deuterium exchange mass spectrometry (HDX-MS) is a powerful method for the biophysical characterization of enzyme conformational changes and enzyme-substrate interactions. Among its many benefits, HDX-MS consumes only small amounts of material, can be performed under near native conditions without the need for enzyme/substrate labeling, and can provide spatially resolved information on enzyme conformational dynamics&#8722;even for large enzymes and multiprotein complexes. The method is initiated by the dilution of the enzyme of interest into buffer prepared in D2O. This triggers the exchange of protium in peptide bond amides (N-H) with deuterium (N-D). At the desired exchange time points, reaction aliquots are quenched, the enzyme is proteolyzed into peptides, the peptides are separated by ultra-performance liquid chromatography (UPLC), and the change in mass of each peptide (due to the exchange of hydrogen for deuterium) is recorded by MS. The amount of deuterium uptake by each peptide is strongly dependent on the local hydrogen bonding environment of that peptide. Peptides present in very dynamic regions of the enzyme exchange deuterium very rapidly, whereas peptides derived from well-ordered regions undergo exchange much more slowly. In this manner, the HDX rate reports on local enzyme conformational dynamics. Perturbations to deuterium uptake levels in the presence of different ligands can then be used to map ligand binding sites, identify allosteric networks, and to understand the role of conformational dynamics in enzyme function. Here, we illustrate how we have used HDX-MS to better understand the biosynthesis of a type of peptide natural products called lanthipeptides. Lanthipeptides are genetically encoded peptides that are post-translationally modified by large, multifunctional, conformationally dynamic enzymes that are difficult to study with traditional structural biology approaches. HDX-MS provides an ideal and adaptable platform for investigating the mechanistic properties of these types of enzymes.

A Hydrogen-Deuterium Exchange Mass Spectrometry HDX-MS Platform for Investigating Peptide Biosynthetic Enzymes

Lanthipeptide synthetases catalyze multistep reactions during the biosynthesis of peptide natural products. Here, we describe a continuous, bottom-up, hydrogen-deuterium exchange mass spectrometry (HDX-MS) workflow that can be employed to study the conformational dynamics of lanthipeptide synthetases, as well as other similar enzymes involved in peptide natural product biosynthesis.

Hydrogen-deuterium exchange mass spectrometry (HDX-MS) is a powerful method for the biophysical characterization of enzyme conformational changes and ...

Spectrophotometric Screening for Potential Inhibitors of Cytosolic Glutathione S-Transferases

Glutathione S-transferases (GSTs) are metabolic enzymes responsible for the elimination of endogenous or exogenous electrophilic compounds by glutathione (GSH) conjugation. In addition, GSTs are regulators of mitogen-activated protein kinases (MAPKs) involved in apoptotic pathways. Overexpression of GSTs is correlated with decreased therapeutic efficacy among patients undergoing chemotherapy with electrophilic alkylating agents. Using GST inhibitors may be a potential solution to reverse this tendency and augment treatment potency. Achieving this goal requires the discovery of such compounds, with an accurate, quick, and easy enzyme assay. A spectrophotometric protocol using 1-chloro-2,4-dinitrobenzene (CDNB) as the substrate is the most employed method in the literature. However, already described GST inhibition experiments do not provide a protocol detailing each stage of an optimal inhibition assay, such as the measurement of the Michaelis-Menten constant (Km) for CDNB or indication of the employed enzyme concentration, crucial parameters to assess the inhibition potency of a tested compound. Hence, with this protocol, we describe each step of an optimized spectrophotometric GST enzyme assay, to screen libraries of potential inhibitors. We explain the calculation of both the half-maximal inhibitory concentration (IC50) and the constant of inhibition (Ki)&#8212;two characteristics used to measure the potency of an enzyme inhibitor. The method described can be implemented using a pool of GSTs extracted from cells or pure recombinant human GSTs, namely GST alpha 1 (GSTA1), GST mu 1 (GSTM1) or GST pi 1 (GSTP1). However, this protocol cannot be applied to GST theta 1 (GSTT1), as CDNB is not a substrate for this isoform. This method was used to test the inhibition potency of curcumin using GSTs from equine liver. Curcumin is a molecule exhibiting anti-cancer properties and showed affinity towards GST isoforms after in silico docking predictions. We demonstrated that curcumin is a potent competitive GST inhibitor, with an IC50 of 31.6 &#177; 3.6 &#181;M and a Ki of 23.2 &#177; 3.2 &#181;M. Curcumin has potential to be combined with electrophilic chemotherapy medication to improve its efficacy.

Glutathione S-transferases (GSTs) are detoxification enzymes involved in the metabolism of numerous chemotherapeutic drugs. Overexpression of GSTs is correlated with cancer chemotherapy resistance. One way to counter this phenotype is to use inhibitors. This protocol describes a method using a spectrophotometric assay to screen for potential GST inhibitors.

Glutathione S-transferases (GSTs) are metabolic enzymes responsible for the elimination of endogenous or exogenous electrophilic compounds by glutathione ...

Transverse Sectioning of Mature Rice (Oryza sativa L.) Kernels for Scanning Electron Microscopy Imaging Using Pipette Tips as Immobilization Support

Starch granules (SGs) exhibit different morphologies depending on the plant species, especially in the endosperm of the Poaceae family. Endosperm phenotyping can be used to classify genotypes based on SG morphotype using scanning electron microscopic (SEM) analysis. SGs can be visualized using SEM by slicing through the kernel (pericarp, aleurone layers, and endosperm) and exposing the organellar contents. Current methods require the rice kernel to be embedded in plastic resin and sectioned using a microtome or embedded in a truncated pipette tip and sectioned by hand using a razor blade. The former method requires specialized equipment and is time-consuming, while the latter introduces a new host of problems depending on rice genotype. Chalky rice varieties, particularly, pose a problem for this type of sectioning due to the friable nature of their endosperm tissue. Presented here is a technique for preparing translucent and chalky rice kernel sections for microscopy, requiring only pipette tips and a scalpel blade. Preparing the sections within the confines of a pipette tip prevents rice kernel endosperm from shattering (for translucent or &#8216;vitreous&#8217; phenotypes) and crumbling (for chalky phenotypes). Using this technique, endosperm cell patterning and the structure of intact SGs can be observed.

Transverse Sectioning of Mature Rice Oryza sativa L. Kernels for Scanning Electron Microscopy Imaging Using Pipette Tips as Immobilization Support

This protocol allows for the preparation of transverse sections of cereal seeds (e.g., rice) for the analysis of endosperm and starch granule morphology using scanning electron microscopy.
