We thank Yuri Shinomoto for providing animal care, training, and awake recordings. The ECoG arrays were manufactured by Cir-Tech (www.cir-tech.co.jp). Furthermore, we would like to thank Editage (www.editage.jp) for English language editing. This work was supported by the Brain Mapping by Integrated Neurotechnologies for Disease Studies (Brain/MINDS), the Japan Agency for Medical Research and development (AMED) (JP18dm0207001), the Brain Science Project of the Center for Novel Science Initiatives (CNSI), the National Institutes of Natural Sciences (NINS) (BS291004, M.K.), and by the Japan Society for the Promotion of Science (JSPS) KAKENHI (JP17H06034, M.K.).

This protocol has been performed on 6 common marmosets (4 males, 2 females; body weight = 320-470 g; age = 14-53 months). All procedures were carried out in accordance with the recommendations of the National Institutes of Health Guidelines for the Care and Use of Laboratory Animals. The protocol was approved by the RIKEN Ethical Committee (No. H28-2-221(3)). All surgical procedures were performed under anesthesia, and all efforts were made to minimize the number of animals used as well as their discomfort.
1. Preparation
<ol>
	<li>Obtain a structural magnetic resonance image (MRI) of each individual brain. This will be used to identify electrode positions through registration with a marmoset brain atlas and computer tomography (CT).</li>
	<li>Preparation of the ECoG array: prepare a customized multichannel ECoG array (Figure 1A). A 96ch ECoG array consists of two sheets with 32 and 64 electrodes. To accommodate individual differences in brain size, the ECoG array has a flexible arm. The arm can cover the temporal pole, depending on individual brain shape. Place the reference electrodes facing opposite to the ECoG electrodes and the ground electrodes facing the same direction.
	<ol>
		<li>Assemble the ECoG array with a connector case (Figure 1B) and seal gaps of connector (Figure 1C) using acrylic glue to prevent the inflow of liquid during surgery. Sterilize the array with ethylene oxide gas.</li>
	</ol>
	</li>
	<li>Prepare and sterilize instruments.
	NOTE: All instruments used are listed in the Table of Materials.</li>
</ol>
2. Implantation of ECoG Array
NOTE: Withdraw ingestion of food and liquids greater than 4 h prior to surgery. Perform all surgical steps with aseptic technique using sterilized gloves and instruments.
<ol>
	<li>Pre-implant procedures
	<ol>
		<li>Induce anesthesia in the marmoset by intramuscular (i.m.) injection of ketamine (15 mg/kg) 5 min after i.m. atropine (0.08 mg/kg) injection.</li>
		<li>Anesthetize and maintain anesthesia using isoflurane (1-3% diluted with a mixture of oxygen/nitrous oxide)&#160;depending on the physiological state of the animal, which should be continuously monitored. Ensure that heart rate is 130-180 BPM and monitor body temperature and arterial blood oxygen saturation (SpO2) continuously to judge the animal&#8217;s condition.</li>
		<li>Shave the top of the animal&#8217;s head with clippers and a hair remover. Fully rinse hair-removal cream off the skin with wet gauze, or it will cause skin damage.</li>
		<li>Administer an antibiotic (cefovecin; 16 mg/kg s.c.), antihypertensive (furosemide; 2.0 mg/kg i.m.), and antihemorrhagic (carbazochrome sodium sulfonate hydrate; 0.2 mg/kg i.m.).</li>
		<li>Place the animal on a stereotaxic frame. At this time, apply 2% lidocaine jelly to the ear-bars and ophthalmic ointment to the eyes to prevent dryness and postoperative pain.</li>
		<li>Disinfect the surgical area with iodine solution and cover it with sterilized drapes.&#160;Apply 2% lidocaine jelly to the place of the skin incision.</li>
	</ol>
	</li>
	<li>Implantation procedures
	<ol>
		<li>Incise skin about 4 cm through the midline of the scalp with a scalpel. Detach the temporal muscle from the skull with a curette until all of the surgical area is exposed. Clean out tissues on the skull surface and stop the bleeding completely with pressure hemostasis, and with bone wax, if necessary. Wrap the edge of the skin and muscles with moistened gauze. Keep the gauze moistened during surgery.</li>
		<li>Place the frontal edge of the array onto the edge of the frontal pole. Mark a planned area for the craniotomy, slits, and holes on the skull with a sterile pencil. The craniotomy location will depend on the design of the array (Figure 2).</li>
		<li>Drill the craniotomy along mark 1, as shown in Figure 2. While drilling the bone, blow air at the cutting edge to maintain a clear view for the surgeon. Next, cut the bone all the way around mark 2, as the bone piece will still be attached to dura at the center. Lift the piece up gently from one edge and peel off the dura with a spatula. This process must be conducted slowly and carefully, or it will tear the dura easily.
		<ol>
			<li>Remove the bone tips from the bone piece and wrap the piece with moistened gauze, as this piece will be returned after implanting the array.</li>
		</ol>
		</li>
		<li>Perform craniotomy 3 and 4 as shown in Figure 2. These allow the insertion of electrodes into the orbitofrontal and occipital areas, respectively.</li>
		<li>Drill slits on mark 5 as shown in Figure 2. These slits allow examination of the array to ensure that it is properly inserted.</li>
		<li>The dura will now be exposed. Wash the area with saline and stop the bleeding with pressure hemostasis and a gelatin sponge, if necessary. The edge of the open craniotomy may need to be cleaned with a curette or bone rongeur.</li>
		<li>Make the slits (marked 6 in Figure 2) into which the reference electrodes are placed. Place the reference electrodes in the epidural space at the contra-lateral sensorimotor and occipital areas. The position should be determined according to specific experimental needs.</li>
		<li>Drill screw holes at four points around each stem of the connector with a 1.0 mm screw (crosses in Figure 2). To prevent damage to the dura matter, insert a spatula under the skull. These holes should be orthogonal against the skull. Then, install PEEK screws (1.4 x 2.5 mm) as anchors to fix the connector to the skull.</li>
		<li>Insert the ECoG array into the epidural space. Use flathead forceps to hold the array.
		NOTE: The array should be inserted without bending. If the array is bent, create an appropriate space by inserting a spatula between the skull and dura. If the bending was caused by the relatively small size of the brain, cut off some of the electrodes.</li>
		<li>Fix the reference and ground electrodes with a dental acrylic. Place the reference electrodes in the epidural space and ground electrodes on the cranial surface. Both contacts should face the skull.</li>
		<li>Put the bone piece back and fix the connector and head post to the skull with dental acrylic on the screws.</li>
		<li>Suture the skin with 6-0 nylon at the forehead and rear head, and fix the skin to the sides of the connector using skin closures.</li>
	</ol>
	</li>
	<li>Post-implantation procedures
	<ol>
		<li>Remove the animal from the stereotaxic frame. Ensure that the animal is kept warm and provided with oxygen during the following steps.</li>
		<li>Immediately after surgery, inject the animal with meloxicam (0.3 mg/kg i.m.) to decrease postoperative pain. Administer an anti-inflammatory corticosteroid (dexamethasone; 2.0 mg/kg i.m.) and subcutaneous infusion (lactated Ringer&#8217;s solution; 5.0 mL), including famotidine (0.5 mg/kg) as a gastroprotectant.
		NOTE: A concurrent use of NSAIDs with steroids has a potential for gastrointestinal side effects.</li>
		<li>After the animal has recovered (confirm by heart rate and SpO2), remove vital sign monitoring and transfer the animal into the ICU for 2-3 days.</li>
	</ol>
	</li>
</ol>
3. Postoperative Treatment
NOTE: It typically takes 5 days for animals to recover completely from the surgery.
<ol>
	<li>To prevent brain swelling, administer the anti-inflammatory corticosteroid dexamethasone (2.0 mg/kg) twice a day on the first day after surgery. Then, reduce the dose to 1.5 mg/kg twice a day on the second and third days, and 1 mg/kg twice a day on the fourth day.</li>
	<li>Administer pain relief (meloxicam; 0.1 mg/kg oral; once a day) and an antihemorrhagic (carbazochrome sodium sulfonate hydrate; 0.2 mg/kg i.m.; twice a day) for 5 days after surgery.
	NOTE: In our case, 1-2 days after the surgery, some marmosets (3 out of 6) became less active and vomited. This may have been caused by increased intracranial pressure due to a blood clot. When marmosets presented these symptoms, we reopened the head and removed the clot under general anesthesia (alfaxalone). If there was no bending of the ECoG array during the implantation, the blood clot was likely in the space between the array and where the bone piece was returned. In this case, the blood clot can be washed away by running saline into the space using a catheter. This procedure usually leads to recovery in the animal.</li>
	<li>Identification of electrode locations
	<ol>
		<li>Around 1 week after surgery, perform a computer tomography (CT) scan of the animal&#8217;s head.
		NOTE: This is a good opportunity to check if signals can be recorded properly. Open the connector case and remove any blood clots if they are present.</li>
		<li>Align T2-weighted MRI to stereotaxic coordinates using AFNI software18 (https://afni.nimh.nih.gov) (Figure 3A). Align the CT image to T2-weighted anatomical magnetic resonance images with AFNI (Figure 3B). Register a marmoset brain atlas to MRI (Figure 3C) with AFNI and ANTS19.</li>
	</ol>
	</li>
</ol>

<ol>
	<li>Fukushima, M., Chao, Z. C., Fujii, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Studying+brain+functions+with+mesoscopic+measurements:+Advances+in+electrocorticography+for+non-human+primates.">Studying brain functions with mesoscopic measurements: Advances in electrocorticography for non-human primates.</a> Current Opinion in Neurobiology. 32, 124-131 (2015).</li><li>Nagasaka, Y., Shimoda, K., Fujii, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multidimensional+recording+(MDR)+and+data+sharing:+an+ecological+open+research+and+educational+platform+for+neuroscience.">Multidimensional recording (MDR) and data sharing: an ecological open research and educational platform for neuroscience.</a> PLoS One. 6 (7), e22561 (2011).</li><li>Fukushima, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+electrocorticographic+electrode+array+for+simultaneous+recording+from+medial,+lateral,+and+intrasulcal+surface+of+the+cortex+in+macaque+monkeys.">An electrocorticographic electrode array for simultaneous recording from medial, lateral, and intrasulcal surface of the cortex in macaque monkeys.</a> Journal of Neuroscience Methods. 233, 155-165 (2014).</li><li>Komatsu, M., Sugano, E., Tomita, H., Fujii, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+Chronically+Implantable+Bidirectional+Neural+Interface+for+Non-human+Primates.">A Chronically Implantable Bidirectional Neural Interface for Non-human Primates.</a> Frontiers in Neuroscience. 11, 514 (2017).</li><li>Komatsu, M., Takaura, K., Fujii, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mismatch+negativity+in+common+marmosets:+Whole-cortical+recordings+with+multi-channel+electrocorticograms.">Mismatch negativity in common marmosets: Whole-cortical recordings with multi-channel electrocorticograms.</a> Scientific Reports. 5, 15006 (2015).</li><li>Sasaki, E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Generation+of+transgenic+non-human+primates+with+germline+transmission.">Generation of transgenic non-human primates with germline transmission.</a> Nature. 459 (7246), 523-527 (2009).</li><li>Okano, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Brain/MINDS:+A+Japanese+National+Brain+Project+for+Marmoset+Neuroscience.">Brain/MINDS: A Japanese National Brain Project for Marmoset Neuroscience.</a> Neuron. 92 (3), 582-590 (2016).</li><li>de la Mothe, L. A., Blumell, S., Kajikawa, Y., Hackett, T. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cortical+connections+of+auditory+cortex+in+marmoset+monkeys:+lateral+belt+and+parabelt+regions.">Cortical connections of auditory cortex in marmoset monkeys: lateral belt and parabelt regions.</a> Anatomical Record. 295 (5), 800-821 (2012).</li><li>Kaas, J. H., Hackett, T. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Subdivisions+of+auditory+cortex+and+processing+streams+in+primates.">Subdivisions of auditory cortex and processing streams in primates.</a> Proceedings of National Academy of Sciences of the United States of America. 97 (22), 11793-11799 (2000).</li><li>Ghahremani, M., Hutchison, R. M., Menon, R. S., Everling, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Frontoparietal+Functional+Connectivity+in+the+Common+Marmoset.">Frontoparietal Functional Connectivity in the Common Marmoset.</a> Cerebral Cortex. , (2016).</li><li>Belcher, A. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Functional+Connectivity+Hubs+and+Networks+in+the+Awake+Marmoset+Brain.">Functional Connectivity Hubs and Networks in the Awake Marmoset Brain.</a> Frontiers in Integrative Neuroscience. 10, 9 (2016).</li><li>Mitchell, J. F., Leopold, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+marmoset+monkey+as+a+model+for+visual+neuroscience.">The marmoset monkey as a model for visual neuroscience.</a> Neuroscience Research. 93, 20-46 (2015).</li><li>Solomon, S. G., Rosa, M. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+simpler+primate+brain:+the+visual+system+of+the+marmoset+monkey.">A simpler primate brain: the visual system of the marmoset monkey.</a> Frontiers in Neural Circuits. 8, 96 (2014).</li><li>Burman, K. J., Palmer, S. M., Gamberini, M., Rosa, M. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cytoarchitectonic+subdivisions+of+the+dorsolateral+frontal+cortex+of+the+marmoset+monkey+(Callithrix+jacchus),+and+their+projections+to+dorsal+visual+areas.">Cytoarchitectonic subdivisions of the dorsolateral frontal cortex of the marmoset monkey (Callithrix jacchus), and their projections to dorsal visual areas.</a> Journals of Comparative Neurology. 495 (2), 149-172 (2006).</li><li>Bakola, S., Burman, K. J., Rosa, M. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+cortical+motor+system+of+the+marmoset+monkey+(Callithrix+jacchus).">The cortical motor system of the marmoset monkey (Callithrix jacchus).</a> Neuroscience Research. 93, 72-81 (2015).</li><li>Krubitzer, L. A., Kaas, J. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+organization+and+connections+of+somatosensory+cortex+in+marmosets.">The organization and connections of somatosensory cortex in marmosets.</a> Journal of Neuroscience. 10 (3), 952-974 (1990).</li><li>Miller, C. T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Marmosets:+A+Neuroscientific+Model+of+Human+Social+Behavior.">Marmosets: A Neuroscientific Model of Human Social Behavior.</a> Neuron. 90 (2), 219-233 (2016).</li><li>Cox, R. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=AFNI:+software+for+analysis+and+visualization+of+functional+magnetic+resonance+neuroimages.">AFNI: software for analysis and visualization of functional magnetic resonance neuroimages.</a> Computers and Biomedical Research. 29 (3), 162-173 (1996).</li><li>Avants, B. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+reproducible+evaluation+of+ANTs+similarity+metric+performance+in+brain+image+registration.">A reproducible evaluation of ANTs similarity metric performance in brain image registration.</a> Neuroimage. 54 (3), 2033-2044 (2011).</li><li>Hashikawa, T., Nakatomi, R., Iriki, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Current+models+of+the+marmoset+brain.">Current models of the marmoset brain.</a> Neuroscience Research. 93, 116-127 (2015).</li></ol>

MK is applying for a patent on whole-cortical ECoG array she have used in this protocol (No. 2018-210975).

For successful implantation, animals should be provided with adequate nutrition before and after surgery. Short operating time is also important to optimize the animal&#39;s recovery. Preparations should be finished at least one day before surgery. To reduce operating time, previous craniotomy training with electrode array insertion in terminated animals for other experimental purposes is recommended.&#160;Table 1 shows an example of the time course for this protocol.
We modif...

Cognition requires the coordination of neural ensembles across widespread brain networks, particularly the neocortex that is well-developed in humans and believed to be involved in higher cognitive behaviors. However, how the neocortex achieves this cognitive behavior is an unsolved issue in the neuroscience field. Recent development of thin, flexible electrocorticographic (ECoG) electrodes enables conduction of stable recordings from large-scale cortical activity1. Fujii and colleagues have developed a whole-cortical ECoG array for macaque monkeys2,3. The array continuously covers almost the entire lateral cortex, from the occipital pole to the temporal and frontal poles, and captures whole-cortical neural activity in one shot. We have further developed this system for application in the common marmoset4,5, a small, new-world monkey with genetic manipulability6,7. This animal has several advantages compared to other species. The visual, auditory, somatosensory, motor, and frontal cortical areas of this species have been previously mapped and reported to have basic homologous organization to the same areas in humans and macaques8,9,10,11,12,13,14,15,16. Their brains are smooth, and most lateral cortical areas are exposed to the surface of the cortex, which is harder to access with ECoG in macaques. Based on these features, the marmoset is suitable for electrocorticographic studies. Furthermore, marmosets exhibit social behaviors and have been proposed to serve as a candidate model of human social behaviors17.
This protocol describes an epidural implantation procedure of the ECoG array on the whole lateral surface of the cortex in a common marmoset. It provides an opportunity to monitor large-scale cortical activity for primate cortical neuroscience, including sensory, motor, higher cognitive, and social domains.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Beaker (100 cc)</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Cotton ball</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Absorption triangles</td>
			<td>Fine Science Tools Inc.</td>
			<td>18105-03</td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Cotton swab with fine tip</td>
			<td>Clean Cross Co., Ltd.</td>
			<td>HUBY340 BB-013</td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Gauze</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Towel forceps</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Scalpel handle</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Needle Holder</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Iris Scissor</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Micro-Mosquito Forceps</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Adson, 1x2 teeth</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Bone Curette</td>
			<td></td>
			<td></td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Micro spatura</td>
			<td>Fine Science Tools Inc.</td>
			<td>10091-12</td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Needle Holders, 12.5cm, Curved, Smooth Jaws</td>
			<td>World Precision Instruments</td>
			<td>14132</td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Vessel Dilator, 12cm, 0.1mm tip</td>
			<td>Fine Science Tools Inc.</td>
			<td>18131-12</td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Vessel Dilator, 12cm, 0.2 mm tip</td>
			<td>Fine Science Tools Inc.</td>
			<td>18132-12</td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Fine-tipped rongeur</td>
			<td>Fine Science Tools Inc.</td>
			<td>16221-14</td>
			<td>Outocrave</td>
		</tr>
		<tr>
			<td>Manipurator of a stereotaxic frame</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Wrench for the manipurator</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Hand-made fixture for the connector</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Silicon cup for dental acril</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Silicon cup hlder</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Paintbrush</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Pencil</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Micro screw, 1.4 mm x 2.0 mm</td>
			<td>Nippon Chemical Screw Co., Ltd.</td>
			<td>PEEK/MPH-M1.4-L2</td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Screw driver for the micro screw</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Micromotor handpiece of a drill</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Stainless steel burr, 1.4 mm</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Stainless steel burr, 1.0 mm</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Drill bit, 1.2 mm</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
		<tr>
			<td>Rubber air blower</td>
			<td></td>
			<td></td>
			<td>Gas sterilization</td>
		</tr>
	</tbody>
</table>

chronic implantation of whole-cortical electrocorticographic array in the common marmoset

Electrocorticography (ECoG) allows the monitoring of electrical field potentials from the cerebral cortex with high spatiotemporal resolution. Recent development of thin, flexible ECoG electrodes has enabled conduction of stable recordings of large-scale cortical activity. We have developed a whole-cortical ECoG array for the common marmoset. The array continuously covers almost the entire lateral surface of cortical hemisphere, from the occipital pole to the temporal and frontal poles, and it captures whole-cortical neural activity in one shot. This protocol describes a chronic implantation procedure of the array in the epidural space of the marmoset brain. Marmosets have two advantages regarding ECoG recordings, one being the homologous organization of anatomical structures in humans and macaques, including frontal, parietal, and temporal complexes. The other advantage is that the marmoset brain is lissencephalic and contains a large number of complexes, which are more difficult to access in macaques with ECoG, that are exposed to the brain surface.These features allow direct access to most cortical areas beneath the surface of the brain. This system provides an opportunity to investigate global cortical information processing with high resolutions at a sub-millisecond order in time and millimeter order in space.

The whole-cortical ECoG array can simultaneously capture neuronal activity from the entirety of a hemisphere. Figure 4 shows examples of auditory evoked potentials (AEPs) from multiple auditory areas in an awake marmoset. ECoG recordings were conducted in passive listening conditions. Each marmoset was exposed to auditory stimuli, which consisted of randomized pure tones with 20 types of frequency. Then, we calculated AEPs by averaging ECoGs aligned with onse...

Watch this Scientific Journal Video about Chronic Implantation of Whole-cortical Electrocorticographic Array in the Common Marmoset at JoVE.com

Chronic Implantation of Whole-cortical Electrocorticographic Array in the Common Marmoset

We have developed a whole-cortical electrocorticographic array for the common marmoset that continuously covers almost the entire lateral surface of cortex, from the occipital pole to the temporal and frontal poles. This protocol describes a chronic implantation procedure of the array in the epidural space of the marmoset brain.

Electrocorticography (ECoG) allows the monitoring of electrical field potentials from the cerebral cortex with high spatiotemporal resolution. Recent ...
