This work was supported by the FY 2013 Research Exchange Program between JSPS and CNRS, JSPS KAKENHI Grant Number 26860858, and the Narishige Neuroscience Research Foundation. We thank Drs. Mariko Harada-Shiba and Kyoko Shioya for helpful discussions. We thank Mari Furuta, Mutsumi Sakamoto, Ritsuko Maki, and Dr. Emi Tanaka for excellent technical assistance.

All experiments were performed in accordance with protocols approved by the Experimental Animal Care and Use Committee of the National Cerebral and Cardiovascular Center, Suita, Japan.
1. Prepare the following animals and materials for MIUH surgery
<ol>
	<li>Prepare timed pregnant Sprague-Dawley rats at gestational day 17, i.e., embryonic day 17 (E17). The dams&#39; average body weights are 307.0 &#177; 40.7 g (mean &#177; SD, n = 9).</li>
	<li>Prepare metal microcoils; inner diameter 0.24 mm, made from gold-coated steel.</li>
	<li>Prepare all the materials as per the Table of Materials.</li>
</ol>
2. Prepare for MIUH surgery
<ol>
	<li>Warm a heating pad at 37 &#176;C for rat placement</li>
	<li>Place a sterile diaper on the heating pad</li>
	<li>Warm sterile saline at 37 &#176;C in a water bath</li>
</ol>
3. Perform MIUH surgery
<ol>
	<li>Perform surgical procedures under sterile condition. Sterilize coils, forceps, needle with 70% ethanol before use. Use sterile gloves, and occasionally disinfect by applying ethanol spray.</li>
	<li>Place the rat in the anesthesia induction box. Introduce 4% isoflurane into the box (approximately 5 min).</li>
	<li>Place the rat onto a sterile diaper on the heating pad in a supine position after the animal is thoroughly anesthetized in the induction box. Check for depth of anesthesia by the lack of a response to a toe pinch. Maintain 1.5-2.0% isoflurane with a nose cone.</li>
	<li>Apply depilatory foam onto the abdomen from the navel down to the region of the pelvic arch. After several minutes, wipe off the depilatory foam with a paper towel. A shaver may be used as a substitute for the depilatory foam.</li>
	<li>Apply gauze soaked in iodine disinfectant solution to the depilated region of the skin.</li>
	<li>Place a surgical drape with a round opening to cover the abdomen other than the area of the surgical incision. Several pieces of gauze may be used as a substitute for the drape.</li>
	<li>Using a surgical scalpel, make an incision approximately 2.5 cm long on the lower abdomen from the upper edge of the pubic bone straight up toward the navel. Then, make an incision through the muscle layer underneath.</li>
	<li>Place several pieces of sterile gauze around the opening of the drape, and wet the gauze with warmed saline.</li>
	<li>Push both lateral sides of the abdomen gently, so that a portion of uterine horn emerges from the incision.</li>
	<li>Disinfect the surgeon&#39;s hands with 70% ethanol.</li>
	<li>Gently pull the entire uterine horn from the abdominal cavity manually without using forceps. Using surgical forceps is not advisable, as they may easily damage the fragile uterus, fetuses, and blood vessels by compressing them strongly and unevenly.</li>
	<li>Place the uterine horn on the wet gauze.</li>
	<li>Perform the same procedure for the other uterine horn.</li>
	<li>Count the number of fetuses.</li>
	<li>Apply warmed saline frequently to keep the uterus warm and wet throughout the surgery.
	<ol>
		<li>Change the diaper when it has absorbed too much saline. To maintain stability, repeat disinfection gloves with 70% ethanol and tips of the instrument with iodine. Keeping the non-sterile fingers away from the sterile tips of the instrument is crucial.</li>
	</ol>
	</li>
	<li>Identify the proximal part of the main arcade of the ovarian and uterine arteries under a stereomicroscope.
	NOTE: It is crucial to distinguish the main arcade from the branches to the placentas. Note that the surgical operation may be easier when the uterine horn is flipped. Occasionally, applying a coil at the very proximal part of the arcade is difficult, because it is located deep within the abdominal cavity and arteries to the placenta are very close to the proximal part of the arcade. In this case, a coil can be applied to a part of the arcade after the first branch forks off.</li>
	<li>Separate the artery from the vein running parallel to it with forceps and make space between them.</li>
	<li>Place a piece of string (silk suture 4.0, 5 cm long) underneath the artery.</li>
	<li>Lift up both ends of the string with forceps so that the artery is lifted and separated from the fragile vein.</li>
	<li>Holding the edge of the microcoil with fine forceps in the other hand, place a microcoil beside the lifted artery (Figure 2.1).</li>
	<li>Rotate the lifted artery by using the string around the microcoil to wrap the microcoil around the artery. It is easier to rotate the artery around the coil than to rotate the coil around the artery (Figure 2.2).</li>
	<li>After rotating the artery 3 or 4 turns (coils have 5 turns), change the site at which the coil is held to the other edge. Hold the edge of the coil that has been wrapped around the artery with forceps. Change the site at which the string lifts the artery to the other side of coil. Rotate the artery around the coil so that the coil completely (5 turns) wraps the artery (Figure 2.3, 2.4).</li>
	<li>Remove the string.</li>
	<li>Perform the same procedure for the other three arteries.</li>
	<li>Note that frequently applying warmed saline to the uterus is crucial; otherwise, the mortality rate of the fetuses increases, and hypothermia might be neuroprotective.</li>
	<li>Gently return the uterine horn into the abdominal cavity. Lifting an edge of the abdominal wall incision with forceps can make this procedure easier.</li>
	<li>Stich the abdominal muscle, and then stich the abdominal skin with suture (silk suture 4.0). Tie the suture after each stich, i.e. interrupted single sutures.</li>
	<li>Apply gauze soaked in iodine disinfectant solution on and around the surgical incision.</li>
	<li>Administer the analgesic meloxicam at 0.5 mg/kg body weight subcutaneously.</li>
	<li>Allow for 30 min of recovery in a warmed cage. Check animals if fully awake and moving around the cage, return to home cage.</li>
</ol>

<ol>
	<li>Ohshima, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mild+intrauterine+hypoperfusion+reproduces+neurodevelopmental+disorders+observed+in+prematurity.">Mild intrauterine hypoperfusion reproduces neurodevelopmental disorders observed in prematurity.</a> Sci Rep. 6, 39377 (2016).</li><li>Anderson, P., Doyle, L. W., Victorian Infant Collaborative Study, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neurobehavioral+outcomes+of+school-age+children+born+extremely+low+birth+weight+or+very+preterm+in+the+1990s.">Neurobehavioral outcomes of school-age children born extremely low birth weight or very preterm in the 1990s.</a> JAMA. 289 (24), 3264-3272 (2003).</li><li>Levine, T. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Early+childhood+neurodevelopment+after+intrauterine+growth+restriction:+a+systematic+review.">Early childhood neurodevelopment after intrauterine growth restriction: a systematic review.</a> Pediatrics. 135 (1), 126-141 (2015).</li><li>Sucksdorff, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preterm+Birth+and+Poor+Fetal+Growth+as+Risk+Factors+of+Attention-Deficit/+Hyperactivity+Disorder.">Preterm Birth and Poor Fetal Growth as Risk Factors of Attention-Deficit/ Hyperactivity Disorder.</a> Pediatrics. 136 (3), e599-e608 (2015).</li><li>Volpe, J. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Brain+injury+in+premature+infants:+a+complex+amalgam+of+destructive+and+developmental+disturbances.">Brain injury in premature infants: a complex amalgam of destructive and developmental disturbances.</a> Lancet Neurol. 8 (1), 110-124 (2009).</li><li>Nardozza, L. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fetal+growth+restriction:+current+knowledge.">Fetal growth restriction: current knowledge.</a> Arch Gynecol Obstet. 295 (5), 1061-1077 (2017).</li><li>Chang, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preterm+birth+and+the+role+of+neuroprotection.">Preterm birth and the role of neuroprotection.</a> Bmj. 350, g6661 (2015).</li><li>Coq, J. O., Delcour, M., Massicotte, V. S., Baud, O., Barbe, M. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Prenatal+ischemia+deteriorates+white+matter,+brain+organization,+and+function:+implications+for+prematurity+and+cerebral+palsy.">Prenatal ischemia deteriorates white matter, brain organization, and function: implications for prematurity and cerebral palsy.</a> Dev Med Child Neurol. 58, 7-11 (2016).</li><li>Jantzie, L. L., Corbett, C. J., Firl, D. J., Robinson, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Postnatal+Erythropoietin+Mitigates+Impaired+Cerebral+Cortical+Development+Following+Subplate+Loss+from+Prenatal+Hypoxia-Ischemia.">Postnatal Erythropoietin Mitigates Impaired Cerebral Cortical Development Following Subplate Loss from Prenatal Hypoxia-Ischemia.</a> Cereb Cortex. 25 (9), 2683-2695 (2015).</li><li>Kubo, K. I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Association+of+impaired+neuronal+migration+with+cognitive+deficits+in+extremely+preterm+infants.">Association of impaired neuronal migration with cognitive deficits in extremely preterm infants.</a> JCI Insight. 2 (10), (2017).</li><li>Delcour, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mild+musculoskeletal+and+locomotor+alterations+in+adult+rats+with+white+matter+injury+following+prenatal+ischemia.">Mild musculoskeletal and locomotor alterations in adult rats with white matter injury following prenatal ischemia.</a> Int J Dev Neurosci. 29 (6), 593-607 (2011).</li><li>Gilbert, J. S., Babcock, S. A., Granger, J. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hypertension+produced+by+reduced+uterine+perfusion+in+pregnant+rats+is+associated+with+increased+soluble+fms-like+tyrosine+kinase-1+expression.">Hypertension produced by reduced uterine perfusion in pregnant rats is associated with increased soluble fms-like tyrosine kinase-1 expression.</a> Hypertension. 50 (6), 1142-1147 (2007).</li><li>Granger, J. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reduced+uterine+perfusion+pressure+(RUPP)+model+for+studying+cardiovascular-renal+dysfunction+in+response+to+placental+ischemia.">Reduced uterine perfusion pressure (RUPP) model for studying cardiovascular-renal dysfunction in response to placental ischemia.</a> Methods Mol Med. 122, 383-392 (2006).</li><li>Mazur, M., Miller, R. H., Robinson, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Postnatal+erythropoietin+treatment+mitigates+neural+cell+loss+after+systemic+prenatal+hypoxic-ischemic+injury.">Postnatal erythropoietin treatment mitigates neural cell loss after systemic prenatal hypoxic-ischemic injury.</a> J Neurosurg Pediatr. 6 (3), 206-221 (2010).</li><li>Olivier, P., Baud, O., Evrard, P., Gressens, P., Verney, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Prenatal+ischemia+and+white+matter+damage+in+rats.">Prenatal ischemia and white matter damage in rats.</a> J Neuropathol Exp Neurol. 64 (11), 998-1006 (2005).</li><li>Robinson, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Developmental+changes+induced+by+graded+prenatal+systemic+hypoxic-ischemic+insults+in+rats.">Developmental changes induced by graded prenatal systemic hypoxic-ischemic insults in rats.</a> Neurobiol Dis. 18 (3), 568-581 (2005).</li><li>Rice, D., Barone, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Critical+periods+of+vulnerability+for+the+developing+nervous+system:+evidence+from+humans+and+animal+models.">Critical periods of vulnerability for the developing nervous system: evidence from humans and animal models.</a> Environ Health Perspect. 108, 511-533 (2000).</li><li>Basilious, A., Yager, J., Fehlings, M. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neurological+outcomes+of+animal+models+of+uterine+artery+ligation+and+relevance+to+human+intrauterine+growth+restriction:+a+systematic+review.">Neurological outcomes of animal models of uterine artery ligation and relevance to human intrauterine growth restriction: a systematic review.</a> Dev Med Child Neurol. 57 (5), 420-430 (2015).</li><li>Delcour, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neuroanatomical,+sensorimotor+and+cognitive+deficits+in+adult+rats+with+white+matter+injury+following+prenatal+ischemia.">Neuroanatomical, sensorimotor and cognitive deficits in adult rats with white matter injury following prenatal ischemia.</a> Brain Pathol. 22 (1), 1-16 (2012).</li></ol>

The authors have nothing to disclose.

The microcoil stenosis of both ovarian and uterine arteries in both uterine horns produces consistent and reproducible intrauterine hypoperfusion in all placentas and fetuses. The level of hypoperfusion can be modified by using microcoils with different inner diameters. Rat pups born from a dam on which artery stenosis has been performed with microcoils 0.24 mm in inner diameter demonstrate IUGR and premature birth (see reference 1 for details). The pups exhibit neuroanatomical and behavioral alterations that resemble th...

Infants with intrauterine growth restriction (IUGR) (also known as fetal growth restriction) (birth weight &#60;10th percentile for gestational age), preterm birth (born at &#60; 37 weeks of gestation), and/or low birth weight (&#60; 2500 g) account for nearly 10% of all newborns 2,3. Many of these infants present with neurological problems such as cerebral palsy and developmental disorders (e.g., attention-deficit/hyperactivity disorder (ADHD) and learning disorders) 3,4,5. Those conditions have similarities and differences in their etiology and outcomes. The etiology of IUGR is multifactorial, and placental insufficiency associated with intrauterine hypoperfusion is considered to be the most common cause in non-anomalous fetuses 7. The etiology of preterm is multifactorial as well, and chorioamnionitis is the most frequent cause 8.
The influence of mild intrauterine hypoperfusion (MIUH) on the developing brain is unclear. Currently available animal models of intrauterine hypoperfusion/ischemia primarily involve either severe hypoperfusion or gradient degree of hypoperfusion with or without reperfusion 9,10,11. In clinical settings, however, cases of MIUH are considered to be far more frequent than those involving such severe conditions. The currently available models of MIUH are a rodent model involving suture ligation of either the uterine or the ovarian artery and a rodent model involving clipping the bilateral ovarian arteries and aorta having patency 12,13,14,15,16,17. One of the disadvantages of these models is the extensive inter-fetus variability, ranging from fetuses with profound hypoperfusion to fetuses with nearly intact perfusion, depending on the position of the fetus within the arterial arcade of the uterine and ovarian arteries. Another disadvantage of these models is their inability to distinguish the position of each fetus after birth; hence, researchers cannot distinguish the severity of intrauterine hypoperfusion experienced by an individual pup after its birth.
We have developed a rat model of MIUH involving multiple artery stenosis 1. Wrapping metal micro-coils with an inner diameter of 0.24 mm around the ovarian and uterine arteries causes stenosis, but not obstruction, of the blood vessels (Figure 1). Applying these microcoils at the proximal parts of all of the arteries supplying the uterus, i.e., the bilateral uterine and ovarian arteries, on embryonic day 17 (equivalent to embryonic weeks 20-25 in humans 18) induces a significant but mild decrease in blood flow to the placentas and fetuses. The decreases in blood flow after coils are applied to all four arteries feeding the uterus are largely the same across each placenta and fetus. The fetus mortality rate is less than 20%. The pups are born via spontaneous labor 1-2 days earlier (embryonic day 21-22) than normal. Almost all pups are born exhibiting significantly low birth weights 1. Gray and white matter volumes are decreased without obvious tissue damage 1. Pups present with delayed acquisition of newborn reflexes, muscle weakness, and altered spontaneous activity 1. This model mimics the clinical signs and symptoms of children born prematurely or with IUGR; children born preterm exhibit reduced gray and white matter volume with or without white matter injury 6, present delayed milestones of neurological development, and may present behavioral problems such as ADHD 3,5; children with IUGR exhibit minimal neuroanatomical alterations, and have an increased risk of impaired neurological development such as motor and cognitive delay 4,7. Preterm birth and IUGR are different conditions, but the two conditions share the basic mechanism, i.e. insults to immature brains before full-term gestational age.

<table>
	<tbody>
		<tr>
			<td>Stereomicroscope</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Isoflurane anesthesia machine</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Anesthesia induction box</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Heating pad</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Diaper 30x40 cm</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Depilatory foam or shaver</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Iodine disinfectant solution</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Gauze 10x20 cm&#160;</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Surgical drape 45x45 cm with a round opening 5 cm in diameter</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Spray bottle with ethanol for disinfection</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Cotton swab</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Forceps with large blunt tips</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Forceps with angled fine tips</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Scissors</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Surgical scalpel, blade size is 27mm long (no.10, Axel, AS ONE Corporation, Osaka, Japan)</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Surgical suture needle</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Metal microcoils; inner diameter 0.24 mm, made from gold-coated steel (SAMINI Co. Ltd., Shizuoka, Japan)</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Silk suture 4-0</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Sterile saline (0.9% sodium chloride)</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Heating water bath</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Plastic syringes (50ml) and needles (18G)</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
	</tbody>
</table>

a rat model of mild intrauterine hypoperfusion with microcoil stenosis

Intrauterine hypoperfusion/ischemia is one of the major causes of intrauterine/fetal growth restriction, preterm birth, and low birth weight. Most studies of this phenomenon have been performed in either models with severe intrauterine ischemia or models with gradient degree of intrauterine hypoperfusion. No study has been performed in a model on uniform mild intrauterine hypoperfusion (MIUH). Two models have been used for studies of MIUH: a model based on suture ligation of either side of the arterial arcade formed with the uterine and ovarian arteries, and a transient model based on clipping the bilateral ovarian arteries and aorta having patency. Those two rodent models of MIUH have some limitations, e.g., not all fetuses are subjected to MIUH, depending on their position in the uterine horn. In our MIUH model, all fetuses are subjected to a comparable level of intrauterine hypoperfusion. MIUH was achieved by mild stenosis of all four arteries feeding the uterus, i.e., the bilateral uterine and ovarian arteries.
Arterial stenosis was induced by metal microcoils wrapped around the feeding arteries. Producing arterial stenosis with microcoils allowed us to control, optimize, and reproduce decreased blood flow with very little inter-animal variability and a low mortality rate, thus enabling accurate evaluation. When microcoils with an inner diameter of 0.24 mm were used, the blood flow in both the placenta and fetus was mildly decreased (approximately 30% from the pre-stenosis level in the placenta). The offspring of our MIUH model clearly demonstrates long-lasting alterations in neurological, neuroanatomical and behavioral test results.

After applying microcoils to all of the arteries feeding the uterus, i.e., the bilateral uterine and ovarian arteries, all fetuses are subjected to comparable levels of hypoperfusion. The application of microcoils with an inner diameter of 0.24 mm causes mild stenosis of those arteries, thereby causing a mild decrease in blood flow to the placentas and fetuses (Figure 3; approximately 30% from the pre-stenosis level in the placenta, see reference 1 for detail...

Watch this Scientific Journal Video about A Rat Model of Mild Intrauterine Hypoperfusion with Microcoil Stenosis at JoVE.com

A Rat Model of Mild Intrauterine Hypoperfusion with Microcoil Stenosis

Mild intrauterine hypoperfusion was produced by artery stenosis with metal microcoils wrapped around the uterine and ovarian arteries in rats at embryonic day 17. This procedure produced prenatal hypoperfusion and intrauterine growth restriction.

Intrauterine hypoperfusion/ischemia is one of the major causes of intrauterine/fetal growth restriction, preterm birth, and low birth weight. Most studies ...

a-rat-model-of-mild-intrauterine-hypoperfusion-with-microcoil-stenosis
