We would like to thank members of the Pelegri lab and fish facility managerial staff, who were instrumental in facilitating this project. Support for this project was provided by NIH R56 GM065303 and NIH 2 T32 GM007133 to E.L.W., NIH 5 F31 GM108449-02 and NIH 2 T32 GM007133 to C.C.E., and NIH RO1 GM065303 to F.P.

All zebrafish were handled in strict accordance with good animal practice, as defined by the relevant national and/or local animal welfare bodies, and all animal work was approved by the appropriate committee (University of Wisconsin-Madison assurance number A3368-01). Animals were maintained under standard conditions at 26.5 &#176;C.
1. Pre-selection of Females
NOTE: Oocytes in adult females typically span a range of developmental stages, from stage I to V (Figure 2). Purging the females of preexisting oocytes through a successful natural mating increases the synchronization of oocyte staging, as newly developing oocytes appear as a cohort3,14. Within about 8 days post-purge, most oocytes are in early stage IV, which is optimal for the initiation of in vitro maturation. Such synchronization increases the yield of oocytes that can go through the full process of in vitro maturation, facilitating experimental manipulation. See previous descriptions13 for details on setting up fish in paired matings and on fish water composition (here, 14 g of ocean salt and 150 g of NaHCO3 per 1,000 L of reverse-osmosis water, pH 6.5-8.5 (preferred range: 6.8-7.5) and a conductivity of 180-360 &#956;S). See Brand et al.13 for additional recipes.
<ol>
	<li>Eight to ten days prior to the in vitro culture manipulation, use a fish net to transfer a single male and a single female fish of the desired strain to a mating tank. Pair multiple sets. Leave them in the mating tank overnight. Allow them to mate during the evening and through the afternoon of the following day.</li>
	<li>Use a fish net to separate the females that yield eggs during mating and place them into a separate tank. Feed these females twice daily with a food mixture containing approximately an equal amount of brine shrimp and fish food flakes. The amount of food should be enough to provide approximately 20 min, but not more, of feeding time.</li>
</ol>
2. Preparation of Maturation Medium
NOTE: Prepare maturation medium on the day of the in vitro maturation experiment, within 1 h of removing the oocytes from the female (see section 3).
<ol>
	<li>Add 20 mL of Leibovitz&#39;s L-15 medium with L-glutamine, pH 7.0, to a 50 mL conical tube under sterile conditions. Bring it to pH 9.0 with 10 N NaOH.</li>
	<li>Add 9 mL of Leibovitz&#39;s L-15 medium, pH 9.0, to 2 separate 50 mL conical tubes. Label 1 tube &#34;+DHP&#34; and the other &#34;-DHP.&#34;</li>
	<li>In the +DHP tube, add 10 &#181;L of 17&#945;-20&#946;-dihydroxy-4 pregnen-3-one (DHP), 490 &#181;L of dH2O, and 500 &#181;L of 10% bovine serum albumin (BSA).</li>
	<li>In the -DHP tube, add 100 &#181;L of 10 mg/mL gentamycin, 400 &#181;L of dH2O, and 500 &#181;L of 10% BSA.</li>
</ol>
3. Dissection of the Oocytes and Initiation of the In Vitro Culture
NOTE: The in vitro culture experiment is carried out with pre-selected females 8-10 days after they release eggs through natural mating. Use maturation medium made the same day (see section 2). Oocytes mature appropriately if the dissection is begun near the end of the fish diurnal cycle (determined in the laboratory by pre-set artificial lighting in the fish facility)13, possibly mimicking processes occurring through natural mating. This implies that most steps in the protocol must be carried out in the evening if fish are housed in a facility with a standard light cycle (e.g., beginning step 3.2 at 6 pm in a facility with an 8 am to 10 pm light period), although other work time-periods are possible with an appropriately time-shifted light cycle.
<ol>
	<li>Prepare a 0.2% tricaine stock solution in dH2O, buffered to pH 7.0 with 1 M Tris, pH 9.0, and keep this solution at 4 &#176;C. This can be prepared ahead of time.</li>
	<li>Initiate the experiment 0-4 h prior to the end of the daily light cycle in the facility. In a 250-mL beaker, add 20 mL of 0.2% tricaine stock solution, pH 7.0, to 80 mL of fish water and mix.</li>
	<li>Transfer the pre-selected females to tricaine solution and euthanize them by overexposure. Leave the females in the tricaine solution for 15 min after the cessation of gill movement.</li>
	<li>Using a spoon, collect the euthanized fish from the tricaine solution and rinse them briefly in fish water. Place the fish onto a paper towel to absorb excess water.</li>
	<li>Use a clean razor blade to decapitate the euthanized fish at the level of the pectoral fin. Using dissecting scissors, make a longitudinal incision on the ventral side of the fish, extending from the anterior end to the anal area.</li>
	<li>Place the fish on a petri dish under a dissecting microscope with incident light. Using a pair of dissecting forceps, transfer ovary portions to a 35 x 10 mm culture dish containing 4 mL of Leibovitz&#39;s L-15 medium +DHP.
	NOTE: The ovaries, which contain developing oocytes, will appear as opaque and clumpy structures within the internal body cavity.</li>
	<li>Using dissecting forceps, gently dissociate the oocytes from the follicular masses. Sort the early stage IV oocytes (Figure 2B; prior to GV breakdown, at near-maximal size and characterized by a dark, opaque cytoplasm and a readily apparent GV located asymmetrically within the oocyte). Discard oocytes at earlier stages (Figure 2A) and translucent, mature stage V eggs (similar to those in Figure 2C but present in the ovaries prior to DHP treatment).
	NOTE: Oocytes are selected for maturation in early stage IV, the earliest stage that results in mature, stage V oocytes after in vitro culture conditions (Figure 2C and D)3. Because stage IV oocytes are actively producing products, manipulation at this stage allows for the expression of exogenous products through RNA injection or for the reduction of gene function via introduced MOs.</li>
	<li>Use a glass Pasteur pipet to transfer the early stage IV oocytes to a second 35 x 10 mm plastic culture dish containing 4 mL of Leibovitz&#39;s L-15 medium +DHP. Transfer minimal amounts of -DHP medium to the dish containing the +DHP solution.</li>
</ol>
4. Oocyte Microinjections
NOTE: Isolated stage IV oocytes undergoing in vitro maturation can be microinjected to introduce reagents for functional manipulation or tagged protein expression. The microinjection of reagents, such as mRNA and MOs (see section 4), is typically carried out when the oocytes are undergoing in vitro maturation in +DHP medium, prior to defolliculation. If desired, in order to allow more time to conduct manipulations prior to oocyte maturation, the injections can also be carried out in -DHP medium, prior to maturation, for at least 2 h. They can subsequently be transferred to +DHP medium.
<ol>
	<li>Prepare mRNAs using a standard expression kit. Keep them at -80 &#176;C as a 100-500 pg/&#181;L stock for injection at a final concentration of 50-500 pg/&#181;L (200 pg/&#181;L is recommended) in RNA-grade water. Prepare MOs at a concentration of 4 ng/&#181;L in water according to the manufacturer&#39;s instructions. Inject them at final concentrations of 2 ng/&#181;L (or as empirically determined).
	NOTE: Injections are typically carried out in +DHP medium prior to defolliculation (see the note in section 5).</li>
	<li>If injecting mRNA, immediately prior to the injection, dilute the mRNA using RNA-grade reverse-osmosis water and 0.2 M KCl to achieve a final solution of 0.1 M KCl.</li>
	<li>If injecting MOs, immediately prior to the injection, dilute the MOs to the desired concentration using reverse-osmosis water and 0.2 M KCl to achieve a final solution of 0.1 M KCl.</li>
	<li>Manually hold oocytes with fine forceps and inject approximately 1 nL into wild-type stage IV oocytes using a needle made with a pulled-glass capillary pipette.
	<ol>
		<li>Prepare the glass needles by pulling heated glass capillary tubes, loading the solution to be injected, and breaking the needle tip with forceps, as previously described in protocols for standard injection into zebrafish early embryos15.
		NOTE: It is helpful if the needle has a gradual taper rather than an abrupt one; this allows more flexibility in terms of the location of the break in the needle tip and also helps to prevent damage to the injected embryo. Using the same needle and solution as for the embryo injections, adjust the injected volume by pre-determining the microinjector pressure settings that produce the desired volume. These settings can be determined by mock-injecting into a drop of mineral oil on a microscope stage calibration slide (0.01 mm) and adjusting the microinjector settings to obtain the desired diameter in the bolus of injected solution, as previously described15.</li>
	</ol>
	</li>
</ol>
5. Oocyte Maturation and Defolliculation
NOTE: During oocyte maturation, the oocytes will become progressively translucent, which allows for the assessment of successful culture conditions.
<ol>
	<li>Continue incubating the immature (and, if appropriate, injected) oocytes in +DHP medium at 26.5 &#176;C, checking periodically (every 30 min) to ensure that the oocytes remain intact and are undergoing proper maturation by becoming progressively translucent (see Figure 2C).
	<ol>
		<li>Remove any lysing oocytes with a Pasteur pipette and discard them in a lab waste beaker to maintain the quality of the medium. Exchange the culture medium with approximately a half-volume of fresh +DHP medium to maintain a clear solution, depending on the amount of oocyte lysis.</li>
		<li>Allow the in vitro maturation to proceed until a majority of the oocytes become translucent and have a GV that is no longer apparent (approximately 2 h in DHP treatment, see Figure 2C as compared to D). View them under a dissecting microscope with transmitted light optics.</li>
	</ol>
	</li>
	<li>Remove the outermost follicular membrane from each matured oocyte. Use extra-fine forceps to make a tear in the follicular membrane in a region with increased space between the oocyte and the membrane. Peel off a portion of the membrane and roll the oocyte out of the membrane while holding down the peeled part.
	NOTE: The underlying chorionic membrane will typically remain in close association with the egg during this process; after egg activation, it expands to form a protective layer for the embryo.</li>
	<li>Transfer the defolliculated oocytes in a minimal volume of medium (typically, transfer about 5-10 mature oocytes in less than 20 &#181;L) to a petri dish with a few drops of culture (+DHP) medium and proceed to fertilization.</li>
</ol>
6. Fertilization of In Vitro Cultured Oocytes
NOTE: The sperm solution on ice, prepared below, will maintain its potency for about 2 h.
<ol>
	<li>Prepare a sperm solution near the end of the oocyte maturation step and prior to defolliculation using testes from five males in 500 &#181;L of Hanks&#39; solution, as described previously16,17.</li>
	<li>Add 10-50 &#181;L of sperm solution to the defolliculated oocytes in +DHP culture medium. Wait 10 s.</li>
	<li>Using a pipette, add a few drops of embryonic (E3) medium to the oocytes. Wait 1 min and then flood the plate with E3 medium.
	NOTE: The composition of E3 medium is as follows: 5 mM NaCl, 0.17 mM KCl, 0.33 mM CaCl2, 0.33 mM MgSO4, and 1-5% Methylene Blue13.</li>
	<li>Repeat steps 5.3, 6.2, and 6.3 to obtain greater numbers of fertilized embryos.</li>
	<li>Allow the fertilized embryos to develop. Use a dissecting microscope with transmitted light optics to observe the progression through the cleavage stages to ensure successful fertilization, as previously described for fertilization17 and staging18.</li>
</ol>

<ol>
	<li>Lindeman, R., Pelegri, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Vertebrate+maternal-effect+genes:+insights+into+fertilization,+early+cleavage+divisions,+and+germ+cell+determinant+localization+from+studies+in+the+zebrafish.">Vertebrate maternal-effect genes: insights into fertilization, early cleavage divisions, and germ cell determinant localization from studies in the zebrafish.</a> Mol Rep Dev. 77 (4), 299-313 (2010).</li><li>Abrams, E. W., Mullins, M. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Early+zebrafish+development:+it's+in+the+maternal+genes.">Early zebrafish development: it's in the maternal genes.</a> Curr Opin Genet Dev. 19 (4), 396-403 (2009).</li><li>Nair, S., Lindeman, R. E., Pelegri, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+vitro+oocyte+culture-based+manipulation+of+zebrafish+maternal+genes.">In vitro oocyte culture-based manipulation of zebrafish maternal genes.</a> Dev Dyn. 242 (1), 44-52 (2013).</li><li>Selman, K., Petrino, T. R., Wallace, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Experimental+conditions+for+oocyte+maturation+in+the+zebrafish,+Brachydanio+rerio.">Experimental conditions for oocyte maturation in the zebrafish, Brachydanio rerio.</a> J Exp Zool. 269 (6), 538-550 (1994).</li><li>Fauvel, C., Omnes, M. H., Suquet, M., Normant, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reliable+assessment+of+overripening+in+turbot+(Scophtalmus+maximus)+by+a+simple+pH+measurement.">Reliable assessment of overripening in turbot (Scophtalmus maximus) by a simple pH measurement.</a> Aquaculture. 117 (1-2), 107-113 (1993).</li><li>Lahnsteiner, F., Weismann, T., Patzner, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Composition+of+the+ovarian+fluid+in+4+salmonid+speices:+Onchorhynchus+mykiss,+Salmo+trutta+flacustris,+Salvelinus+alpinus+and+Husho+hucho.">Composition of the ovarian fluid in 4 salmonid speices: Onchorhynchus mykiss, Salmo trutta flacustris, Salvelinus alpinus and Husho hucho.</a> Reprod Nutr Dev. 35 (5), 465-474 (1995).</li><li>Pati&#241;o, R., Bolamba, D., Thomas, P., Kumakura, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effects+of+external+pH+on+hormonally+regulated+ovarian+follicle+maturation+and+ovulation+in+Atlantic+croaker.">Effects of external pH on hormonally regulated ovarian follicle maturation and ovulation in Atlantic croaker.</a> Gen Comp Endocrinol. 141 (2), 126-134 (2005).</li><li>Seki, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development+of+a+reliable+in+vitro+maturation+system+for+zebrafish+oocytes.">Development of a reliable in vitro maturation system for zebrafish oocytes.</a> Reproduction. 135 (3), 285-292 (2008).</li><li>Selman, K., Wallace, R. A., Sarka, A., Qi, X. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stages+of+oocyte+development+in+the+zebrafish,+Brachydanio+rerio.">Stages of oocyte development in the zebrafish, Brachydanio rerio.</a> J Morphol. 218 (2), 203-224 (1993).</li><li>Clelland, E., Peng, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Endocrine/paracrine+control+of+zebrafish+ovarian+development.">Endocrine/paracrine control of zebrafish ovarian development.</a> Mol Cell Endocrinol. 312 (1-2), 42-52 (2009).</li><li>Kane, D. A., Kimmel, C. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+zebrafish+midblastula+transition.">The zebrafish midblastula transition.</a> Development. 119 (2), 447-456 (1993).</li><li>Kanagaraj, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Souffle/Spastizin+controls+secretory+vesicle+maturation+during+zebrafish+oogenesis.">Souffle/Spastizin controls secretory vesicle maturation during zebrafish oogenesis.</a> PLoS Genet. 10 (6), e1004449 (2014).</li><li>Brand, M., Granato, M., N&#252;sslein-Volhard, C., N&#252;sslein-Volhard, C., Dahm, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Keeping and raising zebrafish,Zebrafish - A Practical Approach. , 7-37 (2002).</li><li>Connoly, M. H., Dutkosky, R. M., Heah, T. P., Sayler, G. S., Henry, T. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Temporal+dynamics+of+oocyte+growth+and+vitellogenin+gene+expression+in+zebrafish+(Danio+rerio).">Temporal dynamics of oocyte growth and vitellogenin gene expression in zebrafish (Danio rerio).</a> Zebrafish. 11 (2), 107-114 (2014).</li><li>Rosen, J. N., Sweeney, M. F., Mably, J. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microinjection+of+zebrafish+embryos+to+analyze+gene+function.">Microinjection of zebrafish embryos to analyze gene function.</a> J Vis Exp. (25), e1115 (2009).</li><li>Pelegri, F., Mullins, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genetic+screens+for+mutations+affecting+adult+traits+and+parental-effect+genes.">Genetic screens for mutations affecting adult traits and parental-effect genes.</a> Meth Cell Biol. 104, 83-120 (2011).</li><li>Baars, D. L., Takle, K. A., Heier, J., Pelegri, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ploidy+manipulation+of+zebrafish+embryos+with+Heat+Shock+2+treatment.">Ploidy manipulation of zebrafish embryos with Heat Shock 2 treatment.</a> J Vis Exp. , (2016).</li><li>Kimmel, C., Ballard, W. W., Kimmel, S. R., Ullman, B., Schilling, T. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stages+of+embryonic+development+in+the+zebrafish.">Stages of embryonic development in the zebrafish.</a> Dev Dyn. 203 (3), 253-310 (1995).</li><li>Eisen, J. S., Smith, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Controlling+morpholino+experiments:+don't+stop+making+antisense.">Controlling morpholino experiments: don't stop making antisense.</a> Development. 135 (10), 1735-1743 (2008).</li><li>Schulte-Merker, S., Stainier, D. Y. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Out+with+the+old,+in+with+the+new:+reassessing+morpholino+knockdowns+in+light+of+genome+editing+technology.">Out with the old, in with the new: reassessing morpholino knockdowns in light of genome editing technology.</a> Development. 141 (16), 3103-3104 (2014).</li><li>Dekens, M. P. S., Santoriello, C., Vallone, D., Frassi, G., Whitmore, D., Foulkes, N. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Light+regulates+the+cell+cycle+in+zebrafish.">Light regulates the cell cycle in zebrafish.</a> Curr Biol. 13 (23), 2051-2057 (2003).</li><li>Sakai, N., Burgess, S., Hopkins, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Delayed+in+vitro+fertilization+of+zebrafish+eggs+in+Hank's+saline+containing+bovine+serum+albumin.">Delayed in vitro fertilization of zebrafish eggs in Hank's saline containing bovine serum albumin.</a> Mol Mar Biotechnol. 6 (2), 84-87 (1997).</li><li>Pelegri, F., Mullins, M. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genetic+screens+for+mutations+affecting+adult+traits+and+parental-effect+genes.">Genetic screens for mutations affecting adult traits and parental-effect genes.</a> Meth Cell Biol. 135, (2016).</li><li>Lindeman, R. E., Pelegri, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Localized+products+of+futile+cycle/lrmp+promote+centrosome-nucleus+attachment+in+the+zebrafish+zygote.">Localized products of futile cycle/lrmp promote centrosome-nucleus attachment in the zebrafish zygote.</a> Curr Biol. 22 (10), 843-851 (2012).</li><li>Nair, S., Marlow, F., Abrams, E., Kapp, L., Mullins, M., Pelegri, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+chromosomal+passenger+protein+Birc5b+organizes+microfilaments+and+germ+plasm+in+the+zebrafish+embryo.">The chromosomal passenger protein Birc5b organizes microfilaments and germ plasm in the zebrafish embryo.</a> PLoS Genetics. 9 (4), e1003448 (2013).</li><li>Eno, C., Solanki, B., Pelegri, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=aura+(mid1ip1l)+regulates+the+cytoskeleton+at+the+zebrafish+egg-to-embryo+transition.">aura (mid1ip1l) regulates the cytoskeleton at the zebrafish egg-to-embryo transition.</a> Development. 143 (9), 1585-1599 (2016).</li></ol>

The authors have no competing financial interests.

The above protocol is for the manipulation of gene products before fertilization, thus allowing for the study of maternal gene products in the early zebrafish embryo. Previous studies have been able to mature oocytes in vitro4; this protocol was modified to allow for the subsequent fertilization of in vitro matured oocytes8. This in turn allows for the injection of reagents for functional manipulation and visualization of maternally inherited products in the early embryo3. Embryos resulting from this method can be viable and can survive to become fertile adults. In preliminary experiments, approximately half of the fertilized embryos derived from this procedure were viable on day 5 of development, as assessed by swim bladder inflation at that stage, about half of which became healthy, fertile adults (unpublished observations).
There are a number of critical steps to consider in the protocol. Oocytes at the appropriate stage to initiate maturation (early stage IV) can be enriched if the female has been mated recently, but not before 8 dpp. Using fish that have not mated recently might result in degenerating eggs14, which will not undergo maturation. Females mated within less than 8 days will have a majority of eggs at stage III or less, and thus, the eggs will not mature properly in vitro. Ovaries in females that mated 8 days prior will have an optimal fraction of oocytes in early stage IV. These can be recognized by their opacity and the presence of the GV in an eccentric position (Figure 2B). Oocyte stage determination can also be aided by size measurement, with the oocytes placed onto a graduated micrometer slide under a microscope and compared to standard staging guidelines (Table 1). However, early stage IV oocytes have near-maximal size compared to mature oocytes (recognized by their relative transparency and lack of a GV; Figure 2C) and are easily recognized, as described above, which generally obviates the need of a direct oocyte size measurement.
In vitro maturation must begin within several hours of the end of the daylight cycle to which the female oocyte donors are acclimated. Oocytes will not mature properly, reflected in poor fertilization rates, if cultured during the morning period of the light cycle. The reason for the circadian dependency of the in vitro oocyte maturation method is not understood but likely reflects underlying circadian biases in in vivo egg maturation involving cycling gene expression during oogenesis21. A common cause for oocytes failing to undergo successful in vitro maturation in spite of proper oocyte staging is that the DHP has expired. DHP hormone generally expires after a year, and to insure effective maturation, the working batch should be replaced within 9 months of use.
The injection of oocytes is another critical step when the purpose of the method is the functional manipulation of maternal products. This procedure has requirements that differ from those for standard injections in the fertilized egg at 0-30 mpf. A key factor in oocyte injection is the need to carry out the injections under conditions that do not lead to premature egg activation, such as in Leibovitz&#39;s L-15 medium22,23. Because they are embedded in ovaries, maturing oocytes also pose particular challenges to injection. The protocol above suggests first dissociating oocytes from the ovaries and then holding each dissociated oocyte separately with forceps while injecting. This technique has worked well and allows pre-sorting oocytes at the appropriate stage with minimal handling. Alternative methods can also be used, such as: i) placing oocytes into standard injection agarose troughs15, where the vertical walls of the trough support the oocyte during injection (in this alternative method, the oocytes need to be transferred to injection plates while kept in in vitro maturation medium) and ii) allowing the oocytes to remain attached to the ovarian mass, which can be held with forceps during the injection to avoid contact with the injected oocyte (in this approach, the oocytes should be dissociated after injection to both facilitate DHP exposure and to allow their defolliculation, itself essential for IVF). In spite of this specific challenge, stage IV oocytes can be readily penetrated with an injection needle, likely because the chorionic membrane at this stage is not fully developed9.
One limitation of the current maturation protocol is that in vitro maturation conditions that promote proper oocyte development cannot be created when oocyte maturation is initiated at stages earlier than stage IV. Oocytes become competent to respond to DHP by undergoing maturation when they reach a diameter of 520 &#181;m, which occurs during stage III (vitellogenesis, corresponding to the 340-to-690-&#181;m range)9. However, the culture of stage III oocytes results in oocytes that are not competent for fertilization3. Only oocytes whose in vitro culture is initiated at stage IV (Figure 2B) can develop into mature, stage V oocytes (Figure 2C and D). This may be related to the fact that stage III is essential for vitellogenesis and oocyte growth9. Thus, the in vitro oocyte maturation procedure presented in this article should only be used with a starting population of stage IV oocytes (B), and not with oocytes at earlier stages (stages I - III; Figure 2A). For the same reason, this procedure is limited to genes that are expressed at stage IV or later. The functional manipulation of genes whose products are expressed earlier may instead have to rely on genetic methods (see below). Improvements to in vitro culture maturation methods may in the future allow for the initiation of oocyte culturing at earlier stages, thus expanding the power of the in vitro maturation approach.
Another limitation in the presented method is that defolliculation, which is essential for the subsequent steps involving fertilization, is currently a rate-limiting step in the procedure. The follicular membrane is a transparent layer surrounding the developing oocyte, and removal can be tedious. If this membrane is not fully removed, the egg will not become fully activated and fertilized. This is made evident by the failure of the chorion to expand and the development of irregularly placed, furrow-like structures (pseudocleavages), characteristic of unfertilized embryos11. Enzymatic defolliculation methods such as collagenase, as used in Xenopus, have been tried. However, in our hands, this technique has not been successful, and we therefore rely on manual defolliculation. Because manual defolliculation is labor-intensive and time-consuming, it is difficult to obtain large batches of fertilized eggs after in vitro oocyte maturation. Due to the temporal limitation imposed by manual defolliculation, we currently fertilize a few defolliculated, mature eggs at a time, in small batches of 5-10 eggs. The incorporation of enzymatic defolliculation with this procedure would likely significantly increase its yield and overall ease of use.
Although embryos produced after the fertilization of in vitro-matured oocytes can become viable adults, we note that after in vitro fertilization, a fraction of embryos do not divide normally or in a timely fashion. We are currently selecting for lines whose propagation includes rounds of in vitro oocyte maturation, which may result in more robust patterns of development in embryos derived through this method.
The procedure has allowed for the clear rescue or visualization of protein localization for a number of mutations24,25. However, for some genes, the regulation of product expression may be crucial, so the products expressed by injected mRNA may lead to variable results26. It is also important to be mindful of all the controls (e.g., embryos injected with reagents that have similar properties to those used in the experiment yet are predicted to not produce an effect, such as control MOs or RNAs coding for inert proteins only, such as GFP), as underlying variability may lead to improper conclusions.
An approach involving in vitro manipulation followed by fertilization is particularly useful in the case of maternally deposited products, where the standard method of injecting RNA, MOs, or protein into the fertilized egg may not effectively reduce products already accumulated in the egg. Other recently developed methods, such as CRISPR-mutant generation, are also effective at generating mutant conditions for maternally expressed genes26. However, this method requires the growth of several generations of fish. The in vitro oocyte maturation technique allows for rapid functional manipulation to study the function of maternally expressed genes, including the rescue and phenocopy of maternal-effect mutations, as well as the expression of RNA and proteins in the early embryo.

During animal development, the mother deposits gene products (e.g., RNAs, proteins, and other biomolecules) into the egg; these products are important for early cellular processes immediately following fertilization1,2. The manipulation of the expression and function of maternal products is typically ineffective when using a standard approach for the injection of reagents into fertilized eggs3. This is because most RNAs and proteins are produced by the oocyte during oogenesis, so pre-loaded maternal products are already present in the mature egg. Such preexisting products are impervious to functional knockdown with gene targeting agents, such as Morpholino antisense oligos (MOs), because MOs target the mRNA, not the preexisting protein already present in the egg at fertilization. In addition, many early embryonic processes happen too soon after fertilization to be influenced by protein products derived from RNA injected into the fertilized egg, as the RNA may not be produced fast enough to influence the first events of embryogenesis. For the same reason, tagged protein fusions expressed through an mRNA injection into the fertilized egg may not be produced in time for visualization during their active role in the early embryo. Injection into extruded mature oocytes prior to egg activation is possible but is associated with similar technical issues: such mature eggs are already pre-loaded with maternal protein, and they will not become translationally active (i.e., produce protein from exogenous transcripts) until after egg activation. For these reasons, the manipulation of maternal gene products acting in early embryogenesis typically needs to be carried out during oogenesis in the maturing oocyte.
As one approach to overcoming these hurdles, in vitro maturation methods, which allow for the maturation of oocytes from stage IV to egg formation, have been established in zebrafish. Early methods allowed in vitro maturation, but the resulting mature eggs were not competent for fertilization4. Subsequently, the manipulation of culture conditions from neutral to pH 9.0, mimicking the alkaline pH of the ovarian fluid found in fish species5,6, allowed for reliable in vitro fertilization (IVF) after in vitro maturation7,8. Indeed, in vitro-matured oocytes can yield viable embryos that survive to adulthood and that are fertile3,8. This improved method has been further adapted to include the functional manipulation of maternal genes, the expression of tagged proteins during zebrafish oogenesis through exogenous expression, and MO-mediated functional knock down in maturing stage IV oocytes3 (Figure 1).
Zebrafish oogenesis exhibits a number of characteristic stages leading to the formation of mature oocytes9 (see Table 1 for a quick guide to the various stages in oogenesis). Briefly, oocyte development is initiated by stage I oocytes and is arrested at the diplotene stage of prophase I of meiosis. These oocytes undergo growth through active transcription (initiated during stages IA and IB), the formation of cortical alveoli (also known as cortical granules, initiated during stage II), and vitellogenesis (initiated during stage III). Oocyte growth is completed during stage IV, when meiosis I resumes, resulting in the disassembly of the oocyte nucleus, referred to as the germinal vesicle (GV). Subsequently, meiosis is arrested again at metaphase II. The completion of oocyte growth and meiotic arrest during stage IV leads to a mature stage V egg9. The removal of the follicular membrane occurs during the release of the oocyte into the lumen of the ovary10 and is essential for fertilization and proper egg activation. Once the eggs are extruded from the mother during natural mating, they become activated. In zebrafish, exposure to water is sufficient for full egg activation, regardless of the presence of sperm11.
In vitro conditions currently allow for the maturation of oocytes from early stage IV-which can be recognized by their size (690-730 &#181;m), the presence of a large GV in an asymmetric position, and a fully opaque appearance due to the accumulation of yolk proteins (Figure 2B)-to the mature stage V egg, characterized by a fully disassembled GV and a translucent appearance due to yolk protein processing12 (Figure 2C). In this approach, whole ovaries containing oocytes at different stages of development are removed from females. The oocytes are allowed to develop in 17&#945;-20&#946;-dihydroxy-4 pregnen-3-one (DHP), an effective maturation-inducing hormone8. During this period, maturing oocytes can be manipulated through the injection of expression (e.g., capped, in vitro-transcribed mRNAs) or reverse-genetics agents (e.g., MOs). The follicular layer does not spontaneously shed towards the end of the maturation period, so it must be manually removed. After defolliculation, in vitro fertilization is achieved by triggering egg activation through the exposure of the eggs to water (present in embryonic (E3) medium)13 and a sperm solution. The resulting zygotes undergo embryonic development and allow for the evaluation of the ability of treatments to manipulate maternal gene function and for the visualization and analysis of tagged maternal products (Figure 3).

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Zebrafish mating boxes</td>
			<td>Aqua Schwarz</td>
			<td>SpawningBox1</td>
			<td></td>
		</tr>
		<tr>
			<td>NaCl</td>
			<td>Sigma</td>
			<td>S5886</td>
			<td></td>
		</tr>
		<tr>
			<td>KCl</td>
			<td>Sigma</td>
			<td>P5405</td>
			<td></td>
		</tr>
		<tr>
			<td>Na2HPO4</td>
			<td>Sigma</td>
			<td>S3264</td>
			<td></td>
		</tr>
		<tr>
			<td>KH2PO4</td>
			<td>Sigma</td>
			<td>P9791</td>
			<td></td>
		</tr>
		<tr>
			<td>CaCl2</td>
			<td>Sigma</td>
			<td>C7902</td>
			<td></td>
		</tr>
		<tr>
			<td>MgSO4-7H2O</td>
			<td>Sigma</td>
			<td>63138</td>
			<td></td>
		</tr>
		<tr>
			<td>NaHCO3</td>
			<td>Sigma</td>
			<td>S5761</td>
			<td></td>
		</tr>
		<tr>
			<td>Tricaine</td>
			<td>Western Chemical</td>
			<td>Tricaine-D (MS 222)</td>
			<td>FDA approved (ANADA 200-226)</td>
		</tr>
		<tr>
			<td>Tris base</td>
			<td>Sigma</td>
			<td>77-86-1</td>
			<td>to prepare 1 M Tris pH 9.0</td>
		</tr>
		<tr>
			<td>HCl</td>
			<td>Sigma</td>
			<td>920-1</td>
			<td>to prepare 1 M Tris pH 9.0</td>
		</tr>
		<tr>
			<td>Fish net (fine mesh) (4-5 in)</td>
			<td>PennPlax</td>
			<td>(ThatFishThatPlace # 212370)</td>
			<td>available in ThatFishThatPlace</td>
		</tr>
		<tr>
			<td>Plastic spoon</td>
			<td></td>
			<td></td>
			<td>available in most standard stores</td>
		</tr>
		<tr>
			<td>Dissecting scissors</td>
			<td>Fine Science Tools</td>
			<td>14091-09</td>
			<td></td>
		</tr>
		<tr>
			<td>Dissecting forceps</td>
			<td>Dumont</td>
			<td>SS</td>
			<td>available from Fine Science Tools</td>
		</tr>
		<tr>
			<td>Dissecting stereoscope (with transmitted light source)</td>
			<td>Nikon</td>
			<td>SMZ645</td>
			<td>or equivalent</td>
		</tr>
		<tr>
			<td>Reflective light source (LED arms)</td>
			<td>Fostec</td>
			<td>KL1600 LED</td>
			<td>or equivalent</td>
		</tr>
		<tr>
			<td>Petri plates 10 cm diameter</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Eppendorf tubes 1.5 ml</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Ice bucket</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Narrow spatula</td>
			<td>Fisher</td>
			<td>14-374</td>
			<td></td>
		</tr>
		<tr>
			<td>Depression glass plate</td>
			<td>Corning Inc</td>
			<td>722085 (Fisher cat. No 13-748B)</td>
			<td>available from Fisher Scientific</td>
		</tr>
		<tr>
			<td>Paper towels</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Kimwipes</td>
			<td>Kimberly-Clark</td>
			<td>06-666-11</td>
			<td>available from Fisher Scientific</td>
		</tr>
		<tr>
			<td>Timer stop watch</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Wash bottle</td>
			<td>Thermo Scientific</td>
			<td>24020500</td>
			<td>available from Fisher Scientific</td>
		</tr>
		<tr>
			<td>beakers, 250 ml (2)</td>
			<td>Corning Inc.</td>
			<td>1000250</td>
			<td>available from Fisher Scientific</td>
		</tr>
		<tr>
			<td>Leibovitz&#39;z L-15 medium</td>
			<td>Thermofisher</td>
			<td>11415064</td>
			<td></td>
		</tr>
		<tr>
			<td>NaOH&#160;</td>
			<td>Sigma</td>
			<td>221465</td>
			<td>for pH&#39;ing</td>
		</tr>
		<tr>
			<td>BSA</td>
			<td>Sigma</td>
			<td>A2058</td>
			<td></td>
		</tr>
		<tr>
			<td>17alph-20beta-dihyroxy-4-pregnen-3-one (DHP)</td>
			<td>Sigma</td>
			<td>P6285</td>
			<td></td>
		</tr>
		<tr>
			<td>gentamicin</td>
			<td>Sigma</td>
			<td>G1272</td>
			<td></td>
		</tr>
		<tr>
			<td>Injection Apparatus</td>
			<td>Eppendorf</td>
			<td>FemtoJet</td>
			<td>or equivalent</td>
		</tr>
		<tr>
			<td>Capillary Tubing for injection needles</td>
			<td>FHC</td>
			<td>30-30-1</td>
			<td>or equivalent, Borosil 1.0 mm OD x 0.5 mm ID with fiber, 100 mm</td>
		</tr>
		<tr>
			<td>Needle puller</td>
			<td>Sutter Instruments</td>
			<td>Model P-87</td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Micropipetor (1-20 &#181;l range) with tips</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Micropipetor (20 - 200 &#181;l range) with tips</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Micropipetor (100 - 1000 &#181;l range) with tips</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Conical tubes 15ml</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Conical tubes 50ml</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>plastic pipette 10 ml with bulb</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>plastic pipette 20 ml with bulb</td>
			<td></td>
			<td></td>
			<td>any maker</td>
		</tr>
		<tr>
			<td>Microscope stage Calibration Slide 0.01 mm</td>
			<td>AmScope</td>
			<td>MR095</td>
			<td>or equivalent</td>
		</tr>
		<tr>
			<td>Reagents for fish water:</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Instant Ocean Salt</td>
			<td>Drs. Foster &#38; Smith</td>
			<td>&#160;CD-116528</td>
			<td></td>
		</tr>
		<tr>
			<td>Sodium bicarbonate (cell culture tested)</td>
			<td>Sigma</td>
			<td>S5761-1KG</td>
			<td></td>
		</tr>
		<tr>
			<td>Reagents for E3 medium:</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>NaCl</td>
			<td>Sigma</td>
			<td>S5886-1KG</td>
			<td></td>
		</tr>
		<tr>
			<td>KCl</td>
			<td>Sigma</td>
			<td>P5405-500G</td>
			<td></td>
		</tr>
		<tr>
			<td>CaCl2, dihydrate</td>
			<td>Sigma</td>
			<td>C7902-500G</td>
			<td></td>
		</tr>
		<tr>
			<td>MgSO4, heptahydrate</td>
			<td>Sigma</td>
			<td>63138-250G</td>
			<td></td>
		</tr>
		<tr>
			<td>Methylene Blue</td>
			<td>Sigma</td>
			<td>M9140-25G</td>
			<td></td>
		</tr>
		<tr>
			<td>Fish Food:</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Frozen brine shrimp</td>
			<td>Brine Shrimp Direct</td>
			<td>FBSFKG50</td>
			<td></td>
		</tr>
		<tr>
			<td>Tetramin Flakes</td>
			<td>Drs. Foster &#38; Smith</td>
			<td>16623</td>
			<td></td>
		</tr>
	</tbody>
</table>

functional manipulation of maternal gene products using in vitro oocyte maturation in zebrafish

Cellular events that take place during the earliest stages of animal embryonic development are driven by maternally derived gene products deposited into the developing oocyte. Because these events rely on maternal products which typically act very soon after fertilization-that preexist inside the egg, standard approaches for expression and functional reduction involving the injection of reagents into the fertilized egg are typically ineffective. Instead, such manipulations must be performed during oogenesis, prior to or during the accumulation of maternal products. This article describes in detail a protocol for the in vitro maturation of immature zebrafish oocytes and their subsequent in vitro fertilization, yielding viable embryos that survive to adulthood. This method allows the functional manipulation of maternal products during oogenesis, such as the expression of products for phenotypic rescue and tagged construct visualization, as well as the reduction of gene function through reverse-genetics agents.

To determine if the procedure described above is successful, the embryos can be observed during the cleavage stages to confirm the appearance of the stereotypical early-embryonic cleavage pattern18, as well as at 24 h post-fertilization (hpf) to confirm the proper development of the basic body plan. This procedure allows for the manipulation of maternal products for functional studies through the injection of reagents, such as mRNAs and MOs, during oocyte development.
Manipulation of maternal products for functional studies:
mRNA coding for wild-type and mutated products can be injected into in vitro maturing oocytes to test the effect of the manipulation of maternal gene function during meiosis and the early embryonic stages. For example, wild-type embryos can be injected with wild-type mRNA to test for the effect of product overexpression, or with mutant RNA to test for potential dominant (e.g., gain-of-function and antimorphic) effects in these processes. Oocytes in in vitro culture are able to produce protein from exogenous mRNA throughout oocyte development, as shown by the expression of GFP from injected mRNA, although only oocytes that initiate culture conditions at stage IV of oogenesis can develop into mature stage V oocytes (Figure 2B-2D, see also Nair et al.3). The expression of wild-type product through injected mRNA is also instrumental for the rescue of maternal-effect mutations to confirm gene identity during positional cloning3,24. In this case, wild-type mRNA is injected into oocytes from homozygous mutant females to test whether wild-type products can rescue the mutant phenotype. This genetic rescue is illustrated in Figure 3A-3C, where injected AurB mRNA is shown to rescue the phenotypic effects of a mutation in its corresponding gene, cellular island (cei) (Figure 3A-3C). The embryos from a control group are also allowed to develop to show the corresponding mutant phenotype3. Mutant RNA can also be injected into mutant oocytes to test whether the mutated product retains partial function by comparing the extent of rescue to that caused by the wild-type product.
Protein expression from mRNA injected into developing oocytes appears to occur with little or no delay. Strong GFP expression is observed within 2 h of the injection of the corresponding mRNA, regardless of the developmental stage of the oocyte3 (Figure 2B-2D; see also Nair et al.3). Products such as mCherry:Sas6 and Birc5b(Motley):GFP can be observed immediately after fertilization and during the first embryonic cell cycle3,25. The injection of mRNA during oogenesis also leads to the production of protein that, regardless of the fused tagged moiety, is functional immediately after fertilization, as shown in the case of maternal products for cellular island/aurB3, futile cycle/lrmp24, and motley/bir5b25. Translation-blocking MOs also have an effect immediately after fertilization, as shown for futile cycle/Lrmp3 and at later stages of embryogenesis, as in the case of mission impossible/dhx163. Splice-blocking MOs, when injected in maturing oocytes, may not have an effect on maternal function, likely due to already-present mature maternal transcripts in stage IV oocytes3.
Generation of morphants:
When using a MO corresponding to a gene with an already-identified mutation, the morphant phenotype is expected to mimic the mutant phenotype. Morphants are compared to uninjected embryos and to those injected with a standard, control MO. The injection of a translation-blocking morpholino can successfully phenocopy the known mutant phenotype3, as shown by the injection of Lrmp MO into oocytes, which mimics the mutant phenotype of the corresponding mutation, futile cycle (Figure 3D-F). The specificity of MOs can be determined through the same approaches used when injecting MOs into embryos (reviewed previously)19,20.
Expression of fluorescently labeled fusion proteins:
mRNA coding for gene products of interest fused to fluorescent proteins (e.g., GFP and mCherry) can also be injected into either wild-type or mutant oocytes to visualize the corresponding products within the early embryo (i.e., reflecting a subcellular localization pattern; Figure 3G and 3H). mRNAs coding for similar fusions but involving the mutant allele can be similarly expressed to test whether the mutation affects any potential subcellular localizations.
<img alt="Figure 1" src="/files/ftp_upload/55213/55213fig1.jpg" />
Figure 1: In Vitro Oocyte Maturation. Schematic diagram showing the various steps involved in in vitro oocyte maturation. Adult females are pre-selected for egg-laying 8 days prior to the procedure, to purge them of eggs that have already matured and to promote new oocyte development. The ovaries, containing developing oocytes, are removed from females and transferred to a medium containing the hormone DHP to induce oocyte maturation in vitro. After removal from females and immediately prior to or during oocyte maturation, oocytes can be injected with RNA products and other reagents for the functional manipulation of maternal factors. Mature oocytes are manually defolliculated and fertilized in vitro with a sperm solution to yield fertilized, viable embryos. <a href="http://cloudflare.jove.com/files/ftp_upload/55213/55213fig1large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 2" src="/files/ftp_upload/55213/55213fig2.jpg" />
Figure 2: In Vitro Oocyte Maturation and Expression of Products from Injected mRNA. (A) Oocytes at stages I-III, observed in ovaries from females 4 days post-purging (dpp). (B) Oocytes at stage IV, observed in ovaries from females 8 dpp. The germinal vesicle (GV, arrowhead) is clearly visible and occupies an eccentric position. The stage III oocytes in (A) also exhibit a readily apparent GV, but it is found centered in the oocyte. Stage IV oocytes in (B) have a size that is near maximal compared to that of mature oocytes in (C). (C and D) Oocytes at stage V (mature oocytes) after 2 h in in vitro maturation conditions initiated at stage IV, as in (B), and injected during maturation with GFP-encoding, in vitro transcribed mRNA (C, visible light only; D, overlay of visible light and GFP fluorescence). The GV is no longer apparent in stage V oocytes, which are also less opaque than stage IV oocytes. Injected oocytes express GFP protein (D). Defolliculation of mature stage IV oocytes is described in the protocol section. Scale bar = 300 &#181;m. All panels were reproduced, with permission, from Nair et al3. <a href="http://cloudflare.jove.com/files/ftp_upload/55213/55213fig2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" src="/files/ftp_upload/55213/55213fig3.jpg" />
Figure 3: Manipulation and Visualization of Maternal Products through In Vitro Oocyte Maturation. (A-C) Rescue of the maternal-effect phenotype caused by a mutation in cellular island/aurora B through the injection of wild-type aurB mRNA into stage IV cei/aurB oocytes. Merged images showing animal views of 65 mpf fixed blastodiscs, visualized with anti-&#223;-catenin antibodies to highlight membranes (green), anti-&#945;-tubulin antibodies to indicate microtubules (red), and DAPI to designate DNA (blue). (A) &#946;-catenin accumulation in wild-type embryos, indicative of normal furrow maturation. (B) A cei/aurB embryo from an uninjected cei/aurB stage IV oocyte shows partial, rudimentary furrows that do not accumulate &#946;-catenin. (C) A rescued cei/aurB embryo from a cei/aurB oocyte injected with wild-type aurB mRNA showing robust &#946;-catenin accumulation at the furrows. (D-F) Phenocopy of the maternal-effect caused by a mutation in futile cycle/lrmp from the injection of Lrmp morpholino into stage IV oocytes. Merged images showing animal views of 70 mpf fixed blastodiscs, visualized with anti-&#947;-tubulin antibodies to indicate centrosomes (red) and DAPI to designate DNA (blue). (D) In wild-type embryos, each nucleus associates with &#947;-tubulin, a marker for centrosomal material. (E) In maternal-effect fue mutants, pronuclear fusion fails, resulting in two to three patches of DNA labels corresponding to unfused parental pro-nuclei and the polar body for meiosis II. (F) In Lrmp morphants, where maternal Lrmp function is inhibited, the nuclei similarly fail to divide and, in addition, fail to associate with &#947;-tubulin. (G and H) Visualization of maternally produced product in the early embryo. Sass6-mCherry protein from exogenous mRNA injected into stage IV oocytes localizes to the centrioles. Merged images showing animal views of 40 mpf fixed blastodiscs, visualized with anti-&#947;-tubulin antibodies to highlight centrosomes (green), mCherry fluorescence to indicate Sass6 (red), and DAPI to designate DNA (blue). (G) Expressed Sass6-mCherry protein localizes to foci labeled by the centrosome marker &#947;-tubulin at sites flanking the nucleus (arrows). (H) The same image, showing only Sass6-mCherry and DAPI for clarity. The embryos in (G and H) are fixed, but the fluorescence of expressed products, such as mCherry fusions, can also be observed in live embryos (not shown). Scale bar = 100 &#181;m in A-F and 10 &#181;m in G and H. All panels were reproduced, with permission, from Nair et al3. <a href="http://cloudflare.jove.com/files/ftp_upload/55213/55213fig3large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Stages of Oogenesis</td>
			<td>Oocyte diameter (&#956;m)</td>
			<td>Key landmark(s)</td>
		</tr>
		<tr>
			<td>1A - Prefollicle</td>
			<td>7 to 20</td>
			<td>Initiation of active transcription, accumulation of nucleoli</td>
		</tr>
		<tr>
			<td>1B - Follicle</td>
			<td>20 to 140</td>
			<td>Decondensation of chromosomes</td>
		</tr>
		<tr>
			<td>II - Cortical alveolus</td>
			<td>140 to 340</td>
			<td>Cortical alveoli production&#160;</td>
		</tr>
		<tr>
			<td>III - Vitellogenesis</td>
			<td>340 to 690</td>
			<td>Darkening of ooplasm by accumulation of yolk precursor protein and lipids&#160;</td>
		</tr>
		<tr>
			<td>Early IV - Oocyte maturation</td>
			<td>690 to 730 (lower range)</td>
			<td>Asymmetric localization of germinal vesicle&#160;</td>
		</tr>
		<tr>
			<td>Early IV - Oocyte maturation</td>
			<td>690 to 730 (upper range)</td>
			<td>Germinal vesicle disappears, arrest at metaphase II</td>
		</tr>
		<tr>
			<td>V - Mature oocyte</td>
			<td>~750</td>
			<td>Ooplasm/yolk becomes translucent</td>
		</tr>
	</tbody>
</table>
Table 1: Landmarks of Oocyte Development in Zebrafish.

Watch this Scientific Journal Video about Functional Manipulation of Maternal Gene Products Using In Vitro Oocyte Maturation in Zebrafish at JoVE.com

Functional Manipulation of Maternal Gene Products Using In Vitro Oocyte Maturation in Zebrafish

An optimized protocol for the in vitro maturation of zebrafish oocytes used for the manipulation of maternal gene products is presented here.

Functional Manipulation of Maternal Gene Products Using In Vitro Oocyte Maturation in Zebrafish

Cellular events that take place during the earliest stages of animal embryonic development are driven by maternally derived gene products deposited into ...

functional-manipulation-maternal-gene-products-using-vitro-oocyte

Universidad de Cartagena UDEC

Research

JoVE Journal

Developmental Biology

11.3K Views.  University of Wisconsin-Madison. An optimized protocol for the in vitro maturation of zebrafish oocytes used for the manipulation of maternal gene products is presented here.

Video: Functional Manipulation of Maternal Gene Products Using In Vitro Oocyte Maturation in Zebrafish

Manipulation and In Vitro Maturation of Xenopus laevis Oocytes, Followed by Intracytoplasmic Sperm Injection, to Study Embryonic Development

Amphibian eggs have been widely used to study embryonic development. Early embryonic development is driven by maternally stored factors accumulated during oogenesis. In order to study roles of such maternal factors in early embryonic development, it is desirable to manipulate their functions from the very beginning of embryonic development. Conventional ways of gene interference are achieved by injection of antisense oligonucleotides (oligos) or mRNA into fertilized eggs, enabling under- or over-expression of specific proteins, respectively. However, these methods normally require more than several hours until protein expression is affected, and, hence, the interference of gene functions is not effective during early embryonic stages. Here, we introduce an experimental system in which expression levels of maternal proteins can be altered before fertilization. Xenopus laevis oocytes obtained from ovaries are defolliculated by incubating with enzymes. Antisense oligos or mRNAs are injected into defolliculated oocytes at the germinal vesicle (GV) stage. These oocytes are in vitro matured to eggs at the metaphase II (MII) stage, followed by intracytoplasmic sperm injection (ICSI). By this way, up to 10% of ICSI embryos can reach the swimming tadpole stage, thus allowing functional tests of specific gene knockdown or overexpression. This approach can be a useful way to study roles of maternally stored factors in early embryonic development.

Manipulation and In Vitro Maturation of Xenopus laevis Oocytes, Followed by Intracytoplasmic Sperm Injection, to Study Embryonic Development

We describe methods of manipulating Xenopus laevis immature oocytes, in vitro maturation of oocytes to eggs, and intracytoplasmic sperm injection. This protocol allows degradation of some maternal proteins and overexpression of genes of interest at fertilization, and hence is valuable to study roles of specific factors in early embryonic development.

Amphibian eggs have been widely used to study embryonic development. Early embryonic development is driven by maternally stored factors accumulated during ...

Mosaic Zebrafish Transgenesis for Functional Genomic Analysis of Candidate Cooperative Genes in Tumor Pathogenesis

Comprehensive genomic analysis has uncovered surprisingly large numbers of genetic alterations in various types of cancers. To robustly and efficiently identify oncogenic &#8220;drivers&#8221; among these tumors and define their complex relationships with concurrent genetic alterations during tumor pathogenesis remains a daunting task. Recently, zebrafish have emerged as an important animal model for studying human diseases, largely because of their ease of maintenance, high fecundity, obvious advantages for in vivo imaging, high conservation of oncogenes and their molecular pathways, susceptibility to tumorigenesis and, most importantly, the availability of transgenic techniques suitable for use in the fish. Transgenic zebrafish models of cancer have been widely used to dissect oncogenic pathways in diverse tumor types. However, developing a stable transgenic fish model is both tedious and time-consuming, and it is even more difficult and more time-consuming to dissect the cooperation of multiple genes in disease pathogenesis using this approach, which requires the generation of multiple transgenic lines with overexpression of the individual genes of interest followed by complicated breeding of these stable transgenic lines. Hence, use of a mosaic transient transgenic approach in zebrafish offers unique advantages for functional genomic analysis in vivo. Briefly, candidate transgenes can be coinjected into one-cell-stage wild-type or transgenic zebrafish embryos and allowed to integrate together into each somatic cell in a mosaic pattern that leads to mixed genotypes in the same primarily injected animal. This permits one to investigate in a faster and less expensive manner whether and how the candidate genes can collaborate with each other to drive tumorigenesis. By transient overexpression of activated ALK in the transgenic fish overexpressing MYCN, we demonstrate here the cooperation of these two oncogenes in the pathogenesis of a pediatric cancer, neuroblastoma that has resisted most forms of contemporary treatment.

The goal of this study is to demonstrate how the mosaic transgenesis strategy can be used in zebrafish to rapidly and efficiently assess the relative contributions of multiple oncogenes in tumor initiation and progression in vivo.

Comprehensive genomic analysis has uncovered surprisingly large numbers of genetic alterations in various types of cancers.  To robustly and efficiently ...

Analysis of Zebrafish Larvae Skeletal Muscle Integrity with Evans Blue Dye

The zebrafish model is an emerging system for the study of neuromuscular disorders. In the study of neuromuscular diseases, the integrity of the muscle membrane is a critical disease determinant. To date, numerous neuromuscular conditions display degenerating muscle fibers with abnormal membrane integrity; this is most commonly observed in muscular dystrophies. Evans Blue Dye (EBD) is a vital, cell permeable dye that is rapidly taken into degenerating, damaged, or apoptotic cells; in contrast, it is not taken up by cells with an intact membrane. EBD injection is commonly employed to ascertain muscle integrity in mouse models of neuromuscular diseases. However, such EBD experiments require muscle dissection and/or sectioning prior to analysis. In contrast, EBD uptake in zebrafish is visualized in live, intact preparations. Here, we demonstrate a simple and straightforward methodology for performing EBD injections and analysis in live zebrafish. In addition, we demonstrate a co-injection strategy to increase efficacy of EBD analysis. Overall, this video article provides an outline to perform EBD injection and characterization in zebrafish models of neuromuscular disease.

In this study, we describe a straightforward method to perform Evans Blue Dye (EBD) analysis on zebrafish larvae. This technique is a powerful tool for the characterization of skeletal muscle integrity and delineation of zebrafish models of muscular dystrophy, and is a valuable method for the development of novel therapeutics.

The zebrafish model is an emerging system for the study of neuromuscular disorders.  In the study of neuromuscular diseases, the integrity of the muscle ...

Functional Cloning Using a Xenopus Oocyte Expression System

Identification of genes responsible for embryonic induction poses a number of challenges; to name a few, secreted molecules of interest may be low in abundance, may not be secreted but tethered to the signaling cell(s), or may require the presence of binding partners or upstream regulatory molecules. Thus in a search for gene products capable of eliciting an early lens-inductive response in competent ectoderm, we utilized an expression cloning system that would allow identification of paracrine or juxtacrine factors as well as transcriptional or other regulatory proteins. Pools of mRNA were injected into Xenopus oocytes, and responding tissue placed directly on the oocytes and co-cultured. Following functional cloning of ldb1 from a neural plate stage cDNA library based on its ability to elicit the expression of the early lens placode marker foxe3 in lens-competent animal cap ectoderm, we characterized the mRNA expression pattern, and assayed developmental progression following overexpression or knockdown of ldb1. This system is suitable in a very wide variety of contexts where identification of an inducer or its upstream regulatory molecules is sought using a functional response in competent tissue.

Functional Cloning Using a Xenopus Oocyte Expression System

We describe a Xenopus oocyte and animal cap system for the expression cloning of genes capable of inducing a response in competent ectoderm, and discuss techniques for the subsequent analysis of such genes. This system is useful in the functional identification of a wide range of gene products.

Identification of genes responsible for embryonic induction poses a number of challenges; to name a few, secreted molecules of interest may be low in ...

Ploidy Manipulation of Zebrafish Embryos with Heat Shock 2 Treatment

Manipulation of ploidy allows for useful transformations, such as diploids to tetraploids, or haploids to diploids. In the zebrafish Danio rerio, specifically the generation of homozygous gynogenetic diploids is useful in genetic analysis because it allows the direct production of homozygotes from a single heterozygous mother. This article describes a modified protocol for ploidy duplication based on a heat pulse during the first cell cycle, Heat Shock 2 (HS2). Through inhibition of centriole duplication, this method results in a precise cell division stall during the second cell cycle. The precise one-cycle division stall, coupled to unaffected DNA duplication, results in whole genome duplication. Protocols associated with this method include egg and sperm collection, UV treatment of sperm, in vitro fertilization and heat pulse to cause a one-cell cycle division delay and ploidy duplication. A modified version of this protocol could be applied to induce ploidy changes in other animal species.

A modified protocol for ploidy manipulation uses a heat shock to induce a one-cycle stall in cytokinesis in the early embryo. This protocol is demonstrated in the zebrafish but may be applicable to other species.

Manipulation of ploidy allows for useful transformations, such as diploids to tetraploids, or haploids to diploids. In the zebrafish Danio rerio, ...

Maturation of Human Stem Cell-derived Cardiomyocytes in Biowires Using Electrical Stimulation

Human pluripotent stem cell-derived cardiomyocytes (hPSC-CMs) have been a promising cell source and have thus encouraged the investigation of their potential applications in cardiac research, including drug discovery, disease modeling, tissue engineering, and regenerative medicine. However, cells produced by existing protocols display a range of immaturity compared with native adult ventricular cardiomyocytes. Many efforts have been made to mature hPSC-CMs, with only moderate maturation attained thus far. Therefore, an engineered system, called biowire, has been devised by providing both physical and electrical cues to lead hPSC-CMs to a more mature state in vitro. The system uses a microfabricated platform to seed hPSC-CMs in collagen type I gel along a rigid template suture to assemble into aligned cardiac tissue (biowire), which is subjected to electrical field stimulation with a progressively increasing frequency. Compared to nonstimulated controls, stimulated biowired cardiomyocytes exhibit an enhanced degree of structural and electrophysiological maturation. Such changes are dependent upon the stimulation rate. This manuscript describes in detail the design and creation of biowires.

The cardiac biowire platform is an in vitro method used to mature human embryonic and induced pluripotent stem cell-derived cardiomyocytes (hPSC-CM) by combining three-dimensional cell cultivation with electrical stimulation. This manuscript presents the detailed setup of the cardiac biowire platform.

Human pluripotent stem cell-derived cardiomyocytes (hPSC-CMs) have been a promising cell source and have thus encouraged the investigation of their ...

Live Cell Imaging of Chromosome Segregation During Mitosis

Chromosomes must be reliably and uniformly segregated into daughter cells during mitotic cell division. Fidelity of chromosomal segregation is controlled by multiple mechanisms that include the Spindle Assembly Checkpoint (SAC). The SAC is part of a complex feedback system that is responsible for prevention of a cell progress through mitosis unless all chromosomal kinetochores have attached to spindle microtubules. Chromosomal lagging and abnormal chromosome segregation is an indicator of dysfunctional cell cycle control checkpoints and can be used to measure the genomic stability of dividing cells. Deregulation of the SAC can result in the transformation of a normal cell into a malignant cell through the accumulation of errors during chromosomal segregation. Implementation of the SAC and the formation of the kinetochore complex are tightly regulated by interactions between kinases and phosphatase such as Protein Phosphatase 2A (PP2A). This protocol describes live cell imaging of lagging chromosomes in mouse embryonic fibroblasts isolated from mice that had a knockout of the PP2A-B56&#947; regulatory subunit. This method overcomes the shortcomings of other cell cycle control imaging techniques such as flow cytometry or immunocytochemistry that only provide a snapshot of a cell cytokinesis status, instead of a dynamic spatiotemporal visualization of chromosomes during mitosis.

This protocol describes an easy and convenient method to label and visualize live chromosomes in mitotic cells using Histone2B-GFP BacMam 2.0 label and a spinning disc confocal microscopy system.

Chromosomes must be reliably and uniformly segregated into daughter cells during mitotic cell division. Fidelity of chromosomal segregation is controlled ...

Generation of Scaffold-free, Three-dimensional Insulin Expressing Pancreatoids from Mouse Pancreatic Progenitors In Vitro

The pancreas is a complex organ composed of many different cell types that work together to regulate blood glucose homeostasis and digestion. These cell types include enzyme-secreting acinar cells, an arborized ductal system responsible for the transportation of enzymes to the gut, and hormone-producing endocrine cells.
Endocrine beta-cells are the sole cell type in the body that produce insulin to lower blood glucose levels. Diabetes, a disease characterized by a loss or the dysfunction of beta-cells, is reaching epidemic proportions. Thus, it is essential to establish protocols to investigate beta-cell development that can be used for screening purposes to derive the drug and cell-based therapeutics. While the experimental investigation of mouse development is essential, in vivo studies are laborious and time-consuming. Cultured cells provide a more convenient platform for screening; however, they are unable to maintain the cellular diversity, architectural organization, and cellular interactions found in vivo. Thus, it is essential to develop new tools to investigate pancreatic organogenesis and physiology.
Pancreatic epithelial cells develop in the close association with mesenchyme from the onset of organogenesis as cells organize and differentiate into the complex, physiologically competent adult organ. The pancreatic mesenchyme provides important signals for the endocrine development, many of which are not well understood yet, thus difficult to recapitulate during the in vitro culture. Here, we describe a protocol to culture three-dimensional, cellular complex mouse organoids that retain mesenchyme, termed pancreatoids. The e10.5 murine pancreatic bud is dissected, dissociated, and cultured in a scaffold-free environment. These floating cells self-assemble with mesenchyme enveloping the developing pancreatoid and a robust number of endocrine beta-cells developing along with the acinar and the duct cells. This system can be used to study the cell fate determination, structural organization, and morphogenesis, cell-cell interactions during organogenesis, or for the drug, small molecule, or genetic screening.

Generation of Scaffold-free, Three-dimensional Insulin Expressing Pancreatoids from Mouse Pancreatic Progenitors In Vitro

Here, we present a protocol to generate insulin expressing 3D murine pancreatoids from free-floating e10.5 dissociated pancreatic progenitors and the associated mesenchyme.

The pancreas is a complex organ composed of many different cell types that work together to regulate blood glucose homeostasis and digestion. These cell ...

Nanoparticle-mediated siRNA Gene-silencing in Adult Zebrafish Heart

Mammals have a very limited capacity to regenerate the heart after myocardial infarction. On the other hand, the adult zebrafish regenerates its heart after apex resection or cryoinjury, making it an important model organism for heart regeneration study. However, the lack of loss-of-function methods for adult organs has restricted insights into the mechanisms underlying heart regeneration. RNA interference via different delivery systems is a powerful tool for silencing genes in mammalian cells and model organisms. We have previously reported that siRNA-encapsulated nanoparticles successfully enter cells and result in a remarkable gene-specific knockdown in the regenerating adult zebrafish heart. Here, we present a simple, rapid, and efficient protocol for the dendrimer-mediated siRNA delivery and gene-silencing in the regenerating adult zebrafish heart. This method provides an alternative approach for determining gene functions in adult organs in zebrafish and can be extended to other model organisms as well.

It remains a major challenge to develop conditional gene-knockout or effective gene-knockdown in adult zebrafish organs. Here we report a protocol for performing nanoparticle-mediated siRNA gene-silencing in adult zebrafish heart, thus providing a new loss-of-function method for studying adult organs in zebrafish and other model organisms.

Mammals have a very limited capacity to regenerate the heart after myocardial infarction. On the other hand, the adult zebrafish regenerates its heart ...

Visualizing the Node and Notochordal Plate In Gastrulating Mouse Embryos Using Scanning Electron Microscopy and Whole Mount Immunofluorescence

The post-implantation mouse embryo undergoes major shape changes after the initiation of gastrulation and morphogenesis. A hallmark of morphogenesis is the formation of the transient organizers, the node and notochordal plate, from cells that have passed through the primitive streak. The proper formation of these signaling centers is essential for the development of the body plan and techniques to visualize them are of high interest to mouse developmental biologists. The node and notochordal plate lie on the ventral surface of gastrulating mouse embryos around embryonic day (E) 7.5 of development. The node is a cup-shaped structure whose cells possess a single slender cilium each. The proper subcellular localization and rotation of the cilia in the node pit determines left-right asymmetry. The notochordal plate cells also possess single cilia albeit shorter than those of the node cells. The notochordal plate forms the notochord which acts as an important signaling organizer for somitogenesis and neural patterning. Because the cells of the node and notochordal plate are transiently present on the surface and possess cilia, they can be visualized using scanning electron microscopy (SEM). Among other techniques used to visualize these structures at the cellular level is whole mount immunofluorescence (WMIF) using the antibodies against the proteins that are highly expressed in the node and notochordal plate. In this report, we describe our optimized protocols to perform SEM and WMIF of the node and notochordal plate in developing mouse embryos to help in the assessment of tissue shape and cellular organization in wild-type and gastrulation mutant embryos.

The node and notochordal plate are transient signaling organizers in developing mouse embryos that can be visualized using several techniques. Here, we describe in detail how to perform two of the techniques to study their structure and morphogenesis: 1) scanning electron microscopy (SEM); and 2) whole mount immunofluorescence (WMIF).

The post-implantation mouse embryo undergoes major shape changes after the initiation of gastrulation and morphogenesis. A hallmark of morphogenesis is ...

Functional Manipulation of Maternal Gene Products Using In Vitro Oocyte Maturation in Zebrafish

Summary

Explore More Videos

Chapters in this video

Manipulation and In Vitro Maturation of Xenopus laevis Oocytes, Followed by Intracytoplasmic Sperm Injection, to Study Embryonic Development

Mosaic Zebrafish Transgenesis for Functional Genomic Analysis of Candidate Cooperative Genes in Tumor Pathogenesis

Analysis of Zebrafish Larvae Skeletal Muscle Integrity with Evans Blue Dye

Functional Cloning Using a Xenopus Oocyte Expression System

Ploidy Manipulation of Zebrafish Embryos with Heat Shock 2 Treatment

Maturation of Human Stem Cell-derived Cardiomyocytes in Biowires Using Electrical Stimulation

Live Cell Imaging of Chromosome Segregation During Mitosis

Generation of Scaffold-free, Three-dimensional Insulin Expressing Pancreatoids from Mouse Pancreatic Progenitors In Vitro

Nanoparticle-mediated siRNA Gene-silencing in Adult Zebrafish Heart

Visualizing the Node and Notochordal Plate In Gastrulating Mouse Embryos Using Scanning Electron Microscopy and Whole Mount Immunofluorescence
