<ol>
<li>The evening before transformation, plate 293T cells at 3-5x106 cells/6 cm tissue cultureplate. Note: We use 293T cells for their ease of transfection and efficacyas virus producing cells. These cells are deficient in packaging the virus unless a helper plasmid is introduced. </li>
<li>The first morning, gently remove medium and replace with 4 ml 293T cell med containing 25 mM Chloroquine. Put in incubator for 1 hr. Note: the plate should be about 80% confluent. </li>
<li>Meanwhile, prepare virus-making mixture for 2 plates at a time, in 5 ml tubes:<ol>
<li>2 x 10 mg retroviral plasmid construct</li>
<li>2 x 5 mg packaging construct (EcoPak), </li>
<li>2 x 62 ml CaCl</li>
<li>complete to 1 ml with sterile ddH2O Note: While the retroviral plasmid encodes the oncogene of interest and a marker, EcoPak encodes gag-pol-env. Together with the 293T cells, they will produce an ecotropic retrovirus(RV) specific for mouse cells, but not infective for human cells. Both Chloroquine and CaCl2 have been shown to increase transfection efficiency. </li>
</ol></li>
<li>Add 1ml of 2x sterileHBS drop-wise to the mixture, while gently vortexing the tube.</li>
<li>Immediately add this solution to 2 plates, 1 ml each, gently, drop by drop. </li>
<li>Put in incubator for 7 to 11 hrs.</li>
<li>In the evening (7 to 11 hrs. later), gently remove medium, and very gently replace with 5 ml fresh 293T medium. Put in incubator until noon, the next day. Note: this step is important, as you need to take off the chloroquine from the cells. If kept for extended periods of time, chloroquine is toxic. The solution in the plates looks fuzzy, due to a very fine, dust-like precipitation of the transfection mixture. Note: It is important to do all media changes with extreme gentleness, as the cells have been sensitized by the chloroquine, and can easily detach from the plate. </li>
<li>Next day, 18 to 24 hrs. before retrieving the virus (around noon), gently remove medium, and very gently replace with 3 ml fresh 293T medium. Replace in incubator O/N.</li>
<li>The third morning (18 to 24 hrs. later), gently suck up the medium form the plates with a 10 ml syringe fitted with an 18 G needle. This supernatant contains the retrovirus.</li>
<li>Change the needle to a 45 mm syringe filter, invert syringe several times to mix the solution well, pass supernatant through filter, and aliquot in cryotubes Note: Alternatively, if you are making 3+ plates of virus, pool all supernatants of the same virus into a 50 ml conical tube. Mix well, then aliquot supernatants containing the retrovirus in cryotubes by filtering. </li>
<li>The tubes containing the virus-full supernatants are kept in -80&deg;C until used.</li>
</ol>

<ol>
	<li>DuBridge, R. B., Tang, P., Hsia, H. C., Leong, P. M., Miller, J. H., Calos, M. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analysis+of+mutation+in+human+cells+by+using+an+Epstein-Barr+virus+shuttle+system.">Analysis of mutation in human cells by using an Epstein-Barr virus shuttle system.</a> Mol Cell Biol. 7, 379-387 (1987).</li><li>Cherry, S. R., Biniszkiewicz, D., van Parijs, L., Baltimore, D., Jaenisch, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Retroviral+expression+in+embryonic+stem+cells+and+hematopoietic+stem+cells.">Retroviral expression in embryonic stem cells and hematopoietic stem cells.</a> Mol Cell Biol. 20, 7419-7426 (2000).</li><li>Finer, M. H., Dull, T. J., Qin, L., Farson, D., Roberts, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=kat:+A+high-efficiency+retroviral+transduction+system+for+primary+human+T+lymphocytes.">kat: A high-efficiency retroviral transduction system for primary human T lymphocytes.</a> Blood. 83, 43-50 (1994).</li><li>Naviaux, R. K., Costanzi, E., Haas, M., Verma, I. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+pCL+vector+system:+rapid+production+of+helper-free,+high-titer,+recombinant+retroviruses.">The pCL vector system: rapid production of helper-free, high-titer, recombinant retroviruses.</a> J Virol. 70, 5701-5705 (1996).</li><li>Pear, W. S., Miller, J. P., Xu, L., Pui, J. C., Soffer, B., Quackenbush, R. C., Pendergast, A. M., Bronson, R., Aster, J. C., Scott, M. L., Baltimore, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Efficient+and+rapid+induction+of+a+chronic+myelogenous+leukemia-like+myeloproliferative+disease+in+mice+receiving+P210+bcr/abl-transduced+bone+marrow.">Efficient and rapid induction of a chronic myelogenous leukemia-like myeloproliferative disease in mice receiving P210 bcr/abl-transduced bone marrow.</a> Blood. 92, 3780-3792 (1998).</li><li>Pear, W. S., Nolan, G. P., Scott, M. L., Baltimore, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Production+of+high-titer+helper-free+retroviruses+by+transient+transfection.">Production of high-titer helper-free retroviruses by transient transfection.</a> Proc Natl Acad Sci USA. 90, 8392-8396 (1993).</li><li>Stocking, C., Kollek, R., Bergholz, U., Ostertag, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Long+terminal+repeat+sequences+impart+hematopoietic+transformation+properties+to+the+myeloproliferative+sarcoma+virus.">Long terminal repeat sequences impart hematopoietic transformation properties to the myeloproliferative sarcoma virus.</a> Proc Natl Acad Sci USA. 82, 5746-5750 (1985).</li><li>Van Etten, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Models+of+chronic+myeloid+leukemia.">Models of chronic myeloid leukemia.</a> Curr Oncol Rep. 3, 228-237 (2001).</li><li>Van Etten, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Studying+the+pathogenesis+of+BCR-ABL++leukemia+in+mice.">Studying the pathogenesis of BCR-ABL+ leukemia in mice.</a> Oncogene. 21, 8643-8651 (2002).</li></ol>

Four critical points will assure the success of a good viral stock: &nbsp;&nbsp;&nbsp;
<ol>
<li>The 293T producing cells have to be very healthy, meaning they have been split on a very regular schedule, were never overgrown, and are plated at the optimized density of 3.5-5 million per 6 cm tissue culture plate, so that they reach a density of 80% of the plate on the morning of the transfection.&nbsp; </li>
<li>Addition of chloroquine improves transfection efficiency and subsequent virus titer, about 3- ...

<table><tbody><tr><td>293T cells</td><td>cell-line</td><td></td><td></td><td>Split 1:3 to 1:4 every 3 days, otherwise they will tend to clump with replating and will not transfect as well. </td></tr><tr><td>293T cell medium</td><td></td><td></td><td></td><td>DMEM/hi-glu + 10 % FBS + 1% Pen/Strep + 1% L-Glutamine (1% NEAA, optional). We obtain our tissue culture slutions from CellGro.</td></tr><tr><td>coding DNA plasmid</td><td></td><td></td><td></td><td>Twice purified by CsCl. MSCV backbone, encoding oncogene and marker of choice (Neo, GFP, etc.)</td></tr><tr><td>EcoPak</td><td></td><td></td><td></td><td>also called pMCV-Ecopac: ecotropic packaging plasmid, encoding gag-pol-env</td></tr><tr><td>2x HBS</td><td></td><td></td><td></td><td>For 500 ml: 8.0 g NaCl+ 0.37 g KCl + 106.5 mg Na2HPO4 (anhydrous; 201.1 mg if 7xH2O) + 1.0 g dextrose (D-glucose) + 5.0 g HEPES powder. Dissolve in 450 ml dH2O (milli-Q), adjust pH to 7.05 with NaOH, then complete to 500 ml with dH2O. Sterile filter thru 0.45 &amp;#x03BC; filter. Store at room temperature, with the cap on tight.</td></tr><tr><td>2M CaCl2</td><td></td><td>Sigma-Aldrich</td><td></td><td></td></tr><tr><td>miliQ H2O</td><td></td><td></td><td></td><td>sterile-filtered</td></tr><tr><td>Chloroquine</td><td></td><td></td><td></td><td>1000x stock is 25 mM in PBS- (w/o Ca2+/Mg2+), stored at -20C. Add fresh to the medium when needed.</td></tr><tr><td>6 cm plates</td><td></td><td></td><td></td><td>for tissue culture</td></tr><tr><td>Incubator</td><td></td><td></td><td></td><td>for tissue culture. Set at 37C, 10% CO2.</td></tr><tr><td>10 cc sterile syringes</td><td></td><td></td><td></td><td>Sterile. One per virus type.</td></tr><tr><td>18G needles</td><td></td><td></td><td></td><td>single use, one per virus type.</td></tr><tr><td>45 um syringe filters</td><td></td><td></td><td></td><td></td></tr><tr><td>5 ml plastic tubes</td><td></td><td></td><td></td><td>Sterile, to mix transfection solution, for up to 2 plates at a time (2 ml). We use Falcon tubes.</td></tr><tr><td>50 ml conical tubes</td><td></td><td></td><td></td><td></td></tr><tr><td>cryovials</td><td></td><td></td><td></td><td>2 and 4 ml, for virus aliquots.</td></tr><tr><td colspan="5">&lt;p&gt;All reagents used in the transfection must be sterile-filtered (CaCl&lt;sub&gt;2&lt;/sub&gt;, 2x HBS, miliQ H&lt;sub&gt;2&lt;/sub&gt;O) and kept sterile.&lt;/p&gt;</td></tr></tbody></table>

production of replication-defective retrovirus by transient transfection of 293t cells

Our lab studies human myeloproliferative diseases induced by such oncogenes as Bcr-Abl or growth factor receptor-derived oncogenes (ZNF198-FGFR1, Bcr-PDGFR&#945;, etc.). We are able to model and study a human-like disease in our mouse model, by transplanting bone marrow cells previously infected with a retrovirus expressing the oncogene of interest. Replication-defective retrovirus encoding a human oncogene and a marker (GFP, RFP, antibiotic resistance gene, etc.) is produced by a transient transfection protocol using 293T cells, a human renal epithelial cell line transformed by the adenovirus E1A gene product. 293 cells have the unusual property of being highly transfectable by calcium phosphate (CaPO4), with up to 50-80% transfection efficiency readily attainable. Here, we co-transfect 293 cells with a retroviral vector expressing the oncogene of interest and a plasmid that expresses the gag-pol-env packaging functions, such as the single-genome packaging constructs kat or pCL, in this case the EcoPak plasmid. The initial transfection is further improved by use of chloroquine. Stocks of ecotropic virus, collected as culture supernatant 48 hrs. post-transfection, can be stored at -80&deg;C and used for infection of cell-lines in view of transformation and in vitro studies, or primary cells such as mouse bone marrow cells, that can then be used for transplant in our mouse model.

Watch this Scientific Journal Video about Production of Replication-Defective Retrovirus by Transient Transfection of 293T cells at JoVE.com

Natural Selection | Biology Video Collection

Production of Replication-Defective Retrovirus by Transient Transfection of 293T cells

This technique demonstrates an efficient way to prepare replication-defective retroviral stocks encoding a human oncogene, and subsequently used for induction of myeloproliferative disease in the mouse model.
