T.R.R conceived the project, designed and performed experiments and prepared the manuscript. E.J.K and S.E.M performed experiments. All authors contributed intellectually to the final manuscript. This work was funded by a University of Leicester Innovation Fellowship to SEM and by a UK Medical Research Council (MRC) Senior Research Fellowship to S.M.C (MR/J009202/1). DNA sequencing was performed by Protein and Nucleic Acid Laboratories (PNACL), Centre for Core Biotechnology Services, University of Leicester. We wish to thank A. Francis Stewart for providing the Rox and Dre plasmids. pL451 and pL452 plasmids were obtained from National Cancer Institute (NCI), Frederick, USA.

1. Gene Targeting Design
<ol style="margin-left: 40px;">
	<li>Order an appropriate BAC clone covering the genomic region of interest. Ensure that this is isogenic to the type of ES cells to be modified e.g., RPCI-23 and RPCI-24 BAC clones for gene targeting with C57BL/6 ES cells.</li>
	<li>Apply conventional gene targeting criteria when designing the targeting vector. Key parameters include whether the modification is required to be constitutive or conditional, defining critical exons (CE) for deletion in a gene knockout strategy and spacing and placement of intronic cassettes.
	NOTE: Each of these has been discussed in detail elsewhere10.</li>
	<li>Choose genomic regions each of 5-6 kb flanking the target modification site.
	NOTE: The size of the subcloned insert is therefore typically 10-12 kb, although the upper limit can be as high as 80 kb with a low copy subcloning plasmid like p15A, pBR322 etc. and up to 200 kb with a BAC vector.</li>
</ol>
2. Multiplex Recombineering Oligos
<ol style="margin-left: 40px;">
	<li>Design oligos for the plasmid backbone (subcloning plasmid) and the selectable marker (insertion cassette). Design each oligo such that it contains 180 bp HA flanking the genomic target site and 20 bp of specific priming sequence of the insertion cassette or the subcloning plasmid (Figure 2).
	NOTE: Homology arms should not contain any repetitive elements, presence of repetitive elements will result in incorrect targeting and subcloning. Repetitive elements can be detected by using web based tools such as the &#8216;&#8217;Repeat Masker&#8217;&#8217;.</li>
	<li>Include a unique restriction enzyme (RE) site on one of the vector oligos to linearize the gene targeting vector for ES cell targeting (Figure 2).</li>
	<li>Check oligo parameters using an oligo analyzer program. Take care to avoid secondary structures in the priming regions.</li>
	<li>Shorter HA (50 bp) of the insertion cassette is tolerated and yields lower number of recombinants but ensure that the subcloning plasmid HA is always longer (180 bp).</li>
	<li>Determine the orientation of the genomic DNA insert of the particular BAC clone using web based tools like &#8216;&#8217;cloneDB&#8217;&#8217;. Establish the direction of replication from OriS by checking the map of the BAC plasmid backbone used in the BAC library construction.
	NOTE: OriS is usually opposite to the transcriptional direction of the Chloramphenicol (Chl) marker for all commonly used BAC plasmids.</li>
	<li>Add two terminal phosphorothioate (PTO) bonds to the 5&#8217; end of the oligo that is opposite to the direction of replication on the BAC clone. Add a 5&#8217; phosphate modification to the reverse oligo (Figure 2).
	NOTE: The asymmetric phosphorothioated PCR cassette upon Red digestion generates an ssDNA intermediate that can prime the lagging strand of the replication fork.
	NOTE: Maximal multiplex recombination frequency is observed with the lagging strand protected cassettes. Leading strand protected or dual protected cassettes may not produce equivalent recombination efficiencies at some loci.</li>
	<li>Order oligos with PAGE or HPLC purification.</li>
</ol>
3. BAC Clone Transformation with pSC101 BADgbaA Recombineering Plasmid.
<ol style="margin-left: 40px;">
	<li>To make the E. coli strain bearing the BAC recombineering proficient, transform it with the pSC101 BADgbaA plasmid containing the Red genes16.
	NOTE: The pSC101 BADgbaA plasmid contains the Red and RecA genes under the control of the Arabinose inducible araC-PBAD promoter, a tetracycline selection marker and the temperature sensitive pSC101 replicon.
	<ol>
		<li>Stab a sterile pipette tip in the BAC agar culture and inoculate 5.0 ml of lysogeny broth (LB) pH 8.0 containing 12.5 &#956;g ml-1 Chl. Grow at 37 &#176;C for 5 hr&#160;shaking at 200 rpm.</li>
		<li>Chill 10% (v/v) glycerol solution, microcentrifuge tubes and electroporation cuvettes on ice. Cool a refrigerated large centrifuge and microcentrifuge to 4 &#176;C&#160;.</li>
		<li>Determine the optical density (OD) of the culture using a spectrophotometer and measure absorbance at 600 nm. Prepare electrocompetent cells (as described below) when an OD600 reading of 0.3 to 0.8 is reached.</li>
		<li>Spin down cells in a 50 ml centrifuge tube in a large centrifuge at 1,216 x&#160;g for 5 min at 4&#160;&#176;C&#160;.</li>
		<li>Wash cells with 1 ml of chilled 10% glycerol and spin down cells at 17,949 x&#160;g for 20 sec at 4 &#176;C&#160;. Perform the wash step a total of 3 times.</li>
		<li>Resuspend the cells in a total volume of 50 &#956;l of 10% glycerol and add 10-200 ng of the pSC101 BADgbaA recombineering plasmid. Obtain a single cell suspension by pipetting up and down several times and then transfer the cells to a pre-chilled 1 mm gap electroporation cuvette.</li>
		<li>Electroporate the cells with a setting of 1.8 kv, 25 &#956;F and 200 &#937;.
		NOTE: Check the correct settings for each brand of electroporator. A time constant of electroporation less than 4 indicates the presence of salt and other impurities.</li>
		<li>Immediately recover the cells in 1 ml of LB and transfer the cells to a 50 ml centrifuge tube.</li>
		<li>Grow the BAC gbaA culture at 30&#160;&#176;C&#160;&#160;for 2 hr&#160;shaking at 200 rpm.
		NOTE: The pSC101 BADgbaA plasmid is lost when cells are grown at 37&#160;&#176;C&#160;&#160;due to inactivation of the temperature sensitive RepE replication factor. Grow gbaA cells at 30&#160;&#176;C&#160;&#160;to maintain the recombineering functions.</li>
		<li>Add 9 ml of LB containing 12.5 &#956;g ml-1 Chl and 4 &#956;g ml-1 Tetracycline (Tet) to the recovered BAC gbaA culture. Grow the BAC gbaA culture O/N&#160;at 30&#160;&#176;C&#160;&#160;shaking at 200 rpm.
		NOTE: The transformation efficiency of electroporating the supercoiled gbaA plasmid is sufficiently high to permit saturation growth O/N&#160;in liquid media.</li>
	</ol>
	</li>
</ol>
4. Preparation of Insertion Cassettes and Subcloning Plasmids
<ol style="margin-left: 40px;">
	<li>To incorporate HA into the insertion cassette(s) and the subcloning plasmid, perform polymerase chain reaction (PCR) using the long modified oligos as described below.
	<ol>
		<li>Optional: to prevent plasmid carryover into the recombineering reaction, use an R6K origin or similar narrow host range plasmid template to amplify the insertion cassette.</li>
		<li>Alternatively, linearize the plasmid template using an RE digest (Table 2). Choose a RE that cuts outside the PCR amplification region and is heat inactivated. Heat inactivate the RE as recommended by the manufacturer.</li>
		<li>Set up polymerase chain reaction (PCR) using a high-fidelity hotstart DNA polymerase system. Prepare a PCR master mix as detailed (Table 3). Perform thermal cycling as shown (Table 3).</li>
	</ol>
	</li>
	<li>Analyze PCR products by agarose gel electrophoresis. Load 1-5 &#956;l&#160;of each PCR onto a 1% (w/v) agarose gel containing 0.5 mg ml-1 Ethidium Bromide (EtBR).
	NOTE: The presence of non-specific amplification products does not interfere in the recombineering reaction. In some cases however, primer-dimers may decrease recombineering efficiency.</li>
	<li>Purify PCR products using a PCR purification kit.
	<ol>
		<li>Optional: remove the plasmid template from PCRs by treatment with DpnI followed by PCR clean-up. Elute DNA in a minimal volume of sterile deionized water (as recommended by the manufacturer).
		NOTE: Addition of DpnI to unpurified PCR reactions results in reduced efficiency of cleavage of the methylated plasmid DNA template.</li>
	</ol>
	</li>
	<li>Quantify PCR amplified DNA by agarose gel analysis against a known set of DNA standards e.g., &#955;&#160;HindIII digest or by using a nanodrop spectrophotometer.</li>
</ol>
5. Subcloning Plus Insertion
<ol style="margin-left: 40px;">
	<li>Dilute the O/N BAC gbaA culture 50 fold by adding 200&#160;&#956;l&#160;in 10 ml LB+Chl+Tet. Grow at 30&#160;&#176;C&#160;&#160;shaking at 200 rpm&#160;for 1 hr 50 min. Include an sample to be used as negative control.</li>
	<li>Chill all recombineering materials and equipment to 4&#160;&#176;C&#160;&#160;as described in step 3.1.2.</li>
	<li>Pour LB agar pH 8 plates containing the correct concentration of the appropriate selective antibiotic(s) that will allow selection of the DNA fragment that is inserted as well as for the selection of the subcloning vector (Table 4).
	NOTE: Some antibiotics are pH sensitive. Use LB agar pH 8 as a rule.</li>
	<li>Prepare a 10% (w/v) solution of L-Arabinose. Filter sterilize through a 0.2 &#956;m syringe filter.
	NOTE: Arabinose induces the expression of the recombineering proteins from the gbaA plasmid.</li>
	<li>Check the OD of the BAC gbaA culture using a spectrophotometer. Once an OD600 of 0.25-0.3 is reached, induce the recombineering proteins as described in the following step.</li>
	<li>Add 200 &#956;l&#160;of the 10% Arabinose solution to 10 ml of the BAC culture to achieve a final concentration of Arabinose of 0.2%. Include an uninduced culture (without Arabinose) to be used as negative control.</li>
	<li>Transfer the BAC culture to a 37&#160;&#176;C&#160;&#160;shaking incubator and induce Red expression for 45 min shaking at 230 rpm.
	NOTE: Expression of Red proteins is inefficient at 30&#160;&#176;C&#160;.</li>
	<li>Spin down cells and wash with 10% glycerol 3 times as described in step 3.1.5.</li>
	<li>Add 600-1,000 ng each of the subcloning plasmid and the insertion cassette(s) to the recombineering reaction. Include a vector only and vector plus single insert controls to check the recombination proficiency and integrity of the vector and the cassettes.</li>
	<li>Obtain a single cell suspension by pipetting up and down. Perform electroporation as described in step 3.1.7 and subsequent recovery in 1 ml LB at 37&#160;&#176;C&#160;&#160;for 1 hr for multi-copy plasmids or in 10 ml of LB at 37&#160;&#176;C&#160;&#160;for 3 hr&#160;for BAC vectors.</li>
	<li>Plate different dilutions of the recovered culture e.g., 90%, 10%, 1% on the dual selection agar plates and grow at 37&#160;&#176;C&#160;&#160;for 16 hr.</li>
</ol>
6. Analysis of Recombinants
<ol style="margin-left: 40px;">
	<li>Optional: Pick 6 to 12 colonies and perform colony PCR using a HA flanking primer and an insert specific primer. Include the subcloning plasmid and the insertion cassette plasmid as well as the parent BAC clone as negative controls.
	<ol>
		<li>Perform agarose gel analysis of the colony PCRs. Identify positive clones by the presence of a bright band at the expected size.
		NOTE: The high efficiency of the SPI cloning process generates mostly correct recombinants.</li>
	</ol>
	</li>
	<li>Pick colonies into 5 ml LB pH 8 containing the selective antibiotic and grow O/N&#160;at 37&#160;&#176;C&#160;.</li>
	<li>Prepare DNA minipreps using a column purification kit as per the manufacturer&#8217;s instructions.</li>
	<li>Prepare BAC miniprep DNA using standard phenol-chloroform isolation or a similar protocol.</li>
	<li>Perform RE digests on the miniprep DNA. Separate DNA by agarose gel electrophoresis. Analyze RE patterns to identify the clones containing the expected fragments sizes of the correct targeting vector. Choose an RE that clearly discriminates between the vector lacking insert(s) and the vector containing the insert(s).</li>
	<li>Optional: to obtain cells that are devoid of the BAC, which is still present in the E. coli after recombineering, use the miniprep plasmid DNA to transform DH5alpha or DH10B E. coli cells.</li>
	<li>Perform DNA sequencing across the HA and insertion cassette to check oligo synthesis errors.</li>
</ol>

<ol>
	<li>Dovey, O. M., Foster, C. T., Cowley, S. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Histone+deacetylase+1+(HDAC1),+but+not+HDAC2,+controls+embryonic+stem+cell+differentiation.">Histone deacetylase 1 (HDAC1), but not HDAC2, controls embryonic stem cell differentiation.</a> Proc. Natl. Acad. Sci. USA. 107, 8242-8247 (2010).</li><li>Harvey, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Spontaneous+and+carcinogen-induced+tumorigenesis+in+p53-deficient+mice.">Spontaneous and carcinogen-induced tumorigenesis in p53-deficient mice.</a> Nat. Genet. 5, 225-229 (1993).</li><li>Waterhouse, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lymphoproliferative+disorders+with+early+lethality+in+mice+deficient+in+Ctla-4.">Lymphoproliferative disorders with early lethality in mice deficient in Ctla-4.</a> Science. 270, 985-988 (1995).</li><li>Thomas, K. R., Capecchi, M. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Site-directed+mutagenesis+by+gene+targeting+in+mouse+embryo-derived+stem+cells.">Site-directed mutagenesis by gene targeting in mouse embryo-derived stem cells.</a> Cell. 51, 503-512 (1987).</li><li>Hasty, P., Rivera-P&#233;rez, J., Bradley, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+length+of+homology+required+for+gene+targeting+in+embryonic+stem+cells.">The length of homology required for gene targeting in embryonic stem cells.</a> Mol. Cell. Biol. 11, 5586-5591 (1991).</li><li>Smithies, O., Gregg, R. G., Boggs, S. S., Koralewski, M. A., Kucherlapati, R. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Insertion+of+DNA+sequences+into+the+human+chromosomal+beta-globin+locus+by+homologous+recombination.">Insertion of DNA sequences into the human chromosomal beta-globin locus by homologous recombination.</a> Nature. 317, 230-234 (1985).</li><li>Hirata, R., Chamberlain, J., Dong, R., Russell, D. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Targeted+transgene+insertion+into+human+chromosomes+by+adeno-associated+virus+vectors.">Targeted transgene insertion into human chromosomes by adeno-associated virus vectors.</a> Nat. Biotechnol. 20, 735-738 (2002).</li><li>Szostak, J. W., Orr-Weaver, T. L., Rothstein, R. J., Stahl, F. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+double-strand-break+repair+model+for+recombination.">The double-strand-break repair model for recombination.</a> Cell. 33, 25-35 (1983).</li><li>Bradley, A., Evans, M., Kaufman, M. H., Robertson, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Formation+of+germ-line+chimaeras+from+embryo-derived+teratocarcinoma+cell+lines.">Formation of germ-line chimaeras from embryo-derived teratocarcinoma cell lines.</a> Nature. 309, 255-256 (1984).</li><li>Fu, J., Teucher, M., Anastassiadis, K., Skarnes, W., Stewart, A. F., Soriano, P. M., Wassarman, P. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+recombineering+pipeline+to+make+conditional+targeting+constructs.">A recombineering pipeline to make conditional targeting constructs.</a> Methods Enzymol. 477, 125-144 (2010).</li><li>Zhang, Y., Buchholz, F., Muyrers, J., Stewart, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+logic+for+DNA+engineering+using+recombination+in+Escherichia+coli.">A new logic for DNA engineering using recombination in Escherichia coli.</a> Nat. Genet. 20, 123-128 (1998).</li><li>Copeland, N., Jenkins, N., Court, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Recombineering:+a+powerful+new+tool+for+mouse+functional+genomics.">Recombineering: a powerful new tool for mouse functional genomics.</a> Nat. Rev. Genet. 2, 769-779 (2001).</li><li>Muyrers, J., Zhang, Y., Testa, G., Stewart, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rapid+modification+of+bacterial+artificial+chromosomes+by+ET-recombination.">Rapid modification of bacterial artificial chromosomes by ET-recombination.</a> Nucleic Acids Res. 27, 1555-1557 (1999).</li><li>Yu, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+efficient+recombination+system+for+chromosome+engineering+in+Escherichia+coli.">An efficient recombination system for chromosome engineering in Escherichia coli.</a> Proc. Natl. Acad. Sci. USA. 97, 5978-5983 (2000).</li><li>Sharan, S. K., Thomason, L. C., Kuznetsov, S. G., Court, D. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Recombineering:+a+homologous+recombination-based+method+of+genetic+engineering.">Recombineering: a homologous recombination-based method of genetic engineering.</a> Nature Protoc. 4, 206-223 (2009).</li><li>Wang, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+improved+recombineering+approach+by+adding+RecA+to+&#955;+red+recombination.">An improved recombineering approach by adding RecA to &#955; red recombination.</a> Mol. Biotechnol. 32, 43-53 (2006).</li><li>Datta, S., Costantino, N., Court, D. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+set+of+recombineering+plasmids+for+gram-negative+bacteria.">A set of recombineering plasmids for gram-negative bacteria.</a> Gene. 379, 109-115 (2006).</li><li>Fu, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Full-length+RecE+enhances+linear-linear+homologous+recombination+and+facilitates+direct+cloning+for+bioprospecting.">Full-length RecE enhances linear-linear homologous recombination and facilitates direct cloning for bioprospecting.</a> Nat. Biotechnol. 30, 440-446 (2012).</li><li>Muyrers, J., Zhang, Y., Buchholz, F., Stewart, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=RecE/RecT+and+Redalpha/Redbeta+initiate+double-stranded+break+repair+by+specifically+interacting+with+their+respective+partners.">RecE/RecT and Redalpha/Redbeta initiate double-stranded break repair by specifically interacting with their respective partners.</a> Genes Develop. 14, 1971-1982 (2000).</li><li>Maresca, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Single-stranded+heteroduplex+intermediates+in+lambda+Red+homologous+recombination.">Single-stranded heteroduplex intermediates in lambda Red homologous recombination.</a> BMC Mol. Biol. 11, 54 (2010).</li><li>Mosberg, J. A., Lajoie, M. J., Church, G. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lambda+Red+recombineering+in+Escherichia+coli+occurs+through+a+fully+single-stranded+intermediate.">Lambda Red recombineering in Escherichia coli occurs through a fully single-stranded intermediate.</a> Genetics. 186, 791-799 (2010).</li><li>Liu, P., Jenkins, N. A., Copeland, N. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+highly+efficient+recombineering-based+method+for+generating+conditional+knockout+mutations.">A highly efficient recombineering-based method for generating conditional knockout mutations.</a> Genome Res. 13, 476-484 (2003).</li><li>Chan, W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+recombineering+based+approach+for+high-throughput+conditional+knockout+targeting+vector+construction.">A recombineering based approach for high-throughput conditional knockout targeting vector construction.</a> Nucleic Acids Res. 35, e64 (2007).</li><li>Zhang, Y., Muyrers, J. P. P., Testa, G., Stewart, A. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DNA+cloning+by+homologous+recombination+in+Escherichia+coli.">DNA cloning by homologous recombination in Escherichia coli.</a> Nat. Biotechnol. 18, 1314-1317 (2000).</li><li>Lee, E. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+highly+efficient+Escherichia+coli-based+chromosome+engineering+system+adapted+for+recombinogenic+targeting+and+subcloning+of+BAC+DNA.">A highly efficient Escherichia coli-based chromosome engineering system adapted for recombinogenic targeting and subcloning of BAC DNA.</a> Genomics. 73, 56-65 (2001).</li><li>Skarnes, W. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+conditional+knockout+resource+for+the+genome-wide+study+of+mouse+gene+function.">A conditional knockout resource for the genome-wide study of mouse gene function.</a> Nature. 474, 337-342 (2011).</li><li>Valenzuela, D. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-throughput+engineering+of+the+mouse+genome+coupled+with+high-resolution+expression+analysis.">High-throughput engineering of the mouse genome coupled with high-resolution expression analysis.</a> Nat. Biotechnol. 21, 652-659 (2003).</li><li>Bantscheff, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chemoproteomics+profiling+of+HDAC+inhibitors+reveals+selective+targeting+of+HDAC+complexes.">Chemoproteomics profiling of HDAC inhibitors reveals selective targeting of HDAC complexes.</a> Nat. Biotechnol. 29, 255-265 (2011).</li><li>Mulryan, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reduced+vas+deferens+contraction+and+male+infertility+in+mice+lacking+P2X1+receptors.">Reduced vas deferens contraction and male infertility in mice lacking P2X1 receptors.</a> Nature. 403, 86-89 (2000).</li><li>Subramanian, K., Rutvisuttinunt, W., Scott, W., Myers, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+enzymatic+basis+of+processivity+in+lambda+exonuclease.">The enzymatic basis of processivity in lambda exonuclease.</a> Nucleic Acids Res. 31, 1585-1596 (2003).</li><li>Antoch, M. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Functional+identification+of+the+mouse+circadian+Clock+gene+by+transgenic+BAC+rescue.">Functional identification of the mouse circadian Clock gene by transgenic BAC rescue.</a> Cell. 89, 655-667 (1997).</li><li>Rostovskaya, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transposon-mediated+BAC+transgenesis+in+human+ES+cells.">Transposon-mediated BAC transgenesis in human ES cells.</a> Nucleic Acids Res. 40, e150 (2012).</li><li>Giraldo, P., Montoliu, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Size+matters:+use+of+YACs,+BACs+and+PACs+in+transgenic+animals.">Size matters: use of YACs, BACs and PACs in transgenic animals.</a> Transgenic Res. 10, 83-103 (2001).</li><li>Hill, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=BAC+trimming:+minimizing+clone+overlaps.">BAC trimming: minimizing clone overlaps.</a> Genomics. 64, 111-113 (2000).</li><li>Warming, S., Costantino, N., Court, D. L., Jenkins, N. A., Copeland, N. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Simple+and+highly+efficient+BAC+recombineering+using+galK+selection.">Simple and highly efficient BAC recombineering using galK selection.</a> Nucleic Acids Res. 33, e36 (2005).</li><li>Cong, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multiplex+Genome+Engineering+Using+CRISPR/Cas+Systems.">Multiplex Genome Engineering Using CRISPR/Cas Systems.</a> Science. 339, 819-823 (2013).</li></ol>

T.R.R is the inventor of a British patent application on multiplex recombineering technology.

Construction of ES cell lines and mouse models has historically involved gene targeting using plasmid constructs that contained the modified allele4. However, the construction of these complex gene targeting vectors has proved to be a significant bottleneck in the timely production of such models. The development of recombineering based vector construction strategies has allowed improved vector designs and more efficient vector assembly. Nonetheless, current recombineering protocols still involve multiple steps, require intermediate plasmid purification and use different bacterial strains. Subcloning plus insertion offers a novel approach to vector construction that can be performed in one electroporation event in the resident BAC host strain. The utility of SPI in gene targeting was tested here in a variety of vector construction applications. In all instances examined here, SPI proved to be efficient and the correct recombinant plasmid was produced. In the majority of the cases, the multiple different cassettes were correctly inserted in the targeting vector. Large DNA cassettes and vectors were easily accommodated in the SPI protocol and demonstrated the flexibility of this system.
SPI relies on the use of long homology sequences and phosphorothioate (PTO) protection of the linear DNA cassettes. PTO modification confers protection against exonucleases to the linear DNA20,21 and the long HA increases recombination efficiency to permit multiplexing. However, synthesis of longer oligo sequences increases the chances of accumulating errors especially deletions. Mutations in the oligo can be particularly detrimental if they cover protein coding regions. DNA sequencing across the HA and covering the full-length of the inserted cassette is highly recommended to eliminate clones with any sequence alterations. Use of a high-fidelity DNA polymerase system is also suggested to avoid introduction of any PCR errors. The length and composition of the HA of the subcloning plasmid is more critical relative to that of the insertion cassette (data not shown). For particularly sensitive applications like construction of knockin vectors, where any mutations in exon regions are not tolerated, the HA of the insertion cassette can be shortened (50-120 bp) to avoid problems associated with long oligos. The insertion cassette can also be left unmodified or dual phosphorothioated (where knowledge of the direction of replication is not available). But multiplexing in these cases still requires long protected HA subcloning plasmids. A caveat of this particular strategy is the lowering of multiplexing efficiency that can potentially impact SPI cloning at different loci.
The length of the insertion cassette and the subcloning plasmid is another important parameter in SPI cloning. Larger DNA molecules electroporate less efficiently and the effect is cumulative, given the requirement to introduce all the cassettes in the same cell (data not shown). Multiplexing is most efficient with smaller insertion cassettes. DNA fragments larger than 3 kb also place a limit on Red mediated ssDNA processing, which is most efficient up to 3 kb30. Insertion cassettes exceeding 3 kb are dual resected and recombine less efficiently via a beta independent pathway20. Therefore, screening of sufficient colonies to identify the correct clone becomes important in these cases. A longer duration of recombination post electroporation also increases the chances of recovery of the correct clone in difficult SPI exercises. Up to four small cassettes (&#60; 1.5 kb) can be inserted simultaneously with the SPI process, though the multiplexing efficiency decreases with each additional cassette (data not shown). However, this reflects the outcome of an optimal SPI experiment and it is advisable to consider the limits of multiplexing when using many large cassettes.
The development of genome editing tools like clustered regularly interspaced short palindromic repeats (CRISPR)-cas9 endonuclease system has enabled the creation of novel genome modifications and has led to more efficient genome engineering36. However, these newer technologies have complemented gene targeting vectors rather than supplanted them. It is envisaged that the CRISPR-cas system could replace antibiotic selection and further refine the multiplex recombineering protocol.

The development of gene targeting technologies has enabled the construction of cell lines and mouse models to investigate different biological systems1-3. A key first stage in the modification of a genomic sequence is the design and construction of a gene targeting vector4. Targeting vectors are plasmid constructs that carry the allele of interest containing the desired modifications(s) flanked by a selection marker (e.g.,&#160;neomycin), and long genomic regions required for efficient homologous recombination in mammalian cells5. Precise gene modification is achieved by the introduction of the targeting vector into embryonic stem (ES) cells6 or somatic cells7, whereby homologous recombination between identical stretches of DNA sequence on the targeting vector and the genomic locus results in the transfer of the intended modification to the genome by gene conversion8. Such modified ES cells can be injected into mouse blastocysts to produce offspring (chimaeras) that can then transmit these modified alleles via the germline9. An alternate route to produce transgenic mice involves the microinjection of a gene expression vector into single celled mouse zygotes, which leads to the random integration of the vector in the mouse genome10. Traditional methods of vector construction have relied on conventional &#8216;cut and paste&#8217; cloning using restriction enzymes and DNA ligases to clone the different selection marker and genomic fragments into a vector backbone. However, an inherent limiting factor of traditional cloning is the positioning and choice of restriction sites, especially with longer DNA sequences. This often necessitates multiple subcloning steps and also introduces extraneous DNA sequences into the vector, which often leads to a lower efficiency of gene targeting.
Recombineering (recombinogenic engineering) is a DNA engineering technology that overcomes these limitations by using homologous recombination (HR) mediated by phage recombination proteins in E. coli cells11,12. Since any region of a homologous sequence can serve as a substrate of recombineering, the constraints of availability of restriction sites are removed. Large DNA sequences can be seamlessly modified directly in vivo, thus also preserving their structural integrity13. Recombineering is very efficient with short homologies (50 bp)14 and therefore homology arms (HA) can be conveniently incorporated into synthetic oligo sequences. In a typical recombineering experiment, an oligo or a double stranded DNA (dsDNA) fragment containing HA is electroporated into recombineering competent E. coli cells containing the target located either on the chromosome or on a plasmid15. The recombination potential is conferred by inducible expression of the Red recombination proteins of the phage16,17 or the RecET proteins of the rac prophage18. The Red/RecE exonuclease converts linear dsDNA to a single-stranded DNA (ssDNA) intermediate, which is then bound by its partner, Red/RecT, a single-stranded annealing protein (SSAP)19. The annealing of a long ssDNA or a short oligo to its complementary target sequence occurs on the lagging strand of the replication fork and leads to the incorporation of the sequence at the target site. Lagging strand ssDNA recombination is the basis of the high efficiency of recombineering and can be described by the &#8216;beta&#8217; recombination model20,21.
A typical recombineering workflow to build a gene targeting vector involves either of the two following routes. One route involves subcloning the desired genomic region from a mouse BAC clone into a plasmid followed by the sequential insertion of LoxP recombination sites, a selection marker22 etc., or the alternative route involves targeting the BAC genomic locus with the different targeting vector elements by multiple rounds of recombineering10,23 and then subcloning the modified locus into a plasmid by gap repair cloning24,25. Variations on this theme have been used in different high-throughput recombineering pipelines as part of large mouse production programs26,27. However, these procedures involve complicated and lengthy stages, require the use of specialized vectors and E. coli strains (e.g., Cre expressing cells) and utilize one or more intermediate steps of vector DNA purification and re-transformation (Table 1). Subcloning plus insertion (SPI) is a novel recombineering technique that combines beta recombination and gap repair cloning into a single process (Figure 1). SPI vector assembly is simple, quick and flexible and offers significant improvement on standard recombineering approaches (Table 1). Here, we demonstrate the ease and utility of using SPI for different vector construction applications with a particular emphasis on constructing non-standard and challenging vector designs. Test cases included the construction of a fluorescent reporter knockin vector, a dual tagged protein expression knockin vector, a BAC fluorescent reporter vector and a conditional knockout vector. These examined variously the requirement to localize a cell surface receptor, purify a nuclear protein complex or conditionally ablate the expression of a gene.

<table border="0" cellpadding="0" cellspacing="0" width="1597">
	<tbody>
		<tr height="42">
			<td height="42" style="height:42px;width:315px;">Name of Material/ Equipment</td>
			<td style="width:127px;">Company</td>
			<td style="width:216px;">Catalog Number</td>
			<td style="width:941px;">Comments/Description</td>
		</tr>
		<tr height="210">
			<td height="210" style="height:210px;width:315px;">Antibiotics except Zeocin</td>
			<td style="width:127px;">Sigma: http://www.sigmaaldrich.com</td>
			<td style="width:216px;">Ampicillin, A9518-5G;
			Chloramphenicol , C1919-5G; Blasticidin, 15205-25MG; Gentamicin, G1264-50MG; Hygromycin, H3274-50MG; Kanamycin,: K1876-1G;
			Tetracycline hydrochloride, T7660-5G; Trimethoprim, 92131-1G</td>
			<td></td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:315px;">Zeocin</td>
			<td style="width:127px;">Invivogen:&#160;</td>
			<td style="width:216px;">ant-zn-1</td>
			<td>Zeocin is also available from Life technologies/Fisher</td>
		</tr>
		<tr height="84">
			<td height="84" style="height:84px;width:315px;">C57BL/6 BAC clones</td>
			<td style="width:127px;">CHORI: https://bacpac.chori.org/&#160;</td>
			<td style="width:216px;">RPCI-23 or RPCI-24 BAC libraries</td>
			<td>129/Sv BAC clones can be obtained from Invivogen or Life technologies/Fisher</td>
		</tr>
		<tr height="105">
			<td height="105" style="height:105px;width:315px;">KOD hotstart DNA polymerase system</td>
			<td style="width:127px;">Millipore: https://www.merckmillipore.com</td>
			<td style="width:216px;">71086-3</td>
			<td></td>
		</tr>
		<tr height="105">
			<td height="105" style="height:105px;width:315px;">L-Arabinose</td>
			<td style="width:127px;">Sigma: http://www.sigmaaldrich.com</td>
			<td style="width:216px;">A3256-25G</td>
			<td></td>
		</tr>
		<tr height="189">
			<td height="189" style="height:189px;width:315px;">Long oligos</td>
			<td style="width:127px;">IDT: https://www.idtdna.com; Gene link: https://www.genelink.com</td>
			<td style="width:216px;">IDT Ultramers or Gene Link long oligos</td>
			<td>PTO and Phosphosphate available as custom modifications. PAGE purification strongly recommended for long oligos.</td>
		</tr>
		<tr height="84">
			<td height="84" style="height:84px;width:315px;">MinElute PCR purification kit</td>
			<td style="width:127px;">Qiagen: http://www.qiagen.com&#160;</td>
			<td align="right" style="width:216px;">28004</td>
			<td>Minimum elution PCR purifications kits are preferred.</td>
		</tr>
		<tr height="84">
			<td height="84" style="height:84px;width:315px;">QIAPrep Spin Mini Prep kit</td>
			<td style="width:127px;">Qiagen: http://www.qiagen.com&#160;</td>
			<td align="right" style="width:216px;">27104</td>
			<td>Silica column or similar matrix kits are preferred.</td>
		</tr>
		<tr height="84">
			<td height="84" style="height:84px;width:315px;">Restriction enzymes</td>
			<td style="width:127px;">NEB: https://www.neb.com</td>
			<td style="width:216px;">DpnI: R0176L</td>
			<td>See NEB website for a list of RE.</td>
		</tr>
	</tbody>
</table>
