Work in our laboratory is funded by a VIDI grant from the Netherlands Organisation for Scientific research (to DJS).
We thank Marc Stuart and the Department of Electron Microscopy at our university, for assistance with and providing access to the transmission electron microscope.

Untagged FtsZ proteins were purified as described earlier11,15, dialyzed against 20 mM Tris/ HCl (pH 7.9), 50 mM KCl, 1 mM EGTA, 2.5 mM MgAc and 10% glycerol and stored at -80 &#176;C. Under those conditions the protein may be stored for over 2 years without significant loss of activity. The protein should be stored in 100 &#181;l aliquots to avoid thawing and freezing the sample. After thawing, the sample can be kept at 4 &#176;C for maximum one week. FtsZ is soluble at high concentrations and may be stored at 7-10 mg/ml. It is important to keep the protein concentration high to avoid unwanted effects of storage buffer components in later experiments. Thus, storage concentration should allow for a dilution of FtsZ of at least 10x to bring glycerol concentration below 1% and to minimize the concentration of the other components of the dialysis buffer in the reaction mix. FtsZ polymerization may also be affected by the presence of high sodium9 or imidazole concentrations thus these components must be removed from the polymerization buffer. SepF was purified as described7 and stored in elution buffer at -80 &#176;C. Alternative published procedures for purification of FtsZ from E. coli and B. subtilis as well as references to the procedures for purification of FtsZ from different sources are summarized in Table 1 (see representative results section).
1. Sample Preparation
<ol>
	<li>Prepare polymerization buffers:
	<table border="1">
		<tbody>
			<tr>
				<td>1</td>
				<td>50 mM Hepes/ NaOH, pH 7.5</td>
			</tr>
			<tr>
				<td>2</td>
				<td>25 mM PIPES/ NaOH, pH 6.8</td>
			</tr>
			<tr>
				<td>3</td>
				<td>50 mM MES/ NaOH, pH 6.5</td>
			</tr>
			<tr>
				<td>4</td>
				<td>50 mM Hepes/ NaOH, pH 7.5; 50 mM KCl</td>
			</tr>
			<tr>
				<td>5</td>
				<td>25 mM PIPES/ NaOH, pH 6.8; 50 mM KCl</td>
			</tr>
			<tr>
				<td>6</td>
				<td>50 mM MES/ NaOH, pH 6.5; 50 mM KCl</td>
			</tr>
			<tr>
				<td>7</td>
				<td>50 mM Hepes/ NaOH, pH 7.5; 300 mM KCl</td>
			</tr>
			<tr>
				<td>8</td>
				<td>25 mM PIPES/ NaOH, pH 6.8; 300 mM KCl</td>
			</tr>
			<tr>
				<td>9</td>
				<td>50 mM MES/ NaOH, pH 6.5; 300 mM KCl</td>
			</tr>
		</tbody>
	</table>
	</li>
	<li>Filter sterilize all buffers using a 22 &#181;m membrane filter.</li>
	<li>Prepare 100 mM GTP, GDP and MgCl2 stock solutions in each polymerization buffer from (1).</li>
	<li>Preclear the proteins by spinning at 100,000 x g for 20 min at 4 &#176;C for all of the experiments.</li>
</ol>
2. FtsZ Sedimentation Assay
<ol>
	<li>Prepare the reaction mix by addition of MgCl2 and FtsZ to one of the polymerization buffers (see sample preparation point 1) in tubes compatible with high-speed centrifugation. Total volume should be 49 &#181;l, with MgCl2 at 10 mM and FtsZ at 12 &#181;M at 50 &#181;l final volume.</li>
	<li>Place the tube in an incubator with shaking function, incubate for 2 min at 30 &#176;C at 300 rpm (alternatively the sample may be gently flicked and briefly microfuged followed by prewarming at 30 &#176;C).</li>
	<li>Start polymerization by adding 1 &#181;l of GTP or GDP stock solution in the same buffer as used in the experiment (final concentration of 2 mM). Incubate for 10 or 2 min (for buffers with 50 mM KCl and 300 mM KCl, respectively) at 30 &#176;C at 300 rpm (or in an incubator with shaking function).</li>
	<li>Transfer the tubes to an ultracentrifuge rotor and spin down for 10 min at 350,000 x g (89,700 rpm for TLA 120.1 rotor) at 25 &#176;C.</li>
	<li>After spinning, carefully remove the tubes from the rotor and immediately transfer the supernatant into a clean tube. Prepare samples for SDS-PAGE by adding 20 &#181;l of supernatant to 20 &#181;l of 2x sample buffer. Boil for 10 min at 98 &#176;C.</li>
	<li>Add 50 &#181;l of 2x sample buffer to the pellet fraction containing FtsZ polymers. Place the ultracentrifuge tube in a 2 ml tube. Resuspend the pellet by boiling for 10 min at 98 &#176;C, then add 50 &#181;l of demineralized H2O to make the sample the same 2x dilution as the supernatant sample.</li>
	<li>Turn the ultracentrifuge tube upside down in the 2 ml tube and spin down for 5 minutes in an Eppendorf centrifuge at 18,000 x g. Remove the ultracentrifuge tube from the 2 ml tube.</li>
	<li>Load 10 &#181;l of each supernatant and pellet sample side by side on a 10% SDS-PAGE gel. Run the gel at 150 V.</li>
	<li>Stain the gel with Coomassie Brilliant Blue G-250 and keep for quantification.</li>
</ol>
3. FtsZ Sedimentation Assay at Slow Spin
<ol>
	<li>Prepare polymerization solution as in step&#160;2, add SepF and/or FtsZ (final concentration 12 &#181;M). These experiments can be performed in Beckman disposable 1.5 ml&#160;tubes in combination with a TLA-55 rotor.</li>
	<li>Place the tube in an incubator with shaking function and incubate for 2 min at 30 &#176;C at 300 rpm.</li>
	<li>Start polymerization by the adding 1 &#181;l of GTP or GDP from a stock solution (final concentration 2 mM), incubate for 20 min at 30 &#176;C at 300 rpm.</li>
	<li>Spin down for 15 min at 24,600 x g (20,000 rpm for TLA 55 rotor) at 25 &#176;C.</li>
	<li>Remove the supernatant and transfer into a clean tube, take 20 &#181;l and transfer into 20 &#181;l of 2x sample buffer. Boil for 10 min at 98 &#176;C.</li>
	<li>Add 50 &#181;l of 2x sample buffer to pellet fraction containing polymers and resuspend by boiling for 10 min at 98 &#176;C, add 50 &#181;l of demineralized H2O.</li>
	<li>Load 10 &#181;l of each supernatant and pellet sample side by side on a 10% SDS-PAGE gel. Run the gel at 150 V.</li>
	<li>Stain the gel with Coomassie Brilliant Blue G-250 and keep for quantification.</li>
</ol>
4. Quantification of the FtsZ Sedimentation Assays
<ol>
	<li>Take a picture of the Coomassie stained gel using a gel documentation system (e.g. LAS-4000, Fujifilm).</li>
	<li>Open the gel image in a program suitable for densitometric analysis of gels (e.g. AIDA image analyzer program (Raytest)) and describe analysis in this program&#160;below.</li>
	<li>Click the &#34;Evaluation&#34; button in the toolbar.</li>
	<li>Select the &#34;2D Densitometry&#34; from the list and click ok.</li>
	<li>On the main menu, click &#34;Evaluation&#34; and choose the &#34;Region Determination&#34; entry.</li>
	<li>To create a region on the gel, click on the symbol of Auto-contour tool in the Region Determination toolbox.</li>
	<li>Click at the upper left corner of the protein band on the gel, hold down the mouse button and drag it to the desired lower right end of the band and release the mouse button.</li>
	<li>Mark each FtsZ/SepF band in the same way.</li>
	<li>All the information about the evaluation of the assigned regions can be found in the Region Report. To obtain the Region Report, click the &#34;Show region Report&#34; button in the Region Determination toolbox.</li>
	<li>To export the report, on the main menu, click File and choose &#34;Export &#224; 2D Region Report&#34; entry.</li>
	<li>In the region report, the intensity of every created region should be found. Calculate the percentage of protein (FtsZ, regulatory protein) in the pellet using the intensity values from the report.</li>
</ol>
5. 90&#176; Light Scattering
<ol>
	<li>Turn on a fluorescence spectrometer (e.g. AMINCO-Bowman Series 2), allow the lamp to warm up for several minutes to avoid thermal fluctuations and turn on a circulating water bath to maintain the cuvette chamber temperature at 30 &#176;C.</li>
	<li>Define the operating parameters of the spectrometer: detector high voltage 300 V, emission and excitation wavelength: 350 nm, slit width: 4 nm. Note that many spectrometers automatically adjust the signal at the start of an experiment to a certain percentage (e.g. 60%) of the maximum. This causes a scatter signal to go out of range as soon as GTP is added to polymerize FtsZ. It is wise to first establish the right signal amplification- detector high voltage- for maximal polymerization before starting a series of experiments.</li>
	<li>Program a data-acquisition protocol. Choose time-based acquisition, with a duration of 3,600 sec.</li>
	<li>Carefully clean a fluorescence cuvette with water and ethanol, if necessary- sonicate in water bath at room temperature for 5 min. In this protocol, cuvettes with a 1&#160;cm path length and a 200 &#956;l&#160;volume were used and stored in storage solution (0.5-1% Hellmanex). As an alternative, single use UV-compatible plastic cuvettes (UVette, Eppendorf) can be used.</li>
	<li>Prepare 294 &#181;l of a master mix of the polymerization buffer (see sample preparation point 1) with 10 mM MgCl2 and 12 &#181;M FtsZ as final concentration calculated for 300 &#181;l, and vortex.</li>
	<li>Transfer 196 &#181;l of the polymerization buffer to the cuvette and place it in spectrometer. Incubate for 2 min at 30 &#176;C.</li>
	<li>Start the data acquisition and wait for 90 sec to verify that the signal is stable.</li>
	<li>Add 4 &#181;l of 100 mM GTP or GDP (final concentration: 2 mM) to achieve a final reaction volume of 200 &#181;l, pipette up and down with a larger volume pipette to mix and resume acquisition.</li>
</ol>
6. Transmission Electron Microscopy
<ol>
	<li>Prepare samples as for the FtsZ sedimentation assay (the volume can be reduced to 10 &#956;l&#160;final volume to save material).</li>
	<li>After the incubation time, apply 2 &#181;l of the sample onto a glow-discharged 400 mesh carbon-coated copper grid, incubate for 15 sec.</li>
	<li>Blot the grid dry by gently touching or dragging the grid parallel or perpendicular to a piece of filter paper.</li>
	<li>Stain the grid using 4 &#181;l of a 2% uranyl-acetate solution. Blot the grid dry as described in step&#160;6.3.</li>
	<li>View the grid in a Philips CM120 electron microscope operating at 120 kV at 39,200X magnification.</li>
</ol>
7. GTP Hydrolysis Assay
The setup of the experiment is designed in such a way that GTP hydrolysis of FtsZ is stopped after various reaction times by mixing the reaction with malachite green. In this way, the time of the color development of malachite green is the same for each sample.
<ol>
	<li>Prepare 1.5 ml 2 mM GTP in one of the polymerization buffers (see sample preparation, point 1).
	Prepare a 0-40 &#181;M&#160;phosphate standard dilution&#160;in a polymerization buffer, and prepare malachite green working reagent as described in the POMG-25H (Bio assays) kit. Alternatively, working reagents can be prepared in-house according to protocols described by Lanzetta et al.16</li>
	<li>Prepare master mixes in a total volume 360 &#181;l:
	<table border="1">
		<tbody>
			<tr>
				<td>I</td>
				<td>24 &#181;M FtsZBs, 20 mM MgCl2, polymerization buffer</td>
			</tr>
			<tr>
				<td>II</td>
				<td>12 &#181;M FtsZEc, 20 mM MgCl2, polymerization buffer</td>
			</tr>
			<tr>
				<td>III (control 1)</td>
				<td>24 &#181;M FtsZBs, 2 mM EDTA, polymerization buffer</td>
			</tr>
			<tr>
				<td>IV (control 2)</td>
				<td>12 &#181;M FtsZEc, 2 mM EDTA, polymerization buffer</td>
			</tr>
		</tbody>
	</table>
	</li>
	<li>Pipette 20 &#181;l aliquots of the master mixes, 100 &#181;l &#160;phosphate standards and 180 &#181;l of 2 mM GTP in a qPCR 96-well plate in the following order:
	<table border="1">
		<tbody>
			<tr>
				<td></td>
				<td>A</td>
				<td>B</td>
				<td>C</td>
				<td>D</td>
				<td>E</td>
				<td>F</td>
				<td>G</td>
				<td>H</td>
			</tr>
			<tr>
				<td>1</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>2</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>3</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>4</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>5</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>6</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>7</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>8</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>9</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
			</tr>
			<tr>
				<td>10</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
			</tr>
			<tr>
				<td>11</td>
				<td></td>
				<td></td>
				<td></td>
				<td></td>
				<td></td>
				<td></td>
				<td></td>
				<td></td>
			</tr>
			<tr>
				<td>12</td>
				<td>GTP</td>
				<td>GTP</td>
				<td>GTP</td>
				<td>GTP</td>
				<td>GTP</td>
				<td>GTP</td>
				<td>GTP</td>
				<td>GTP</td>
			</tr>
		</tbody>
	</table>

	PS - phosphate standard</li>
	<li>Place the qPCR plate in a PCR machine with the program set to 40 min cycle at 30 &#176;C.</li>
	<li>Prepare 20 &#181;l aliquots of malachite green working reagent in a 96-well plate. Add 60 &#181;l of the polymerization buffer from the experiment to lanes 1&#39;-8&#39;.&#160;The sample will be diluted 4x compared to the phosphate standard, please consider this fact during final calculations.
	<table border="1" cellpadding="0" cellspacing="0">
		<tbody>
			<tr>
				<td></td>
				<td>A</td>
				<td>B</td>
				<td>C</td>
				<td>D</td>
				<td>E</td>
				<td>F</td>
				<td>G</td>
				<td>H</td>
			</tr>
			<tr>
				<td>1&#39;</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>2&#39;</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>3&#39;</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>4&#39;</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>5&#39;</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>6&#39;</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>7&#39;</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>8&#39;</td>
				<td>III</td>
				<td>III</td>
				<td>I</td>
				<td>I</td>
				<td>IV</td>
				<td>IV</td>
				<td>II</td>
				<td>II</td>
			</tr>
			<tr>
				<td>9&#39;</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
			</tr>
			<tr>
				<td>10&#39;</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
				<td>PS</td>
			</tr>
		</tbody>
	</table>
	</li>
	<li>Add 20 &#181;l of GTP to lane 1, pipette up and down to mix, start timer (this is the starting time point for the 30 min reaction).</li>
	<li>After 10 min, 30 sec add GTP to lane 2, pipette up and down to mix (20 min reaction).</li>
	<li>After 16 min add GTP to lane 3, pipette up and down to mix (15 min reaction).</li>
	<li>After 21 min, 30 sec add GTP to lane 4, pipette up and down to mix (10 min reaction).</li>
	<li>After 25 min add GTP to lane 5, pipette up and down to mix (7 min reaction).</li>
	<li>After 27 min, 30 sec add GTP to lane 6, pipette up and down to mix (5 min reaction).</li>
	<li>After 29 min add GTP to lane 7, pipette up and down to mix (4 min reaction)..</li>
	<li>After 30 min transfer 20 &#181;l from lane 1 into lane 1&#39;, pipette up and down to mix (starting point of malachite green color development for the 30 min reaction).</li>
	<li>After 30 min, 30 sec transfer 20 &#181;l from lane 2 to 2&#39;, pipette up and down to mix (starting point of malachite green color development for the 20 min reaction).</li>
	<li>Repeat the step for lanes 3-7 every 30 sec.</li>
	<li>After 33 min, 30 sec add 20 &#181;l of GTP to lane 8, pipette up and down to mix and transfer 20 &#181;l to lane 8&#39;, pipette up and down to mix (0 min reaction and starting time point for malachite green color development for the reaction).</li>
	<li>After 34 min add 80 &#181;l from lane 9 to 9&#39;, pipette up and down to mix (the starting time point for malachite green color development for the phosphate standard 1).</li>
	<li>After 34 min 30 sec transfer 80 &#181;l from lane 10 to 10&#39;, pipette up and down to mix (the starting time point for malachite green color development for the phosphate standard 2).</li>
	<li>Remove all the air bubbles from the samples and incubate the plate at room temperature for another 25 min 30 sec.</li>
	<li>Place the plate in 96-well plate reader.</li>
	<li>After 60 min measure the plate 10x every 30 sec at wavelength 630 nm (malachite green color development is now 30 min for the first reaction). Every measurement corresponds to every time point from steps 7.6-7.12 and 7.16 and must be calculated separately during a data analysis.</li>
	<li>Calculate the free phosphate in every sample using the phosphate standard calibration curve.</li>
	<li>Plot the data as Phosphate release over time, and calculate the FtsZ GTP hydrolysis activity from the linear range of the curve.</li>
</ol>

<ol>
	<li>Haydon, D. J., Stokes, N. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+inhibitor+of+FtsZ+with+potent+and+selective+anti-staphylococcal+activity.">An inhibitor of FtsZ with potent and selective anti-staphylococcal activity.</a> Science. 321 (5896), 1673-1675 (2008).</li><li>Adams, D. W., Errington, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bacterial+cell+division:+assembly,+maintenance+and+disassembly+of+the+Z+ring.">Bacterial cell division: assembly, maintenance and disassembly of the Z ring.</a> Nat. Rev. Microbiol. 7 (9), 642-653 (2009).</li><li>Erickson, H. P., Anderson, D. E., Osawa, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=FtsZ+in+bacterial+cytokinesis:+cytoskeleton+and+force+generator+all+in+one.">FtsZ in bacterial cytokinesis: cytoskeleton and force generator all in one.</a> Microbiol. Mol. Biol. Rev. 74 (4), 504-528 (2010).</li><li>Li, Z., Trimble, M. J., Brun, Y. V., Jensen, G. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+structure+of+FtsZ+filaments+in+vivo+suggests+a+force-generating+role+in+cell+division.">The structure of FtsZ filaments in vivo suggests a force-generating role in cell division.</a> EMBO J. 26 (22), 4694-4708 (2007).</li><li>Kr&#243;l, E., van Kessel, S. P., van Bezouwen, L. S., Kumar, N., Boekema, E. J., Scheffers, D. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bacillus+subtilis+SepF+binds+to+the+C-terminus+of+FtsZ.">Bacillus subtilis SepF binds to the C-terminus of FtsZ.</a> PLoS One. 7 (8), e43293 (2012).</li><li>Singh, J. K., Makde, R. D., Kumar, V., Panda, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=SepF+increases+the+assembly+and+bundling+of+FtsZ+polymers+and+stabilizes+FtsZ+protofilaments+by+binding+along+its+length.">SepF increases the assembly and bundling of FtsZ polymers and stabilizes FtsZ protofilaments by binding along its length.</a> J. Biol. Chem. 283 (45), 31116-31124 (2008).</li><li>G&#252;ndo&#287;du, M. E., Kawai, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Large+ring+polymers+align+FtsZ+polymers+for+normal+septum+formation.">Large ring polymers align FtsZ polymers for normal septum formation.</a> EMBO J. 30 (3), 617-626 (2011).</li><li>Pacheco-Gomez, R., Roper, D. I., Dafforn, T. R., Rodger, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+pH+dependence+of+polymerization+and+bundling+by+the+essential+bacterial+cytoskeletal+protein+FtsZ.">The pH dependence of polymerization and bundling by the essential bacterial cytoskeletal protein FtsZ.</a> PLoS One. 6 (6), e19369 (2011).</li><li>Mendieta, J., Rico, A. I., Lopez-Vinas, E., Vicente, M., Mingorance, J., Gomez-Puertas, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structural+and+functional+model+for+ionic+(K(+)/Na(+))+and+pH+dependence+of+GTPase+activity+and+polymerization+of+FtsZ,+the+prokaryotic+ortholog+of+tubulin.">Structural and functional model for ionic (K(+)/Na(+)) and pH dependence of GTPase activity and polymerization of FtsZ, the prokaryotic ortholog of tubulin.</a> J. Mol. Biol. 390 (1), 17-25 (2009).</li><li>Tadros, M., Gonzalez, J. M., Rivas, G., Vicente, M., Mingorance, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Activation+of+the+Escherichia+coli+cell+division+protein+FtsZ+by+a+low-affinity+interaction+with+monovalent+cations.">Activation of the Escherichia coli cell division protein FtsZ by a low-affinity interaction with monovalent cations.</a> FEBS Lett. 580 (20), 4941-4946 (2006).</li><li>Scheffers, D. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+effect+of+MinC+on+FtsZ+polymerization+is+pH+dependent+and+can+be+counteracted+by+ZapA.">The effect of MinC on FtsZ polymerization is pH dependent and can be counteracted by ZapA.</a> FEBS Lett. 582 (17), 2601-2608 (2008).</li><li>Mukherjee, A., Lutkenhaus, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analysis+of+FtsZ+assembly+by+light+scattering+and+determination+of+the+role+of+divalent+metal+cations.">Analysis of FtsZ assembly by light scattering and determination of the role of divalent metal cations.</a> J. Bacteriol. 181 (3), 823-832 (1999).</li><li>Chen, Y., Erickson, H. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rapid+in+vitro+assembly+dynamics+and+subunit+turnover+of+FtsZ+demonstrated+by+fluorescence+resonance+energy+transfer.">Rapid in vitro assembly dynamics and subunit turnover of FtsZ demonstrated by fluorescence resonance energy transfer.</a> J. Biol. Chem. 280 (23), 22549-22554 (2005).</li><li>Hou, S., Wieczorek, S. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Characterization+of+Caulobacter+crescentus+FtsZ+protein+using+dynamic+light+scattering.">Characterization of Caulobacter crescentus FtsZ protein using dynamic light scattering.</a> J. Biol. Chem. 287 (28), 23878-23886 (2012).</li><li>Mukherjee, A., Lutkenhaus, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamic+assembly+of+FtsZ+regulated+by+GTP+hydrolysis.">Dynamic assembly of FtsZ regulated by GTP hydrolysis.</a> EMBO J. 17 (2), 462-469 (1998).</li><li>Lanzetta, P. A., Alvarez, L. J., Reinach, P. S., Candia, O. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+improved+assay+for+nanomole+amounts+of+inorganic+phosphate.">An improved assay for nanomole amounts of inorganic phosphate.</a> Anal. Biochem. 100 (1), 95-97 (1979).</li><li>Ray, S., Kumar, A., Panda, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=GTP+regulates+the+interaction+between+MciZ+and+FtsZ:+a+possible+role+of+MciZ+in+bacterial+cell+division.">GTP regulates the interaction between MciZ and FtsZ: a possible role of MciZ in bacterial cell division.</a> Biochemistry. 52 (2), 392-401 (2013).</li><li>Rivas, G., Lopez, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Magnesium-induced+linear+self-association+of+the+FtsZ+bacterial+cell+division+protein+monomer.+The+primary+steps+for+FtsZ+assembly.">Magnesium-induced linear self-association of the FtsZ bacterial cell division protein monomer. The primary steps for FtsZ assembly.</a> J. Biol. Chem. 275 (16), 11740-11749 (2000).</li><li>Oliva, M. A., Cordell, S. C., Lowe, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structural+insights+into+FtsZ+protofilament+formation.">Structural insights into FtsZ protofilament formation.</a> Nat. Struct. Mol. Biol. 11 (12), 1243-1250 (2004).</li><li>Lowe, J., Amos, L. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Crystal+structure+of+the+bacterial+cell-division+protein+FtsZ.">Crystal structure of the bacterial cell-division protein FtsZ.</a> Nature. 391 (6663), 203-206 (1998).</li><li>Cordell, S. C., Robinson, E. J., Lowe, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Crystal+structure+of+the+SOS+cell+division+inhibitor+SulA+and+in+complex+with+FtsZ.">Crystal structure of the SOS cell division inhibitor SulA and in complex with FtsZ.</a> Proc. Natl. Acad. Sci. U.S.A. 100 (13), 7889-7894 (2003).</li><li>Chen, Y., Anderson, D. E., Rajagopalan, M., Erickson, H. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Assembly+dynamics+of+Mycobacterium+tuberculosis+FtsZ.">Assembly dynamics of Mycobacterium tuberculosis FtsZ.</a> J. Biol. Chem. 282 (38), 27736-27743 (2007).</li><li>White, E. L., Ross, L. J., Reynolds, R. C., Seitz, L. E., Moore, G. D., Borhani, D. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Slow+polymerization+of+Mycobacterium+tuberculosis+FtsZ.">Slow polymerization of Mycobacterium tuberculosis FtsZ.</a> J. Bacteriol. 182 (14), 4028-4034 (2000).</li><li>Oliva, M. A., Trambaiolo, D., Lowe, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structural+insights+into+the+conformational+variability+of+FtsZ.">Structural insights into the conformational variability of FtsZ.</a> J. Mol. Biol. 373 (5), 1229-1242 (2007).</li><li>Thanbichler, M., Shapiro, L. M. i. p. Z. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=a+spatial+regulator+coordinating+chromosome+segregation+with+cell+division+in+Caulobacter.">a spatial regulator coordinating chromosome segregation with cell division in Caulobacter.</a> Cell. 126 (1), 147-162 (2006).</li><li>Buske, P. J., Levin, P. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Extreme+C+terminus+of+bacterial+cytoskeletal+protein+FtsZ+plays+fundamental+role+in+assembly+independent+of+modulatory+proteins.">Extreme C terminus of bacterial cytoskeletal protein FtsZ plays fundamental role in assembly independent of modulatory proteins.</a> J. Biol. Chem. 287 (14), 10945-10957 (2012).</li><li>Mukherjee, A., Lutkenhaus, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analysis+of+FtsZ+assembly+by+light+scattering+and+determination+of+the+role+of+divalent+metal+cations.">Analysis of FtsZ assembly by light scattering and determination of the role of divalent metal cations.</a> J. Bacteriol. 181 (3), 823-832 (1999).</li></ol>

No conflicts of interest declared.

We describe a set of methods that allows a quick analysis of FtsZ activity and its interaction with other proteins. Light scattering, sedimentation and GTPase assays as well as electron microscopy have been widely used to study FtsZ polymerization. We have made some improvements to existing protocols, we showed the influence of different conditions on FtsZ assembly, and we propose controls that should be included in FtsZ studies.
We introduce low speed centrifugation to distinguish large structures formed by the association between FtsZ and its interacting proteins from FtsZ polymers. This method shows two advantages over the standard sedimentation assay. First, no background is formed by the FtsZ polymers in the pellet fraction as they are not spun down at 24,600 x g. Second, the amount of FtsZ present in the structure formed with an interacting protein may be calculated from the gel. Two critical steps in this method are the incubation time and the GTP concentration. It is important to centrifuge the large protein structure when it is complete but before it disassembles when all GTP is hydrolyzed. The best control for this study is polymerization of FtsZ with GDP. There is one potential limitation of the assay. FtsZ forms a stable complex with SepF, which can easily be spun down at 24,600 x g. If the sedimentation with another activator or a drug that bundles FtsZ polymers is performed, it may be necessary to adapt the assay. It may be done by changing the incubation time, or increasing the speed of centrifugation.
Proper preparation of the sample is the most important for light scattering experiments. Proteins must be precleared by spinning and all the buffers should be filtered prior to use. If any aggregates are present in the sample, they will disrupt a stable signal obtained from FtsZ polymers. For the analysis of the FtsZ structures by electron microscopy, preparation of a grid is the main step. The time of sample incubation on the grid will have the effect of producing more or less compacted polymers. For bundles of FtsZBs, the time of incubation must be shorter than for FtsZEc and FtsZBs at high KCl concentration. We used a concentration of 12 &#181;M for every sample to be able to compare the results. However, for FtsZBs at 50 mM KCl a lower FtsZ concentration should be used, as 12 &#181;M resulted in a full saturation of the grid. This makes the polymers highly compacted and difficult to detect. Less compacted polymers are better to detect on EM.
The GTPase assay is the only experiment used to study the activity rather than the structures of FtsZ. Mg2+ is necessary for GTP turnover in FtsZ polymers. Thus, in the absence of Mg2+, FtsZ does not hydrolyze GTP. Therefore, a sample with no Mg2+ is the right control in this assay but cations of Mg are present in the FtsZ storage buffer. They may be removed by addition of 1 mM EDTA to the control sample. The critical step in this assay is the incubation time. It is important to stop FtsZ activity after a given time. This is achieved by transferring the FtsZ sample to a malachite green solution in a 96-well plate. However, development of the malachite green color is a continuous process. Thus the measurements must be taken at the same time for every sample. Using a well-planned GTP addition protocol with measurements taken each 30 sec apart in an established order, it is possible to obtain the same incubation and sample handling time for every time point. Another critical step is choosing the concentration of the protein for the experiment. In the experiment we used two different concentrations for FtsZEc and FtsZBs. GTP hydrolysis is much quicker for FtsZEc compared to FtsZBs. The GTPase activity of FtsZEc under chosen conditions and at 12 &#181;M is linear only for maximum&#160;5 min and after that time the hydrolysis rate plateaus. Thus, it is difficult to interpret data from the experiment when performed under these conditions. In this case FtsZEc must be used at lower concentration than FtsZBs to be able to compare activities of both proteins. The GTPase activity of FtsZs from different sources may vary. Thus, the right concentration must be chosen. The concentration for FtsZ polymerization should be well above the critical concentration (in general from 2.5-10 &#181;M). The dynamics of FtsZ assembly and disassembly is also important. Some proteins show a significant lag in polymerization after addition of GTP, as shown for FtsZBs at 50 mM KCl. It is useful to perform the light scattering assay before the GTPase assay to approximate the time of assembly and disassembly of FtsZ polymers. After that, the time of incubation and concentration of protein may be chosen. Since the conditions chosen for FtsZ polymerization are crucial, it is important to use the right pH and KCl concentration in each method. In this work we studied 9 different buffers with pH ranging from 6.5-7.5 and KCl concentrations from 0 M to 300 mM. We noticed that the best condition to analyze FtsZs from B. subtilis and E.coli and their biological activity is at pH that is close to physiological level (7.5) together with a high KCl concentration. At a high KCl concentration, FtsZ has a higher GTPase activity and produces polymers that are better detectable by electron microscopy. We also confirmed that the physiological pH and a high KCl concentration are better for the study of the interaction between FtsZ and regulatory proteins than any other buffers mostly used to study FtsZ assembly. FtsZBs shows a similar activity to FtsZEc when studied at high KCl concentration. In addition, at low salt concentration the influence of pH is more visible than in the buffers with high salt concentration. FtsZ sometimes precipitates when using buffers without KCl, as a result, buffers without salt should be avoided. Sedimentation of FtsZ polymers is low when using buffers with high KCl concentrations. This may be an advantage when studying interactions between FtsZ and proteins that assemble FtsZ filaments such as SepF and ZapA as these higher order structures are easy to detect with centrifugation. In all our experiments we used MgCl2 at a 10 mM concentration. It was shown that a relatively high Mg2+ concentration stabilizes FtsZ polymers and reduces the GTPase activity of FtsZ. In Table 2 results from various studies are summarized describing FtsZ polymerization and GTPase activity at different Mg2+ concentrations using otherwise identical buffer conditions 27. The measured concentration of free cytoplasmic Mg2+ is 0.9 mM3. It should be noticed that GTP will chelate an equivalent amount of Mg2+. Thus, the optimal Mg2+ concentration for GTPase experiments is around 2-2.5 mM, which is close to physiological level3. However, in our experiments we used MgCl2 at a 10 mM concentration to obtain an easily detectable light scattering signal and to stabilize FtsZ polymers during the sedimentation assay.
Although we applied our protocols to FtsZ from the model organisms E. coli and B. subtilis, they can be adapted to FtsZ from any other organism. It has to be noted that the physiological pH, and concentrations of monovalent, and divalent cations differ among organisms. Thus, the optimal conditions for FtsZ polymerization may vary. Differences in doubling time and growth conditions of different bacteria may result in different assembly kinetics of FtsZ and optimal conditions of the experiments. However, our protocol provides a good starting point for the experiments with FtsZs from other organisms. The protocols should be useful for the study of FtsZ with regulatory proteins or the study of effects of small compounds and drugs on FtsZ.
<table border="1">
	<tbody>
		<tr>
			<td>Source</td>
			<td>Polymerization [% of FtsZ sedimented]</td>
			<td>GTPase [Pi/FtsZ/min]</td>
			<td>Mg2+ concentration [mM]</td>
			<td>FtsZ concentration [&#181;M]</td>
			<td>References</td>
		</tr>
		<tr>
			<td>FtsZEc</td>
			<td>~ 28%</td>
			<td>~ 2.1</td>
			<td>10</td>
			<td>12</td>
			<td>This work</td>
		</tr>
		<tr>
			<td></td>
			<td>~ 50%</td>
			<td>~ 2.4</td>
			<td>10</td>
			<td>12.5</td>
			<td>27</td>
		</tr>
		<tr>
			<td></td>
			<td>~ 43%</td>
			<td>~ 3.5</td>
			<td>5</td>
			<td>12.5</td>
			<td>27</td>
		</tr>
		<tr>
			<td></td>
			<td>~ 27%</td>
			<td>~ 4.6</td>
			<td>2.5</td>
			<td>12.5</td>
			<td>27</td>
		</tr>
		<tr>
			<td></td>
			<td>ND</td>
			<td>~ 5.4</td>
			<td>2.5</td>
			<td>5</td>
			<td>26</td>
		</tr>
		<tr>
			<td>FtsZBs</td>
			<td>~ 30%</td>
			<td>~ 0.8</td>
			<td></td>
			<td>12</td>
			<td>This work</td>
		</tr>
		<tr>
			<td></td>
			<td>~ 52% (with DEAE dextran)</td>
			<td>~ 0.5</td>
			<td>10</td>
			<td>10</td>
			<td>11</td>
		</tr>
		<tr>
			<td></td>
			<td>ND</td>
			<td>~ 2.25</td>
			<td>2.5</td>
			<td>5</td>
			<td>26</td>
		</tr>
	</tbody>
</table>
Table 2. Effect on Mg2+ on FtsZ polymerization and GTPase. Results from this work compared to published data. All experiments were carried out in 50 mM MES/ NaOH, pH=6.5, 50 mM KCl.

The essential bacterial protein FtsZ is the best characterized protein of the bacterial cell division machinery. FtsZ is the prokaryotic homolog of tubulin and polymerizes in vitro in a GTP dependent manner. FtsZ is a very attractive target for new antibiotics due to its conserved nature and uniqueness to bacteria1,2. At the beginning of cell division, FtsZ forms a cytokinetic ring at midcell, which serves as a scaffold for the assembly of other cell division proteins. Formation of the Z-ring is crucial for correct localization of the division plane. The assembly dynamics of FtsZ are regulated by several accessory proteins, such as (depending on the bacterial species) MinC, SepF, ZapA, UgtP, and EzrA2. FtsZ polymerization has been intensively studied in vitro and many different structures including straight protofilaments, curved protofilaments, sheets of filaments, bundles of filaments and tubes of filaments have been described depending on the assembly buffer, nucleotide, and additional proteins included in the assay3. The architecture of FtsZ protofilaments in vivo is not yet fully understood, although electron cryotomography experiments in Caulobacter crescentus suggest that the Z-ring is assembled from relatively short, noncontinuous single protofilaments without extensive bundling4.
In vitro, the polymerization properties of FtsZ and the interaction of FtsZ with regulatory proteins are sensitive to the composition of the reaction buffer. For example, we recently described the interaction site for SepF on the FtsZ C-terminus and showed that a FtsZBs&#8710;16 C-terminal truncate no longer binds to SepF5. In a previous study on the SepF-FtsZBs interaction, a similar FtsZBs&#8710;16 truncate still cosedimented with SepF, which suggested that SepF binds to a secondary site on FtsZ6. The difference between these studies was the composition of reaction buffers- at pH 7.5 there was no cosedimentation of SepF with the FtsZ truncate, whereas at pH 6.5 there was cosedimentation. G&#252;ndo&#287;du et al. noted that SepF is not functional and precipitates at pH 6.57, showing that the observed cosedimentation at pH 6.5 is likely to be caused by precipitation of SepF rather than interaction with the FtsZBs&#8710;16 C-terminal truncate. The influence of pH and KCl concentration on the polymerization of FtsZ has been previously examined. Polymers of E. coli FtsZ (FtsZEc) at pH 6.5 are longer and more abundant than those formed at neutral pH8,9. Tadros et al. have studied the polymerization of FtsZEc in the presence of monovalent cations noting that K+ binding is linked to FtsZEc polymerization and is crucial for FtsZ activity10. The pH is more critical when the interaction of FtsZ with other proteins is studied, as shown by the previous example of SepF, and the pH dependency of the inhibitory effect of MinC on FtsZ11. As both pH and salt concentration may influence the interaction of FtsZ with other proteins, it is important to choose the right conditions and controls for the FtsZ polymerization studies.
Here we describe protocols to study FtsZ polymerization and GTPase activity by light scattering, electron microscopy, sedimentation,&#160;and GTPase assays. Right angle light scattering is a standard method to study FtsZ polymerization in real time12. We introduced a few improvements to the sedimentation and GTPase assay. We present in detail how to prepare samples for light scattering and electron microscopy. Several buffers used in the literature to study FtsZ polymerization were tested and we describe the best conditions for each experiment. We also show which controls should be introduced to obtain the best data.
These methods allow a quick study of FtsZ polymerization, activity and interaction with other proteins using simple methods and equipment which is available in most laboratories. More sophisticated methods to study FtsZ polymerization exist but often require access to more specialized equipment, and/or modification of FtsZ with fluorescent labels8,13,14. The simple methods described in this paper are illustrated using FtsZ from B. subtilis and E. coli, the most common Gram+ and Gram- model organisms. The protocols can be adapted to any other FtsZ protein. Based on preliminary assays with these novel FtsZs, slight changes regarding time, buffer or temperature of incubation may be necessary for an optimal result. The experiments described here should aid in finding these optimal conditions.

<table border="0" cellpadding="0" cellspacing="0" width="1048">
	<colgroup>
		<col span="2" />
		<col />
		<col />
	</colgroup>
	<tbody>
		<tr height="21">
			<td height="21" style="height:21px;width:381px;">GTP</td>
			<td style="width:381px;">Roche</td>
			<td align="right" style="width:119px;">10106399001</td>
			<td style="width:167px;">Part 1, 2, 3, 4, 5, 6, 7</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Thickwall Polycarbonate Tubes</td>
			<td style="width:381px;">Beckman Coulter</td>
			<td align="right">343776</td>
			<td>Part 2</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:381px;">Optima MAX-XP Ultracentrifuge</td>
			<td style="width:381px;">Beckman Coulter</td>
			<td align="right">393315</td>
			<td>Part 2, 3</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Polyallomer Tube with Snap-on Cap</td>
			<td style="width:381px;">Beckman Coulter</td>
			<td align="right">357448</td>
			<td>Part 3</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:381px;">AIDA Bio-package, 1D, 2D, FL</td>
			<td style="width:381px;">Raytest Isotopenmessger&#228;te GmbH</td>
			<td align="right" style="width:119px;">15000001</td>
			<td>Part 4</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:381px;">Luminescence Image Analyzer LAS-4000</td>
			<td style="width:381px;">Fujifilm</td>
			<td style="width:119px;"></td>
			<td>Part 4</td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:381px;">Thermo Spectronic AMINCO-Bowman Luminescence Spectrometer</td>
			<td style="width:381px;">Spectronic Instruments</td>
			<td style="width:119px;"></td>
			<td>Part 5</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:381px;">Fluorescence Cell</td>
			<td>Hellma Analytics</td>
			<td>105-250-15-40</td>
			<td>Part 5</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Square 400 Mesh, Copper, 100/vial</td>
			<td style="width:381px;">Electron Microscopy Sciences</td>
			<td style="width:119px;">G400-Cu</td>
			<td>Part 6</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">CM120 Electron Microscope Operating at 120 kV</td>
			<td style="width:381px;">Philips</td>
			<td style="width:119px;"></td>
			<td>Part 6</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">96 ml x 0.2 ml Plate</td>
			<td style="width:381px;">BIOplastics</td>
			<td style="width:119px;">B70501</td>
			<td>Part 7</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:381px;">Malachite Green Phosphate Assay Kit</td>
			<td style="width:381px;">BioAssay System</td>
			<td style="width:119px;">POMG-25H</td>
			<td>Part 7</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">PowerWave HT Microplate Spectrophotometer</td>
			<td style="width:381px;">BioTek</td>
			<td style="width:119px;"></td>
			<td>Part 7</td>
		</tr>
	</tbody>
</table>

ftsz polymerization assays: simple protocols and considerations

During bacterial cell division, the essential protein FtsZ assembles in the middle of the cell to form the so-called Z-ring. FtsZ polymerizes into long filaments in the presence of GTP in vitro, and polymerization is regulated by several accessory proteins. FtsZ polymerization has been extensively studied in vitro using basic methods including light scattering, sedimentation, GTP hydrolysis assays and electron microscopy. Buffer conditions influence both the polymerization properties of FtsZ, and the ability of FtsZ to interact with regulatory proteins. Here, we describe protocols for FtsZ polymerization studies and validate conditions and controls using Escherichia coli and Bacillus subtilis FtsZ as model proteins. A low speed sedimentation assay is introduced that allows the study of the interaction of FtsZ with proteins that bundle or tubulate FtsZ polymers. An improved GTPase assay protocol is described that allows testing of GTP hydrolysis over time using various conditions in a 96-well plate setup, with standardized incubation times that abolish variation in color development in the phosphate detection reaction. The preparation of samples for light scattering studies and electron microscopy is described. Several buffers are used to establish suitable buffer pH and salt concentration for FtsZ polymerization studies. A high concentration of KCl is the best for most of the experiments. Our methods provide a starting point for the in vitro characterization of FtsZ, not only from E. coli and B. subtilis but from any other bacterium. As such, the methods can be used for studies of the interaction of FtsZ with regulatory proteins or the testing of antibacterial drugs which may affect FtsZ polymerization.

Purification of FtsZ from different bacterial sources has been described in the literature and is summarized in Table 1.
<table border="1">
	<tbody>
		<tr>
			<td>Source</td>
			<td>Method</td>
			<td>Modification</td>
			<td>Yield obtained [mg/L of culture]&#62;</td>
			<td>References</td>
		</tr>
		<tr>
			<td>B. subtilis</td>
			<td>1) Ammonium sulfate precipitation/ion exchange chromatography</td>
			<td>no</td>
			<td>40</td>
			<td>This work, 11,15</td>
		</tr>
		<tr>
			<td>2) Affinity chromatography</td>
			<td>His-tag</td>
			<td>ND</td>
			<td>17</td>
			<td></td>
		</tr>
		<tr>
			<td>E. coli</td>
			<td>1) Ammonium sulfate precipitation/ion exchange chromatography</td>
			<td>no</td>
			<td>35</td>
			<td>This work, 11,15</td>
		</tr>
		<tr>
			<td>2) Calcium precipitation, ion exchange chromatography</td>
			<td>no</td>
			<td>40</td>
			<td>18</td>
			<td></td>
		</tr>
		<tr>
			<td>Methanococcus jannaschii</td>
			<td>1) Affinity chromatography under denaturing conditions/refolding/ammonium sulfate precipitation/gel filtration</td>
			<td>His-tag</td>
			<td>1.3</td>
			<td>19</td>
		</tr>
		<tr>
			<td>2) Affinity chromatography/ gel filtration</td>
			<td>His-tag</td>
			<td>ND</td>
			<td>20</td>
			<td></td>
		</tr>
		<tr>
			<td>Thermotoga maritima</td>
			<td>Ion exchange chromatography/gel filtration</td>
			<td>no</td>
			<td>6.7</td>
			<td>19</td>
		</tr>
		<tr>
			<td>Pseudomonas aeruginosa</td>
			<td>Affinity chromatography/gel filtration</td>
			<td>Strep-tag, His-tag</td>
			<td>ND</td>
			<td>21</td>
		</tr>
		<tr>
			<td>Mycobacterium tuberculosis</td>
			<td>1) Affinity/ion exchange chromatography</td>
			<td>no</td>
			<td>ND</td>
			<td>22</td>
		</tr>
		<tr>
			<td>2) Affinity chromatography/ gel filtration</td>
			<td>no</td>
			<td>30</td>
			<td>23</td>
			<td></td>
		</tr>
		<tr>
			<td>Aquifex aeolicus</td>
			<td>Affinity chromatography/gel filtration</td>
			<td>His-tag, C-terminal truncation (331-367)</td>
			<td>ND</td>
			<td>24</td>
		</tr>
		<tr>
			<td>Caulobacter crescentus</td>
			<td>Ion exchange chromatography/ammonium sulfate precipitation/gel filtration</td>
			<td>no</td>
			<td>ND</td>
			<td>25</td>
		</tr>
	</tbody>
</table>
Table 1. FtsZ purification protocols described. ND: not determined.
Sedimentation of FtsZ polymers
Initially, we used two different velocities to spin down FtsZ polymers. We found that only at a velocity of 350,000 x g single polymers of FtsZEc are spun down (Figure&#160;1) whereas at 190,000 x g only bundles of FtsZBs are present in the pellet fraction (data not shown). Therefore 350,000 x g was used in our further experiments. The percentage of polymerized FtsZEc and FtsZBs is similar at 50 mM KCl even though the light scattering experiments revealed a much higher scattering signal for FtsZBs. This is due to bundles formed by FtsZBs which scatter more light than single polymers of FtsZEc. It was not possible to obtain high amount of FtsZ polymers in the pellet fraction in the experiment with 300 mM KCl for both FtsZEc and FtsZBs (Figure&#160;1). We attribute this to a combination of quick disassembly of the FtsZ structures and decreased bundling of the filaments.
Sedimentation of FtsZ-SepF tubules
To analyze the interaction of FtsZ with certain activators sedimentation assays can be performed at lower centrifugation speeds. At this velocity only large structures of FtsZ may be pelleted, e.g.&#160;the large tubules formed by SepF rings and FtsZBs filaments5, or the bundles formed by FtsZ and ZapA. We used lower centrifugation (24,600 x g) to demonstrate the feasibility of this approach for the tubules formed by FtsZ and SepF. FtsZ was recovered in the pellet above background levels only when both SepF and GTP were present in the sample (Figure&#160;2), and the presence of SepF does not influence FtsZ GTPase activity7 showing that FtsZ is fully active in the presence of SepF. Specific sedimentation of SepF and FtsZ is roughly 45% of total SepF and 15% of total FtsZ (compared to material sedimenting when GDP is added). This shows that the SepF-FtsZ tubules contain more SepF than FtsZ. This may be because many SepF rings organize the FtsZ-SepF tubules5,7. The exact stoichiometry of SepF-FtsZ in these tubules is not known but our results suggest that there is more SepF present than FtsZ.
FtsZEc and FtsZBs polymerization and bundling properties
To characterize the polymerization efficiency of FtsZBs and FtsZEc in different buffers we analyzed both proteins by 90&#176; angle light scattering. At 50 mM KCl, FtsZBs gives a 20-40-fold higher light scattering signal than FtsZEc depending on buffer pH (Figures&#160;3A and&#160;B) confirming results of Buske et al.26&#160;Increasing the KCl concentration in the buffer did not significantly influence the light scattering signal of FtsZEc (Figure&#160;3D) but the signal of FtsZBs decreased ~80-fold at pH 7.5, ~30-fold at pH 6.8 and ~45-fold at pH 6.5 in 300 mM KCl (Figure&#160;3C) compared to buffers with 50 mM KCl (Figure&#160;3A). Disassembly of FtsZ polymers is faster at higher KCl concentration for both proteins (Figures&#160;3C and&#160;D). Studies of Pacheco-G&#243;mez et al. show that E. coli FtsZ polymerization and bundling is pH dependent. These authors found that in a buffer with 50 mM KCl the light scattering signal of FtsZ polymerization was higher, and disassembly of FtsZ took longer at pH 6.0 compared to pH 7.0 8. These results are not in agreement with our data from polymerization of FtsZEc at 50 mM KCl (Figure&#160;3B), but it has to be noted that we have used three different buffers (HEPES, MES and PIPES) where Pacheco-G&#243;mez et al. only used MES. Thus, not only the pH, but also buffer composition (ionic strength) affects the kinetics of FtsZ polymers at 50 mM KCl. However, at 300 mM KCl neither buffer composition nor pH influenced FtsZEc assembly in a detectable manner.
A light scattering experiment of FtsZBs in buffers without KCl was not possible due to precipitation of the protein under these conditions. When the concentration of FtsZBs was lowered to 3 &#181;M, precipitation did not occur. However, 3 &#181;M is not the physiological concentration of FtsZ in the cell. In plastic cuvettes, FtsZBs did not precipitate at 12 &#181;M at pH 7.5, but at pH 6.8 and 6.5 FtsZ still precipitated in the absence of KCl.
Morphologies of FtsZ structures from E. coli and B. subtilis
The structures formed by FtsZ were inspected by TEM. FtsZBs assembled into closely compacted polymers that covered the whole grid in all buffers at low salt (Figures&#160;4A-C). FtsZEc formed long filaments, cables and bundles in all buffers at low salt (Figures&#160;4D-F). However, the observable amount of polymers formed by FtsZEc was lower than the amount formed by FtsZBs. In high salt buffers FtsZBs formed longer single-stranded protofilaments which did not associate into bundles (Figures&#160;4G-I). While FtsZBs protofilaments changed structure at higher salt concentration, FtsZEc formed structures indistinguishable from those of low salt buffer (Figures&#160;4J-L). There was no observable pH influence on polymerization of FtsZEc but FtsZBs forms more bundles at pH 6.5 which are visible as closely compacted polymers and sheets (Figure&#160;4B). These results are in accord with our light scattering experiments and previously published TEM work8,11,26.
The GTPase activity of FtsZ at high and low KCl concentrations
The GTP hydrolysis activity of FtsZ was measured under different conditions using a colorimetric assay for free phosphate. As reported previously15 the GTPase activity of FtsZ increased with increasing KCl concentration: depending on the buffer used FtsZBs. showed a 3-7 fold increase, and FtsZEc showed a 1.5-2.5 fold increase in GTPase activity at 300 mM KCl compared to 50 mM KCl. The reduced GTPase activity at 50 mM KCl is due to bundling of FtsZBs filaments. At 50 mM KCl FtsZEc had a 3-6 fold higher GTPase activity than FtsZBs due to quicker disassembly of the FtsZEc polymers. The difference in GTP hydrolysis activity between FtsZBs and FtsZEc was reduced at 300 mM KCl, possibly because of reduced bundling of FtsZBs filaments (Figure&#160;5).
<img alt="Figure 1" fo:content-width="5in" src="/files/ftp_upload/50844/50844fig1.jpg" width="600px" />
Figure 1. Quantification of FtsZ polymerization by sedimentation.&#160;(A) 12 &#181;M FtsZ was polymerized in the presence of 2 mM GTP or GDP at pH 7.5 (black bars), 6.8 (grey bars) or 6.5 (white bars). The amount of protein pelleted was determined by densitometric analysis of Coomassie stained gels. GDP served as a control for a specific sedimentation and the percentage of FtsZ sedimented with GDP was subtracted from the percentage of FtsZ sedimented with GTP to obtain the values plotted in the graph. On the left: FtsZ sedimented at 50 mM KCl, on the right: FtsZ sedimented at 300 mM KCl. (B) Representative results from Coomassie stained gels. Polymerization of FtsZBs (upper gel) and FtsZEc (lower gel) at 50 mM KCl. (S) supernatant, (P) pellet fractions from the experiment. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/50844/50844fig1highres.jpg" target="_blank">Click here to view larger image</a>.
<img alt="Figure 2" fo:content-width="5in" src="/files/ftp_upload/50844/50844fig2.jpg" width="600px" />
Figure 2. Sedimentation of SepF/FtsZ tubules at low speed. (A) 12 &#181;M FtsZBs was polymerized with 2 mM GDP (white bars) or GTP (black bars). The amount of protein pelleted was determined by densitometric analysis of Coomassie stained gels. The + and - signs under the x-axis indicate the presence or absence of FtsZ and SepF in the reaction. (B) Representative results from a Coomassie stained gel. Polymerization of FtsZBs in the presence and absence of SepF. As a control SepF without FtsZ was used. Polymerization was carried out with GTP and GDP. (S) supernatant, (P) pellet fractions from the experiment. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/50844/50844fig2highres.jpg" target="_blank">Click here to view larger image</a>.
<img alt="Figure 3" fo:content-width="5in" src="/files/ftp_upload/50844/50844fig3.jpg" width="600px" />
Figure 3. Light scattering of 12 &#956;M FtsZEc and 12 &#956;M FtsZBs. FtsZs were assembled in the presence of 2 mM GTP and polymerization was monitored by 90&#176; angle light scattering. Polymerization of FtsZBs (A) and FtsZEc (B) at 50 mM KCl at pH 7.5, pH 6.8, pH 6.5. Polymerization of FtsZBs (C) and FtsZEc (D) at 300 mM KCl at pH 7.5, pH 6.8 and pH 6.5. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/50844/50844fig3highres.jpg" target="_blank">Click here to view larger image</a>.
<img alt="Figure 4" fo:content-width="5in" src="/files/ftp_upload/50844/50844fig4.jpg" width="600px" />
Figure 4. Structures of FtsZBs and FtsZEc polymers visualized by electron microscopy. (A-L) Images of 12 &#181;M FtsZBs (A-C and G-I) and FtsZEc (D-F) and (J-L) polymerized with 2 mM GTP. (A-C) FtsZBs in buffer with 50 mM KCl and pH 7.5, 6.8, and 6.5 respectively. (D-F) FtsZEc in buffer with 50 mM KCl and pH 7.5, 6.8, and 6.5 respectively. (G-I) FtsZBs in buffer with 300 mM KCl and pH 7.5, 6.8, and 6.5 respectively. (J-L) FtsZEc in buffer with 300 mM KCl and pH 7.5, 6.8, and 6.5 respectively. Scale bar: 100 nm. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/50844/50844fig4highres.jpg" target="_blank">Click here to view larger image</a>.
<img alt="Figure 5" fo:content-width="5in" src="/files/ftp_upload/50844/50844fig5.jpg" width="600px" />
Figure 5. GTP hydrolysis during FtsZ polymerization in 6 different buffers.&#160;In all experiments 2 mM GTP was used. As a control sample with no MgCl2 was used. Activity of FtsZ without MgCl2 was subtracted from the activity of FtsZ in the presence of MgCl2. On the left: GTPase activity of FtsZ at 50 mM KCl, on the right: GTPase activity of FtsZ at 300 mM KCl. <a href="https://jove.unicartagenaproxy.elogim.com/files/ftp_upload/50844/50844fig5highres.jpg" target="_blank">Click here to view larger image</a>.

Watch this Scientific Journal Video about FtsZ Polymerization Assays: Simple Protocols and Considerations at JoVE.com

FtsZ Polymerization Assays: Simple Protocols and Considerations

Polymerization of FtsZ is essential for bacterial cell division. In this report, we detail simple protocols to monitor FtsZ polymerization activity and discuss the influence of buffer composition. The protocols can be used to study the interaction of FtsZ with regulatory proteins or antibacterial drugs that affect FtsZ polymerization.

During bacterial cell division, the essential protein FtsZ assembles in the middle of the cell to form the so-called Z-ring. FtsZ polymerizes into long ...

ftsz-polymerization-assays-simple-protocols-and-considerations

Universidad de Cartagena UDEC

Research

JoVE Journal

Biology

15.2K Views.  University of Groningen. Polymerization of FtsZ is essential for bacterial cell division. In this report, we detail simple protocols to monitor FtsZ polymerization activity and discuss the influence of buffer composition. The protocols can be used to study the interaction of FtsZ with regulatory proteins or antibacterial drugs that affect FtsZ polymerization.

Video: FtsZ Polymerization Assays: Simple Protocols and Considerations

Protocols for Oral Infection of Lepidopteran Larvae with Baculovirus

Baculoviruses are widely used both as protein expression vectors and as insect pest control agents. This video shows how lepidopteran larvae can be infected with polyhedra by droplet feeding and diet plug-based bioassays. This accompanying Springer Protocols section provides an overview of the baculovirus lifecycle and use of baculoviruses as insecticidal agents, including discussion of the pros and cons for use of baculoviruses as insecticides, and progress made in genetic enhancement of baculoviruses for improved insecticidal efficacy.

In this video, we demonstrate oral infection techniques of lepidopteran larvae with baculovirus in order to determine insecticidal efficiency.

Baculoviruses are widely used both as protein expression vectors and as insect pest control agents. This video shows how lepidopteran larvae can be ...

Protocols for Microapplicator-assisted Infection of Lepidopteran Larvae with Baculovirus

Baculoviruses are widely used both as protein expression vectors and as insect pest control agents. . This video shows how lepidopteran larvae can be infected with microapplicator techniques in the gut with baculovirus polyhedra and in the hemolymph with budded virus. This accompanying Springer Protocols section provides an overview of the baculovirus lifecycle and use of baculoviruses as insecticidal agents.  Formulation and application of baculoviruses for pest control purposes are described elsewhere.

In this video, we demonstrate two microapplicator techniques used to infect of lepidopteran larvae with baculovirus in order to determine insecticidal efficiency.

Baculoviruses are widely used both as protein expression vectors and as insect pest control agents. . This video shows how lepidopteran larvae can be ...

Mutagenesis and Functional Selection Protocols for Directed Evolution of Proteins in E. coli

The efficient generation of genetic diversity represents an invaluable molecular tool that can be used to label DNA synthesis, to create unique molecular signatures, or to evolve proteins in the laboratory. Here, we present a protocol that allows the generation of large (>1011) mutant libraries for a given target sequence. This method is based on replication of a ColE1 plasmid encoding the desired sequence by a low-fidelity variant of DNA polymerase I (LF-Pol I). The target plasmid is transformed into a mutator strain of E. coli and plated on solid media, yielding between 0.2 and 1 mutations/kb, depending on the location of the target gene. Higher mutation frequencies are achieved by iterating this process of mutagenesis. Compared to alternative methods of mutagenesis, our protocol stands out for its simplicity, as no cloning or PCR are involved. Thus, our method is ideal for mutational labeling of plasmids or other Pol I templates or to explore large sections of sequence space for the evolution of activities not present in the original target. The tight spatial control that PCR or randomized oligonucleotide-based methods offer can also be achieved through subsequent cloning of specific sections of the library. Here we provide protocols showing how to create a random mutant library and how to establish drug-based selections in E. coli to identify mutants exhibiting new biochemical activities.

Mutagenesis and Functional Selection Protocols for Directed Evolution of Proteins in E. coli

Here we demonstrate a simple protocol to create a random mutant library for a given target sequence. We show how this method, which is performed in vivo in Escherichia coli, can be coupled with functional selections to evolve new enzymatic activities.

The efficient generation of genetic diversity represents an invaluable molecular tool that can be used to label DNA synthesis, to create unique molecular ...

Simple and Efficient Technique for the Preparation of Testicular Cell Suspensions

Mammalian testes are very complex organs that contain over 30 different cell types, including somatic testicular cells and different stages of germline cells. This heterogeneity is an important drawback concerning the study of the bases of mammalian spermatogenesis, as pure or enriched cell populations in certain stages of sperm development are needed for most molecular analyses1.
 Various strategies such as Staput2,3, centrifugal elutriation1, and flow cytometry (FC)4,5 have been employed to obtain enriched or purified testicular cell populations in order to enable differential gene expression studies.
It is required that cells are in suspension for most enrichment/ purification approaches. Ideally, the cell suspension will be representative of the original tissue, have a high proportion of viable cells and few multinucleates - which tend to form because of the syncytial nature of the seminiferous epithelium6,7 - and lack cell clumps1 . Previous reports had evidenced that testicular cell suspensions prepared by an exclusively mechanical method clumped more easily than trypsinized ones1 . On the other hand, enzymatic treatments with RNAses and/or disaggregating enzymes like trypsin and collagenase lead to specific macromolecules degradation, which is undesirable for certain downstream applications. The ideal process should be as short as possible and involve minimal manipulation, so as to achieve a good preservation of macromolecules of interest such as mRNAs. Current protocols for the preparation of cell suspensions from solid tissues are usually time-consuming, highly operator-dependent, and may selectively damage certain cell types1,8 .
	The protocol presented here combines the advantages of a highly reproducible and extremely brief mechanical disaggregation with the absence of enzymatic treatment, leading to good quality cell suspensions that can be used for flow cytometric analysis and sorting4, and ulterior gene expression studies9 .

A novel protocol for the mechanical preparation of testicular cell suspensions from rodent material, avoiding enzymes and detergents, is described. The method is very simple, fast, reproducible, and renders good quality cell suspensions, which are suitable for flow sorting and RNA extraction.

Mammalian testes are very complex organs that contain over 30 different cell types, including somatic testicular cells and different stages of germline ...

Coupled Assays for Monitoring Protein Refolding in Saccharomyces cerevisiae

Proteostasis, defined as the combined processes of protein folding/biogenesis, refolding/repair, and degradation, is a delicate cellular balance that must be maintained to avoid deleterious consequences 1. External or internal factors that disrupt this balance can lead to protein aggregation, toxicity and cell death. In humans this is a major contributing factor to the symptoms associated with neurodegenerative disorders such as Huntington's, Parkinson's, and Alzheimer's diseases 10. It is therefore essential that the proteins involved in maintenance of proteostasis be identified in order to develop treatments for these debilitating diseases. This article describes techniques for monitoring in vivo protein folding at near-real time resolution using the model protein firefly luciferase fused to green fluorescent protein (FFL-GFP). FFL-GFP is a unique model chimeric protein as the FFL moiety is extremely sensitive to stress-induced misfolding and aggregation, which inactivates the enzyme 12. Luciferase activity is monitored using an enzymatic assay, and the GFP moiety provides a method of visualizing soluble or aggregated FFL using automated microscopy. These coupled methods incorporate two parallel and technically independent approaches to analyze both refolding and functional reactivation of an enzyme after stress. Activity recovery can be directly correlated with kinetics of disaggregation and re-solubilization to better understand how protein quality control factors such as protein chaperones collaborate to perform these functions. In addition, gene deletions or mutations can be used to test contributions of specific proteins or protein subunits to this process. In this article we examine the contributions of the protein disaggregase Hsp104 13, known to partner with the Hsp40/70/nucleotide exchange factor (NEF) refolding system 5, to protein refolding to validate this approach.

Coupled Assays for Monitoring Protein Refolding in Saccharomyces cerevisiae

This article describes the use of a firefly luciferase-GFP fusion protein to investigate in vivo protein folding in Saccharomyces cerevisiae. Using this reagent, refolding of a model heat-denatured protein can be monitored simultaneously by fluorescence microscopy and an enzymatic assay to probe the roles of proteostasis network components in protein quality control.

Proteostasis, defined as the combined processes of protein folding/biogenesis, refolding/repair, and degradation, is a delicate cellular balance that must ...

In vitro Cell Migration and Invasion Assays

Migration is a key property of live cells and critical for normal development, immune response, and disease processes such as cancer metastasis and inflammation. Methods to examine cell migration are very useful and important for a wide range of biomedical research such as cancer biology, immunology, vascular biology, cell biology and developmental biology. Here we use tumor cell migration and invasion as an example and describe two related assays to illustrate the commonly used, easily accessible methods to measure these processes. The first method is the cell culture wound closure assay in which a scratch is generated on a confluent cell monolayer. The speed of wound closure and cell migration can be quantified by taking snapshot pictures with a regular inverted microscope at several time intervals. More detailed cell migratory behavior can be documented using the time-lapse microscopy system. The second method described in this paper is the transwell cell migration and invasion assay that measures the capacity of cell motility and invasiveness toward a chemo-attractant gradient. It is our goal to describe these methods in a highly accessible manner so that the procedures can be successfully performed in research laboratories even just with basic cell biology setup.

In vitro Cell Migration and Invasion Assays

Commonly used, highly accessible methods for examining cell migration and invasion in vitro are described. The first method is the cell wound closure assay that measures cell motility. The second method is the transwell migration and invasion assay that assesses the chemotactic and invasive capacity of cells.

Migration is a key property of live cells and critical for normal development, immune response, and disease processes such as cancer metastasis and ...

In Vitro Aggregation Assays Using Hyperphosphorylated Tau Protein

Alzheimer's disease is one of a large group of neurodegenerative disorders known as tauopathies that are manifested by the neuronal deposits of hyperphosphorylated tau protein in the form of neurofibrillary tangles (NFTs). The density of NFT correlates well with cognitive impairment and other neurodegenerative symptoms, thus prompting the endeavor of developing tau aggregation-based therapeutics. Thus far, however, tau aggregation assays use recombinant or synthetic tau that is devoid of the pathology-related phosphorylation marks. Here we describe two assays using recombinant, hyperphosphorylated tau as the subject. These assays can be scaled up for high-throughput screens for compounds that can modulate the kinetics or stability of hyperphosphorylated tau aggregates. Novel therapeutics for Alzheimer's disease and other tauopathies can potentially be discovered using hyperphosphorylated tau isoforms.

In Vitro Aggregation Assays Using Hyperphosphorylated Tau Protein

Unmodified and hyperphosphorylated tau proteins were used in two in vitro aggregation assays to reveal the hyperphosphorylation-dependent fast aggregation kinetics. These assays pave the way for future screens for compounds that can modulate the propensity of hyperphosphorylated tau to form fibrils that underlie the progression of Alzheimer&#8217;s disease.

Alzheimer's disease is one of a large group of neurodegenerative disorders known as tauopathies that are manifested by the neuronal deposits of ...

Preparation, Imaging, and Quantification of Bacterial Surface Motility Assays

Bacterial surface motility, such as swarming, is commonly examined in the laboratory using plate assays that necessitate specific concentrations of agar and sometimes inclusion of specific nutrients in the growth medium. The preparation of such explicit media and surface growth conditions serves to provide the favorable conditions that allow not just bacterial growth but coordinated motility of bacteria over these surfaces within thin liquid films. Reproducibility of swarm plate and other surface motility plate assays can be a major challenge. Especially for more &#8220;temperate swarmers&#8221; that exhibit motility only within agar ranges of 0.4%-0.8% (wt/vol), minor changes in protocol or laboratory environment can greatly influence swarm assay results. &#8220;Wettability&#8221;, or water content at the liquid-solid-air interface of these plate assays, is often a key variable to be controlled. An additional challenge in assessing swarming is how to quantify observed differences between any two (or more) experiments. Here we detail a versatile two-phase protocol to prepare and image swarm assays. We include guidelines to circumvent the challenges commonly associated with swarm assay media preparation and quantification of data from these assays. We specifically demonstrate our method using bacteria that express fluorescent or bioluminescent genetic reporters like green fluorescent protein (GFP), luciferase (lux operon), or cellular stains to enable time-lapse optical imaging. We further demonstrate the ability of our method to track competing swarming species in the same experiment.

Swarming motility is influenced by physical and environmental factors. We describe a two-phase protocol and guidelines to circumvent the challenges commonly associated with swarm assay preparation and data collection. A macroscopic imaging technique is employed to obtain detailed information on swarm behavior that is not provided by current analysis techniques.

Bacterial surface motility, such as swarming, is commonly examined in the laboratory using plate assays that necessitate specific concentrations of agar ...

Simple Bulk Readout of Digital Nucleic Acid Quantification Assays

Digital assays are powerful methods that enable detection of rare cells and counting of individual nucleic acid molecules. However, digital assays are still not routinely applied, due to the cost and specific equipment associated with commercially available methods. Here we present a simplified method for readout of digital droplet assays using a conventional real-time PCR instrument to measure bulk fluorescence of droplet-based digital assays.
We characterize the performance of the bulk readout assay using synthetic droplet mixtures and a droplet digital multiple displacement amplification (MDA) assay. Quantitative MDA particularly benefits from a digital reaction format, but our new method&#160;applies to any digital assay. For established digital assay protocols such as digital PCR, this method serves to speed up and simplify assay readout.
Our bulk readout methodology brings the advantages of partitioned assays without the need for specialized readout instrumentation. The principal limitations of the bulk readout methodology are reduced dynamic range compared with droplet-counting platforms and the need for a standard sample, although the requirements for this standard are less demanding than for a conventional real-time experiment. Quantitative whole genome amplification (WGA) is used to test for contaminants in WGA reactions and is the most sensitive way to detect the presence of DNA fragments with unknown sequences, giving the method great promise in diverse application areas including pharmaceutical quality control and astrobiology.

We describe an endpoint digital assay for quantifying nucleic acids with a simplified (analog) readout. We measure bulk fluorescence of droplet-based digital assays using a standard qPCR machine rather than specialized instrumentation and confirm our results by microscopy.

Digital assays are powerful methods that enable detection of rare cells and counting of individual nucleic acid molecules. However, digital assays are ...

Filtration Isolation of Nucleic Acids:  A Simple and Rapid DNA Extraction Method

FINA, filtration isolation of nucleic acids, is a novel extraction method which utilizes vertical filtration via a separation membrane and absorbent pad to extract cellular DNA from whole blood in less than 2 min. The blood specimen is treated with detergent, mixed briefly and applied by pipet to the separation membrane. The lysate wicks into the blotting pad due to capillary action, capturing the genomic DNA on the surface of the separation membrane. The extracted DNA is retained on the membrane during a simple wash step wherein PCR inhibitors are wicked into the absorbent blotting pad. The membrane containing the entrapped DNA is then added to the PCR reaction without further purification. This simple method does not require laboratory equipment and can be easily implemented with inexpensive laboratory supplies. Here we describe a protocol for highly sensitive detection and quantitation of HIV-1 proviral DNA from 100 &#181;l whole blood as a model for early infant diagnosis of HIV that could readily be adapted to other genetic targets.

We describe here a simple and rapid paper-based DNA extraction method of HIV proviral DNA from whole blood detected by quantitative PCR. This protocol can be extended for use in detecting other genetic markers or using alternative amplification methods.

FINA, filtration isolation of nucleic acids, is a novel extraction method which utilizes vertical filtration via a separation membrane and absorbent pad ...

FtsZ Polymerization Assays: Simple Protocols and Considerations

Summary

Explore More Videos

Chapters in this video

Protocols for Oral Infection of Lepidopteran Larvae with Baculovirus

Protocols for Microapplicator-assisted Infection of Lepidopteran Larvae with Baculovirus

Mutagenesis and Functional Selection Protocols for Directed Evolution of Proteins in E. coli

Simple and Efficient Technique for the Preparation of Testicular Cell Suspensions

Coupled Assays for Monitoring Protein Refolding in Saccharomyces cerevisiae

In vitro Cell Migration and Invasion Assays

In Vitro Aggregation Assays Using Hyperphosphorylated Tau Protein

Preparation, Imaging, and Quantification of Bacterial Surface Motility Assays

Simple Bulk Readout of Digital Nucleic Acid Quantification Assays

Filtration Isolation of Nucleic Acids: A Simple and Rapid DNA Extraction Method
