Funding for this work was provided by a Garnett Passe and Rodney Williams Memorial Foundation Project grant to R. Lim and A.J. Camp.

1. Animals
<ol>
	<li>Mice were obtained from the Australian Rodent Centre (ARC; Perth, Australia) and held at the University of Sydney Bosch Animal Facility on a normal 12-hr light/dark cycle with environmental enrichment. All experiments described were approved by The University of Sydney Animal Ethics Committee.</li>
	<li>Male and female mice (C57/Bl6) were used for all experiments since this strain are commonly used as the background for genetic manipulation, and can be considered equivalent to wildtype 8-9.</li>
</ol>
2. Tissue Preparation
<ol>
	<li>Prepare 300 ml of a glycerol-based artificial cerebrospinal fluid (ACSF) consisting of (in mM): 26 NaHCO3, 11 glucose, 250 glycerol, 2.5 KCl, 1.2 NaH2PO4, 1.2 MgCl2, and 2.5 CaCl2. Prior to the addition of CaCl2, gas the solution with carbogen (95% O2 and 5% CO2) to establish a pH of 7.4 and avoid calcium precipitation (cloudiness). Freeze the solution in a -80 &deg;C freezer for 45 min so that an ice slurry is formed.</li>
	<li>Deeply anaesthetize mice with ketamine (100 mg/kg) (Parnell, Alexandria, Australia) via an intra-peritoneal injection.</li>
	<li>Once hind-limb pinch reflexes are absent decapitate mice using sharp stainless steel scissors and make a sagittal skin incision using a razor blade (rounded #22) to expose the skull. At this point and throughout steps 2.3-2.8 the cranial vault, brain, and underlying vestibular apparatus should be kept as cool as possible by regular application of ice-cold ACSF over the tissue.</li>
	<li>Using the pointed arm of standard pattern scissors (FST, North Vancouver, Canada) make a small incision in the skull at Lambda and cut along the sagittal suture. Ensure that the brain is not "dragged" by the shear blade during this step.</li>
	<li>Carefully peel the parietal bones away laterally and the occipital bone posteriorly using shallow bend pearson rongeurs (FST).</li>
	<li>A small stainless steel spatula is then used to gently lift the brain from the surface of the middle and posterior cranial fossae, and the exposed vestibulocochlea nerve (CNVIII) cut midway between the inner ear and the brainstem with a pair of fine iris scissors. Cutting this nerve minimizes undue tension on axons of the primary afferents and their connections with hair cells.</li>
	<li>Following transection of CN VIII the brain is removed in toto.</li>
	<li>The vestibular labyrinth is now clearly visible in the middle cranial fossa, with the cochlea pointing anteromedially. Rongeur either side of the vestibular labyrinth before gently excising by gripping the anterior semicircular canal and pulling laterally.</li>
	<li>Immerse the excised labyrinths (Figure 1) in a dissecting dish containing the ice-cold, continuously gassed ACSF described in section 2.1. Under a stereomicroscope, hold the labyrinth to the base of the dish by gripping the cochlea. Use fine forceps to scratch away at the bone overlying the anterior semicircular canal ampulla. Once a small hole in the bone is achieved begin to flick the bone away from the ampulla. Caution should be taken not to push the forceps through the bone as this can cause damage to the underlying membranous labyrinth and sensory epithelium. Continue this procedure until both the anterior and adjacent horizontal semicircular membranous ducts and ampullae are exposed (Figure 2).</li>
</ol>
<img alt="Figure 1" src="/files/ftp_upload/50471/50471fig1.jpg" />
Figure 1. The isolated mouse vestibular labyrinth. A. Left panel) Schematic representation of the isolated mouse vestibular labyrinth. Important points of reference for accessing the vestibular sensory epithelium, the cochlea, anterior, and horizontal semicircular canals are labeled. Asterisks indicate the semicircular canal ampulla containing the vestibular sensory epithelium. B. Right panel) Photomicrograph of the isolated vestibular labyrinth from a 1-month-old mouse.
<img alt="Figure 2" src="/files/ftp_upload/50471/50471fig2.jpg" />
Figure 2. Exposure of the Membranous vestibular labyrinth. The bone overlying the anterior and horizontal semicircular canal ampullae have been scratched away to reveal the black/brown-speckled membranous ampullae and associated ampullary nerves (CNVIII). The schematic in the bottom panel represents the structures in the highlighted region of the photomicrograph and shows the relationship of the semicircular canal ducts to the ampullae and CNVIII.
<ol start="10">
	<li>Using fine forceps, gently lift the ampullae and associated utricle away from the bony labyrinth, ensuring that the central region of the ampullae (containing the sensory epithelium) is not damaged. In some cases the proximal part of the semicircular membranous duct may need to be cut with iris scissors to release the ampullae from the bone.</li>
	<li>Transfer the triad containing the two ampullae and utricle into a Petri dish filled with Leibovitz's L-15 culture medium (Sigma-Aldrich, St. Louis, MO). Use a fiber optic to "backlight" the tissue. This allows clear visualization of the crista containing the sensory epithelium within the ampullae.</li>
	<li>Carefully make an incision in the speckled "roof" of the utricle with the fine iris scissors. Continue this incision through the roof of the anterior and then the horizontal ampullae. Make the incision as close to the edge of the sensory epithelium as possible without contacting it (Figure 3A). Ensure that there are no pieces of membrane overlying the sensory epithelium (Figure 3B).</li>
	<li>Transfer the isolated semi intact preparation to a small glass-bottomed recording chamber filled with L-15 media. Weigh down the preparation using a grid of fine nylon fibers secured to a flattened U-shaped platinum wire (Figure 3B). Ideally, the fibers of the grid should not overlie the sensory epithelium, however in some cases where more stability is required, a single fiber transecting the sensory epithelium maybe preferred.</li>
</ol>
<img alt="Figure 3" src="/files/ftp_upload/50471/50471fig3.jpg" />
Figure 3. The isolated semi-intact preparation of the vestibular sensory epithelium. A. Schematic representation of the semi-intact preparation and electrode configuration. The ampulla overlying the crista has been "de-roofed" to expose the surface of the sensory epithelium (green). B. Photomicrograph of the semi-intact 'triad' preparation showing the anterior (ac) and horizontal (hc) crista (utricle obscured behind ac). Note the nylon fiber used to secure the preparation to the base of the recording chamber. Scale bar: 100 &mu;m. C. A recording electrode positioned on an individual vestibular hair cell. Scale bar: 15 &mu;m.
3. Electrophysiology
<ol>
	<li>Perfuse the semi-intact preparation with continuously oxygenated L-15 medium. The media contains a pH indicator (phenol red) and color of the medium should be monitored throughout the recordings. The pH with oxygen should be 7.3-7.4 and correspond to a red color.</li>
	<li>Prepare recording pipettes from 1.5 mm (1.19 mm ID) borosilicate glass using a two-step protocol (heat step 1: 72; and heat step 2: 50) on a micropipette puller (Narishige, Japan, model PP-830) to achieve a final impedance of 3-4 M&Omega;.</li>
	<li>Fill the shank of the pipette with 3-4 mm of Potassium fluoride-based internal solution containing (in mM) 110 KF, 12 KCl, 27 KOH, 1 NaCl, 10 HEPES, 10 EGTA, 1.8 MgCl2, 3 D-glucose, and 2 Na-ATP; pH 7.4 with KOH.</li>
	<li>Wrap the shank of the pipette 2-3 times and as far down to the tip as possible with a thin strip of parafilm to insulate the electrode and reduce pipette capacitance.</li>
	<li>Position the pipette over the sensory epithelium under low power magnification (5X) on an upright microscope (Olympus BX51). Switch to high power (40X) and visualize individual vestibular hair cells with an attached CCD camera.</li>
	<li>Position pipette on the membrane of a visualized hair cell (Figure 3C) using a micromanipulator (Sutter Instruments, California, USA). Once a gigaohm seal is achieved, rupture the cell membrane with a small amount of negative pressure applied through a suction port on the pipette holder.</li>
	<li>Make whole-cell voltage clamp recordings using standard techniques 8-9.</li>
</ol>
4. Two-photon Microscopy
<ol>
	<li>Prepare a 0.9% saline solution containing 5 mM Oregon Green 488 BAPTA-1 (OGB-1; hexapotassium salt; Invitrogen, Germany).</li>
	<li>While still submerged, place the "de-roofed" semi-intact triad preparation onto a small piece of filter paper (4X4 mm, 0.8 &mu;m thick; Millipore, Germany) ensuring that the sensory epithelium is unobstructed from above.</li>
	<li>Transfer the filter paper and preparation onto the saline covered base platinum electrode (7 &mu;l) of an electroporator consisting of the combination of a pulse generator and a wide-band amplifier, and cover with a further 5 &mu;l of 5 mM solution of the synthetic calcium indicator dye Oregon Green 488 BAPTA-1 (Figure 4).</li>
</ol>
<img alt="Figure 4" src="/files/ftp_upload/50471/50471fig4.jpg" />
Figure 4. Bulk electroporation. A. schematic showing cross-section of electroporation configuration. The semi-intact preparation (*) is placed on a piece of filter paper immersed in calcium dye (Oregon Green 488 BAPTA-1) and current applied between 2 platinum electrodes. Adapted from Briggman and Euler, 2011 10.
<ol start="4">
	<li>Bring the top platinum electrode parallel with the base electrode at a distance of approximately 2 mm, being careful not to disrupt the orientation of the preparation when contact with the Oregon Green 488 BAPTA-1 solution is made.</li>
	<li>Pass a brief current pulse across the preparation (Parameters for the current; +13 V, 10 msec pulse width, 1 Hz frequency, 10 square-wave pulses) 10-11.</li>
	<li>On the bottom of a glass bottomed recording chamber filled with L-15 medium, place a small dab of silicon oil and position the semi-intact preparation onto it, again ensuring that the sensory epithelium is unobstructed from above. To ensure stability throughout imaging, replace the nylon grid over the preparation as described above (see point 2.13).</li>
	<li>Using the two-photon microscope make optical recordings of spontaneous calcium activity in the sensory epithelium (Figure 7) using standard imaging protocols 10-11.</li>
</ol>

<ol>
	<li>Dulon, D., Safieddine, S., Jones, S. M., Petit, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Otoferlin+is+critical+for+a+highly+sensitive+and+linear+calcium-dependent+exocytosis+at+vestibular+hair+cell+ribbon+synapses.">Otoferlin is critical for a highly sensitive and linear calcium-dependent exocytosis at vestibular hair cell ribbon synapses.</a> J. Neurosci. 29, 10474-10487 (2009).</li><li>Highstein, S., Art, J., Holstein, G., Rabbitt, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Simultaneous+pre-+and+post-synaptic+recording+from+the+peripheral+vestibular+calyx+and+its+included+type+I+hair+cell.">Simultaneous pre- and post-synaptic recording from the peripheral vestibular calyx and its included type I hair cell.</a> , (2009).</li><li>Kindig, A. E., Lim, R., Callister, R. J., Brichta, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Voltage+dependent+currents+in+type+I+and+II+hair+cell+and+calyx+terminals+of+primary+afferents+in+an+intact+in+vitro+mouse+vestibular+crista+preparation.">Voltage dependent currents in type I and II hair cell and calyx terminals of primary afferents in an intact in vitro mouse vestibular crista preparation.</a> , (2009).</li><li>Chatlani, S., Goldberg, J. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Whole-cell+recordings+from+calyx+endings+in+the+turtle+posterior+crista.">Whole-cell recordings from calyx endings in the turtle posterior crista.</a> , (2010).</li><li>Songer, J. E., Eatock, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transduction+in+the+mammalian+saccule.">Transduction in the mammalian saccule.</a> , (2010).</li><li>Lee, H. Y., Camp, A. J., Callister, R. J., Brichta, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Vestibular+primary+afferent+activity+in+an+in+vitro+preparation+of+the+mouse+inner+ear.">Vestibular primary afferent activity in an in vitro preparation of the mouse inner ear.</a> J. Neurosci. Methods. 145, 73-87 (2005).</li><li>Lim, R., Kindig, A. E., Donne, S. W., Callister, R. J., Brichta, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Potassium+accumulation+between+type+I+hair+cells+and+calyx+terminals+in+mouse+crista.">Potassium accumulation between type I hair cells and calyx terminals in mouse crista.</a> Exp. Brain Res. 210, 607-621 (2011).</li><li>Camp, A. J., Callister, R. J., Brichta, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Inhibitory+synaptic+transmission+differs+in+mouse+type+A+and+B+medial+vestibular+nucleus+neurons+in+vitro.">Inhibitory synaptic transmission differs in mouse type A and B medial vestibular nucleus neurons in vitro.</a> J. Neurophysiol. 95, 3208-3218 (2006).</li><li>Camp, A. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Attenuated+glycine+receptor+function+reduces+excitability+of+mouse+medial+vestibular+nucleus+neurons.">Attenuated glycine receptor function reduces excitability of mouse medial vestibular nucleus neurons.</a> Neuroscience. 170, 348-360 (2010).</li><li>Briggman, K. L., Euler, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bulk+electroporation+and+population+calcium+imaging+in+the+adult+mammalian+retina.">Bulk electroporation and population calcium imaging in the adult mammalian retina.</a> J. Neurophysiol. 105, 2601-2609 (2011).</li><li>Briggman, K. L., Helmstaedter, M., Denk, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Wiring+specificity+in+the+direction-selectivity+circuit+of+the+retina.">Wiring specificity in the direction-selectivity circuit of the retina.</a> Nature. 471, 183-188 (2011).</li><li>Rennie, K. J., Streeter, M. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Voltage-dependent+currents+in+isolated+vestibular+afferent+calyx+terminals.">Voltage-dependent currents in isolated vestibular afferent calyx terminals.</a> J. Neurophysiol. 95, 26-32 (2006).</li><li>Hudspeth, A. J., Lewis, R. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Kinetic+analysis+of+voltage-+and+ion-dependent+conductances+in+saccular+hair+cells+of+the+bull-frog,+Rana+catesbeiana.">Kinetic analysis of voltage- and ion-dependent conductances in saccular hair cells of the bull-frog, Rana catesbeiana.</a> J. Physiol. 400, 237-274 (1988).</li><li>Rennie, K. J., Ashmore, J. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ionic+currents+in+isolated+vestibular+hair+cells+from+the+guinea-pig+crista+ampullaris.">Ionic currents in isolated vestibular hair cells from the guinea-pig crista ampullaris.</a> Hear. Res. 51, 279-291 (1991).</li></ol>

The authors declare that they have no competing financial interests.

The mechanisms underlying our sense of balance have received limited attention in comparison with other sensory systems, e.g. the visual and auditory systems. Of the studies that have investigated changes in vestibular or balance function, most have focused on behavioral measures including the vestibulo-ocular reflex, with incomplete knowledge of the fundamental building blocks of balance- the vestibular hair cells themselves. Those studies that have concentrated on the hair cells have almost invariably do...

Despite the significant contribution of the vestibular system to our everyday lives, a clear understanding of the processes responsible for the observed decline in vestibular function with age remain elusive. One reason for this lack of knowledge is that decline in vestibular function has almost exclusively been explored using behavioral assays, including the vestibulo-ocular reflex (VOR), a precise indicator of extrinsic vestibular function, but provides limited insights into the changes of intrinsic components. This is a major impediment to our understanding of vestibular hair cell function in health, disease, or aging.
While there have been many studies of individual vestibular hair cells, a major shortcoming has been the reliance on acute hair cell preparations, where hair cells and even calyx afferent terminals are removed from their normal environment via mechanical and/or enzymatic treatment. Such approaches inevitably disrupt the delicate microarchitecture between hair cell and calyx, and hair cell and supporting cell. With the development of semi-intact preparations 1-5, and an isolated mouse labyrinth preparation 6, there is now an opportunity to study the various forms of synaptic communication under conditions that more closely resemble those in vivo. Indeed, Lim et al. (2011) showed marked differences in whole cell currents recorded from acutely isolated type I vestibular hair cells compared to those that remained embedded within the neuroepithelium. Specifically, potassium is thought to accumulate in the intercellular space, between the hair cell and calyx afferent, and significantly alter hair cell response7. This type of information would be impossible to obtain without the semi-intact preparation of the vestibular sensory epithelium described here. We demonstrate the semi-intact preparation of the mouse crista 3, and show representative results obtained from whole-cell patch electrophysiology, and two-photon calcium imaging.

<table><tbody><tr><td colspan="4">&lt;strong&gt;REAGENTS&lt;/strong&gt;</td></tr><tr><td>Leibovitz medium L-15</td><td>Sigma Aldrich</td><td>L4386-10X1L</td><td></td></tr><tr><td>BAPTA-1-oregon green</td><td>Invitrogen</td><td>O6806</td><td></td></tr><tr><td colspan="4">&lt;strong&gt;EQUIPMENT &lt;/strong&gt;</td></tr><tr><td>Stereo microscope</td><td>Leica Microsystems</td><td>A60S</td><td></td></tr><tr><td>Upright microscope</td><td>Olympus</td><td>BX51WI</td><td></td></tr><tr><td>Two-photon microscope</td><td>Olympus/La Vision</td><td>BX51WI/ TriMScope II</td><td></td></tr><tr><td>Dumont #5 SF Forceps</td><td>FST</td><td>11252-00</td><td></td></tr><tr><td>Friedman-Pearson Rongeurs</td><td>FST</td><td>16221-14</td><td></td></tr><tr><td>Standard Pattern Scissors</td><td>FST</td><td>14001-12</td><td></td></tr><tr><td>InstraTECH A-D converter</td><td>HEKA</td><td>ITC-18</td><td></td></tr><tr><td>Sutter Micromanipulator</td><td>Sutter</td><td>MP-225/M</td><td></td></tr><tr><td>multiclamp amplifier</td><td>Axon Instruments</td><td>700B</td><td></td></tr><tr><td>Data acquisition software (electrophysiology)</td><td>Axograph</td><td>N/A</td><td></td></tr><tr><td>Imspector Data acquisition software (two-photon)</td><td>Max Planck innovation</td><td>N/A</td><td></td></tr></tbody></table>

an isolated semi-intact preparation of the mouse vestibular sensory epithelium for electrophysiology and high-resolution two-photon microscopy

Understanding vestibular hair cells function under normal conditions, or how trauma, disease, and aging disrupt this function is a vital step in the development of preventative approaches and/or novel therapeutic strategies. However, the majority of studies looking at abnormal vestibular function have not been at the cellular level but focused primarily on behavioral assays of vestibular dysfunction such as gait analyses and vestibulo-ocular reflex performance. While this work has yielded valuable data about what happens when things go wrong, little information is gleaned regarding the underlying causes of dysfunction. Of the studies that focus on the cellular and subcellular processes that underlie vestibular function, most have relied on acutely isolated hair cells, devoid of their synaptic connections and supporting cell environment. Therefore, a major technical challenge has been access to the exquisitely sensitive vestibular hair cells in a preparation that is least disrupted, physiologically. Here we demonstrate a semi-intact preparation of the mouse vestibular sensory epithelium that retains the local micro-environment including hair cell/primary afferent complexes.

The electrophysiological properties of vestibular hair cells are dependent on the complex microarchitecture within which they are embedded 7. Figure 5 shows that the semi-intact vestibular epithelium preparation can be used to differentiate between type I hair cells (Figure 5A), type II hair cells (Figure 5B), and the calyx primary afferent (Figure 5C) based on characteristic whole cell conductances. These characteristics include a prono...

Watch this Scientific Journal Video about An Isolated Semi-intact Preparation of the Mouse Vestibular Sensory Epithelium for Electrophysiology and High-resolution Two-photon Microscopy at JoVE.com

An Isolated Semi-intact Preparation of the Mouse Vestibular Sensory Epithelium for Electrophysiology and High-resolution Two-photon Microscopy

Analysis of vestibular hair cell function is complicated by their location deep within the hardest part of the skull, the petrous temporal bone. Most functional hair cell studies have used acutely isolated hair cells. Here we describe a semi-intact preparation of mouse vestibular epithelium for electrophysiological and two-photon microscopy studies.

Understanding vestibular hair cells function  under normal conditions, or how trauma, disease, and aging disrupt this  function is a vital step in the ...
