1. Differentiating iMOP-Derived Neurons
<ol>
	<li>Make 50 ml of neuronal differentiation media: Neurobasal media, 1X B27 supplement, 2 mM L-Glutamine. Thaw bottle of 50X B27 and 200 mM L-Glutamine in 37 &#176;C water bath for 5 min. Add 1ml 50X B27 and 0.5 ml 200 mM L-Glutamine to 48.5 ml of Neurobasal media.</li>
	<li>Coat coverglass by placing 12 mm round 1.5 glass coverslips in a sterile 10 cm plate and add 70% ethanol (EtOH) to the plate to sterilized and clean the coverslips.</li>
	<li>Gently agitate the coverslips to ensure they are covered in ethanol. Leave the plate for 10 min at RT. Rinse the coverslips 3 times with sterile 1X phosphate-buffered saline (PBS) to wash out the remaining ethanol. Rinse the coverslip once with sterile H2O to wash out the remaining 1X PBS.</li>
	<li>Aspirate the H2O using a 2 ml aspirating pipette and let the coverslips dry. Expose the coverslips to UV light in the tissue culture hood for 15 min. Store coverslips in a sterile environment if not immediately used.</li>
	<li>Place one 12 mm round coverslip in each well of a 24 well dish. Shake plate gently to ensure that the coverslips lie flat on the bottom of the well.</li>
	<li>Thaw 2 mg/ml poly-D-lysine stock solution at room temperature (RT) and dilute to a 10 &#181;g/ml poly-D-lysine concentration in 1X PBS. Add 0.25 ml of 10 ug/ml poly-D-lysine to the wells. Leave the plate in the 37 &#176;C incubator for 1 hr.</li>
	<li>Wash the wells 3 times with sterile 1X PBS. Thaw 10 mg/ml laminin stock solution at RT and dilute to 10 &#181;g/ml in 1X PBS. Add 0.25 ml of 10 &#181;g/ml laminin working solution into a single well of a 24 multi-well dish. Incubate the plate at 37 &#176;C incubator. Aspirate out the laminin solution using a 2 ml aspirating pipette.</li>
	<li>Wash the coverslip 3 times with 1X PBS by adding in 1 ml of 1X PBS with a P1000 pipette and removing the 1X PBS by aspirating with a 2 ml aspirating pipette. Leave 1X PBS from last wash in the well until cells are ready to be plated. Initiate neuronal differentiation by harvesting, dissociating and counting cells. Plate 1 x 106 cells in a 6 cm dish at Day -3.</li>
	<li>On Day 0, harvest, dissociate and count cells. Seed 1 x 105 - 1.5 x 105 iMOP cells into 0.5 ml pre-warmed neuronal differentiation media per well in a 24 multi-well dish. Aspirate and add pre-warmed neuronal differentiation media to cultures every other day.</li>
	<li>Fix iMOP-derived neurons in 4% formaldehyde for 15 min. at RT on Day 7. Remove formaldehyde solution, wash iMOP-derived neurons with wash buffer (1X PBS containing 0.1% TritonX-100) before incubating in blocking buffer (1X PBS containing 10% normal goat serum and 0.1% Triton X-100) for 1 hr.
	<ol>
		<li>Replace buffer and incubate samples in blocking buffer with diluted antibody. Incubate at 4 &#176;C. Wash samples with 1X PBS containing 0.1% Triton X-100 subject cells to immunostaining. Wash the coverglass with 1X PBS before placing onto mounting media. Allow the mounting media to dry at 4 &#176;C before acquiring epifluorescence images.</li>
	</ol>
	</li>
</ol>

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>1.5 Thickness Glass Coverslip (Round 12 mm)</td>
			<td>Electron Microscopy Sciences 7</td>
			<td>72230-01</td>
			<td></td>
		</tr>
		<tr>
			<td>DMEM/F12</td>
			<td>Life Technologies</td>
			<td>11320-082</td>
			<td></td>
		</tr>
		<tr>
			<td>Neurobasal Medium</td>
			<td>Life Technologies</td>
			<td>21103</td>
			<td></td>
		</tr>
		<tr>
			<td>Phosphate Buffered Saline (PBS) pH 7.4</td>
			<td>Life Technologies</td>
			<td>10010-023</td>
			<td></td>
		</tr>
		<tr>
			<td>B27 Supplement (50X) Serum Free</td>
			<td>Life Technologies</td>
			<td>17504-044</td>
			<td>Stored as 1 ml aliquots</td>
		</tr>
		<tr>
			<td>L-Glutamine(200 mM)</td>
			<td>Life Technologies</td>
			<td>25030-081</td>
			<td>Stored as 5 ml aliquots</td>
		</tr>
		<tr>
			<td>Natural Mouse Laminin</td>
			<td>Life Technologies</td>
			<td>23017-015</td>
			<td>Stored as 1 mg/ml aliquots</td>
		</tr>
		<tr>
			<td>Prolong Gold Antifade Mountant</td>
			<td>Life Technologies</td>
			<td>47743-736</td>
			<td>Stored as 10 mg/ml 100 &#181;l aliquots</td>
		</tr>
		<tr>
			<td>Moxi Z Mini Automated Cell Counter</td>
			<td>Orflo</td>
			<td>MXZ001</td>
			<td></td>
		</tr>
		<tr>
			<td>Moxi Z Cassette Type S</td>
			<td>Orflo</td>
			<td>MXC002</td>
			<td></td>
		</tr>
		<tr>
			<td>Poly-D-Lysine</td>
			<td>Sigma</td>
			<td>P7886</td>
			<td>Resuspended in 1X PBS and stored as 10 mg/ml 100 &#181;l aliquots</td>
		</tr>
		<tr>
			<td>5 ml pipet individually wrapped paperback (200/case)</td>
			<td>Thermo Fisher Scientific</td>
			<td>1367811D</td>
			<td></td>
		</tr>
		<tr>
			<td>10 ml pipet individually wrapped paperback (200/case)</td>
			<td>Thermo Fisher Scientific</td>
			<td>1367811E</td>
			<td></td>
		</tr>
		<tr>
			<td>Tissue Culture Treated Biolite 24- Well Plate</td>
			<td>Thermo Fisher Scientific</td>
			<td>130188</td>
			<td></td>
		</tr>
		<tr>
			<td>Tissue Culture Treated Biolite 6- Well Plate</td>
			<td>Thermo Fisher Scientific</td>
			<td>130184</td>
			<td></td>
		</tr>
		<tr>
			<td>Tissue Culture Treated 6 cm Dish</td>
			<td>Thermo Fisher Scientific</td>
			<td>130181</td>
			<td></td>
		</tr>
		<tr>
			<td>EMD Millipore Millex Sterile Syringe PVDF Filter Pore size: 0.22 &#956;m</td>
			<td>Thermo Fisher Scientific</td>
			<td>SLGV033RS</td>
			<td></td>
		</tr>
		<tr>
			<td>TipOne filter pipet tips 0.1 - 10 &#956;l elongated filter tip</td>
			<td>USA Scientific</td>
			<td>1120-3810</td>
			<td></td>
		</tr>
		<tr>
			<td>TipOne filter pipet tips 1 - 20 &#956;l filter tip</td>
			<td>USA Scientific</td>
			<td>1120-1810</td>
			<td></td>
		</tr>
		<tr>
			<td>TipOne filter pipet tips 1 - 200 &#956;l filter tip</td>
			<td>USA Scientific</td>
			<td>1120-8810</td>
			<td></td>
		</tr>
		<tr>
			<td>TipOne filter pipet tips 101 - 1000 &#956;l filter tip</td>
			<td>USA Scientific</td>
			<td>1126-7810</td>
			<td></td>
		</tr>
		<tr>
			<td>15 ml conical tubes sterile 20 bags of 25 tubes (500 tubes)</td>
			<td>USA Scientific</td>
			<td>1475-0511</td>
			<td></td>
		</tr>
		<tr>
			<td>50 ml conical tubes sterile 20 bags of 25 tubes (500 tubes)</td>
			<td>USA Scientific</td>
			<td>1500-1211</td>
			<td></td>
		</tr>
	</tbody>
</table>

differentiating immortalized multipotent otic progenitors into spiral ganglion neurons and evaluating the differentiation

Source: Azadeh, J., et al. <a href="https://appjove.unicartagenaproxy.elogim.com/v/53692">Initiating Differentiation in Immortalized Multipotent Otic Progenitor Cells.</a> J. Vis. Exp. (2016).
The video demonstrates the differentiation of immortalized multipotent otic progenitors (iMOPs) into spiral ganglion neurons (SGNs) and immunofluorescence-based confirmation of the differentiation. The iMOPs are plated onto culture substrate-coated coverslips in a neuronal differentiation medium for differentiation into SGNs. The differentiated cells are labeled with antibodies specific for neuronal differentiation markers and analyzed under a microscope to confirm differentiation.

Differentiating Immortalized Multipotent Otic Progenitors into Spiral Ganglion Neurons and Evaluating the Differentiation

1. Differentiating iMOP-Derived Neurons

	Make 50 ml of neuronal differentiation media: Neurobasal media, 1X B27 supplement, 2 mM L-Glutamine. Thaw ...

Take a multi-well plate containing sterile coverslips coated with a cell culture substrate.
Introduce immortalized multipotent otic progenitors, or iMOPs, in a neuronal differentiation medium.
iMOPs are precursors to various inner ear cells, including spiral ganglion neurons, or SGNs, that transmit auditory information to the brain.
Incubate, allowing the cells to adhere to the substrate. The medium induces differentiation of the iMOPs into SGNs.
Add a fixative to induce protein crosslinking, preserving cell morphology, and a detergent solution to permeabilize cellular membranes.
Introduce a blocking reagent to prevent non-specific labeling.
Add fluorophore-conjugated antibodies specific for neuronal differentiation markers and incubate, allowing the antibodies to label the SGNs.
Wash to remove unbound antibodies, and mount the coverslips with a mounting medium containing a fluorescent nuclear stain.
Using fluorescence microscopy, detect the antibody signals to confirm the differentiation of iMOPs into SGNs.
