The authors thank Karen Hilburn for excellent technical support. This project was supported by the National Research Initiative of the USDA Cooperative State Research, Education and Extension Service (Award #2004-35604-14327). Matias Pasquali is supported by Branco Weiss Fellowship. The US Wheat and Barley Scab Initiative is also acknowledged for the continuing support of research.

<ol>
<li>Carrot agar (Klittich and Leslie, 1988) was prepared in 9-cm diameter Petri dishes. </li>
<li>A 2 mm cube of agar containing fresh mycelium grown on potato dextrose agar was applied to the centre of each Petri dish. </li>
<li>Cultures were grown at 25&deg;C and a 12-h photoperiod for 96 hrs. </li>
<li>One ml of aqueous 2.5% Tween 60 was applied to the surface of the culture (Trail and Common, 2000) and spread across the culture with a plastic rod, by gently pressing. </li>
<li>Perithecia shooting ascospores developed 7-10 days after this induction treatment when kept in a high humidity environment at 25&deg;C with the same photoperiod. </li>
<li>Spore collection is performed by changing the Petri plate lid, leaving perithecia to shoot for a limited time (for example 12 hrs) in the dark. </li>
<li>Sterile water is added to the lid, suspending ascospores by gently moving water on the surface. </li>
<li>Ascospores are collected in sterile Falcon tubes, washed and used for further analysis. </li>
</ol>

<ol>
	<li>Beyer, M., Verreet, J. A., Francl, L., Shaner, G., Bergstrom, G., Gilbert, J., Pedersen, W., Dill-Macky, R., Sweets, L., Corwin, B., Jin, Y., Gallenberg, D., Wiersma, J., Goswami, R. S., Kistler, H. C., Klittich, C. J. R., Leslie, J. F., Trail, F., Common, R., Tschantz, A. T., Horst, R. L., Nelson, P. E., Tschanz, A. T., Horst, R. K., Nelson, P. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Germination+of+Gibberella+zeae+ascospores+as+affected+by+age+of+spores+after+discharge+and+environmental+factors.">Germination of Gibberella zeae ascospores as affected by age of spores after discharge and environmental factors.</a> Genetics. 118, 417-2013 (2005).</li></ol>

The protocol presented here is based on previous procedures used for perithecial production for Fusarium spp. (Klittich and Leslie, 1988; Trail and Common, 2000). Standardization of the procedure by which large quantities of ascospores (sufficient for microarray analysis) were generated was essential for the reproducibility of the experiment. It has been reported that environmental factors, age and substrate differences can change the biological character of ascospores (Beyer and Verreet, 2005). Therefore the use of vide...

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml" xml:lang="en" lang="en">

		<div>
		<table border="1">
		<thead>
		<tr>
		<th>Material Name</th>
		<th>Type</th>
		<th>Company</th>
		<th>Catalogue Number</th>
		<th>Comment</th>
		</tr>
		</thead>
		<tbody>

<tr>
<td>Petri dish 9 cm Diameter</td>
<td>Tool</td>
<td>&nbsp;</td>
<td>&nbsp;</td>
<td>&nbsp;</td>
<tr>
<td>Tween 60 (20%)</td>
<td>Reagent</td>
<td>&nbsp;</td>
<td>&nbsp;</td>
<td>&nbsp;</td>
<tr>
<td>Carrot agar (20% w/v organic carrots and 1.5% w/v agar) </td>
<td>Reagent</td>
<td>&nbsp;</td>
<td>&nbsp;</td>
<td>&nbsp;</td>		</tbody>
		</table>
		</div>
			<div>
					</div>

gibberella zeae ascospore production and collection for microarray experiments.

Fusarium graminearum Schwabe (teleomorph Gibberella zeae) is a plant pathogen causing scab disease on wheat and barley that reduces crop yield and grain quality. F. graminearum also causes stalk and ear rots of maize and is a producer of mycotoxins such as the trichothecenes that contaminate grain and are harmful to humans and livestock (Goswami and Kistler, 2004).

The fungus produces two types of spores. Ascospores, the propagules resulting from sexual reproduction, are the main source of primary infection.  These spores are forcibly discharged from mature perithecia and dispersed by wind (Francl et al 1999). Secondary infections are mainly caused by macroconidia which are produced by asexual means on the plant surface. To study the developmental processes of ascospores in this fungus, a procedure for their collection in large quantity under sterile conditions was required. Our protocol was filmed in order to generate the highest level of information for understanding and reproducibility; crucial aspects when full genome gene expression profiles are generated and interpreted. In particular, the variability of ascospore germination and biological activity are dependent on the prior manipulation of the material. The use of video for documenting every step in ascospore production is proposed in order to increase standardization, complying with the increasingly stringent requirements for microarray analysis. The procedure requires only standard laboratory equipment. Steps are shown to prevent contamination and favor time synchronization of ascospores.

Watch this Scientific Journal Video about Gibberella zeae Ascospore Production and Collection for Microarray Experiments. at JoVE.com

Gibberella zeae Ascospore Production and Collection for Microarray Experiments.

To study the developmental processes of ascospores in Gibberella zeae, a procedure for collection under sterile conditions is filmed in order to generate the highest level of information for protocol description. This should facilitate the reproducibility of the experiment, a crucial aspect when full genome expression profile tests are implemented.
