This work was supported by the Fundamental Research Funds for the Central Universities (2017ZY21) and the National Natural Science Foundation of China (21607038).

1. Leaf Collection, Elution and Mass Measurement of PM
<ol>
	<li>Select five healthy individual trees (i.e., five replicates) of each tree species with similar diameter at breast height. Collect four larger branches randomly from four directions of the outer canopy in the middle canopy layer and cut off all intact leaves.
	NOTE: All plants for leaf sampling should be located closely in a greening strip with length and width of about 250 and 60 m, respectively, to ensure that the environment conditions (wind, light, and rain) of these trees are similar. The leaves used in the protocol were collected on October 15th (short dust retention (SDR) period) and October 25th (long dust retention (LDR) period) in 2014, which were 4 and 14 days after the latest rainfall (&#62; 15 mm), respectively. The average levels of PM under the short and long dust retention period (i.e., the duration between the last rainfall and the leaf sampling time) in our experiment were 26 (PM2.5), 57 (PM10), and 111 (PM2.5), 160 &#181;g/m3 (PM10), respectively.
	<ol>
		<li>Place the sampled leaves in labeled valve bags and transport the bags to the laboratory immediately. Store the leaf samples in the fridge.</li>
	</ol>
	</li>
	<li>Wash and dry the beakers in the 80 &#176;C oven. Equilibrate the beakers to room temperature and humidity and weigh the empty beakers (W1).</li>
	<li>Randomly select a certain amount of leaves from leaf samples and put the leaves in a 1000 mL beaker (Beaker A).
	NOTE: The leaf area is about 2000 cm2, which can guarantee all the leaves can be immersed in the water completely and the eluted dust has sufficient weight to be weighed accurately.</li>
	<li>Add 270 mL of deionized water to the Beaker A and immerse the leaves in water completely.
	<ol>
		<li>Stir the water for 60 s with a glass rod in one direction (frequency: 2 seconds for one rotation). Afterwards, pour the eluent into three 100 mL small beakers (Beaker a) evenly.</li>
		<li>Wash the leaves using a fine tipped squeeze bottle with 30 mL of deionized water and transfer the washed leaves to a 1000 mL beaker (Beaker B). Pour the eluent into three 100 mL small beaker (Beaker a) evenly.</li>
	</ol>
	</li>
	<li>Add 270 mL of deionized water to Beaker B and immerse the leaves in water again. Then use a nylon brush to scrub the leaf surface (placing on flat thin plastic plate) with deionized water and avoid destroying the microstructure of leaf surface. Pour the eluent into three 100 mL small beakers (Beaker b).
	<ol>
		<li>Wash the leaves using the squeezable bottle with fine tip with 30 mL of deionized water and transfer the leaves into a 1000 mL beaker (Beaker C). Pour the eluent into three 100 mL small beaker (Beaker b).</li>
	</ol>
	</li>
	<li>Add 270 mL of deionized water to Beaker C and immerse the leaves in water again.
	<ol>
		<li>Put the glass container into the ultrasonic cleaning machine. Using an ultrasonic power of 500 W, clean for 3 min and 10 min for leaves of the broadleaf and needleleaf tree species, respectively. Stir the leaves with a glass rod in one direction (frequency: 2 seconds for one circle) simultaneously.</li>
		<li>Wash the leaves using the squeezable bottle with fine tip with 30 mL of deionized water and pour the eluent into three 100 mL small beakers (beaker c).</li>
	</ol>
	</li>
	<li>Cover a piece of clean filter paper (diameter = 11 cm, area = 94.99 cm2) on each beaker (a, b, c) and dry the beakers in the 80 &#176;C oven for approximately 5 days until the mass of the beakers becomes constant.
	<ol>
		<li>Put the beakers in a balance chamber to equilibrate the temperature and humidity for 30 min, and weigh the mass of each 100 mL beakers (W2). Calculate the mass of PM eluted by each cleaning step by W2-W1.</li>
	</ol>
	</li>
</ol>
2. Measurement of PM Size Distribution and Leaf Area
<ol>
	<li>Add 50 mL of deionized water to each weighed beaker (a, b, c) mentioned above and place these beakers in an ultrasonic cleaning machine for 30 min until the PM disperses in deionized water.</li>
	<li>Add the supernatant in beaker (a, b, c) to the laser granularity instrument and measure the size distribution of PM eluted by different cleaning steps.
	<ol>
		<li>Assume the measured volume percentages to be mass percentages (Q) of different-sized particles. Calculate the proportion of different-sized particles eluted by each cleaning step by equation (1):
		<img alt="Equation 1" src="/files/ftp_upload/58026/58026eq1.jpg" />&#160; &#160;(1)
		where Pi,j represents the mass proportion (%) of the particles within the j diameter class eluted from the leaf surfaces by the cleaning step i; Wi represents the total mass (g) of all sized particles eluted by the cleaning step i; Qi,j represents the mass percentage (%) of the particles within the j diameter class in the total PM mass eluted by the cleaning step i; i is the cleaning step (i.e., WC, BC, and UC); and j is the diameter class, which was set to d &#8804; 1 &#181;m (PM1), 1 &#60; d &#8804; 2.5 &#181;m (PM1-2.5), 2.5 &#60; d &#8804; 5 &#181;m (PM2.5-5), 5 &#60; d &#8804; 10 &#181;m (PM5-10), d &#62; 10 &#181;m (PM&#62;10) in the present study.</li>
	</ol>
	</li>
	<li>Spread leaves on the plastic board and scan the leaves with a high-quality scanner. Use automatic image analysis software to estimate the surface area and projected area of leaves.
	NOTE: The protocol can be paused here.</li>
</ol>
3. Data Presentation and Analysis
<ol>
	<li>Calculate the total removable particulate matter (TRP) as the sum of the ERP and DRP that can be eluted by WC + BC + UC.</li>
	<li>Under different dust retention periods, calculate the total mass of the PM within a specificdiameter class retained on leaves as the sum of the mass of the PM within corresponding diameter class eluted by the different cleaning steps (i.e., WC, BC, and UC).
	<ol>
		<li>Using these data and the leaf area data, calculate the retention efficiency (AEleaf) of the various sized particles on unit leaf surface area using equation (2):
		<img alt="Equation 2" src="/files/ftp_upload/58026/58026eq2.jpg" />&#160; &#160; &#160;(2)
		where LZj and SZj&#160;are the mass (g) of the particles within the j diameter class retained on unit leaf area under the periods of LDR and SDR, respectively; LT and ST are the numbers of days in the periods of LDR and SDR, respectively.</li>
	</ol>
	</li>
	<li>Conduct all the statistical analyses with SPSS software.
	<ol>
		<li>Use the Kolmogorov-Smirnov test and the Levene test to verify the ANOVA assumptions of normality and the homogeneity of variances, respectively, for the elution percentages of the different-sized particles and the PM retention capacity data.</li>
		<li>Apply one-way ANOVA to investigate the effects of the different cleaning steps on the elution percentages of the different-sized particles under various dust retention periods. Use Duncan&#39;s test (P = 0.05) to detect the significant differences among different cleaning steps.</li>
	</ol>
	</li>
</ol>

<ol>
	<li>Baidurela, A., Halik, U., Aishan, T., Nuermaimaiti, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Maximum+dust+retention+of+main+greening+trees+in+arid+land+oasis+cities,+Northwest+China.">Maximum dust retention of main greening trees in arid land oasis cities, Northwest China.</a> Scientia Silvae Sinicae. 51, 57-63 (2015).</li><li>Fan, S. Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dust+capturing+capacities+of+twenty-six+deciduous+broad-leaved+trees+in+Beijing.">Dust capturing capacities of twenty-six deciduous broad-leaved trees in Beijing.</a> Chinese Journal of Plant Ecology. 39, 736-745 (2015).</li><li>Dzierzanowski, K., Gawro&#324;ski, S. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Use+of+trees+for+reducing+particulate+matter+pollution+in+air.">Use of trees for reducing particulate matter pollution in air.</a> Challenges of Modern Technology. 2, 69-73 (2011).</li><li>Przybysz, A., S&#230;b&#248;, A., Hanslin, H. M., Gawro&#324;ski, S. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Accumulation+of+particulate+matter+and+trace+elements+on+vegetation+as+affected+by+pollution+level,+rainfall+and+the+passage+of+time.">Accumulation of particulate matter and trace elements on vegetation as affected by pollution level, rainfall and the passage of time.</a> Science of the Total Environment. 481, 360-369 (2014).</li><li>Chen, L. X., Liu, C. M., Zou, R., Yang, M., Zhang, Z. Q. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Experimental+examination+of+effectiveness+of+vegetation+as+bio-filter+of+particulate+matter+in+the+urban+environment.">Experimental examination of effectiveness of vegetation as bio-filter of particulate matter in the urban environment.</a> Environmental Pollution. 208, 198-208 (2016).</li><li>Zhang, Z. D., Xi, B. Y., Cao, Z. G., Jia, L. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Exploration+of+a+quantitative+methodology+to+characterize+the+retention+of+PM2.5+and+other+atmospheric+particulate+matter+by+plant+leaves:+Taking+Populus+tomentosa+as+an+example.">Exploration of a quantitative methodology to characterize the retention of PM2.5 and other atmospheric particulate matter by plant leaves: Taking Populus tomentosa as an example.</a> Chinese Journal of Applied Ecology. 25, 2238-2242 (2014).</li><li>Zhang, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Studies+on+the+Existing+Shrubs+of+the+Road+in+Changchun+and+the+Dust+Retention+Capacity+of+the+Three+Shrubs.">Studies on the Existing Shrubs of the Road in Changchun and the Dust Retention Capacity of the Three Shrubs.</a> Jilin Agricultural University. , (2013).</li><li>Beckett, K. P., Freer-Smith, P., Taylor, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effective+tree+species+for+local+air-quality+management.">Effective tree species for local air-quality management.</a> Journal of Arboriculture. 163, 12-19 (2000).</li><li>Wang, H. X., Shi, H., Wang, Y. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamics+of+the+captured+quantity+of+particulate+matter+by+plant+leaves+under+typical+weather+conditions.">Dynamics of the captured quantity of particulate matter by plant leaves under typical weather conditions.</a> Acta Ecologica Sinica. 35, 1696-1705 (2015).</li><li>Wang, Z. H., Li, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Capacity+of+dust+uptake+by+leaf+surface+of+Euonymus+Japonicus+Thunb.+and+the+morphology+of+captured+particle+in+air+polluted+city.">Capacity of dust uptake by leaf surface of Euonymus Japonicus Thunb. and the morphology of captured particle in air polluted city.</a> Ecology &amp; Environment. 15, 327-330 (2006).</li><li>Liu, H. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analysis+of+the+Role+of+Ultrasonic+Cleaning+in+Quantitative+Evaluation+of+the+Retention+of+Tree+Leaves+to+Atmospheric+Particles:+A+Case+Study+with+Ginkgo+biloba.">Analysis of the Role of Ultrasonic Cleaning in Quantitative Evaluation of the Retention of Tree Leaves to Atmospheric Particles: A Case Study with Ginkgo biloba.</a> Scientia Silvae Sinicae. 52 (12), 133-140 (2016).</li><li>Chen, W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dust+absorption+effect+of+urban+conifers+in+Northeast+China.">Dust absorption effect of urban conifers in Northeast China.</a> Chinese. Journal of Applied Ecology. 14 (12), 2113-2116 (2003).</li><li>Li, H., Yang, S. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Changes+of+suspended+particulates+adhering+to+salt+marsh+plants.">Changes of suspended particulates adhering to salt marsh plants.</a> Acta Oceanolo Giga Sinica. 32 (1), 114-119 (2010).</li><li>Nguyen, T., Yu, X. X., Zhang, Z. M., Liu, M. M., Liu, X. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Relationship+between+types+of+urban+forest+and+PM2.5+capture+at+three+growth+stages+of+leaves.">Relationship between types of urban forest and PM2.5 capture at three growth stages of leaves.</a> Journal of Environmental Sciences. 27 (1), 33-41 (2015).</li><li>Fan, S. X., Li, X. P., Han, J., Cao, Y., Dong, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Field+assessment+of+the+impacts+of+landscape+structure+on+different-sized+airborne+particles+in+residential+areas+of+Beijing,+China.">Field assessment of the impacts of landscape structure on different-sized airborne particles in residential areas of Beijing, China.</a> Atmospheric Environment. 166, 192-203 (2017).</li><li>Liu, J. Q., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ultrasonic+based+investigation+on+particulate+size+distribution+and+retention+efficiency+of+particulate+matters+retained+on+tree+leaves-Taking+Ginkgo+biloba+and+Pinus+tabuliformis+as+examples.">Ultrasonic based investigation on particulate size distribution and retention efficiency of particulate matters retained on tree leaves-Taking Ginkgo biloba and Pinus tabuliformis as examples.</a> Chinese Journal of Applied Ecology. 40, 798-809 (2016).</li><li>Yao, X. Y., Hu, Y. S., Liu, Y. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dust-retention+effect+of+8+common+greening+Tree+Species+in+Beijing.">Dust-retention effect of 8 common greening Tree Species in Beijing.</a> Journal of Northwest Forestry University. 29, 92-95 (2014).</li><li>Wang, H. X., Shi, H., Wang, Y. H., Duan, J., Wang, Y. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Influence+of+surface+structure+on+the+particle+size+distribution+captured+by+Ligustrum+lucidum.">Influence of surface structure on the particle size distribution captured by Ligustrum lucidum.</a> Journal of Safety &amp; Environment. 1, 258-262 (2015).</li></ol>

The authors have nothing to disclose.

Accurate and proper collection of the PM retained on leaf surfaces is the basis for assessing the PM removal abilities of different tree species. However, the conventional cleaning method (WC or plus BC) cannot completely remove the dust on leaf surfaces, which has been confirmed by scanning electron microscopy10. This was further demonstrated clearly by the present study (Figure 1, Figure 2,&#160;Fig...

The abilities of different tree species to remove PM from ambient air can be assessed through quantifying the mass of PM retained on leaf surfaces. To achieve this objective, the subtraction method1,2, the membrane filter method3,4,5, and the elution-weighing method coupled with particle size analysis6 have been applied to quantitatively estimate the mass of PM2.5 (diameter &#8804; 2.5 &#181;m), PM10 (diameter &#8804; 10 &#181;m) or total suspended particulate (TSP) retained on leaves. However, the accuracy of these methods basically depends on their performance in collecting PM retained on the leaf surfaces. At present, the conventional leaf cleaning method used in related studies often includes one or two steps, namely only water washing (soak and rinse leaves using deionized water)3,7 or plus brushing5,8,9. However, some studies10,11 have demonstrated that PM on leaf surfaces could not be completely eluted by the conventional cleaning method. As ultrasonic cleaning has the advantages of high speed, high quality, and little damage to the surface of the object, it has great potential to be used to collect the PM retained on leaf surfaces with complex microstructures. At present, ultrasonic cleaning has been applied in some studies to collect PM retained on leaf surfaces (i.e., put the leaves into deionized water, and use the ultrasonic cleaner to elute PM)12,13. However, this method is only used as a supplement to a leaf cleaning method, while it is not known whether the ultrasonic cleaning has a positive effect on collecting PM from leaf surfaces and its optimum operating parameters are also not clear. Our previous research has shown that the PM retained on Ginkgo biloba leaf surface could be completely eluted without destroying the leaf surfaces, if a proper ultrasonic cleaning procedure was supplemented to the conventional cleaning method11. However, the stability and general applicability of the ultrasonic cleaning parameters (ultrasonic power, time, and other information) to different plant species experiencing different dust retention periods are still not clear.
Currently, the mass of PM2.5, PM10, or TSP on unit leaf area has often been utilized to evaluate the abilities of different tree species to remove PM from ambient air14,15. Under the natural condition, the PM retained on leaf surfaces can be classified into two parts: the first part is the PM that can fall off leaves due to the effects of wind and rainfall, while the other part is the PM that is tightly adhered to leaf surfaces and cannot be easily washed off by rainfall. However, few studies have focused on the mass of both types of PM on leaf surfaces. In addition, the PM retention periods of leaves in different studies differ enormously. Thus, the comparability of the results of these studies will be poor, if the mass of PM retained on unit leaf area is adopted to assess the PM removal abilities of trees16. Consequently, the PM retention efficiency (the mass of PM retained on unit leaf area per unit time), as an alternative, was proposed to evaluate the PM purification effects of urban trees5,17. In general, there is still a lack of research in this aspect. It is extremely necessary to carry out relevant studies for different tree species to provide methodological basic and data support for assessing the PM removal abilities of different tree species accurately.
Here, three broadleaf tree species (G. biloba, Sophora japonica, and Salix babylonica) and two needleleaf tree species (Pinus tabuliformis and Sabina chinensis) were selected to evaluate their PM removal abilities under two PM retention periods. The leaf sampling site was in Xitucheng Park (39.97&#176; N, 116.36&#176; E), located in an area with heavy pollution in Beijing. The three specific objectives of this study were: (1) to assess the efficiency of different leaf cleaning methods (water cleaning (WC), brush cleaning (BC), and ultrasonic cleaning (UC)) in eluting the PM on leaves, (2) to verify the effect of ultrasonic cleaning on eluting PM, and (3) to assess the retention efficiency of different tree species to PM1, PM2.5, PM5, PM10, and TSP.

<table><tbody><tr><td>MSA2258-1CE-DU ten-thousandth scale</td><td>Sartorius Scientific Instruments (Beijing) Co., Ltd.</td><td>MSA2258-1CE-DU</td><td>precision: 0.01 mg</td></tr><tr><td>The IS13320 laser granularity instrument</td><td>Beckman Coulter, Brea, USA</td><td>IS13320</td><td>working conditions: liquid/power samples; particle size range of measurement: 0.017-2000 &amp;mu;m</td></tr><tr><td>Epson Twain Pro high-quality scanner</td><td>Seiko Epson, Nagano, Japan</td><td>expression1680</td><td></td></tr><tr><td>Automatic image analysis software WinRHIZO</td><td>Regent Instruments Inc., Quebec, Canada</td><td>WinRHIZO Pro 2013a</td><td></td></tr></tbody></table>

assessing the particulate matter removal abilities of tree leaves

Based on the conventional cleaning methods (water cleaning (WC) + brush cleaning (BC)), this study evaluated the influence of ultrasonic cleaning (UC) on collecting various sized particulate matter (PM) retained on leaf surfaces. We further characterized the retention efficiency of leaves to various sized PM, which will help to assess the abilities of urban trees to remove PM from ambient air quantitatively.
Taking three broadleaf tree species (Ginkgo biloba, Sophora japonica, and Salix babylonica) and two needleleaf tree species (Pinus tabuliformis and Sabina chinensis) as the research objects, leaf samples were collected 4 days (short PM retention period) and 14 days (long PM retention period) after the latest rainfall. PM retained on the leaf surfaces was collected by means of WC, BC, and UC in sequence. Then, retention efficiencies of leaves (AEleaf) to three types of the various sized PM, including easily removable PM (ERP), difficult-to-remove PM (DRP), and totally removable PM (TRP), were calculated. Only around 23%-45% of the total PM retained on leaves could be cleaned off and collected by WC. When the leaves were cleaned through WC+BC, the underestimation of the PM retention capacity of different tree species was in the range of 29%-46% for various sized PM. Almost all PM retained on leaves could be removed if UC was supplemented to WC+BC.
In conclusion, if the UC was complemented after the conventional cleaning methods, more PM on leaf surfaces could be eluted and collected. The procedure developed in this study can be used for assessing the PM removal abilities of different tree species.

The PM retained on leaf surfaces had two types under natural conditions. The PM falls off easily by rainfall and wind under natural conditions is defined as the easily removable particulate matter (ERP). This type of PM was represented by the PM eluted by WC in this study. The PM that tightly adheres to leaf surfaces and cannot be easily washed off by BC and UC is defined as the difficult-to-remove particulate matter (DRP). This kind of PM cannot be eluted by natural rainfall and wind.</p...

Watch this Scientific Journal Video about Assessing the Particulate Matter Removal Abilities of Tree Leaves at JoVE.com

Assessing the Particulate Matter Removal Abilities of Tree Leaves

The ultrasonic cleaning method was applied to elute the particulate matter (PM) retained on leaf surfaces after PM was eluted by the conventional cleaning methods (water cleaning only or water cleaning plus brush cleaning). The methodology can help to improve the estimation accuracy for PM retention capacity of leaves.

Based on the conventional cleaning methods (water cleaning (WC) + brush cleaning (BC)), this study evaluated the influence of ultrasonic cleaning (UC) on ...
