The sections for the molecular machine-based detection should be prepared first because their preparation takes more time than the assembly of the molecular device. The construct works well with 5-6&mu;m-thick sections cut from paraformaldehyde-fixed, paraffin-embedded tissue blocks. Use slide brands which retain sections well, such as ProbeOn Plus charged and precleaned slides (Fisher Scientific) or similar. We recommend at first using a tissue with a well-known pattern of DNA damage which contains both DNase I- and DNase II-type breaks, such as dexamethasone-treated apoptotic rat thymus 13,14.
1. Preparation of sections
<ol>
	<li>Place the sections in a slide rack and dewax in xylene for 15 min, transfer to a fresh xylene bath for an additional 5 minutes.</li>
	<li>Rehydrate by passing through graded ethanol concentrations: 96% Ethanol -2x5min; 80% Ethanol - 5min; water - 2x5 min.</li>
	<li>Digest section with Proteinase K. Use 100&mu;L of a 50&mu;g/mL solution per section. Incubate 15' at room temperature (23&deg; C) in a humidified chamber. The time may need adjustment depending on the tissue type. Hard tissues might require longer digestion. Times of 15-25 min are usually used. Insufficient digestion may result in the weaker signal. Overdigestion on the other hand results in signal disappearance and section disruption.</li>
	<li>Rinse in distilled water for 2x10 min.</li>
	<li>Apply 100 &mu;L per section of 2% BSA for preblocking. Incubate for 15 min at room temperature (23&deg; C). During this time assemble the molecular machine.</li>
</ol>
2. Molecular machines assembly
All reagents are scaled for 25 &mu;L total volume, which is sufficient for a single detection in an average size tissue section (10x10mm). The volume can be scaled up as needed.
<ol>
	<li>Combine in a small plastic tube in this order:</li>
</ol>
<table border="1">
	<tbody>
		<tr>
			<td>
			<ol>
				<li>Bidistilled water;</li>
				<li>15% polyethylene glycol-8000;</li>
				<li>Solution of 66 mM-Tris HCl, pH 7.5, 5 mM MgCl2, 0.1 mM dithioerythritol, 1 mM ATP, (i.e. regular T4 DNA ligase buffer);</li>
				<li>70 pmoles of Oligonucleotide 1,</li>
				<li>215 pmoles (1.76 - 7.1 &mu;g) VACC TOPO</li>
				<li>10 units T4 DNA ligase (500 U/mL)</li>
			</ol>
			</td>
		</tr>
	</tbody>
</table>
<ol start="2">
	<li>Mix gently by pipetting. The molecular construct almost instantly self-assembles in this solution and can be used immediately at room temperature (23&deg; C). Increasing the temperature to 37&deg; C blocks the T4 DNA ligase-based component of the labeling.</li>
</ol>
3. Using molecular machines in tissue sections to dual label 5'OH and 5'PO4 DNA breaks
<ol>
	<li>Aspirate the preblocking solution and apply 25&mu;L of the full reaction mix containing 70 pmoles of Oligonucleotide 1, 53 - 215 pmoles (1.76 - 7.1 &mu;g) VACC TOPO and 10 units T4 DNA ligase (500 U/mL) in solution of 66 mM-Tris HCl, pH 7.5, 5mM MgCl2, 0.1 mM dithioerythritol, 1 mM ATP, and 15% polyethylene glycol-8000. The same sequence oligonucleotide carrying a single FITC label, Oligonucleotide 2, can be used instead for detection of a single type of DNA breaks. In such case omit ligase from the labeling reaction. Also in this situation a solution of 50mM Tris-HCL, pH 7.4, 15% PEG-8000 can be used instead of T4 DNA ligase buffer.</li>
	<li>Incubate for 1 hr at room temperature (23&deg; C) in a humidified chamber with a plastic coverslip. Protect from light. Lowering of the temperature to 16&deg; C reduces the ligase-based signal; the temperature increase to 37&deg; C completely eliminates the ligase-based signal. A partial inhibition of ligase sometimes occurs in the reaction mix, possibly due to contaminants introduced with topoisomerase preparations. Therefore, longer incubation (2-4 hours) might be required especially when significant numbers of ligase-labeled breaks are present. Although both ligase and topo signals can be observed at this stage, in many instances the ligase signal can be further enhanced by re-application of the reaction mix without VACC TOPO and dual-labeled Oligonucleotide, but containing a hairpin shaped oligonucleotide (Oligonucleotide 3) (35 mg/mL) and T4 DNA ligase (250 U/mL). To enhance signal proceed to Step 3, to see the reaction without enhancement go to Step 5.</li>
	<li>Remove coverslips by gently immersing the slides vertically in a Coplin jar containing water at room temperature. Aspirate excess water.</li>
	<li>Enhance ligase signal by applying 25 &mu;L of reaction mix without VACC TOPO and Oligonucleotide 1, but containing Oligonucleotide 3: 66 mM-Tris HCl, pH 7.5, 5 mM MgCl2, 0.1 mM dithioerythritol, 1 mM ATP, and 15% polyethylene glycol-8000, 5 units T4 DNA ligase, 35 mg/mL Oligonucleotide 3 (blunt ended hairpin). The total volume of the labeling solution can be scaled up to accommodate the bigger sections. Incubate for 18 hr (overnight) at room temperature (23&deg; C) in a humidified chamber with a plastic coverslip.</li>
	<li>Remove coverslips by gently immersing the slides vertically in Coplin jar containing water at room temperature. Then wash section 3x10 min in distilled water.</li>
	<li>Rinse with sodium bicarbonate buffer. Alkaline solution rinse enhances FITC fluorescence, which is pH sensitive and is significantly reduced below pH 7.</li>
	<li>Cover section with an antifading solution (Vectashield with DAPI), coverslip and analyze the signal using a fluorescent microscope. Double-strand DNA breaks with 5'OH will fluoresce green, 5'PO4 breaks - will fluoresce red (Figure 2).</li>
</ol>
4. Representative Results
<img alt="Figure 2." src="/files/ftp_upload/3628/3628fig2.jpg" />
Figure 1. Semi-artificial molecular machine detects two types of DNA damage in situ. The fluorescent machine self-assembles when VACC TOPO binds to the double-hairpin 32-mer. The machine begins operation by splitting itself into two detector units via topoisomerase-made cut at the 3' end of the recognition sequence. This results in a cyclic process where the FITC-labeled unit continuously separates and religates back to the rhodamine-labeled unit. This persists until a detectable DNA break is encountered. When such an alternative acceptor (5'OH blunt end DNA break) is present in the tissue section, the FITC part will ligate to it. The remaining rhodamine part will attach to 5' PO4 DNA blunt end breaks with the help of T4 DNA ligase. Consequently, both types of DNA breaks are simultaneously detected.
<img alt="Figure 1." src="/files/ftp_upload/3628/3628fig1.jpg" />

Figure 2. Molecular machine dual labels two types of DNA breaks in a tissue section of dexamethasone-treated thymus. Blunt-ended DNA breaks of DNase I- and DNase II-type are detected in the thymic cortical areas undergoing apoptosis. Green cytoplasmic fluorescence (5'OH DNA breaks) marks cortical macrophages digesting nuclear material of apoptotic thymocytes. This signal is produced by VACC TOPO, and localizes to phagolysosomes with DNA containing 5'OH double-strand breaks 11,12. Red fluorescence (5'PO4 breaks) labels nuclei of apoptotic thymocytes not engulfed by macrophages. Massive numbers of thymocytes simultaneously undergo apoptosis accompanied by generation of 5'PO4 double-strand breaks, visualized by ligase-based labeling. These breaks are located at the nuclear periphery, forming ring-shaped patterns. All cellular nuclei are visualized by counterstaining with DAPI (blue fluorescence).

<ol>
	<li>Meacham, G. C., Patterson, C., Zhang, W., Younger, J. M., Cyr, D. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Nature. Cell. Biol. 3, 100-105 (2001).</li><li>Schuldt, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamic+Pol+expeditions.">Dynamic Pol expeditions.</a> Nature. Cell. Biol. 4, E279-E279 (2002).</li><li>Urry, D. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+machines:+how+motion+and+other+functions+of+living+organisms+can+result+from+reversible+chemical+changes.">Molecular machines: how motion and other functions of living organisms can result from reversible chemical changes.</a> Angew. Chem. Int. Ed. Engl. 32, 819-841 (1993).</li><li>Schneider, T. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Theory+of+molecular+machines+I.+Channel+capacity+of+molecular+machines.">Theory of molecular machines I. Channel capacity of molecular machines.</a> J. Theor. Biol. 148, 83-123 (1991).</li><li>McClare, C. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chemical+machines,+Maxwell's+demon+and+living+organisms.">Chemical machines, Maxwell's demon and living organisms.</a> J. Theor. Biol. 30, 1-34 (1971).</li><li>Spirin, A. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ribosome+as+a+molecular+machine.">Ribosome as a molecular machine.</a> FEBS Lett. 514, 2-10 (2002).</li><li>Fabbrizzi, L., Foti, F., Licchelli, M., Maccarini, P. M., Sacchi, D., Zema, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Light-emitting+molecular+machines:+pH-induced+intramolecular+motions+in+a+fluorescent+nickel(II)+scorpionate+complex.">Light-emitting molecular machines: pH-induced intramolecular motions in a fluorescent nickel(II) scorpionate complex.</a> Chemistry. 8, 4965-4972 (2002).</li><li>Drexler, K. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Nanosystems: Molecular Machinery, Manufacturing and Computation. , (1992).</li><li>Freitas, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Nanomedicine: basic capabilities. , (1999).</li><li>Didenko, V. V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DNA+probes+using+fluorescence+resonance+energy+transfer+(FRET):+designs+and+applications.">DNA probes using fluorescence resonance energy transfer (FRET): designs and applications.</a> BioTechniques. 31, 1106-1121 (2001).</li><li>Minchew, C. L., Didenko, V. V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fluorescent+probes+detecting+the+phagocytic+phase+of+apoptosis:+enzyme-substrate+complexes+of+topoisomerase+and+DNA.">Fluorescent probes detecting the phagocytic phase of apoptosis: enzyme-substrate complexes of topoisomerase and DNA.</a> Molecules. 16, 4599-4614 (2011).</li><li>Didenko, V. V., Minchew, C. L., Shuman, S., Baskin, D. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Semi-artificial+fluorescent+molecular+machine+for+DNA+damage+detection.">Semi-artificial fluorescent molecular machine for DNA damage detection.</a> Nano. Letters. 4, 2461-2466 (2004).</li><li>Didenko, V. V., Hornsby, P. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Presence+of+double-strand+breaks+with+single-base+3'+overhangs+in+cells+undergoing+apoptosis+but+not+necrosis.">Presence of double-strand breaks with single-base 3' overhangs in cells undergoing apoptosis but not necrosis.</a> J. Cell Biol. 135, 1369-1376 (1996).</li><li>Didenko, V. V., Tunstead, J. R., Hornsby, P. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Biotin-labeled+hairpin+oligonucleotides.+Probes+to+detect+double-strand+breaks+in+DNA+in+apoptotic+cells.">Biotin-labeled hairpin oligonucleotides. Probes to detect double-strand breaks in DNA in apoptotic cells.</a> Am. J. Pathol. 152, 897-902 (1998).</li><li>Jones, R. A. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Soft Machines: Nanotechnology and life. , (2007).</li><li>Samejima, K., Earnshaw, W. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Trashing+the+genome:+Role+of+nucleases+during+apoptosis.">Trashing the genome: Role of nucleases during apoptosis.</a> Nat. Rev. Mol. Cell. Biol. 6, 677-688 (2005).</li></ol>

No conflicts of interest declared.

In this video, we demonstrate how to assemble and use a dual-labeling DNA damage sensor. The sensor is a molecular machine driven by bio-molecular engine, a virus-encoded protein VACC TOPO linked with artificial components. The presented development exemplifies a bio-enabled approach which advocates adapting biological structures, architectures and actual parts and components of cells to the design of non-toxic molecular scale devices 12,15. This approach resolves two issues inherent to the field of in viv...

in vitro assembly of semi-artificial molecular machine and its use for detection of dna damage

Naturally occurring bio-molecular machines work in every living cell and display a variety of designs 1-6. Yet the development of artificial molecular machines centers on devices capable of directional motion, i.e. molecular motors, and on their scaled-down mechanical parts (wheels, axels, pendants etc) 7-9. This imitates the macro-machines, even though the physical properties essential for these devices, such as inertia and momentum conservation, are not usable in the nanoworld environments 10. Alternative designs, which do not follow the mechanical macromachines schemes and use mechanisms developed in the evolution of biological molecules, can take advantage of the specific conditions of the nanoworld. Besides, adapting actual biological molecules for the purposes of nano-design reduces potential dangers the nanotechnology products may pose. Here we demonstrate the assembly and application of one such bio-enabled construct, a semi-artificial molecular device which combines a naturally-occurring molecular machine with artificial components. From the enzymology point of view, our construct is a designer fluorescent enzyme-substrate complex put together to perform a specific useful function. This assembly is by definition a molecular machine, as it contains one 12. Yet, its integration with the engineered part - fluorescent dual hairpin - re-directs it to a new task of labeling DNA damage12.
Our construct assembles out of a 32-mer DNA and an enzyme vaccinia topoisomerase I (VACC TOPO). The machine then uses its own material to fabricate two fluorescently labeled detector units (Figure 1). One of the units (green fluorescence) carries VACC TOPO covalently attached to its 3'end and another unit (red fluorescence) is a free hairpin with a terminal 3'OH. The units are short-lived and quickly reassemble back into the original construct, which subsequently recleaves. In the absence of DNA breaks these two units continuously separate and religate in a cyclic manner. In tissue sections with DNA damage, the topoisomerase-carrying detector unit selectively attaches to blunt-ended DNA breaks with 5'OH (DNase II-type breaks)11,12, fluorescently labeling them. The second, enzyme-free hairpin formed after oligonucleotide cleavage, will ligate to a 5'PO4 blunt-ended break (DNase I-type breaks)11,12, if T4 DNA ligase is present in the solution 13,14 . When T4 DNA ligase is added to a tissue section or a solution containing DNA with 5'PO4 blunt-ended breaks, the ligase reacts with 5'PO4 DNA ends, forming semi-stable enzyme-DNA complexes. The blunt ended hairpins will interact with these complexes releasing ligase and covalently linking hairpins to DNA, thus labeling 5'PO4 blunt-ended DNA breaks.
This development exemplifies a new practical approach to the design of molecular machines and provides a useful sensor for detection of apoptosis and DNA damage in fixed cells and tissues.
