שלב מעבר לברט: הקרינה על ידי מאוגד עירור מההארה (דלק)

The overall goal of the following experiment is to demonstrate the simplicity of fuel and observe the generation of red photons due to radiative excitation emission events. This is achieved by combining bioluminescent bacteria and luminescent nanoparticles for the production of fuel. Next, a bioluminescence plate reader is used to observe the resulting red photons that arise from fuel results are obtained that show a substantial quantity of red photons can be produced when the bioluminescent bacteria and quantum dots are maintained within the same solution.

Based on the observed increase in red photon flux, The implications of this technique extend towards questioning the paradigm of NCE residential entry transfer or Brett. That is often reported in the literature Starting from individual colonies. On standard culture plates start overnight cultures of luminescent bacteria.

Here, Vibrio Fisher Eye were used the day of experimentation. Initiate fresh subcultures allow them to progress until an optical density or OD at 600 nanometers of one to 1.5 is achieved. Use bacteria in similar growth states in which they produce intense signals to achieve comparable results.

Combine aliquots of 100 microliters from each with either five microliters of the fluorescent probe, QD 7 0 5 or physiological saline. Then add the mixture to 895 microliters of physiological saline and standard spectroscopic cuvettes. Place the filled cuvettes into a whole animal bioluminescence imager and take the measurements under the appropriate filter sets.

Here the 710 to 730 nanometer emission filter was used to perform fuel over varying distances. Fill two reduced volume plastic photometric cuvettes with either 50 microliters of QD 7 0 5 or 97.2 microliters of non fluorescent 48 nanometer polystyrene microspheres in a total volume of one milliliter of physiological saline. This ensures similar solid surface area per total volume between the two entities.

Prepare a light source qve by encasing a third qve with standard black tape or some other opaque material capable of blocking light. Carefully prepare two identical optical windows on opposite sides of the vete. Add a one milliliter aliquot of Vibrio fii or other culture from a fresh subculture into the light source vete and cover it with an opaque material such as black paper to reduce any light contamination.

Next place the previously filled cuvettes directly onto either side of the light source vete in the imager. Visualize the three Q vets under the appropriate emission filters such as the total light and 710 to 730 nanometer emission filters with exposure times of 10, 30 and 30 seconds respectively. Acquire a fluorescence image at 450 to 480 nanometers excitation and 710 to 730 nanometers emission to validate the QD 7 0 5 location.

Reposition both external Q vets at equivalent further distances from the Central Q Vet. Then visualize and acquire a fluorescence image before repeating this process again until a final face-to-face distance of three centimeters is achieved. Fill two reduced volume cuvettes with one milliliter solutions containing either a fluoro four or a fluorescent nanoparticle of interest in one and physiological saline with non fluorescent nanoparticles as the negative control in the other.

Add a one milliliter aliquot of fresh Vibrio FII or other luminescent bacteria to a blacked out third vete containing two physically equal optical windows situated on opposite side cover their vete with an opaque substance such as a piece of black paper at a short but equal distance. Place the two reduced volume cuvettes on either side of the blacked out Q vet and visualize under the appropriate filters here a distance of 0.7 centimeters was used. Repeat with the other floor force upon of the qd 7 0 5 to the bacteria.

A substantial increase in the number of red photons is observed compared to the bacteria only. Control fuel can occur over long distances in the absence of any absorber. This distance dependence can be characterized by the inverse square law.

For point sources. The targeting of the flora fours to the bacterial membrane appears to have little to no effect on the overall amount of fuel signal generated. In this context, targeted fuel is maintained even after several washing steps.

After watching this video, you should have a good idea how to reconstitute fuel under multiple modalities as a means to generate red photons from radiative excitation emission events.
