<p class="jove_content">Agradecemos a Silke Classen del Instituto de investigación para el análisis de ecosistemas y evaluación (gaiac), RWTH Aquisgrán para su asistencia en el establecimiento de los conjuntos de primer grupo específico utilizado en el presente Protocolo. También agradecemos a Peter Martin y Laura Schynawa de la Universidad de Kiel para la colaboración en los experimentos de los ácaros de agua. También agradecemos a los asistentes de laboratorio técnico para mantenimiento de laboratorio funcionando sin problemas y preparar el registro de empresas y números de catálogo. Este trabajo fue financiado por la Fundación de investigación alemana (DFG; proyecto GE 2219/3-1).</p>

<ol>
	<li>Carreon-Martinez, L., Heath, D. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Revolution+in+food+web+analysis+and+trophic+ecology:+diet+analysis+by+DNA+and+stable+isotope+analysis.">Revolution in food web analysis and trophic ecology: diet analysis by DNA and stable isotope analysis.</a> <em style='font-style: italic'>Mol Ecol</em>. <b>9</b> (1), 25-27 (2010).</li><li>Hardy, C. M., Krull, E. S., Hartley, D. M., Oliver, R. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Carbon+source+accounting+for+fish+using+combined+DNA+and+stable+isotope+analyses+in+a+regulated+lowland+river+weir+pool.">Carbon source accounting for fish using combined DNA and stable isotope analyses in a regulated lowland river weir pool.</a> <em style='font-style: italic'>Mol Ecol</em>. <b>19</b> (1), 197-212 (2010).</li><li>Baxter, C. V., Fausch, K. D., Saunders, W. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tangled+webs:+reciprocal+flows+of+invertebrate+prey+link+streams+and+riparian+zones.">Tangled webs: reciprocal flows of invertebrate prey link streams and riparian zones.</a> <em style='font-style: italic'>Freshwater Biol</em>. <b>50</b> (2), 201-220 (2005).</li><li>Baxter, C. V., Fausch, K. D., Murakami, M., Chapman, P. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fish+invasion+restructures+stream+and+forest+food+webs+by+interrupting+reciprocal+prey+subsidies.">Fish invasion restructures stream and forest food webs by interrupting reciprocal prey subsidies.</a> <em style='font-style: italic'>Ecol</em>. <b>85</b> (10), 2656-2663 (2004).</li><li>Traugott, M., Kamenova, S., Ruess, L., Seeber, J., Plantegenest, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Empirically+Characterising+Trophic+Networks:+What+Emerging+DNA-Based+Methods,+Stable+Isotope+and+Fatty+Acid+Analyses+Can+Offer.">Empirically Characterising Trophic Networks: What Emerging DNA-Based Methods, Stable Isotope and Fatty Acid Analyses Can Offer.</a> <em style='font-style: italic'>Adv. Ecol. Res. Vol 49: Ecological Networks in an Agricultural World</em>. <b>49</b>, 177-224 (2013).</li><li>Diaz Arredondo, M. A., Guzman del Proo, S. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Feeding+habits+of+the+spiny+lobster+(Panulirus+interruptus+Randall,+1840)+in+Bahia+Tortugas,+Baja+California+Sur.">Feeding habits of the spiny lobster (Panulirus interruptus Randall, 1840) in Bahia Tortugas, Baja California Sur.</a> <em style='font-style: italic'>Cienc Mar</em>. <b>21</b> (4), 439-462 (1995).</li><li>Letourneur, Y., Galzin, R., Harmelin-Vivien, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Temporal+variations+in+the+diet+of+the+damselfish+Stegastes+nigricans+(Lacep&#232;de)+on+a+R&#233;union+fringing+reef.">Temporal variations in the diet of the damselfish Stegastes nigricans (Lacep&#232;de) on a R&#233;union fringing reef.</a> <em style='font-style: italic'>J Exp Mar Biol Ecol</em>. <b>217</b> (1), 1-18 (1997).</li><li>Akin, S., Winemiller, K. O. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Seasonal+variation+in+food+web+composition+and+structure+in+a+temperate+tidal+estuary.">Seasonal variation in food web composition and structure in a temperate tidal estuary.</a> <em style='font-style: italic'>Estuar Coast</em>. <b>29</b> (4), 552-567 (2006).</li><li>Redd, K. S., Jarman, S. N., Frusher, S. D., Johnson, C. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+molecular+approach+to+identify+prey+of+the+southern+rock+lobster.">A molecular approach to identify prey of the southern rock lobster.</a> <em style='font-style: italic'>Bull Entomol Res</em>. <b>98</b> (3), 233-238 (2008).</li><li>Gergs, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dreissena+polymorpha+in+Lake+Constance:+An+example+of+a+keystone+engineer?.">Dreissena polymorpha in Lake Constance: An example of a keystone engineer?.</a> <em style='font-style: italic'>Universit&#228;t Konstanz</em>. , (2009).</li><li>Sheppard, S. K., Harwood, J. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advances+in+molecular+ecology:+tracking+trophic+links+through+predator-prey+food-webs.">Advances in molecular ecology: tracking trophic links through predator-prey food-webs.</a> <em style='font-style: italic'>Funct Ecol</em>. <b>19</b> (5), 751-762 (2005).</li><li>Jarman, S. N., Ward, R. D., Elliott, N. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Oligonucleotide+primers+for+PCR+amplification+of+coelomate+introns.">Oligonucleotide primers for PCR amplification of coelomate introns.</a> <em style='font-style: italic'>Mar Biotechnol (NY)</em>. <b>4</b> (4), 347-355 (2002).</li><li>Verma, S. K., Singh, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Novel+universal+primers+establish+identity+of+an+enormous+number+of+animal+species+for+forensic+application.">Novel universal primers establish identity of an enormous number of animal species for forensic application.</a> <em style='font-style: italic'>Mol Ecol Notes</em>. <b>3</b> (1), 28-31 (2003).</li><li>Deagle, B. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+scatology+as+a+tool+to+study+diet:+analysis+of+prey+DNA+in+scats+from+captive+Steller+sea+lions.">Molecular scatology as a tool to study diet: analysis of prey DNA in scats from captive Steller sea lions.</a> <em style='font-style: italic'>Mol Ecol</em>. <b>14</b> (6), 1831-1842 (2005).</li><li>Jarman, S. N., Deagle, B. E., Gales, N. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Group-specific+polymerase+chain+reaction+for+DNA-based+analysis+of+species+diversity+and+identity+in+dietary+samples.">Group-specific polymerase chain reaction for DNA-based analysis of species diversity and identity in dietary samples.</a> <em style='font-style: italic'>Mol Ecol</em>. <b>13</b> (5), 1313-1322 (2004).</li><li>Jarman, S. N., Redd, K. S., Gales, N. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Group-specific+primers+for+amplifying+DNA+sequences+that+identify+Amphipoda,+Cephalopoda,+Echinodermata,+Gastropoda,+Isopoda,+Ostracoda+and+Thoracica.">Group-specific primers for amplifying DNA sequences that identify Amphipoda, Cephalopoda, Echinodermata, Gastropoda, Isopoda, Ostracoda and Thoracica.</a> <em style='font-style: italic'>Mol Ecol Notes</em>. <b>6</b> (1), 268-271 (2006).</li><li>Hayashi, K., Yandell, D. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=How+sensitive+is+PCR-SSCP?.">How sensitive is PCR-SSCP?.</a> <em style='font-style: italic'>Hum Mutat</em>. <b>2</b> (5), 338-346 (1993).</li><li>Glava&#269;, D., Dean, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimization+of+the+single-strand+conformation+polymorphism+(SSCP)+technique+for+detection+of+point+mutations.">Optimization of the single-strand conformation polymorphism (SSCP) technique for detection of point mutations.</a> <em style='font-style: italic'>Hum Mutat</em>. <b>2</b> (5), 404-414 (1993).</li><li>M&#252;lhardt, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> <em style='font-style: italic'>Der Experimentator Molekularbiologie / Genomics</em>. , (2013).</li><li>Lee, S. V., Bahaman, A. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Discriminatory+Power+of+Agarose+Gel+Electrophoresis+in+DNA+Fragments+Analysis.">Discriminatory Power of Agarose Gel Electrophoresis in DNA Fragments Analysis.</a> <em style='font-style: italic'>Gel Electrophoresis - Principles and Basics</em>. , (2012).</li><li>Wang, X. W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+electrophoresis+technique+to+separate+microsatellite+alleles.">A new electrophoresis technique to separate microsatellite alleles.</a> <em style='font-style: italic'>Afr J Biotechnol</em>. <b>8</b> (11), 2432-2436 (2009).</li><li>Gemmer, I., Gergs, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Characterization+of+the+first+twelve+microsatellite+loci+for+the+amphipod+Gammarus+roeselii+(Crustacea:+Amphipoda).">Characterization of the first twelve microsatellite loci for the amphipod Gammarus roeselii (Crustacea: Amphipoda).</a> <em style='font-style: italic'>Conserv Genet Resour</em>. <b>5</b> (4), 955-957 (2013).</li><li>Olafsson, K., Hjorleifsdottir, S., Pampoulie, C., Hreggvidsson, G. O., Gudjonsson, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Novel+set+of+multiplex+assays+(SalPrint15)+for+efficient+analysis+of+15+microsatellite+loci+of+contemporary+samples+of+the+Atlantic+salmon+(Salmo+salar).">Novel set of multiplex assays (SalPrint15) for efficient analysis of 15 microsatellite loci of contemporary samples of the Atlantic salmon (Salmo salar).</a> <em style='font-style: italic'>Mol Ecol Resour</em>. <b>10</b> (3), 533-537 (2010).</li><li>Baric, S., Hollrigl, A., Fureder, L., Petutschnig, J., Dalla Via, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=First+analysis+of+genetic+variability+in+Carinthian+populations+of+the+white-clawed+crayfish+Austropotamobius+pallipes.">First analysis of genetic variability in Carinthian populations of the white-clawed crayfish Austropotamobius pallipes.</a> <em style='font-style: italic'>Bull. Fr. Peche Piscicult</em>.  (380-381), 977-990 (2006).</li><li>Koester, M., Gergs, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=No+evidence+for+intraguild+predation+of+Dikerogammarus+villosus+(Sowinsky,+1894)+at+an+invasion+front+in+the+Untere+Lorze,+Switzerland.">No evidence for intraguild predation of Dikerogammarus villosus (Sowinsky, 1894) at an invasion front in the Untere Lorze, Switzerland.</a> <em style='font-style: italic'>Aquat Invasions</em>. <b>9</b> (4), 489-497 (2014).</li><li>Sonnenberg, R., Nolte, A. W., Tautz, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+evaluation+of+LSU+rDNA+D1-D2+sequences+for+their+use+in+species+identification.">An evaluation of LSU rDNA D1-D2 sequences for their use in species identification.</a> <em style='font-style: italic'>Front Zool</em>. <b>4</b> (6), 6 (2007).</li><li>Koester, M., Bayer, B., Gergs, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Is+Dikerogammarus+villosus+(Crustacea,+Gammaridae)+a+'killer+shrimp'+in+the+River+Rhine+system?.">Is Dikerogammarus villosus (Crustacea, Gammaridae) a 'killer shrimp' in the River Rhine system?.</a> <em style='font-style: italic'>Hydrobiologia</em>. <b>768</b> (1), 299-313 (2016).</li><li>Koester, M., Cla&#223;en, S., Gergs, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Establishment+of+group-specific+PCR+primers+for+the+identification+of+freshwater+macroinvertebrates.">Establishment of group-specific PCR primers for the identification of freshwater macroinvertebrates.</a> <em style='font-style: italic'>Conserv Genet Resour</em>. <b>5</b> (4), 1091-1093 (2013).</li><li>Martin, P., Koester, M., Schynawa, L., Gergs, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=First+detection+of+prey+DNA+in+Hygrobates+fluviatilis+(Hydrachnidia,+Acari):+a+new+approach+for+determining+predator-prey+relationships+in+water+mites.">First detection of prey DNA in Hygrobates fluviatilis (Hydrachnidia, Acari): a new approach for determining predator-prey relationships in water mites.</a> <em style='font-style: italic'>Exp Appl Acarol</em>. <b>67</b> (3), 373-380 (2015).</li><li>Deagle, B. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Studying+Seabird+Diet+through+Genetic+Analysis+of+Faeces:+A+Case+Study+on+Macaroni+Penguins+(Eudyptes+chrysolophus).">Studying Seabird Diet through Genetic Analysis of Faeces: A Case Study on Macaroni Penguins (Eudyptes chrysolophus).</a> <em style='font-style: italic'>PLoS One</em>. <b>2</b> (9), e831 (2007).</li><li>Sint, D., Niederklapfer, B., Kaufmann, R., Traugott, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Group-Specific+Multiplex+PCR+Detection+Systems+for+the+Identification+of+Flying+Insect+Prey.">Group-Specific Multiplex PCR Detection Systems for the Identification of Flying Insect Prey.</a> <em style='font-style: italic'>PLoS One</em>. <b>9</b> (12), e115501 (2014).</li><li>Zarzoso-Lacoste, D., Corse, E., Vidal, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Improving+PCR+detection+of+prey+in+molecular+diet+studies:+importance+of+group-specific+primer+set+selection+and+extraction+protocol+performances.">Improving PCR detection of prey in molecular diet studies: importance of group-specific primer set selection and extraction protocol performances.</a> <em style='font-style: italic'>Mol Ecol Resour</em>. <b>13</b> (1), 117-127 (2013).</li><li>Vestheim, H., Jarman, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Blocking+primers+to+enhance+PCR+amplification+of+rare+sequences+in+mixed+samples+-+a+case+study+on+prey+DNA+in+Antarctic+krill+stomachs.">Blocking primers to enhance PCR amplification of rare sequences in mixed samples - a case study on prey DNA in Antarctic krill stomachs.</a> <em style='font-style: italic'>Front Zool</em>. <b>5</b> (1), 12 (2008).</li><li>Harper, G. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rapid+screening+of+invertebrate+predators+for+multiple+prey+DNA+targets.">Rapid screening of invertebrate predators for multiple prey DNA targets.</a> <em style='font-style: italic'>Mol Ecol</em>. <b>14</b> (3), 819-827 (2005).</li></ol>

<p class="jove_content">Los autores no tienen nada que revelar.</p>

<p class="jove_content">Aquí, presentamos un método fácil y costo-eficiente para la polimerización en cadena-basado determinación de interacciones depredador-presa de muestras de campo a través de cartillas de Grupo-específicas para las regiones de ADNr, que pueden combinarse con otros análisis no moleculares de las mismas muestras. Sin embargo, hay varios pasos críticos dentro del protocolo. En primer lugar, es esencial asegurar la especificidad de los cebadores utilizados. En segundo lugar, es crucial para evitar la contaminación y ...

<p class="jove_content">Las interacciones depredador-presa, que constituyen la mayoría de las interacciones tróficas y dinámica trófica, son aspectos claves para caracterizar los flujos de materia y energía a través de redes tróficas dentro y entre ecosistemas, que es uno de los principales objetivos de la ecología <sup class="xref">1</sup>. la determinación de la fuente y el flujo de carbono y nutrientes es promover la comprensión de la conectividad ecológica entre los ecosistemas<sup class="xref">2</sup>. Sin embargo, los ecosistemas, tales como ríos y sus cuencas, no están ligados sólo por flujos de materia orgánica y nutrientes sino también por los movimientos de los organismos<sup class="xref">3</sup>. Así, alteraciones de hábitat interrumpiendo el flujo de recursos que los sistemas pueden fuertemente alterar las redes tróficas de ambos ecosistemas, no sólo directamente sino también indirectamente cambiando la composición respectiva de las comunidades de depredador-presa. Por ejemplo, cambios de redes tróficas han demostrado para ser ligado a los movimientos de depredador solo especies (<em>e.g.</em>, trucha arco iris)<sup class="xref">4</sup>. Tales cambios potencialmente amenazan la biodiversidad y el funcionamiento de los ecosistemas acuáticos. Por lo tanto, analizando las interacciones depredador-presa en el campo es esencial para determinar el impacto de los cambios ambientales inducidos por humanos, como prácticas de manejo de agua, en la biodiversidad nativa de los ecosistemas acuáticos.</p>
<p class="jove_content">Puesto que el seguimiento de los vínculos tróficos es difícil en sistemas complejos, varios acercamientos se han establecido que permiten la evaluación de la alimentación de las interacciones en el campo<sup class="xref">5</sup>. Tradicionalmente, las investigaciones de interacciones en el campo de la alimentación se basan en la identificación visual de los restos de la presa en intestinos disecados y requieren un amplio conocimiento acerca de la diversidad morfológica de la presa. Análisis de contenido de Visual intestino han proporcionado penetraciones en el uso de los recursos de varios grupos de consumidores (<em>por ejemplo,</em> variación estacional en la dieta de langosta pescado de<sup class="xref">6</sup> y<sup class="xref">7</sup><sup>,</sup><sup class="xref">8</sup> o alimentación preferencias de copépodos). Sin embargo, el proceso físico de digestión dificulta el análisis de contenido de visual intestino y generalmente falta presa-organismos con cuerpo blando<sup class="xref">9</sup>. Para la alimentación de las especies por ingestión de líquido o para algunos consumidores invertebrados que intensivo dilacerar su comida antes de la ingestión, como anfípodos, identificación visual de especies de presas en contenido estomacal es imposible<sup class="xref">10</sup>. Debido a estas limitaciones, el análisis molecular ofrece una alternativa prometedora.</p>
<p class="jove_content">Los análisis moleculares se han convertido en una herramienta común que permiten la detección de la presa rápida y precisa en el contenido estomacal. La gama de tales técnicas es diversa: estrategias basadas en anticuerpos monoclonales o reacciones en cadena de polimerasa (polimerización en cadena) se utilizan a menudo, debido a su alta especificidad y sensibilidad<sup class="xref">11</sup>. El desarrollo de nuevos anticuerpos monoclonales es intensivo en tiempo y costo, por lo tanto, la aplicación de otras técnicas moleculares es más útil cuando los anticuerpos ya no existen<sup class="xref">11</sup>. Otro método común es la amplificación de regiones del ácido desoxirribonucleico (ADN), como el ácido ribonucleico ribosomal (ARN) genes presentes en la mayoría de las especies, usando la cartilla universal establece<sup class="xref">12</sup><sup>,</sup><sup class="xref">13</sup>. Cuando se utiliza esta técnica, a menudo no es posible identificar toda la gama de organismos presa dentro de fuentes mixtas de ADN<sup class="xref">14</sup>. Un enfoque eficaz para evitar tal inconveniente es usar primer grupo-específicas para el análisis de contenido intestinal genéticos. Diseñado para amplificar sólo regiones de ADN de grupos particulares y excluyen otras especies<sup class="xref">15</sup><sup>,</sup><sup class="xref">16</sup>, cebadores específicos de Grupo permiten la identificación de organismos presa en el nivel taxonómico de los grupos especificados sin análisis secundario de tiempo y costosa. Sin embargo, como todo análisis de contenido de la tripa, tales análisis proporcionan sólo una instantánea del comportamiento alimentario. Por lo tanto, la combinación de análisis de contenido intestinal molecular con análisis de marcadores naturales integración de tiempo (<em>por ejemplo,</em> los isótopos estables) se considera beneficioso<sup class="xref">1</sup><sup>,</sup><sup class="xref">2</sup>.</p>
<p class="jove_content">Aquí, describimos un método detallado para las investigaciones basadas en la PCR de las interacciones depredador-presa utilizando conjuntos de primer grupo-específicas para las regiones de ADN (ADNr) ribosomales nucleares para ser combinado con análisis de isótopos estables de la misma muestra. Describimos la detección de ADN de grupos de presas solo mediante electroforesis en gel de agarosa. Además, se presenta una oportunidad para mayores posteriores análisis de productos PCR de tales cartillas de Grupo-específicas aplicables siempre que se requiera una mayor resolución taxonómica que la especificidad de los cebadores. Porque la sola DNA trenzada (ssDNA) fragmentos de conformaciones terciaria de forma que se determinaron por su secuencia primaria<sup class="xref">17</sup>, pequeñas variaciones en los fragmentos amplificados por tales cebadores específicos de grupo conducen a cambios conformacionales. Estos cambios pueden detectarse por análisis de polimorfismo (SSCP) conformación de cadena única con geles de poliacrilamida<sup class="xref">17</sup><sup>,</sup><sup class="xref">18</sup>, lo que permite una identificación más precisa de organismos presa (hasta el nivel de especie).</p>
<p class="jove_content">Mientras que la electroforesis en gel de agarosa es una herramienta común y barata para visualizar fragmentos de ADN y determinar su longitud aproximada<sup class="xref">19</sup>, la resolución depende de la cantidad de ADN y el tinción colorante usado<sup class="xref">20</sup>. Por lo general, la visualización es sencillo cuando se trabaja con muestras de ADN puras, pero potencialmente bajas cantidades de presas DNA en el contenido estomacal de los consumidores puede complicar el marcador de resultados de electroforesis de gel de agarosa. Todavía, este método de detección es factible para detectar un bajo número de muestras al consumidor desde el campo uno o presa de algunos grupos, pero complicación en el marcador hace que la proyección de un gran número de muestras por múltiples presas taxones extremadamente tiempo intensivo y así impracticable. Un método de detección más sensible es el análisis automatizado de fragmentos por electroforesis capilar, que además permite la determinación de la longitud exacta de fragmentos<sup class="xref">21</sup>. Varios microsatélites en estudios han demostrado que mediante el uso de diferentes tintes fluorescentes como las etiquetas, es posible detectar y determinar diferentes fragmentos de longitud comparable por fragmento automatizado análisis<sup class="xref">22</sup><sup>,</sup><sup class="xref">23</sup><sup>, </sup> <sup class="xref">24</sup>. Por lo tanto, también presentamos un protocolo detallado para paralelo detección de ADN de presas múltiples grupos mediante PCR con conjuntos de etiquetado específico de grupo primer y detección mediante análisis del fragmento automatizado con un secuenciador automatizado. Además, presentamos los resultados de un estudio de caso que demuestra que la detección del ADN de la presa mediante el análisis del fragmento automatizado es un enfoque que también permite una cuantificación relativa de la presa ingerida.</p>

<table><tbody><tr><td>liquid nitrogen</td><td>Any</td><td>NA</td><td>For transport of field samples of macroinvertebrates to the laboratory.</td></tr><tr><td>1.5 ml reaction tubes - Safelock</td><td>Any</td><td>NA</td><td>For collection of consumer specimens in the field and subsequent conservation in liquid nitrogen reaction tubes do not necessarily need to be PCR clean. To avoid exploding of the tubes, the lid of the tubes should be punctured with a needle.</td></tr><tr><td>Stereomicroscope</td><td>Any</td><td>NA</td><td>Make sure magnification is suitable to prepare the gastro-intestinaltract of the size of consumer of interest.</td></tr><tr><td>Petri dishes</td><td>Any</td><td>NA</td><td>To dissect the gastro-intestinal tract of consumer specimens under the stereomikroscope.</td></tr><tr><td>Stainless steel foceps: Dumont forceps No. 7</td><td>Bioform</td><td>B40d</td><td>This curved stainless steel forceps can sometimes be very helful to hold specimen fixed inbetween the curved part without puncturing the gastro-intestinal tract.</td></tr><tr><td>Stainless steel foceps: Dumont forceps Electronic No. 5</td><td>Bioform</td><td>B40b</td><td>This fine stainless steel forceps is ideally suited for the preparation of the gastro-intestinal tract of consumer specimens.</td></tr><tr><td>DNA-ExitusPlus</td><td>AppliChem</td><td>A7409,1000RF</td><td>Decontamination solution for the removal of DNA and RNA contaminations</td></tr><tr><td>fuzz-free paper towel</td><td>Any</td><td>NA</td><td></td></tr><tr><td>Lab scale</td><td>Any</td><td>NA</td><td>Precision needs to be at least 0.01 g.</td></tr><tr><td>Microlitre pipettes (0.5-10/10-100/50-200/100-1000 &amp;mu;L)</td><td>Any</td><td>NA</td><td></td></tr><tr><td>Safe-Lock Tubes 2.0 ml</td><td>VWR</td><td>211-2165</td><td>It is crucial that these raction tubes are free of DNA, DNase, RNase and PCR inhibitors (PCR clean)!</td></tr><tr><td>Safe-Lock Tubes 1.5 ml</td><td>VWR</td><td>211-2164</td><td>It is crucial that these raction tubes are free of DNA, DNase, RNase and PCR inhibitors (PCR clean)!</td></tr><tr><td>Sodium chloride &amp;ge;99.5%, p.a., ACS, ISO</td><td>carlroth</td><td>3957.3</td><td>For salt extraction buffer (SEB) and 5M NaCl-solution required for extraction of DNA.</td></tr><tr><td>Tris(hydroxymethyl)-aminomethane Tris</td><td>carlroth</td><td>4855.2</td><td>For salt extraction buffer (SEB) and TBE buffer</td></tr><tr><td>Microlitre pipettes (0.5-10/10-100/50-200/100-1000 &amp;mu;L)</td><td>carlroth</td><td>8043.1</td><td>For salt extraction buffer (SEB) and TBE buffer</td></tr><tr><td>Boric acid &amp;ge;99.8 %, p.a., ACS, ISO</td><td>carlroth</td><td>6943.2</td><td>For TBE buffer. Not needed if commercialy available TBE buffer is obtained.</td></tr><tr><td>Sodium dodecyl sulfate (SDS)</td><td>carlroth</td><td>4360.1</td><td>For extraction of DNA</td></tr><tr><td>Proteinase K lyophil.</td><td>carlroth</td><td>7528.1</td><td>Prepare a working solution containing 10 mg/ml.</td></tr><tr><td>TissueLyser II</td><td>Quiagen</td><td>85300</td><td>Bead mill for homogenization of the samples.</td></tr><tr><td>Stainless Steel Beads, 5 mm</td><td>Quiagen</td><td>69989</td><td>For homogenization of samples.</td></tr><tr><td>Heating Thermoshaker</td><td>Any</td><td>NA</td><td></td></tr><tr><td>Vortex Mixer</td><td>Any</td><td>NA</td><td></td></tr><tr><td>Refrigerated centrifuge: himac CT 15 RE</td><td>Hitachi</td><td>NA</td><td>Refrigerated centrifuge used for centrifugation during the extraction of DNA (Protocol 1).</td></tr><tr><td>Isopropanol</td><td>carlroth</td><td>6752.5</td><td></td></tr><tr><td>Ethanol 99.8 %, p.a.</td><td>Any</td><td>NA</td><td></td></tr><tr><td>Water Molecular biology grade (ddH&lt;sub&gt;2&lt;/sub&gt;O)</td><td>AppliChem</td><td>A7398,1000</td><td>nuclease-free (stream sterilized and DEPC treated) water used for re-suspension of DNA and whenever refered to ddH&lt;sub&gt;2&lt;/sub&gt;O within the manuscript</td></tr><tr><td>Unmodified Olegonucleotides</td><td>Eurofins MWG Operon</td><td>NA</td><td>Primers unlabeled</td></tr><tr><td>Modified olegonucleotides</td><td>Metabion International AG</td><td>NA</td><td>Primers labelled</td></tr><tr><td>peqGOLD Taq all inclusive</td><td>VWR Peqlab</td><td>01-1000</td><td>Taq all inclusive for PCR reaction mixtures (reaction buffer Y and S, dNTPs and MgCl2)</td></tr><tr><td>Primus 96 advanced gradient thermocycler or peqStar96x Universal Gradient</td><td>Peqlab</td><td>NA</td><td>Primer sets were originally established on a Primus 96 advanced gradient thermocycler. As this cycler was quite old, we than checked if our primer sets are efficient and specific under the same conditions using the peqSta96x (which also could simulate the older model). However, tests showed that our primers work well and are still specific (see Koester et al. 2013) without using the simulation of the old machine.</td></tr><tr><td>Standard 96 Well PCR Plates</td><td>VWR Peqlab</td><td>732-2879</td><td>Used for PCR reactions.</td></tr><tr><td>Low Profile Tube Stripes 0.15 ml with Flat Cap Stripes</td><td>VWR Peqlab</td><td>732-3223</td><td>Cap stripes used to close the PCR plates.</td></tr><tr><td>Agarose</td><td>Peqlab</td><td>35-1020</td><td>Used for gel electrophoresis.</td></tr><tr><td>Microwave</td><td>Any</td><td>NA</td><td></td></tr><tr><td>Conical flask</td><td>Any</td><td>NA</td><td></td></tr><tr><td>Measuring cylinder</td><td>Any</td><td>NA</td><td></td></tr><tr><td>Horizontal electrophoresis unit and respective combs with teeth</td><td>Any</td><td>NA</td><td>For agarose gel electrophoresis.</td></tr><tr><td>Electrophoresis Power Supply PS3002</td><td>Life Technologies</td><td>NA</td><td></td></tr><tr><td>Ethidium bromide solution 1 %</td><td>carlroth</td><td>2218.1</td><td>Used to prepare staining bath for agarose gels.</td></tr><tr><td>Formamide</td><td>carlroth</td><td>6749.1</td><td>Needded for the denaturation buffer for SSCP analyses.</td></tr><tr><td>Bromphenol blue</td><td>AppliChem</td><td>A3640.0010</td><td>Needed for the loading dye for agarose gel electrophoresis.</td></tr><tr><td>Sucrose</td><td>carlroth</td><td>4621.1</td><td>Needed for the loading dye for agarose gel electrophoresis.</td></tr><tr><td>100 bp-DNA-Ladder extended</td><td>carlroth</td><td>T835.1</td><td>As size standard for agarose gel electrophoresis.</td></tr><tr><td>UV-Documentation system</td><td>Any</td><td>NA</td><td>To visualize gel electrophoresis results.</td></tr><tr><td>Rotiphorese NF-Acrylamide/Bis-solution 40 % (29:1)</td><td>carlroth</td><td>A121.1</td><td>For the preparation of polyacrylamid gels.</td></tr><tr><td>Ammonium peroxydisulphate</td><td>carlroth</td><td>9592.2</td><td>For the preparation of polyacrylamid gels.</td></tr><tr><td>foldback clips (32 mm)</td><td>Any</td><td>NA</td><td>For the preparation of polyacrylamid gels.</td></tr><tr><td>square-shaped plastic box (21 &amp;times; 6.5 &amp;times; 5 cm)</td><td>Any</td><td>NA</td><td>For the preparation of polyacrylamid gels.</td></tr><tr><td>Tetramethylethylenediamine (TEMED)</td><td>carlroth</td><td>23.67.1</td><td>For the preparation of polyacrylamid gels.</td></tr><tr><td>Beaker</td><td>Any</td><td>NA</td><td></td></tr><tr><td>RC 10 Digital chiller</td><td>VWR</td><td>462-0138</td><td>For SSCP analyses using polyacrylamide gel electrophoresis.</td></tr><tr><td>Vertical electrophoresis unit P10DS (OWL Separation Systems)</td><td>VWR</td><td>700-2361</td><td>For SSCP analyses using polyacrylamide gel electrophoresis.</td></tr><tr><td>Notched glass plate</td><td>VWR</td><td>730-0261</td><td>For SSCP analyses using polyacrylamide gel electrophoresis.</td></tr><tr><td>Blank glass plate</td><td>VWR</td><td>730-0260</td><td>For SSCP analyses using polyacrylamide gel electrophoresis.</td></tr><tr><td>Spacers</td><td>VWR</td><td>730-0262</td><td>For SSCP analyses using polyacrylamide gel electrophoresis.</td></tr><tr><td>Comb with 25 teeth</td><td>VWR</td><td>730-0294</td><td>For SSCP analyses using polyacrylamide gel electrophoresis.</td></tr><tr><td>Shaking platform</td><td>Any</td><td>NA</td><td>For constant shaking of the staining bath.</td></tr><tr><td>GelStar Nucleic Acid Stain (Lonza Rockland, Inc.)</td><td>Biozym</td><td>850535 (50535)</td><td>For staining of polyacrylamide gels.</td></tr><tr><td>GenomeLab DNA Size Standard Kit 400bp</td><td>AB Sciex</td><td>608098</td><td>For automated fragment analyses. Size stanard for Batch B.</td></tr><tr><td>GenomeLab DNA Size Standard Kit 600bp</td><td>AB Sciex</td><td>608095</td><td>For automated fragment analyses. Size stanard for Batch A.</td></tr><tr><td>Sample Loading Solution (SLS)</td><td>AB Sciex</td><td>608082</td><td>For automated fragment analyses.</td></tr><tr><td>Sequenzing plate - 96 Well Polypropylene PCR Microplate</td><td>Costar</td><td>6551</td><td>For automated fragment analyses.</td></tr><tr><td>Plate centrifuge, PerfectSpin P</td><td>VWR Peqlab</td><td>NA</td><td>mini plate centrifuge used to spin down PCR products.</td></tr><tr><td>Buffer plate - 96 Well EIA/RIA Clear Flat Bottom Polystyrene Not Treated Microplate</td><td>Corning</td><td>9017</td><td>For automated fragment analyses.</td></tr><tr><td>GenomeLab Seperation buffer</td><td>AB Sciex</td><td>608012</td><td>For automated fragment analyses.</td></tr><tr><td>Separation Gel - LPAI</td><td>AB Sciex</td><td>608010</td><td>For automated fragment analyses.</td></tr><tr><td>Sequenzer - CEQ8000 Genetic Analysis System</td><td>Beckman Coulter</td><td>NA</td><td>For automated fragment analyses.</td></tr><tr><td>GeneMarker V1.95</td><td>Softgenetics</td><td>NA</td><td>To analyze results of automated fragment analyses.</td></tr></tbody></table>

laboratory protocol for genetic gut content analyses of aquatic macroinvertebrates using group-specific rdna primers

<p class="jove_content">Análisis de redes tróficas es esencial para una mejor comprensión de los ecosistemas. Por ejemplo, las interacciones tróficas pueden sufrir cambios severos causados por la invasión de especies no autóctonas. Sin embargo, es difícil en muchos casos una identificación exacta de las interacciones depredador-presa de campo. Estos análisis a menudo se basan en una evaluación visual del contenido de la tripa o el análisis de ratios de isótopos estables (δ<sup>15</sup>N y δ<sup>13</sup>C). Tales métodos requieren amplio conocimiento, respectivamente, diversidad morfológica o la firma isotópica de organismos presa individual, conduce a obstáculos en la identificación exacta de organismos presa. Análisis de contenido de Visual intestino especialmente subestimar organismos presa de cuerpo suave, porque maceración, ingestión y digestión de presas organismos dificultan la identificación de especies específicas. Por lo tanto, estrategias de polimerasa en la reacción en cadena (PCR), por ejemplo el uso de la cartilla del específico de grupo se establece, brindan una herramienta poderosa para la investigación de las interacciones tróficas. Aquí, describimos protocolos detallados para investigar el contenido estomacal de los consumidores de macroinvertebrados del campo mediante sistemas específicos de grupo primer nuclear ácido desoxirribonucleico ribosómico (ADNr). ADN puede ser extraído de especímenes enteros (en el caso de taxa pequeño) o de contenido estomacal de ejemplares recolectados en el campo. Presencia y eficiencia funcional de las plantillas de ADN necesitan ser confirmado directamente desde el individuo probado usando la cartilla universal establece contra la subunidad correspondiente del DNA. También demostramos que presa consumida puede ser determinado más a nivel de especie mediante PCR con cebadores específicos de grupo sin modificar combinan con análisis de polimorfismo (SSCP) hebra posterior conformación utilizando geles de poliacrilamida. Además, nos muestran que el uso de diferentes tintes fluorescentes como etiquetas permite proyección paralela para fragmentos de ADN de grupos de presas diferentes de múltiples muestras contenido intestinal mediante el análisis del fragmento automatizado.</p>

<p class="jove_content" fo:keep-together.within-page="1">Hemos utilizado con éxito pasos descritos en este protocolo para el análisis de la dieta en diferentes estudios. En esta sección, presentamos ejemplos que describe la aplicabilidad de las distintas secciones del protocolo.</p>
<p class="jove_content" fo:keep-together.within-page="1">Por ejemplo, para demostrar la efectividad de los sistemas de primer grupo-específica establecida por los autores<sup class="xref">28</sup> y el potencial de mayores aguas abajo análisis de productos PCR ...

Watch this Scientific Journal Video about Laboratory Protocol for Genetic Gut Content Analyses of Aquatic Macroinvertebrates Using Group-specific rDNA Primers at JoVE.com

Laboratory Protocol for Genetic Gut Content Analyses of Aquatic Macroinvertebrates Using Group-specific rDNA Primers

<p class="jove_content">Análisis de contenido intestinal más común de macroinvertebrados son visuales. Que requiere intenso conocimiento sobre la diversidad morfológica de los organismos presa, perder presa con cuerpo suave y, debido a la fuerte trituración de presa, son casi imposibles para algunos organismos, incluyendo los anfípodos. Ofrecemos detallados novela enfoques genéticos para macroinvertebrados presa de identificación en la dieta de los anfípodos.</p>

Protocolo de laboratorio para análisis genéticos de contenido intestinal de macroinvertebrados acuáticos con grupo-específica rDNA cartillas

Analyzing food webs is essential for a better understanding of ecosystems. For example, food web interactions can undergo severe changes caused by the ...

laboratory-protocol-for-genetic-gut-content-analyses-aquatic

Universidad de Cartagena UDEC

Research

JoVE Journal

Biology

8.8K vistas.  University of Koblenz-Landau. Análisis de contenido intestinal más común de macroinvertebrados son visuales. Que requiere intenso conocimiento sobre la diversidad morfológica de los organismos presa, perder presa con cuerpo suave y, debido a la fuerte trituración de presa, son casi imposibles para algunos organismos, incluyendo los anfípodos. Ofrecemos detallados novela enfoques genéticos para macroinvertebrados presa de identificación en la dieta de los anfípodos.

Video: Laboratory Protocol for Genetic Gut Content Analyses of Aquatic Macroinvertebrates Using Group-specific rDNA Primers
