作者想感谢梅奥诊所的材料和结构测试核心, 他们在进行骨折测试时的技术支持。此外, 我们还要感谢拉梅什 Raghupathy 和 Ian Gerstel 在梅奥诊所任职期间协助编写 dic 方案的剧本和具体细节, 以及明尼苏达大学的维克多 Barocas 研究小组底层开源软件, 它执行数字图像相关应变计算的核心11。这项研究由 Grainger 基金会的 Grainger 创新基金资助。

所有实验都是通过机构审查委员会的批准进行的。这些样本是从解剖学研究实验室合作获得的.
 1. 准备用于测试的标本 <ol> <li> 在 RT 中解冻股骨 24 h. </li>
	<li> 当股骨在队列中进行测试时, 取出在冻结前应用的任何包装, 用干毛巾擦拭股骨, 去除残余水分、脂肪堆积或软组织。将较大的大转子放入一个带有骨水泥的预制铝杯中. </li>
	<li> 用一个盒子尽可能多地容纳微粒, 用白色的塑料底漆喷涂骨头, 以达到一种薄而均匀的涂层。注意用一层均匀的油漆覆盖骨, 以获得最佳的对比度, 并与股骨表面有很强的附着力.
	注意: 未测量厚度. </li>
	<li> 让油漆干燥至少5分钟。这是很重要的, 以避免与斑点滴的意外混合2节. </li>
	<li> 用湿布包裹骨头以避免组织干燥. </li>
</ol> 2。斑点进程 <ol> <li> 近似地, 将1部分水添加到2部分的油漆中, 以便在骨骼上进行最佳斑点。将水逐渐 (为更好的混合物) 添加到丙烯酸漆中使其成为黑色. </li>
	<li> 在黑色颜料的调色板上蘸一把干净的牙刷, 以吸收颜色并轻拂画笔, 使白色涂层上的黑色斑点. </li>
	<li> 让油漆干5分钟, 然后再继续. </li>
</ol> 3。图像采集 <ol> <li> 在机械试验机上插入准备好的有斑点的股骨, 方法是将远端装入夹具, 并拧紧两个螺钉以固定试样. </li>
	<li> 调整两个高强度放电光反射器, 使股骨表面达到尽可能高的光照, 同时避免相机图像中的反射。请在3节中快速执行以下步骤, 以避免在测试之前对样品进行不必要的加热. </li>
	<li> 减少前、后视图的光圈高速摄像机镜头, 使整个区域的股骨在视野中的兴趣集中. </li>
	<li> 调整光线反射器以进一步改善光照, 同时减少眩光. </li>
	<li> 将图像采集软件设置为捕获6000帧/秒和 #160; 分辨率为 1024年 x 512 像素。设置接收到12288的触发信号后要获取的帧总数。当从测试系统接收到触发信号时, Arm 高速视频软件用于图像采集。测试完成后, 视频驻留在照相机和 #39 的缓冲区内存中. </li>
	<li> 使用图像采集软件, 通过指定所需的路径和文件名并单击和 #34, 将视频保存到磁盘中; 保存和 #34;。准备在 5-40 分钟之间等待此过程的完成, 这取决于要保存的帧数. </li>
</ol> 4。图像准备 <ol> <li> 为股骨的正面和背面视图创建单独的工作目录 </li>
	<li> 使用视频分析软件打开适当的高速视频录制, 并记下关键帧参考号码在 1) 开始 加载帧执行器移动, 和 2) 在 断开事件后立即帧 . </li>
	<li> 要从高速视频缩减未压缩的 TIFF 图像序列, 请打开并运行 #34; mov_frames. #34; 在相关的股骨侧的工作目录中编写脚本.
	<ol> <li> 在结果对话框中, 输入步骤4.2 中标识的结束帧编号, 步骤大小为 25-40。单击并 #34; 提取帧和 #34; 检查工作目录以确保正确提取了 tiff 文件. </li>
	</ol> </li> </ol> 5。有限元网格创建 <ol> <li> 使用外部有限元啮合程序创建有限元网格。用有限元法计算了差分位移矢量的2D 应变。将初始提取的 *. tiff 图像导入有限元软件预处理作为样条创建的模板. </li>
	<li> 查找两个容易识别位于帧的相反角的图像中的信讬点, 并记录它们的 X 和 Y 坐标 (这些将最终用于步骤 6.1)。根据有限元软件用于导入 *. tiff 图像的约定, 这些坐标是任意的。这些点的坐标将用于在步骤6.2 中将有限元网格的节点与视频图像的相应像素进行注册. </li>
	<li> 在图像编辑软件中, 打开导入到有限元软件预处理器中的同一图像, 并记录与步骤5.2 中标识的点相关联的像素的 X 和 Y 方向值。这些最终将在步骤6.1 中使用. </li>
	<li> 在 #34; 草图和 #34; 有限元啮合程序的模块, 使用样条工具勾勒出表示感兴趣区域的闭合剖面。验证区域是不是太大, 这样, 骨骼的表面会在骨折前由于旋转而移动到区域之外. </li>
	<li> 准备在步骤5.4 中创建的闭合截面, 通过在菜单和 #34 下播种全局网格大小为 1 mm 的边缘进行啮合; 种子部件实例和 #34;. </li>
	<li> 下 #34; 分配网格控件和 #34;, 将元素形状设置为四边形. </li>
	<li> 将已关闭的分区网格. </li>
	<li> 将网格导出为由节点坐标和元素定义组成的网格数据库的 ASCII 文件. </li>
	<li> 在文本编辑器中打开所生成的有限元素输入文件, 将包含节点编号的节点块复制到一个新的文本文件中, 并将其另存为和 #34; nodes.txt 和 #34;。重复执行元素块并将新的文本文件保存为和 #34; elements.txt 和 #34;. </li>
</ol> 6。将 FE 网格与高速视频图像进行注册, 并进行数字图像相关分析 <ol> <li> 在新会话内, 创建2元素行向量, 称为 ab1 和 ab2 , 并使用步骤5.2 中标识的值. px1 和 px2步骤5.3 中标识的值, 方法是在命令行上键入这些向量名称。将工作区保存为和 #34;p oints #34;... </li>
	<li> 运行脚本和 #34; convert_imagesize #34; 用提取的高速视频图像对有限元网格中的点进行注册. </li>
	<li> 运行脚本和 #34; rrImageTrackGui #34;。加载第一个图像 (和 #34;p 01.tif 和 #34;) 并输入作为要处理的图像总数提取的最后一个. tiff 文件的编号. </li>
	<li> 加载在步骤5.7 中创建的网格, 方法是确保将网格选项设置为 #34; 从文件和 #34 中读取; 然后单击并 #34; 接受和 #34;。有限元网格应出现在骨骼图像上. </li>
	<li> 根据跟踪参数的下列准则指定跟踪值, 并单击和 #34;P roceed 和 #34; (请记住, 参数值是图像大小、纹理和变形量, 需要进行测试仔细的个案基础上).
	<ol> <li> 使用起始内核大小21。内核大小, n, 是大小 of n x n 窗口 (其中 n 是奇数) 的像素, 用于互相关, 并确定该区域的变形向量将用于应变计算. </li>
		<li> 使用起始子像素大小4。亚像素的大小, m, 是大小的 (2 米 + 1) x (2 m + 1) 子的亚像素变形计算通过假设均匀应变在该子. </li>
		<li> 使用起始平滑系数2。平滑系数是在计算应变之前, 在履带位置的位移场上平滑应用的量. </li>
		<li> 使用起始 maxMove 系数 10. maxMove 因子是任何节点相对于其相邻和 #39 的轨迹, 可以远离其轨迹的最大像素数。这有助于避免严重的变形跟踪. </li>
		<li> 使用起始 smoothGrid 系数15。smoothGrid 因子是用于平滑处理的网格大小 (比跟踪节点的网格略粗). </li>
	</ol> </li> <li> 选择一个具有显著对比度的参考线, 同时避免带有眩光或模糊的区域。通过单击和 #34 检查此点; 检查导轨和 #34; 并验证相关峰值是否强 (至少是振幅的两倍) 与它的邻居相比。单击和 #34; 接受和 #34; #34;P erform 跟踪和 #34; 当满足时。这可以是一个冗长的计算过程, 其中差分位移计算的时序图像序列. </li>
	<li> 步骤6.6 完成后, 单击并 #34; 动画和 #34;。动画完成后, 单击并 #34; 写入应变 (后处理软件) 和 #34;, 输入 * exe, 然后选择 writeStrainRR_simple 11 。这将计算菌株。关闭 GUI. </li>
</ol> 7。位移和应变数据的后处理 <ol> <li> 获取应变 与 帧数、运行和 #34; analyzeFailurePrecursor 和 #34; 从命令行到步长大小的输入参数 (选择 20-30)。峰值将意味着骨损伤, 最大的峰值将对应于接近全球骨衰竭的框架. </li>
	<li> 创建应变、运行和 #34 的影片文件; makeMovies 和 #34; 从命令窗口中使用参数 (numVars、endstep、标志).
	注意: 参数 numVars 定义为 1-3 是位移, 4-6 是 xx , yy , 和 xy 应变分量, 7 和 #38; 8 是两个主要和冯米塞斯应变, 9 是应变能。参数 endstop 是要包含在影片中的最后一个框架。
	<ol> <li> 将可选参数标志设置为 1, 以便仅为 numVars 参数指定的实体和0创建所有变量的影片. </li>
	</ol> </li> </ol> 8。对结果进行微调和细化 <ol> <li> 如果 DIC 跟踪给出了糟糕的结果, 如不连续的应变场, 这是在连续体力学假设之外, 确定发生了什么以及为什么跟踪失败。重复6节, 特别注意跟踪参数的调整。第二个选项可能是返回到有限元软件, 并创建一个更均匀和可能更细的网格. </li>
	<li> 如果 dic 跟踪给出了合理的结果, 则为 dic 创建更精细的图像系列。使用步骤4.2 中的关键帧参考编号和视频的相应帧速率, 在断裂试验中确定三不同的感兴趣制度的帧间距, 并记住这些点应移动不超过6帧之间的像素.
	注: 对于测试的初始段, 当应变在股骨缓慢上升时, 帧间距将相对较大 (例如, 对于 100 mm/秒的位移率, 此部分的帧间距为3333和 #956; s)。对于更接近于断裂框架的中间部分, 应变增加得更快, 需要更小的帧间距 (1667 和 #956; s 用于 100 mm/秒的位移率)。在断裂前的最后部分, 帧间距在最小 (16.7 和 #956; s 在100毫米/秒的位移率). </li>
	仅用于文档用途的 <li> 可选: 使用步骤8.2 中的信息, 在名为 "和 #34 的 ASCII 文件中创建格式化数据项; steps.txt 和 #34; 包含每个帧间距的一行数据。每行的格式将是该制度的起始帧, 该框架由要跳过的帧数 (基于步骤 8.2) 分隔, 然后是该制度的最终框架 ( 即 和 #160; #34 的格式; 1:20:200 和 #34; 将指示提取软件提取帧1到帧200的步骤 20).
	<ol> <li> 紧接该指定之后, 插入一个选项卡并指定图像提取号码范围 (用于和 #34; 1:20:200 和 #34; 例如, 完整的行指定将是和 #34; 1:20:200 和 #60;P ress 选项卡和 #62; 1:11 和 #34; 没有引文)。对其他两个测试机制重复, 以便在 #34 中有三行信息; steps.txt 和 #34; 文件。此文件用作记录如何从原始的高速视频中提取图像. </li>
	</ol> </li> <li> 在该对话框中指定多个帧间距制度时, 再次运行 mov_Frames. m 代码。输入步骤8.2 中标识的帧号和步长, 以确定在 "工具和 #39" 对话框中预期的开始、完成和帧跳过参数。请确保在新目录中执行此项, 否则将覆盖原始图像. </li>
	<li> 重复6和7节, 并查看改进结果。每个股骨可能需要不同的额外的迭代, 这取决于骨折事件的性质, 斑点图案和照明。重复步骤6.5 时, 将设置保持不变, 除非将 maxMove 减少到 6 (从 10). </li>
</ol>

<ol>
	<li>Peters, W., Ranson, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Digital+imaging+techniques+in+experimental+stress+analysis.">Digital imaging techniques in experimental stress analysis.</a> Opt Eng. 21 (3), 213427-213427 (1982).</li><li>Kwon, O., Hanna, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Enhanced+Digital+Image+Correlation+Technique+for+Feature+Tracking+During+Drying+of+Wood.">The Enhanced Digital Image Correlation Technique for Feature Tracking During Drying of Wood.</a> Strain. 46 (6), 566-580 (2010).</li><li>Sutton, M. A., Orteu, J. J., Schreier, H. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Image+Correlation+for+Shape,+Motion+and+Deformation+Measurements.">Image Correlation for Shape, Motion and Deformation Measurements.</a> Adv of Opt Methods in Exp Mech. 3, (2009).</li><li>Grassi, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=How+accurately+can+subject-specific+finite+element+models+predict+strains+and+strength+of+human+femora?+Investigation+using+full-field+measurements.">How accurately can subject-specific finite element models predict strains and strength of human femora? Investigation using full-field measurements.</a> J Biomech. 49 (5), 802-806 (2016).</li><li>Den Buijs, J. O., Dragomir-Daescu, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Validated+finite+element+models+of+the+proximal+femur+using+two-dimensional+projected+geometry+and+bone+density.">Validated finite element models of the proximal femur using two-dimensional projected geometry and bone density.</a> Comput Methods Programs Biomed. 104 (2), 168-174 (2011).</li><li>Keyak, J. H., Rossi, S. A., Jones, K. A., Skinner, H. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Prediction+of+femoral+fracture+load+using+automated+finite+element+modeling.">Prediction of femoral fracture load using automated finite element modeling.</a> J Biomech. 31 (2), 125-133 (1998).</li><li>Lotz, J. C., Cheal, E. J., Hayes, W. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fracture+Prediction+for+the+Proximal+Femur+Using+Finite-Element+Models+.+1Linear-Analysis.">Fracture Prediction for the Proximal Femur Using Finite-Element Models . 1Linear-Analysis.</a> J Biomech Eng-T Asme. 113 (4), 353-360 (1991).</li><li>Cody, D. D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Femoral+strength+is+better+predicted+by+finite+element+models+than+QCT+and+DXA.">Femoral strength is better predicted by finite element models than QCT and DXA.</a> J Biomech. 32 (10), 1013-1020 (1999).</li><li>Dragomir-Daescu, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Robust+QCT/FEA+models+of+proximal+femur+stiffness+and+fracture+load+during+a+sideways+fall+on+the+hip.">Robust QCT/FEA models of proximal femur stiffness and fracture load during a sideways fall on the hip.</a> Ann Biomed Eng. 39 (2), 742-755 (2011).</li><li>Bettamer, A., Hambli, R., Allaoui, S., Almhdie-Imjabber, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Using+visual+image+measurements+to+validate+a+novel+finite+element+model+of+crack+propagation+and+fracture+patterns+of+proximal+femur.">Using visual image measurements to validate a novel finite element model of crack propagation and fracture patterns of proximal femur.</a> Comput Methods Biomech Biomed Eng Imaging Vis. , 1-12 (2015).</li><li>Raghupathy, R., Barocas, V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Robust Image Correlation Based Strain Calculator for Tissue Systems. , (2016).</li><li>Taddei, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Subject-specific+finite+element+models+of+long+bones:+An+in+vitro+evaluation+of+the+overall+accuracy.">Subject-specific finite element models of long bones: An in vitro evaluation of the overall accuracy.</a> J Biomech. 39 (13), 2457-2467 (2006).</li><li>Grassi, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Accuracy+of+finite+element+predictions+in+sideways+load+configurations+for+the+proximal+human+femur.">Accuracy of finite element predictions in sideways load configurations for the proximal human femur.</a> J Biomech. 45 (2), 394-399 (2012).</li><li>Gerstel, I., Raghupathy, R., Dragomir-Daescu, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Digital+Image+Correlation+Identifies+Quantitative+Characteristics+in+Proximal+Femur+Fracture+Crack.">Digital Image Correlation Identifies Quantitative Characteristics in Proximal Femur Fracture Crack.</a> ORS Annual Mtg. , (2012).</li></ol>

作者没有相关的披露。

我们介绍了一个协议, 以一致准备在骨折试验期间的高对比度成像的股骨样本, 然后用于估计全场应变分布的 DIC。这个协议确保了适当的对比纹理黑色跟踪斑点对坚实的白色背景的骨骼表面。根据该协议, 我们成功地复制了八十九股骨的 DIC 分析的应变估计。
DIC 是一种光学方法, 它涉及在高速摄像机拍摄的一系列图像上放置一个网格, 并使用互相关算法跟踪帧之间的像素亮度变...

数字图像相关 (DIC) 是一种图像后处理方法, 用于在目前的协议中估计的全场表面应变的尸体股骨试验标本从时序图像中获得的机械断裂试验。该技术在1980的实验应力分析中首次被开发和应用, 并在近几年的使用中迅速增加1,2,3。它有几个关键的优势超过传统的方法安装应变计的结构, 包括增加空间分布的应变场, 更精细的测量长度通过增加相机分辨率, 并避免问题的应变计粘合或合规性。生物组织 DIC 的一个主要优势, 如骨骼, 是它可以应用于不规则的几何图形, 包括高度异构的材料属性4,5。它的主要缺点是传统的应变采集方法是, 它需要昂贵的高速摄像机的足够分辨率的测量区域的利益, 以实现足够的空间和时间采样准确估计应变场。
从骨折 DIC 分析得到的时间应变场的初步应用是验证 QCT/有限元模型中的应变估计5。这种验证是许多骨科研究小组的重点, 主要利用远程测量的力量和位移从负载细胞和位移传感器6,7,8。此外, 骨折图像分析的断裂模式已与这些远程测量结合起来, 作为进一步的模型验证9。最近, 应用 DIC 法对股骨近端断裂和裂纹扩展的有限元模型进行了验证, 并对其进行了10。利用模型与实验之间的应变相关性, 对近股骨的计算模型的有效性有了更深入的把握, 进一步提高了 QCT/有限元诊断方法在临床上的应用效果。
这项工作解释了详细的协议, 以纳入必要的步骤, DIC 分析在断裂试验的近端股骨。该程序包括在骨表面喷涂白色涂料的骨准备步骤, 然后在骨骼干白表面斑点黑点, 利用高速视频获取具有足够空间和时间分辨率的图像的方法摄像机, 以及我们用于计算这些图像中的应变场的过程和工具。我们还解释了一些可能影响测量质量的警告。

<table><tbody><tr><td>Krylon plastic primer white</td><td>Krylon, Peoria, AZ, USA</td><td>N/A</td><td>Used as a base coat for a smooth white finish on bone surface</td></tr><tr><td>Water-based acrylic white and black paint&amp;nbsp;</td><td>Plaid Enterprises (Ceramcoat), Norcross, GA, USA</td><td>N/A</td><td>Paint source for white and black colors</td></tr><tr><td>Mixing bowl</td><td>Not specific (generic)</td><td>N/A</td><td>Used to mix and prepare paint</td></tr><tr><td>Foam brush</td><td>Linzer Products, Wyandanch, NY, USA</td><td>N/A</td><td>Used to apply paint on bone surface</td></tr><tr><td>Toothbrush</td><td>Colgate-Palmolive, New York, NY, USA</td><td>Firm bristle</td><td>Used to apply appropriate size and distribution of speckling pattern</td></tr><tr><td>Hygenic Orthodontic Resin (PMMA)</td><td>Patterson Dental, St Paul, MN, USA</td><td>H02252</td><td>Controlled substance and can be purchased with proper approval</td></tr><tr><td>Kenmore Freezer</td><td>Sears Holdings, Hoffman Estates, IL, USA</td><td>N/A</td><td>Used to maintain a -20&lt;sup&gt;o&lt;/sup&gt;C storage enviroment for bone specimens</td></tr><tr><td>Physiologic Saline (0.9% Sodium Chloride)</td><td>Baxter Healthcare, Deerfield, IL, USA</td><td>NDC 0338-0048-04</td><td>Used for keeping specimens hydrated</td></tr><tr><td>Scalpels and scrapers</td><td>Aspen Surgical (Bard-Parker), Caledonia, MI, USA&amp;nbsp;</td><td>N/A</td><td>Used to remove soft tissue from bone specimens</td></tr><tr><td>Fume Hood</td><td>Hamilton Laboratory Solutions, Manitowoc, WI, USA</td><td>70532</td><td>Used for ventilation when preparing PMMA for potting of specimens</td></tr><tr><td>Lighting units</td><td>ARRI, Munich, Germany</td><td>N/A</td><td>Needed for illumination of target for image capture</td></tr><tr><td>High-speed video camera</td><td>Photron Inc., San Diego, CA, USA</td><td>Photron Fastcam APX-RS&amp;nbsp;</td><td>Used to capture the high speed video recordings of the fracture events</td></tr><tr><td>Photron FASTCAM Imager and Viewer</td><td>Photron Inc., San Diego, CA, USA</td><td>Ver.3392(x64)</td><td>Used to record and view the high speed video recordings</td></tr><tr><td>Camera lens</td><td>Zeiss, Oberkochen, Germany</td><td>Zeiss Planar L4/50 ZF Lens</td><td>Needed for appropriate image resolution</td></tr><tr><td>ABAQUS CAE</td><td>Dassault System&amp;egrave;s, Waltham, MA, USA</td><td>Versions 6.13-4</td><td>Used for defining region of interest and creating finite element mesh</td></tr><tr><td>MATLAB</td><td>Mathworks, Natick, MA, USA</td><td>Version 2015b</td><td>Used for image processing and DIC analysis</td></tr><tr><td>TecPlot</td><td>TecPlot Inc., Bellevue, WA</td><td></td><td>Used for post processing of strain fields</td></tr><tr><td>Strain Calculator Software</td><td>Victor Barocas Research Group, University of Minnesota, Minneapolis, MN, USA</td><td>http://license.umn.edu/technologies/20130022_robust-image-correlation-based-strain-calculator-for-tissue-systems</td><td>Used to calculate strain field</td></tr><tr><td>mov_frames.m</td><td>Matlab script, Mayo Clinic, Rochester, MN,USA</td><td>N/A</td><td>Used to downsample uncompressed images from high speed video files</td></tr><tr><td>convert_imagesize.m</td><td>Matlab script, Mayo Clinic, Rochester, MN,USA</td><td>N/A</td><td>Used to register image pixel coordinates with mesh coordinates</td></tr><tr><td>rrImageTrackGui.m</td><td>Matlab script, Mayo Clinic, Rochester, MN,USA</td><td>N/A</td><td>Used to perform the image cross-correlation to obtain deformations and run Strain Calculator</td></tr><tr><td>analyzeFailurePrecursor.m</td><td>Matlab script, Mayo Clinic, Rochester, MN,USA</td><td>N/A</td><td>Used to track the peak strain components temporally</td></tr><tr><td>makeMovies.m</td><td>Matlab script, Mayo Clinic, Rochester, MN,USA</td><td>N/A</td><td>Used to create portable *.avi movies of the deformation components, strain components, principal strains, von Mises strain, and strain energy</td></tr></tbody></table>

a method to estimate cadaveric femur cortical strains during fracture testing using digital image correlation

本协议描述了利用数字图像相关技术对从机械测试中获得的尸体股骨表面的高速视频图像中的皮层应变进行估计的方法。这种光学方法要求在一个坚实的白色背景上有许多对比的信讬标记的纹理, 以准确地跟踪表面变形, 因为载荷被应用到试样上。在测试之前, 在相机视图的兴趣表面被涂上了一个水性白色底漆, 并允许干燥几分钟。然后, 黑色的油漆在白色的背景上仔细地斑点, 特别考虑到水滴的均匀大小和形状。照明是精心设计和设置这样, 有最好的对比, 这些标记, 同时尽量减少反射通过使用过滤器。图像是通过高速视频捕获1.2万帧/秒获得的。提取之前和包括骨折事件的关键图像, 并在经过特定区域的详细询问窗口中的连续帧之间进行变形估计。这些变形然后被用来计算表面应变在断裂试验期间。应变数据是非常有用的识别骨折开始在股骨, 并最终验证的股骨近端骨折强度模型从定量计算 Tomography-based 有限元分析 (QCT)。

在斑点过程之前, 股骨是从多余的脂肪和软组织清洗, 和大转子是盆栽在一个铝杯。在酯 (PMMA) 凝固过程中, 骨头被用盐水浸泡过的布料包裹, 以避免组织干燥。一旦 PMMA 固化后, 在喷涂(图 1)之前, 再次对骨骼进行清洗。然后, 用水性塑料白颜色喷涂或刷骨表面。干燥后, 白色表面上有黑色斑点, 在白色背景上有一个随机的黑点图案(<stro...
